Nikkai L35AK User manual

Air Cooler / Humidifier
User’s Manual
Model No L35AK
PLEASE READ THE USER’S MANUAL CAREFULLY BEFORE OPERATION

Thankyou for purchasin this Aircooler/Humidifier from Maplin Electronics
Limited.
Please keep this manual in a safe place for future reference.
If the unit is transferred to another person please attach the User Manual
with the unit.
Names and Functions
1. Air Vent – this is the outlet for the cool air
2. Blower Louver – this can be adjusted via the louver stick
3. Horizontal Louver – the auto oscillatin an le is 100 de rees
4. Water reservoir index – shows the water level in the reservoir
5. Control panel – indicators of the timer, swin , cool, power, and speed
switch
6. Power cord – approx. 1.8m len th
7. Water reservoir – replenished water throu h the water inlet is stored
(up to 6.5 litres)
8. Suction – air inlet
9. Filter holder – used for protectin and supportin the filter
10. Filter – anti-bacterial filter
11. Handle – to be used when transportin the unit
12. Water inlet – entrance for fillin the water
13. Castors – for easy transportation of the unit
14. Rubber plu and water outlet – remove plu to dischar e water.
15. Remote control – ma netic attachment to keep remote control safe

Be ore Operation
• Do not use in the bathroom
• Do not use connect to mains electricity with wet hands
• If the unit is tipped over, unplu it immediately
• Do not sit on the unit or place other objects on top of the unit
Functional Drawing
Control Panel
Timer switch – the unit can be set to run in 30-minute intervals up to a
maximum of 7.5 hours
Speed switch – switch between low, medium and hi h airflow

Oscillatin switch – enables the louvers to swin automatically
Cool switch – ambient air passes the rollin filters and releases cool airflow
On/Off switch – si nals the operation status
Remote control – can be used instead of the control panel
Factors Causing the Unit to Mal unction
Control panel – do not use any sharp object to press the buttons on the
control panel
Please clean out any remainin water in the reservoir and ensure it is
completely dry prior to stora e
Do not place objects on the unit or this may cause dama e to the casin
Instructions on Using the Cooler Blocks
1. Open the water inlet and remove the cooler blocks from the unit
2. Release the cover on the block in a counter-clockwise direction
3. Fill the cooler blocks with water up the fill level
4. Ti hten the cover in a clockwise direction and shake the cooler to
ensure the ice crystals reach full saturation
5. Place cooler blocks in home freezer for a minimum of three hours
6. Remove from freezer and place in water reservoir filled with water
7. Enjoy even cooler airflow
Precautions
1. Do not empty refri erants from the cooler block
2. It is not necessary to re-fill the cooler block with water – only to re-
freeze
3. If the refri erants are eaten or consumed please consult your doctor
immediately
4. If refri erants enter the eye, flush with plenty of clean water and
consult your doctor immediately
Sa ety Instructions
When usin any electrical appliance, basic safety precautions should be
followed.
1. Prior to usin the air cooler check the power cord for any si ns of
dama e – do not use if the power cord is frayed or there are exposed
wires
2. Place the air cooler on a firm, flat level surface
3. Always place the air cooler away from heat sources such as ovens,
stoves, radiators, or heaters as these can dama e the unit
4. Place the air cooler in an area where it is not accessible to children and
with the power cord positioned so that it is not a trip hazard
5. Always unplu and empty the air cooler before servin or cleanin
6. Never try turnin on the power while the unit is unplu ed
7. Never tilt or attempt to move the air cooler while it is operatin
8. Always unplu the air cooler prior to any movement
9. Turn the air cooler off if the relative humidity is very hi h

10. When not in use, unplu and empty the air cooler and wrap the power
cord for safety stora e
Operating Instructions
1. Before fillin the air cooler make sure the unit is unplu ed
2. Open the water inlet and fill the water reservoir with cold, clean water.
Before doin so ensure the rubber plu is located correctly
3. Do not use hot water and never add chemicals or solutions to the
water
4. Fill the reservoir only to the water line indicator to avoid overfillin
5. After fillin , close the water inlet securely. Use care when transportin
filled air cooler
6. Place the water-filled air cooler on a firm, flat and level surface. To
safe uard fine wood finishes place a protective coverin between the
air cooler and surface
7. Plu air cooler into socket outlet and switch on the machine. Do not
plu in the air cooler with wet hands
8. The water will last between 22 and 24 hours – check water level
periodically
9. Do not block the suction and exhaust openin s. If they are blocked it
will affect not only the operational effectiveness but also the normal
operation of the machine
10. Never lift the lid off the water inlet violently as dama e to the hin es
will occur
11. If the water reservoir is over-filled remove rubber plu and dischar e
water from the container
12. The air cooler produces cooler airflow if the frozen cooler blocks are
placed in the water reservoir
Cleaning
1. Never immerse the power cord in water as electric shock may occur as
a result
2. Periodic cleanin is required for proper operational effectiveness of the
unit
3. Tap water may contain impurities or dissolved solids that could leave a
residue and deposit upon the inner surface of the water tank and
promote the rowth of al ae or bacteria. It is recommended that you
clean this air cooler often in areas where the tap water is poorer. More
frequent cleanin may be necessary where you see a heavy build-up of
impurities or notice the presence of an unpleasant odour. Never use
abrasive cleaners when cleanin this unit
To clean the air cooler use the followin steps:
1. Unplu the air cooler
2. Remove the filter and wash it under runnin water
3. Empty the water tank, remove the rear casin and wash the water
reservoir tank with mild soap deter ent.

4. Rinse with clean tap water
5. To remove scales or lime deposits, fill the water tank with water and a
mixture of 200ml of white vine ar. Use a soft cloth or soft brush to
clean the tank
6. For external cleanin only use mild deter ents. Do not use products
containin alcohol or benzene
Storage
1. Clean and dry the air cooler thorou hly as per the cleanin instructions
above
2. Ensure all components are dry. Do not leave any water in the air cooler
when storin . Water left in the air cooler may cause deposits or
bacterial rowth which could impair the units performance
Whilst Using the Air Cooler
When usin this unit the external of the appliance may create condensed
water drips due to the ambient temperature and relative humidity conditions.
The water drips are not due to malfunction or leaka e of the unit. Please
remove water drips with a soft cloth and if necessary place a tray under the
unit
Maintenance
Dischar e the water reservoir re ularly and dry the unit
in a well-ventilated place. To dischar e the water remove
the plu at the back of the unit
If the power cord is dama ed it must be fixed by its service a ent, or a
similarly qualified person on order to avoid electric shock hazard
After dischar in the water, make sure the internals of the unit is completely
dry. To speed up the dryin you may turn on the air cooler and press the
‘hi h’ speed switch. It takes approximately one hour to dry the unit
completely
Offensive odour or weak airflow can result from particles attached to the back
filter pad. Remove the filter pad, wash it in neutral deter ent and dry before
replacin
To clean the outside of the unit wipe with a soft cloth
Never immerse the complete unit in water
Never use chemical solutions such as bleach or oil on the casin

I the Air Cooler is Not Working as Expected…
Q The air is not as cool as expected
A Fill the water in the water reservoir and add the frozen cooler blocks
Q The airflow is weak
A Check the filter is clean. Clean the filter in mild deter ent and dry
before replacin
Q There is no power output
A Check the air cooler is plu ed in to an appropriate socket. If the
power is off via the Time, turn on the power switch to Normal
operation
Q Other abnormal conditions
A Unplu the power cord from the wall and contact your nearest Maplin
store for repairin . All information can be found on www.maplin.co.uk
Speci ication
Product: Air Cooler / Humidifier
Model: L35AK
Power rated: 220-240VAC / 50-60Hz
Power Watts: 50W
Water reservoir: 6.5 Litres
Speed Switch: Hi h / Medium / Low
Functions: Swin louvers, Cool and Ordinary Fan Function
Main Body Material: ABS
Net Wei ht: 7.3 KGs
Dimension: 32.7cm (L) x 30.2cm (D) x 63.7cm (H)
