Next Level Racing PRO GAMING CHAIR User manual

Video Instruction: bit.ly/nlrbuild
INSTRUCTION MANUAL
TAKE RACING TO THE NEXT LEVEL

2 3
[e-mail] Video Instruction: bit.ly/nlrbuild
YOUR GAMING JOURNEY STARTS HERE Take your time with the instructions and follow this guide to assemble your product. You’ll be setting yourself up for success with following the instruction booklet to fully optimize your product.
T A K E R A C I N G
T O T H E N E X T L E V E L®
NEXTLEVELRACING.COM
@nextlevelracingOcial @next_level_racing @nextlvlracing Next Level Racing [e-mail]
ASSEMBLY
VIDEO
bit.ly/nlrbuild
FOLLOW US

4 5
[e-mail] Video Instruction: bit.ly/nlrbuild
PRE-CHECKS IN THE
BOX
WARNING • Please do not use power tools for assembly as over tightening can damage your Gaming Chair. • Lay out and build the Gaming Chair on a level surface. • Do not force parts together. • Avoid cross threading bolts. • If in doubt consult the installation video.
If you require any support with your product please contact our friendly team at: [e-mail]
WARNING CHOKING HAZARD - Small parts not for children under 3 years or any individuals who have a tendency to place inedible objects in their mouths.
ASSEMBLY
VIDEO
bit.ly/nlrbuild
1 x Right Arm Rest
5 x Castor Wheels 1 x Gas Strut
1 x Left Arm Rest
1 x Gas Strut Cover
1 x Frog Mechanism
Side Covers
1 x Star Base
4 x M8 25mm Bolts
8 x M8 25mm Bolts
2 x Plastic Caps
4 x M8 20mm Bolts
1 x Seat Backrest 1 x Seat Base
1 x Headrest Cushion 2 x M5 10mm Bolts
1 x Lumbar Cushion 1 x M8 Allen Key
NOTE: Some Items Come with Rust Resistant Coating

PARTS: • Seat Covers • 2 x M5 Machine Screws • 2 x Plastic Caps PARTS: • NIL
PARTS: • 1 x Seat Base • 1 x Right Arm Rest • 1 x Left Arm Rest • 8 x M8 25mm Bolts and Washers PARTS: • 1 x Seat Backrest • 4 x M8 25mm Bolts and Washers
[e-mail] Video Instruction: bit.ly/nlrbuild
03 Align the mounting holes on the Side Cover with the threaded hole on the recliner plate. Bolt through
and secure with 1 x M5 Screw. Once assembled insert Plastic Cap.
04 For the following steps it is recommended to lay the chair in a at surface as shown in the picture to
get access to underneath the chair.
01 Align the holes on the Arm Rests with the threaded inserts on the bottom of the Seat Base. Bolt
through and secure with 8 x M8 25mm Bolts and Washers.
02 Align the mounting holes on the Seat Backrest with the mounting holes on the Seat Base recliner
plates. Bolt through and secure with 4 x M8 25mm Bolts and Washers.
6 7
Repeat
on Other
Side

PARTS: • 1 x Gas Strut Cover • 1 x Gas Strut PARTS: • NIL
PARTS: • 1 x Frog Mechanism • 4 x M8 20mm Bolts and Washers PARTS: • 1 x Star Base • 5 x Castor Wheels
[e-mail] Video Instruction: bit.ly/nlrbuild
8
07 Flip the Star Base and Wheels assembly to the upright position. Install the wider end of the Gas Strut
into the Star Base Assembly. Place the Gas Strut cover over the top of the Gas Strut.
08 Install the narrow end of the Gas Strut into the Frog Mechanism by pushing into the mounting hole.
05 Align the mounting holes on the Frog Mechanism with the threaded inserts on the bottom of the Seat
Base. Bolt through and secure with 4 x M8 Bolts and Washers.
06 Install 5 x Castor Wheels in the Star Base. Push until the Castor Wheels lock in place.
9
NOTE: Tighten the bolts in an X pattern to
avoid cross threading.
NOTE: Place the Star Base upside down on a
at surface before installation.
