Ecco EW4011 Installation instructions

Page 1 of 5
IMPORTANT! Read all instructions before installing and using. Installer: This manual must be delivered to the end user.
WARNING!
Failure to install or use this product according to manufacturer’s recommendations may result in property damage, serious injury, and/
or death to those you are seeking to protect!
Do not install and/or operate this safety product unless you have read and understood the safety information
contained in this manual.
1. Proper installation combined with operator training in the use, care, and maintenance of emergency warning devices are essential to
ensure the safety of emergency personnel and the public.
2. Emergency warning devices often require high electrical voltages and/or currents. Exercise caution when working with live electrical
connections.
3. This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high current arcing,
which can cause personal injury and/or severe vehicle damage, including re.
4. Proper placement and installation is vital to the performance of this warning device. Install this product so that output performance of
the system is maximized and the controls are placed within convenient reach of the operator so that they can operate the system without
losing eye contact with the roadway.
5. Do not install this product or route any wires in the deployment area of an air bag. Equipment mounted or located in an air bag
deployment area may reduce the e󰀨ectiveness of the air bag or become a projectile that could cause serious personal injury or death.
Refer to the vehicle owner’s manual for the air bag deployment area. It is the responsibility of the user/operator to determine a suitable
mounting location ensuring the safety of all passengers inside the vehicle particularly avoiding areas of potential head impact.
6. It is the responsibility of the vehicle operator to ensure daily that all features of this product work correctly. In use, the vehicle operator
should ensure the projection of the warning signal is not blocked by vehicle components (i.e., open trunks or compartment doors),
people, vehicles or other obstructions.
7. The use of this or any other warning device does not ensure all drivers can or will observe or react to an emergency warning signal.
Never take the right-of-way for granted. It is the vehicle operator’s responsibility to be sure they can proceed safely before entering an
intersection, drive against tra󰀩c, respond at a high rate of speed, or walk on or around tra󰀩c lanes.
8. This equipment is intended for use by authorized personnel only. The user is responsible for understanding and obeying all laws
regarding emergency warning devices. Therefore, the user should check all applicable city, state, and federal laws and regulations. The
manufacturer assumes no liability for any loss resulting from the use of this warning device.
Specications
Size: 8.5in x 5.9in x 3.3in
Weight: 8.5lbs
Input Voltage: 12-24VDC
Temp. Range: -40ºC to 65ºC
-40ºF to 150ºF
Installation and Operation Instructions
EW4011 Snow Plow Worklights Kit
Power Consumption: Per Light 50W max
Low Beams w/ Lens Heater 52W max
High Beams w/ Lens Heater 70W max
Current Draw: High Beams 2.9A max (@13.8VDC)
Low Beams 1.5A max (@13.8VDC)
Parking Light 0.1A max (@13.8VDC)
Indicator Light 1.5A max (@13.8VDC)
Low Beams w/ Lens Heater 4.1A max (@13.8VDC)
High Beams w/ Lens Heater 5.5A max (@13.8VDC)
Automatic lens heater turns on when ambient temperatures reach or get below (approximately) 35°F (2°C). The heater will self-regulate at a
max temperature of 154°F (68°C) when operating.

Page 2 of 5
Un-packing and Pre-installation:
Carefully examine the unit for damage before installation. If damage
is found, contact the transit company or ECCO. Do not use broken or
damaged parts.
Prior to mounting, consideration should be given to cable location.
The mounting location should be chosen such that there is maximum
visibility to the oncoming tra󰀩c.
Installation:
Each kit includes 1 indicator light per ood light which can be installed
on top or either side.
To assemble the indicator on the ood light, start by removing the M3
screws and indicator port cover. Connect the indicator wires to the ood
light and cover the connection in dielectric grease to reduce exposure to
the elements.
Install the indicator as shown in Figure 1 and secure in place with
the two M4 screws included using a 3mm hex key. Note: The amber
indicator functions only as a turn signal.
Installation and Mounting
Figure 1
Figure 2

Page 3 of 5
Figure 3
Bracket Mounting:
Step 1. Select a mounting location for the unit on a at surface and drill a 15/32” hole.
Step 2. Secure the light head with the supplied hardware by using the M5 screws and lock
washers as shown in Figures 2 or 3.
Aiming Instructions:
Installer is responsible for ensuring the snowplow lights are aimed properly such that beams
comply with current highway regulations. Beams should project the same distance ahead as
compliant OEM headlights.
Wiring Instructions
Important! Disable power before wiring the product.
The wiring conguration is as shown in Figure 4. All wiring should be a minimum of 16 AWG. The
positive line must have a slow blow 25 or 30 amp fuse. Routing the ground wire directly back to
negative battery terminal is recommended. Pack dielectric grease, such as Dow Corning 4, around
each electric connection exposed to moisture or the ambient environment
+ -
25A Fuse
High Beams (Red)
Ground (-) (Black)
Low Beams (Yellow)
Parking Light (Green)
Indicator Light (Grey)
Not Used (Blue)
Ignition
Switch
Figure 4
Description Part No.
Singular Snow Plow Light Replacement EZ4011-LIGHT
Mounting Kit Replacement EZ4010-MK
10’ Wire Harness Replacement EZ4010-WIRE
Replacement Parts and Accesories

Page 4 of 5
Notes

Page 5 of 5
Warranty
© 2022 ECCO, Inc. All rights reserved.
920-1037-00 Rev. A
An ECCO SAFETY GROUP™ Brand
ECCOSAFETYGROUP.com
833 West Diamond St, Boise, Idaho 83705
Customer Service USA 800-635-5900
UK [phone] | AUS [phone]
ECCOESG.com
Manufacturer Limited Warranty and Limitation of Liability:
Manufacturer warrants that on the date of purchase, this product will conform to Manufacturer’s specications for this product (which are available from the
Manufacturer upon request). This Limited Warranty extends for sixty (60) months from the date of purchase.
DAMAGE TO PARTS OR PRODUCTS RESULTING FROM TAMPERING, ACCIDENT, ABUSE, MISUSE, NEGLIGENCE, UNAPPROVED
MODIFICATIONS, FIRE OR OTHER HAZARD; IMPROPER INSTALLATION OR OPERATION; OR NOT BEING MAINTAINED IN ACCORDANCE WITH
THE MAINTENANCE PROCEDURES SET FORTH IN MANUFACTURER’S INSTALLATION AND OPERATING INSTRUCTIONS VOIDS THIS LIMITED
WARRANTY.
Exclusion of Other Warranties:
MANUFACTURER MAKES NO OTHER WARRANTIES, EXPRESSED OR IMPLIED. THE IMPLIED WARRANTIES FOR MERCHANTABILITY, QUALITY
OR FITNESS FOR A PARTICULAR PURPOSE, OR ARISING FROM A COURSE OF DEALING, USAGE OR TRADE PRACTICE ARE HEREBY
EXCLUDED AND SHALL NOT APPLY TO THE PRODUCT AND ARE HEREBY DISCLAIMED, EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE
LAW. ORAL STATEMENTS OR REPRESENTATIONS ABOUT THE PRODUCT DO NOT CONSTITUTE WARRANTIES.
Remedies and Limitation of Liability:
MANUFACTURER’S SOLE LIABILITY AND BUYER’S EXCLUSIVE REMEDY IN CONTRACT, TORT (INCLUDING NEGLIGENCE), OR UNDER ANY
OTHER THEORY AGAINST MANUFACTURER REGARDING THE PRODUCT AND ITS USE SHALL BE, AT MANUFACTURER’S DISCRETION,
THE REPLACEMENT OR REPAIR OF THE PRODUCT, OR THE REFUND OF THE PURCHASE PRICE PAID BY BUYER FOR NON-CONFORMING
PRODUCT. IN NO EVENT SHALL MANUFACTURER’S LIABILITY ARISING OUT OF THIS LIMITED WARRANTY OR ANY OTHER CLAIM RELATED TO
THE MANUFACTURER’S PRODUCTS EXCEED THE AMOUNT PAID FOR THE PRODUCT BY BUYER AT THE TIME OF THE ORIGINAL PURCHASE.
IN NO EVENT SHALL MANUFACTURER BE LIABLE FOR LOST PROFITS, THE COST OF SUBSTITUTE EQUIPMENT OR LABOR, PROPERTY
DAMAGE, OR OTHER SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES BASED UPON ANY CLAIM FOR BREACH OF CONTRACT,
IMPROPER INSTALLATION, NEGLIGENCE, OR OTHER CLAIM, EVEN IF MANUFACTURER OR A MANUFACTURER’S REPRESENTATIVE HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. MANUFACTURER SHALL HAVE NO FURTHER OBLIGATION OR LIABILITY WITH RESPECT
TO THE PRODUCT OR ITS SALE, OPERATION AND USE, AND MANUFACTURER NEITHER ASSUMES NOR AUTHORIZES THE ASSUMPTION OF
ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH SUCH PRODUCT.
This Limited Warranty denes specic legal rights. You may have other legal rights which vary from jurisdiction to jurisdiction. Some jurisdictions do not
allow the exclusion or limitation of incidental or consequential damages.
