INSTRUCTION MANUAL
MODEL #HD55345
TRI-MOTOR HEPA VACUUM

____
INDUSTRIES, INC.
--------WARNING--------
All Nikro Industries Inc. products that have rated efficiencies of 99.97% @ 0.3 microns and 99.99% @
0.3 microns, have H.E.P.A. filters that have been individually tested to meet these minimum
efficiencies.
Although all the filters have been pre-tested, the possibility of leaks or filter failure due to handling,
transportation, punctures, loaded filters, moisture, wear and tear, etc., does exist.
Therefore, when using this equipment in highly sensitive areas or where any release of particles above
and beyond the minimum efficiencies would be detrimental and harmful to humans, plants or property;
it is strongly recommended that the units be individually tested prior to their use.
This is to assure that they are maintaining the efficiency levels, which they were designed to filter out.
FAILURE TO DO SO COULD RESULT IN SERIOUS HARM TO HUMAN LIFE, PLANT LIFE
AND/OR PROPERTY.
1115 N. Ellsworth Ave., Villa Park, IL 60181
Telephone: [phone] FAX: [phone]
Toll Free: 800-875-6457

OPERATING INSTRUCTIONS
Inspection
Thoroughly inspect your machine for any shipping damage. Your machine has already been thoroughly
tested at the Nikro Industries manufacturing plant prior to shipping.
Electrical Specification
This machine is designed to operate on a 15 amp. 115V., 60 hz., AC circuit. A deviance of this could
cause serious damage to the unit.
Grounding Instructions
This machine is equipped with a grounding type cord and three
prong plug. Make sure that the plug is connected to an outlet with
three receptacles designed for use with the three-prong plug. (See
Illustration) Never use an adapter with machine.
Maintenance
Lubrication of this motor is not required as it is equipped with sealed bearings.
Always keep the air cooling intake screen free, not allowing any restriction of airflow. Airflow restriction
will overheat and damage the motor.
To prolong the life of the H.E.P.A. filter, empty, clean, and replace bags and filters regularly as described
in the following sections.
SAFETY INSTRUCTIONS
Read all safety instructions before using!
1. Electrical shock could occur if used outdoors or on wet surfaces.
2. Always store machine indoors in a dry area. If machine is dropped in water or left in rain, it should be
serviced by an authorized service technician prior to plugging the unit in.
3. Prior to plugging in machine, always inspect cord for cuts and exposed wires. If these problems are
found, return the machine to an authorized service technician..
4. Never use the cord as a handle, or pull the machine by using the cord.
5. Never unplug this machine or any other electrical appliance by pulling on the cord.
6. Do not wrap the cord around the dome. Wrapping the cord around the dome will restrict the motor
from exhausting properly and will result in overheating and damaging the motor.
7. Keep hair, fingers, and other objects away from all moving parts and openings on this machine.
8. This vacuum cleaner should never be used in explosion-hazardous areas or to pick up combustible or
flammable liquids such as gasoline, etc.
9. Never leave the machine unattended when plugged in or running.
10. Always have the switch in the OFF position before unplugging the unit.
11. Do not operate this machine with any of the openings blocked; always keep these areas free of lint and
dust or any other particles that could reduce the airflow.
12. Never operate or plug in this machine or any other electrical appliance with wet hands or when
standing in water.
13. This machine should never be operated without the proper filters installed in the manner described in
the following pages of this manual.
14. This machine should never be serviced by anyone other than an authorized technician.
15. Use only original NIKRO replacement parts and attachments.

FILTER MAINTENANCE AND REPLACEMENT INSTRUCTIONS
Your Nikro vacuum has a five stage filtration system; Non-clinging Dacron bag filter bag,
Canvas filter bag, Polyester Prefilter, Impaction filter, and HEPA Filter. These filters should be
inspected every time the tank is emptied or when a significant loss of vacuum power is detected.
If a decrease in vacuum power is detected, turn off the vacuum immediately. (WARNING:
Continued use could cause serious damage to motor and or HEPA filter.) This loss of vacuum
power could be caused by one of the following:
a) The tank may be full and needs to be emptied.
b) The Dacron filter bag may be clogged and needs cleaning.
c) The canvas filter bag may be clogged and needs cleaning.
d) The polyester prefilter may be clogged and needs to be cleaned or replaced.
e) The impaction filter may be clogged and needs to be replaced.
t) The HEPA filter may be clogged and needs to be replaced.
g) The wand, hose, or intake may be clogged and needs to be cleaned.
PROCEDURES FOR REMOVING CONT AMINATED FILTERS
Caution:
When removing contami5ated filters or using this machine, you should always wear gloves,
clothing, and a respirator approved for use with the particular contaminant you are working with.
FILTER REMOVAL PROCEDURES
1. Turn off and unplug machine.
2. Slowly and carefully lift one side of the lid assembly from the tank. Holding the lid with one
hand, reach under the lid and gently tap all around the Dacron bag, allowing any dust
particles to drop into the tank.
3. Carefully lift the lid assembly off the tank. With a damp rag, wipe the underside of the lid
assembly. Set it aside and dispose of the rag properly.
4. Carefully remove the Dacron filter bag from the tank. This filter bag can be washed and
reused.
5. Remove the 6 mil. breather bag. This bag can be removed by gathering the top of the bag
together, hold bag just below breather holes and lift out of tank. This bag can be tied or taped
below the breather holes.
6. Unhook the canvas filter bag clamp and slide the bag off the lid assembly. This filter bag can
be washed and reused.
7. Carefully unfasten the Velcro from the polyester prefilter and remove it from the HEPA
filter. This filter can be washed and reused or discarded when material begins to separate or
fall apart.
8. Remove the impaction filter and discard it.
9. Take a damp rag and wipe down the inside of the tank. Dispose of contaminated rag
properly.
10. All hazardous waste material must be disposed of properly. Never put contaminated debris in
a regular trash container. All debris must be placed in a plastic bag or container labeled
"Hazardous Materials", and should be removed by a licensed hauler. Consult proper
authorities on disposal regulations.

FILTER SET-UP PROCEDURE
1. Place HEPA filter on lid, making sure the airflow arrows are pointing towards motors
2. Slide HEPA filter-hold down bracket over HEPA and onto the four bolts. Using the locking
nuts, tighten down the cage to secure the HEPA filter
3. Place the impaction filter on the HEPA filter.
4. Next fasten the polyester filter pad to the Velcro on the HEPA filter.
5. Pull the filter bag with locking band over the bag holding ring and secure into place by
snapping the latch.
6. Place the plastic collection bag into the tank. Make sure the breather holes on the bag are
inside the tank and the intake tube is through the tube hole in bag, allowing for materials to
dump into the bag. Pull the top portion of the plastic bag over the top of the tank and roll it
over the outside of the tank.
7. Take the Dacron filter bag and stretch the elastic over the top of the tank, allowing the elastic
to rest on the outside of the tank. Push center of bag into the tank.
8. Set lid assembly on the tank. Snap the four latches into place.
9. Vacuum is ready for operation.

REFERENCE PART NO. DESCRIPTION QTY. REQ.
1 520001 MOTOR DOME 3
2 520013 CORD STRAIN RELIEF 3
3 520010 POWER CORD 3
4 520015 SWITCH 3
5 520004 DOME FELT 3
6 520016 FOAM RING 3
7 520214 LARGE SPACER 24
8 520304 MOTOR HOLD DOWN 3
9 520029 UPPER MOTOR GASKET 3
10 520365 MOTOR 3
11 520327 LOWER MOTOR GASKET 3
12 540058 MOTOR HOUSING 3
13 520009 MOUNTING PLATE 3
14 860922 MOUNTING PLATE GASKET 3
15 860150 TRI-HEAD 55 GAL. LID 1
16 520222 LID HANDLES 3
17 860807 NON REVERSE FLUTTER VALVE 3
18 860582 LID GASKET 1

' '
REFERENCE PART NO. DESCRIPTION QTY. REQ.
1 860150 LID ASSEMBLY 1
2 860152 FILTER BAG SPACER CAGE 1
3 860942 BAG SEALING GASKET 1
4 520214 BAG HOLDING SPACER 4
5 860151 FILTER CAGE 1
6 560028 HEPA FILTER 1
7 560030 IMPACTION FILTER 1
8 560020 POLYESTER PRE-FILTER 1
9 560022 FILTER BAG 1
10 860153 FILTER BAG CLAMP 1

REPLACEMENT PARTS
1) #520220 2” ALUMINUM INTAKE
2) #860089 POLY BAG W/ BREATHER HOLES
3) #560029 DACRAON FILTER BAG
4) #560022 CANVAS FILTER BAG W/ LOCKING RING
5a) #560020 POLYESTER PREFILTER
5b) #560030 IMPACTION FILTER
6) #560028 HEPA FILTER
7) #520365 2 HP MOTOR

REFERENCE PART NO. DESCRIPTION OTY. REO.
1 560029 DACRON FILTER BAG 1
2 860154 CART ASSEMBLY 1
3 520220 INTAKE 1
4 520308 55 GALLON DRUM 1
5 520217 INTAKE KNOB 1
6 540001 DOWN TUBE ELBOW 1
7 860808 TANK MOUNTING BRACKET 2
8 860554 3” INTAKE ELBOW (OPT.)
9 520216 INTAKE GASKET 1
10 520019 LID LATCH 4
11 520214 LARGE SPACER 8
12 860928 REPLACEMENT WHEELS 2

WARRANTY
Nikro equipment is warranted for 2 years from the date delivered to the original
purchaser. Parts, which become defective due to faulty workmanship or materials during
normal use in these years will be repaired or exchanged at no charge if returned and
approved by an authorized Nikro service center. The freight shall be at the expense of the
customer.
This warranty does not apply to normal wear and tear, neglect, misuse, or
incorrect installation. If any other replacement parts, filters or attachments are used other
an original Nikro parts, this warranty will become void.
This warranty does not apply to hoses, switches, lights, sensors, or breaks in cords. All
motors are subject to manufacturer’s warranty. Contact Nikro Industries for assistance
with these items.
Nikro disclaims responsibility for loss of production, profits, or any other costs
that may indirectly occur due to the failure of this product.
