NiteRider Lumina 650 User manual

RIDING AT NIGHT
While a Lumina lighting system will improve your view, control
and enjoyment of night riding, please remember that cycling
at night is an inherently dangerous activity. In addition to using
your lighting system properly and riding with extreme caution,
NiteRider urges you to:
• Never ride alone.
• Always let someone know where you are going.
• Wear a helmet and reective clothing.
• Carry an auxiliary light and emergency supplies.
• Make sure the headlamp & mounting bracket is
securely fastened.
IMPORTANT INFORMATION!
LOCKING THE HEADLAMP FOR TRANSIT
It is important to lock the headlamp and protect the switch
from being pressed while it is in transit. The headlamp can be
easily turned on if placed in something like a backpack, duel
bag or suitcase. The headlamp gets hot while in operation. To
prevent potential damage from high heat or even re, it is very
important to put the headlamp in lock mode and protect the
switch from being pressed.
NiteRider will not be held responsible for damages to person
or property resulting from a failure to follow the ‘lock’ mode
instructions.
PROTECTING YOUR INVESTMENT
Properly charge your battery to maximize its lifespan. (See the
“Battery Charging and Care” section for detailed information)
The Lumina will perform in wet weather conditions, but
submerging it in water will damage the system.
SUPPORT
If you experience diculties during product installation
or operation, NiteRider provides free telephone support
on weekdays from 8:00 AM to 4:30 PM (Pacic Time) at
800.466.8366, ext 4.
You may also e-mail us at [e-mail].
WARRANTY
NiteRider stands behind its products with the followin
warranties:
•Lifetime warranty on all mechanical components
•2 years on electrical components
•180 days on rechargeable batteries
To obtain warranty service, it is preferable to have your
original sales receipt. Contact the NiteRider customer
service department at 800.466.8366, ext 4 to obtain a
Return Merchandise Authorization (RMA) number. The RMA
number must be prominently displayed on the outside of your
package. The product must be properly packaged to prevent
damage in transit. For complete warranty information, please
visit our website at www.niterider.com.
The Lumina 650 will run up to:
The Lumina 500 will run up to:
The Lumina 350 will run up to:
RUN TIMES
Light Level
High
Med
Low
Walk
Light Level
High
Med
Low
Walk
Light Level
High
Med
Low
Walk
Time*
1:30
3:00
5:30
18:00
Time*
1:30
3:00
5:30
18:00
Time*
2:00
4:00
6:00
21:00
Lumens
650
400
200
40
Lumens
500
250
150
40
Lumens
350
200
125
30
*Run times are approximations and will vary.
Lumina Series
User Guide
Lumina: 350, 500, 650
NiteRider Technical Lighting Systems, Inc.
8295 Aero Place, Suite 200
San Diego, CA 92123
www.niterider.com
150-22844 - Rev A

OPERATION
1. The Lumina headlamp is shipped in lock mode. In order to
use the headlamp it must be unlocked. To unlock the
headlamp, press and hold the power button for several
seconds until the power button turns, or ashes blue.
Release the power button.
2. The light has 5 modes - low, medium and high beam -
daylight ash mode and walk mode. Press and release the
headlamp power button to turn the light on. Cycle through
the three brightness levels by pressing and releasing the
power button.
3. To access the daylight visible ash mode and,
press and hold the power button for greater than 3 seconds
or until the headlamp begins to ash.
LOW BATTERY INDICATOR
With approximately 15 - 20% battery capacity remaining, the
indicator LED on the headlamp will turn from blue to red.
RESERVE MODE
Reserve Mode will automatically shift your light to low beam
when the battery is very low and about to cut o. Once
reserve mode starts you will only be able to use Low Beam,
Flash Mode and Walking Mode. High Beam and Medium Beam
will be disabled.
BATTERY CHARGING AND CARE
1. Plug one micro USB side of the USB charging cable into the
Lumina charging port and the other into your computer.
2. The LED charging indicator on the Lumina will remain red
until the battery is fully charged; once charged it will then
switch to blue.
3. Leaving the headlamp and USB charging cable connected
indenitely will not harm the battery.
4. When storing for an extended period of time, charge the
battery every 3 months to maximize battery life.
PARTS LIST AND IDENTIFICATION
Please verify the contents of your Lumina system:
A. Lumina (350, 500, 650)
B. Lumina Handlebar Mount
C. Lumina Handlebar Mount Shim
D. Lumina Helmet Mount (included with 650)
E. USB Charging Cable
NOTE: The Lumina headlamp is shipped in lock mode.
The headlamp will not operate until it is unlocked. See the
Operation section on how to unlock the headlamp.
2. Position the plastic mounting plate as close to the centerline
of the helmet as possible, orienting the parallel grooves on
the slider clip to the rear.
3. Feed each strap into and out of two helmet vents, circling
each strap back to the upper edge of the corresponding
clamp.
4. Fasten the straps by inserting them into the clamps and
snapping them shut.
MOUNTING
The Lumina can be mounted to the handlebar or a helmet.
Lumina Handlebar Mount
The Lumina Handlebar Mount is designed to t on virtually any
handlebar.
Remove the headlamp from the mount
by pressing down on the release lever
and sliding the headlamp o of the
mount towards the release lever.
Turn the knob counter-clockwise,
allowing the hinge to swing open.
Place the mount on the handlebar
on the either side of the stem.
Swing the hinge down
to make contact with the
handlebar. Swing the hex
bolt up, seating the knob
into its recess. Turn the
knob clockwise to tighten
and secure the mount to the
handlebar.
Aim the
headlamp by
swiveling the
headlamp back
and forth.
Once the handlebar mount is
securely mounted, slide the
headlamp into place.
Helmet Mount
1. Unclamp the straps on each side of the helmet mount and
pull them free
A. B.
C.
D.
E.
Release
Lever
Hinge
Knob
4. With the headlamp in ash mode, press and release the
power button to access walk mode. From walk mode you
can return to normal mode by pressing and releasing the
power button.
5. To turn the light o from either normal, ash, or walk mode,
press and hold the power button until the light turns o.
6. Always put the light into lock mode during transport of
the headlamp in order to prevent accidentally turning
on the headlamp. To put the headlamp in lock mode,
press and hold the power button for several seconds
until the headlamp turns o and continue holding the
power button down through ash mode until the power
button turns or ashes red. Then let go of the Power
button and test to make sure the light is in Lock Mode
by tapping the power button, the light will not turn on if
the lock mode is engaged. To Unlock the lock mode-
See step #1 of OPERATION.
DISCOVER THE NIGHT
Thank you for choosing the Lumina from NiteRider, the
innovator in technical lighting systems. The Lumina combines
a self contained, high-powered, white LED headlamp with a
rechargeable, replaceable Lithium Ion battery.
To get the most from your NiteRider light, we urge you to
familiarize yourself with the following safety and operating
instructions.

OPERATION
1. The Lumina headlamp is shipped in lock mode. In order to
use the headlamp it must be unlocked. To unlock the
headlamp, press and hold the power button for several
seconds until the power button turns, or ashes blue.
Release the power button.
2. The light has 5 modes - low, medium and high beam -
daylight ash mode and walk mode. Press and release the
headlamp power button to turn the light on. Cycle through
the three brightness levels by pressing and releasing the
power button.
3. To access the daylight visible ash mode and,
press and hold the power button for greater than 3 seconds
or until the headlamp begins to ash.
LOW BATTERY INDICATOR
With approximately 15 - 20% battery capacity remaining, the
indicator LED on the headlamp will turn from blue to red.
RESERVE MODE
Reserve Mode will automatically shift your light to low beam
when the battery is very low and about to cut o. Once
reserve mode starts you will only be able to use Low Beam,
Flash Mode and Walking Mode. High Beam and Medium Beam
will be disabled.
BATTERY CHARGING AND CARE
1. Plug one micro USB side of the USB charging cable into the
Lumina charging port and the other into your computer.
2. The LED charging indicator on the Lumina will remain red
until the battery is fully charged; once charged it will then
switch to blue.
3. Leaving the headlamp and USB charging cable connected
indenitely will not harm the battery.
4. When storing for an extended period of time, charge the
battery every 3 months to maximize battery life.
PARTS LIST AND IDENTIFICATION
Please verify the contents of your Lumina system:
A. Lumina (350, 500, 650)
B. Lumina Handlebar Mount
C. Lumina Handlebar Mount Shim
D. Lumina Helmet Mount (included with 650)
E. USB Charging Cable
NOTE: The Lumina headlamp is shipped in lock mode.
The headlamp will not operate until it is unlocked. See the
Operation section on how to unlock the headlamp.
2. Position the plastic mounting plate as close to the centerline
of the helmet as possible, orienting the parallel grooves on
the slider clip to the rear.
3. Feed each strap into and out of two helmet vents, circling
each strap back to the upper edge of the corresponding
clamp.
4. Fasten the straps by inserting them into the clamps and
snapping them shut.
MOUNTING
The Lumina can be mounted to the handlebar or a helmet.
Lumina Handlebar Mount
The Lumina Handlebar Mount is designed to t on virtually any
handlebar.
Remove the headlamp from the mount
by pressing down on the release lever
and sliding the headlamp o of the
mount towards the release lever.
Turn the knob counter-clockwise,
allowing the hinge to swing open.
Place the mount on the handlebar
on the either side of the stem.
Swing the hinge down
to make contact with the
handlebar. Swing the hex
bolt up, seating the knob
into its recess. Turn the
knob clockwise to tighten
and secure the mount to the
handlebar.
Aim the
headlamp by
swiveling the
headlamp back
and forth.
Once the handlebar mount is
securely mounted, slide the
headlamp into place.
Helmet Mount
1. Unclamp the straps on each side of the helmet mount and
pull them free
A. B.
C.
D.
E.
Release
Lever
Hinge
Knob
4. With the headlamp in ash mode, press and release the
power button to access walk mode. From walk mode you
can return to normal mode by pressing and releasing the
power button.
5. To turn the light o from either normal, ash, or walk mode,
press and hold the power button until the light turns o.
6. Always put the light into lock mode during transport of
the headlamp in order to prevent accidentally turning
on the headlamp. To put the headlamp in lock mode,
press and hold the power button for several seconds
until the headlamp turns o and continue holding the
power button down through ash mode until the power
button turns or ashes red. Then let go of the Power
button and test to make sure the light is in Lock Mode
by tapping the power button, the light will not turn on if
the lock mode is engaged. To Unlock the lock mode-
See step #1 of OPERATION.
DISCOVER THE NIGHT
Thank you for choosing the Lumina from NiteRider, the
innovator in technical lighting systems. The Lumina combines
a self contained, high-powered, white LED headlamp with a
rechargeable, replaceable Lithium Ion battery.
To get the most from your NiteRider light, we urge you to
familiarize yourself with the following safety and operating
instructions.

OPERATION
1. The Lumina headlamp is shipped in lock mode. In order to
use the headlamp it must be unlocked. To unlock the
headlamp, press and hold the power button for several
seconds until the power button turns, or ashes blue.
Release the power button.
2. The light has 5 modes - low, medium and high beam -
daylight ash mode and walk mode. Press and release the
headlamp power button to turn the light on. Cycle through
the three brightness levels by pressing and releasing the
power button.
3. To access the daylight visible ash mode and,
press and hold the power button for greater than 3 seconds
or until the headlamp begins to ash.
LOW BATTERY INDICATOR
With approximately 15 - 20% battery capacity remaining, the
indicator LED on the headlamp will turn from blue to red.
RESERVE MODE
Reserve Mode will automatically shift your light to low beam
when the battery is very low and about to cut o. Once
reserve mode starts you will only be able to use Low Beam,
Flash Mode and Walking Mode. High Beam and Medium Beam
will be disabled.
BATTERY CHARGING AND CARE
1. Plug one micro USB side of the USB charging cable into the
Lumina charging port and the other into your computer.
2. The LED charging indicator on the Lumina will remain red
until the battery is fully charged; once charged it will then
switch to blue.
3. Leaving the headlamp and USB charging cable connected
indenitely will not harm the battery.
4. When storing for an extended period of time, charge the
battery every 3 months to maximize battery life.
PARTS LIST AND IDENTIFICATION
Please verify the contents of your Lumina system:
A. Lumina (350, 500, 650)
B. Lumina Handlebar Mount
C. Lumina Handlebar Mount Shim
D. Lumina Helmet Mount (included with 650)
E. USB Charging Cable
NOTE: The Lumina headlamp is shipped in lock mode.
The headlamp will not operate until it is unlocked. See the
Operation section on how to unlock the headlamp.
2. Position the plastic mounting plate as close to the centerline
of the helmet as possible, orienting the parallel grooves on
the slider clip to the rear.
3. Feed each strap into and out of two helmet vents, circling
each strap back to the upper edge of the corresponding
clamp.
4. Fasten the straps by inserting them into the clamps and
snapping them shut.
MOUNTING
The Lumina can be mounted to the handlebar or a helmet.
Lumina Handlebar Mount
The Lumina Handlebar Mount is designed to t on virtually any
handlebar.
Remove the headlamp from the mount
by pressing down on the release lever
and sliding the headlamp o of the
mount towards the release lever.
Turn the knob counter-clockwise,
allowing the hinge to swing open.
Place the mount on the handlebar
on the either side of the stem.
Swing the hinge down
to make contact with the
handlebar. Swing the hex
bolt up, seating the knob
into its recess. Turn the
knob clockwise to tighten
and secure the mount to the
handlebar.
Aim the
headlamp by
swiveling the
headlamp back
and forth.
Once the handlebar mount is
securely mounted, slide the
headlamp into place.
Helmet Mount
1. Unclamp the straps on each side of the helmet mount and
pull them free
A. B.
C.
D.
E.
Release
Lever
Hinge
Knob
4. With the headlamp in ash mode, press and release the
power button to access walk mode. From walk mode you
can return to normal mode by pressing and releasing the
power button.
5. To turn the light o from either normal, ash, or walk mode,
press and hold the power button until the light turns o.
6. Always put the light into lock mode during transport of
the headlamp in order to prevent accidentally turning
on the headlamp. To put the headlamp in lock mode,
press and hold the power button for several seconds
until the headlamp turns o and continue holding the
power button down through ash mode until the power
button turns or ashes red. Then let go of the Power
button and test to make sure the light is in Lock Mode
by tapping the power button, the light will not turn on if
the lock mode is engaged. To Unlock the lock mode-
See step #1 of OPERATION.
DISCOVER THE NIGHT
Thank you for choosing the Lumina from NiteRider, the
innovator in technical lighting systems. The Lumina combines
a self contained, high-powered, white LED headlamp with a
rechargeable, replaceable Lithium Ion battery.
To get the most from your NiteRider light, we urge you to
familiarize yourself with the following safety and operating
instructions.

OPERATION
1. The Lumina headlamp is shipped in lock mode. In order to
use the headlamp it must be unlocked. To unlock the
headlamp, press and hold the power button for several
seconds until the power button turns, or ashes blue.
Release the power button.
2. The light has 5 modes - low, medium and high beam -
daylight ash mode and walk mode. Press and release the
headlamp power button to turn the light on. Cycle through
the three brightness levels by pressing and releasing the
power button.
3. To access the daylight visible ash mode and,
press and hold the power button for greater than 3 seconds
or until the headlamp begins to ash.
LOW BATTERY INDICATOR
With approximately 15 - 20% battery capacity remaining, the
indicator LED on the headlamp will turn from blue to red.
RESERVE MODE
Reserve Mode will automatically shift your light to low beam
when the battery is very low and about to cut o. Once
reserve mode starts you will only be able to use Low Beam,
Flash Mode and Walking Mode. High Beam and Medium Beam
will be disabled.
BATTERY CHARGING AND CARE
1. Plug one micro USB side of the USB charging cable into the
Lumina charging port and the other into your computer.
2. The LED charging indicator on the Lumina will remain red
until the battery is fully charged; once charged it will then
switch to blue.
3. Leaving the headlamp and USB charging cable connected
indenitely will not harm the battery.
4. When storing for an extended period of time, charge the
battery every 3 months to maximize battery life.
PARTS LIST AND IDENTIFICATION
Please verify the contents of your Lumina system:
A. Lumina (350, 500, 650)
B. Lumina Handlebar Mount
C. Lumina Handlebar Mount Shim
D. Lumina Helmet Mount (included with 650)
E. USB Charging Cable
NOTE: The Lumina headlamp is shipped in lock mode.
The headlamp will not operate until it is unlocked. See the
Operation section on how to unlock the headlamp.
2. Position the plastic mounting plate as close to the centerline
of the helmet as possible, orienting the parallel grooves on
the slider clip to the rear.
3. Feed each strap into and out of two helmet vents, circling
each strap back to the upper edge of the corresponding
clamp.
4. Fasten the straps by inserting them into the clamps and
snapping them shut.
MOUNTING
The Lumina can be mounted to the handlebar or a helmet.
Lumina Handlebar Mount
The Lumina Handlebar Mount is designed to t on virtually any
handlebar.
Remove the headlamp from the mount
by pressing down on the release lever
and sliding the headlamp o of the
mount towards the release lever.
Turn the knob counter-clockwise,
allowing the hinge to swing open.
Place the mount on the handlebar
on the either side of the stem.
Swing the hinge down
to make contact with the
handlebar. Swing the hex
bolt up, seating the knob
into its recess. Turn the
knob clockwise to tighten
and secure the mount to the
handlebar.
Aim the
headlamp by
swiveling the
headlamp back
and forth.
Once the handlebar mount is
securely mounted, slide the
headlamp into place.
Helmet Mount
1. Unclamp the straps on each side of the helmet mount and
pull them free
A. B.
C.
D.
E.
Release
Lever
Hinge
Knob
4. With the headlamp in ash mode, press and release the
power button to access walk mode. From walk mode you
can return to normal mode by pressing and releasing the
power button.
5. To turn the light o from either normal, ash, or walk mode,
press and hold the power button until the light turns o.
6. Always put the light into lock mode during transport of
the headlamp in order to prevent accidentally turning
on the headlamp. To put the headlamp in lock mode,
press and hold the power button for several seconds
until the headlamp turns o and continue holding the
power button down through ash mode until the power
button turns or ashes red. Then let go of the Power
button and test to make sure the light is in Lock Mode
by tapping the power button, the light will not turn on if
the lock mode is engaged. To Unlock the lock mode-
See step #1 of OPERATION.
DISCOVER THE NIGHT
Thank you for choosing the Lumina from NiteRider, the
innovator in technical lighting systems. The Lumina combines
a self contained, high-powered, white LED headlamp with a
rechargeable, replaceable Lithium Ion battery.
To get the most from your NiteRider light, we urge you to
familiarize yourself with the following safety and operating
instructions.

RIDING AT NIGHT
While a Lumina lighting system will improve your view, control
and enjoyment of night riding, please remember that cycling
at night is an inherently dangerous activity. In addition to using
your lighting system properly and riding with extreme caution,
NiteRider urges you to:
• Never ride alone.
• Always let someone know where you are going.
• Wear a helmet and reective clothing.
• Carry an auxiliary light and emergency supplies.
• Make sure the headlamp & mounting bracket is
securely fastened.
IMPORTANT INFORMATION!
LOCKING THE HEADLAMP FOR TRANSIT
It is important to lock the headlamp and protect the switch
from being pressed while it is in transit. The headlamp can be
easily turned on if placed in something like a backpack, duel
bag or suitcase. The headlamp gets hot while in operation. To
prevent potential damage from high heat or even re, it is very
important to put the headlamp in lock mode and protect the
switch from being pressed.
NiteRider will not be held responsible for damages to person
or property resulting from a failure to follow the ‘lock’ mode
instructions.
PROTECTING YOUR INVESTMENT
Properly charge your battery to maximize its lifespan. (See the
“Battery Charging and Care” section for detailed information)
The Lumina will perform in wet weather conditions, but
submerging it in water will damage the system.
SUPPORT
If you experience diculties during product installation
or operation, NiteRider provides free telephone support
on weekdays from 8:00 AM to 4:30 PM (Pacic Time) at
800.466.8366, ext 4.
You may also e-mail us at [e-mail].
WARRANTY
NiteRider stands behind its products with the followin
warranties:
•Lifetime warranty on all mechanical components
•2 years on electrical components
•180 days on rechargeable batteries
To obtain warranty service, it is preferable to have your
original sales receipt. Contact the NiteRider customer
service department at 800.466.8366, ext 4 to obtain a
Return Merchandise Authorization (RMA) number. The RMA
number must be prominently displayed on the outside of your
package. The product must be properly packaged to prevent
damage in transit. For complete warranty information, please
visit our website at www.niterider.com.
The Lumina 650 will run up to:
The Lumina 500 will run up to:
The Lumina 350 will run up to:
RUN TIMES
Light Level
High
Med
Low
Walk
Light Level
High
Med
Low
Walk
Light Level
High
Med
Low
Walk
Time*
1:30
3:00
5:30
18:00
Time*
1:30
3:00
5:30
18:00
Time*
2:00
4:00
6:00
21:00
Lumens
650
400
200
40
Lumens
500
250
150
40
Lumens
350
200
125
30
*Run times are approximations and will vary.
Lumina Series
User Guide
Lumina: 350, 500, 650
NiteRider Technical Lighting Systems, Inc.
8295 Aero Place, Suite 200
San Diego, CA 92123
www.niterider.com
150-22844 - Rev A

RIDING AT NIGHT
While a Lumina lighting system will improve your view, control
and enjoyment of night riding, please remember that cycling
at night is an inherently dangerous activity. In addition to using
your lighting system properly and riding with extreme caution,
NiteRider urges you to:
• Never ride alone.
• Always let someone know where you are going.
• Wear a helmet and reective clothing.
• Carry an auxiliary light and emergency supplies.
• Make sure the headlamp & mounting bracket is
securely fastened.
IMPORTANT INFORMATION!
LOCKING THE HEADLAMP FOR TRANSIT
It is important to lock the headlamp and protect the switch
from being pressed while it is in transit. The headlamp can be
easily turned on if placed in something like a backpack, duel
bag or suitcase. The headlamp gets hot while in operation. To
prevent potential damage from high heat or even re, it is very
important to put the headlamp in lock mode and protect the
switch from being pressed.
NiteRider will not be held responsible for damages to person
or property resulting from a failure to follow the ‘lock’ mode
instructions.
PROTECTING YOUR INVESTMENT
Properly charge your battery to maximize its lifespan. (See the
“Battery Charging and Care” section for detailed information)
The Lumina will perform in wet weather conditions, but
submerging it in water will damage the system.
SUPPORT
If you experience diculties during product installation
or operation, NiteRider provides free telephone support
on weekdays from 8:00 AM to 4:30 PM (Pacic Time) at
800.466.8366, ext 4.
You may also e-mail us at [e-mail].
WARRANTY
NiteRider stands behind its products with the followin
warranties:
•Lifetime warranty on all mechanical components
•2 years on electrical components
•180 days on rechargeable batteries
To obtain warranty service, it is preferable to have your
original sales receipt. Contact the NiteRider customer
service department at 800.466.8366, ext 4 to obtain a
Return Merchandise Authorization (RMA) number. The RMA
number must be prominently displayed on the outside of your
package. The product must be properly packaged to prevent
damage in transit. For complete warranty information, please
visit our website at www.niterider.com.
The Lumina 650 will run up to:
The Lumina 500 will run up to:
The Lumina 350 will run up to:
RUN TIMES
Light Level
High
Med
Low
Walk
Light Level
High
Med
Low
Walk
Light Level
High
Med
Low
Walk
Time*
1:30
3:00
5:30
18:00
Time*
1:30
3:00
5:30
18:00
Time*
2:00
4:00
6:00
21:00
Lumens
650
400
200
40
Lumens
500
250
150
40
Lumens
350
200
125
30
*Run times are approximations and will vary.
Lumina Series
User Guide
Lumina: 350, 500, 650
NiteRider Technical Lighting Systems, Inc.
8295 Aero Place, Suite 200
San Diego, CA 92123
www.niterider.com
150-22844 - Rev A

RIDING AT NIGHT
While a Lumina lighting system will improve your view, control
and enjoyment of night riding, please remember that cycling
at night is an inherently dangerous activity. In addition to using
your lighting system properly and riding with extreme caution,
NiteRider urges you to:
• Never ride alone.
• Always let someone know where you are going.
• Wear a helmet and reective clothing.
• Carry an auxiliary light and emergency supplies.
• Make sure the headlamp & mounting bracket is
securely fastened.
IMPORTANT INFORMATION!
LOCKING THE HEADLAMP FOR TRANSIT
It is important to lock the headlamp and protect the switch
from being pressed while it is in transit. The headlamp can be
easily turned on if placed in something like a backpack, duel
bag or suitcase. The headlamp gets hot while in operation. To
prevent potential damage from high heat or even re, it is very
important to put the headlamp in lock mode and protect the
switch from being pressed.
NiteRider will not be held responsible for damages to person
or property resulting from a failure to follow the ‘lock’ mode
instructions.
PROTECTING YOUR INVESTMENT
Properly charge your battery to maximize its lifespan. (See the
“Battery Charging and Care” section for detailed information)
The Lumina will perform in wet weather conditions, but
submerging it in water will damage the system.
SUPPORT
If you experience diculties during product installation
or operation, NiteRider provides free telephone support
on weekdays from 8:00 AM to 4:30 PM (Pacic Time) at
800.466.8366, ext 4.
You may also e-mail us at [e-mail].
WARRANTY
NiteRider stands behind its products with the followin
warranties:
•Lifetime warranty on all mechanical components
•2 years on electrical components
•180 days on rechargeable batteries
To obtain warranty service, it is preferable to have your
original sales receipt. Contact the NiteRider customer
service department at 800.466.8366, ext 4 to obtain a
Return Merchandise Authorization (RMA) number. The RMA
number must be prominently displayed on the outside of your
package. The product must be properly packaged to prevent
damage in transit. For complete warranty information, please
visit our website at www.niterider.com.
The Lumina 650 will run up to:
The Lumina 500 will run up to:
The Lumina 350 will run up to:
RUN TIMES
Light Level
High
Med
Low
Walk
Light Level
High
Med
Low
Walk
Light Level
High
Med
Low
Walk
Time*
1:30
3:00
5:30
18:00
Time*
1:30
3:00
5:30
18:00
Time*
2:00
4:00
6:00
21:00
Lumens
650
400
200
40
Lumens
500
250
150
40
Lumens
350
200
125
30
*Run times are approximations and will vary.
Lumina Series
User Guide
Lumina: 350, 500, 650
NiteRider Technical Lighting Systems, Inc.
8295 Aero Place, Suite 200
San Diego, CA 92123
www.niterider.com
150-22844 - Rev A
