NISBETS ESSENTIALS DA091 User manual

Electronic Scales
Instruction manual
Model:
DA091
DA091_EN_A5_v2_20201030.indb 1DA091_EN_A5_v2_20201030.indb 1 2020/10/30 11:372020/10/30 11:37

2
EN
Features:
• Indicates the volume of milk and water
• Converts between metric and imperial measurements, for both weight and volume
• Low battery power / Overload indication
• High precision strain gauge sensor
• Zero and tare function
• Auto off
• Increment: 1g/0.1oz
• Max. load capacity: 5kg / 11lb
• Min. load capacity: 20g
To install or replace batteries
1. Remove the battery compartment cover (on the bottom of the appliance).
2. Insert 2 x 1.5V AAA batteries (not supplied), and ensure to follow polarity markings on the battery
compartment. Re-locate the battery compartment cover.
3. Position the appliance on a flat stable surface.
Note: It is important that the scales are level to ensure accuracy.
LCD Screen:
Weight unit (kg)
Volume unit (ml)
Volume unit (fl’oz)
Weight unit (lb:oz)
Tare Weight
Zero weight
Negative value
Mode
Weight mode Milk volume mode Water volume mode
Button function
MODE Mode conversion
Turn on / Turn off / Zero / Tare
UNIT Convert unit systems between Metric and imperial
(Conversion button on the bottom of the appliance)
DA091_EN_A5_v2_20201030.indb 2DA091_EN_A5_v2_20201030.indb 2 2020/10/30 11:372020/10/30 11:37

3
EN
Mode conversion
1. Press to turn on.
2. Press MODE button to select desired mode as shown below.
To convert weight unit
If the scale is with both unit systems of metric (g, ml) and Imperial (lb:oz, fl’oz), press MODE bottom to choose
working mode (weight, milk volume, water volume). Then press UNIT conversion button to convert between
two systems.
Take the conversion of weight unit for example:
• When setting “g” as weight unit, the default volume unit is “ml”.
• When setting “lb:oz” as weight unit ,the default volume unit is “fl’oz”.
To start weighing
Weighing mode
1. Place a bowl (if necessary) on the scale.
2. Press to turn on. Wait until LCD shows “O”.
3. Press MODE button to convert to weighing mode.
4. Load weighing object on the scale (or in the bowl) to start weighing. LCD will show the weight reading.
5. If the weighing object is water or milk, press MODE button to choose volume mode and view the volume
of weighing object.
DA091_EN_A5_v2_20201030.indb 3DA091_EN_A5_v2_20201030.indb 3 2020/10/30 11:372020/10/30 11:37

4
EN
Volume indication mode
1. Press to turn on. Wait until LCD shows “O”.
2. Press MODE button to choose “Water” or “Milk”
mode.
3. Put a liquid container onto the scale platform.
LCD shows the weight of container.
4. Press to zero or tare weight.
5. Pour liquid (water or milk) into the container. LCD
shows the volume of the liquid.
6. Press MODE button to choose “Weight” mode
and view the weight of liquid.
“ZERO” or “TARE” function
To weigh different loads consecutively without
removing previous loads from the scale:
1. Put first Load on the scale and get weight
reading.
2. Press button to reset the reading to “O”
before adding next load. You can repeat this
operation.
Condition 1: “ZERO” function
When total sum of all loads on scale is ≤4% of scale’s
max. weight capacity (4% here means 200g with this
scale), LCD will show “-----” or “0g” each time is
pressed.
“-----” means reading is not stable. Please wait for a
moment. “0g” and meanwhile an icon “O” on the left
side of LCD indicate ZERO function is activated. In
this case, Max. weight capacity remains unchanged.
DA091_EN_A5_v2_20201030.indb 4DA091_EN_A5_v2_20201030.indb 4 2020/10/30 11:372020/10/30 11:37

5
EN
Condition 2: “TARE” function
When total sum of all loads on scale is >4% of scale’s
max. weight capacity, LCD will show “-----” or “0g”
each time is pressed.
“-----” means reading is not stable. Please wait for
a moment. “0g” and meanwhile an icon “T” on the
left side of LCD indicate TARE function is activated.
In this case, Max. Weight capacity is reduced by total
weight of all loads.
Under this condition:
• By pressing , you can see the total weight of
all loads on the scale.
• To weigh more loads, just press to reset LCD
reading to ‘0’ again.
Shut off
Auto shut-off: Auto shut-off occurs if LCD shows ‘0’
or shows the same weight reading for 2 minutes.
Manual shut-off: To maximize battery life, press
button continuously to turn off scale after use.
Warning indicators
Low battery.
Replace with new batteries.
Scale overloaded.
Remove items to avoid damage
Cleaning, Care &
Maintenance
• Clean the case with a damp cloth and warm
water.
• Remove the batteries if the unit is not to be used
for an extended period of time.
Compliance
Dispose of depleted batteries in accordance with
local regulations, within the EC there are nominated
disposal points for batteries.
The WEEE logo on this product or its
documentation indicates that the product
must not be disposed of as household
waste.
To help prevent possible harm to human health and/
or the environment, the product must be disposed
of in an approved and environmentally safe recycling
process. For further information on how to dispose of
this product correctly, contact the product supplier,
or the local authority responsible for waste disposal
in your area.
Nisbets Essentials parts have undergone strict
product testing in order to comply with regulatory
standards and specifications set by international,
independent, and federal authorities.
Nisbets Essentials products
have been approved to carry
the following symbol:
All rights reserved. No part of these instructions may be produced
or transmitted in any form or by any means, electronic, mechanical,
photocopying, recording or otherwise, without the prior written
permission of Nisbets Essentials.
Every effort is made to ensure all details are correct at the time of
going to press, however, Nisbets Essentials reserves the right to
change specifications without notice.
