A4 Installation Manual
A4 Max Installation Manual
A4 Max 安装手册
文件编号
File No
：
IM-A4MAX
版本
Version
：
2021 V3
日期
Date
：
2021.06.16

www.niu-power.com [e-mail] A4 MAX Manual 2021 V3
A4 Installation Manual
1. 警告 Warning
1) 为防止电击，在安装和拆卸连接器时必须断开电源。
In order to protect against electric shock, please shut down the power when assembling and
disassembling the PV connectors.
2) 终端产品必须提供防电击功能。
The final products must be supplied with the function electric shock proof.
3) 不要在负载下断开：在有负载的情况下，不能拔出 PV 插头连接器！关掉 DC/AC 直流-交流变频器
或打开 DC 交流电路断路器，使 PV 接头连接器处于无负载的状态，则允许插拔。
Do not disconnect under Load: PV plug connections must not be disconnected while under load.
They can be placed in a no load state by switching off the DC/AC converter or breaking the AC
circuit.
4) 该连接器仅适用于 B 类和 C 类多股铜导线（见 NFPA NEC 70 第 9 章，表 10）。建议使用光伏专用
线缆，镀锡铜芯，双层绝缘，绝缘材料为 XLPE。不建议使用无镀锡电缆，不建议使用 PVC 电缆。
This connector is suitable for use only with Class B and C stranded copper conductors (See NFPA
NEC 70 Chapter 9, Table 10). The use of PV cable is recommended, Tinned copper wire, Double
insulation, Insulating material: XLPE. Tin free cable is not recommended. PVC cable is not
recommended.
5) 断开的连接器必须使用防尘塞，以防止灰尘和水进入。被污染的连接器不能插合。
Sealing cap must be used for disconnected connector, avoiding dust and water. The male and
female parts must not be plugged together when soiled.
6) 插合部件防水等级 IP68。它们不能长久置于水下使用。不要将连接器放在屋顶表面。
Waterproof degree for inserted parts is IP68. They can’t be put under water for long time. Don’t put
the connector on the roof of surface.
7) 连接器不能承受持续的机械拉伸，电缆应该由电缆扎带固定。
The plug connection must not be subjected to continuous mechanical tension. The cable should be
fixed with cable binders.
8) 产品不得在含有烃、酚、酮、氨合物等与塑料有腐蚀的环境中使用。安装过程中，禁止在连接器
里添加或涂抹任何油脂及润滑剂。（见耐化学品附表）
Do not use under hydrocarbon, phenol, Ammine and plastic corrosive environment.During
installation process, do not add any grease and lubricant in the connector.（See chemical resistance
form）
9) 该产品应由有相应资质或经过专家培训的、具备相关安全应用规范的专业人员安装。只有在按照
安装手册指定的方式组装时，连接器才被认为符合 UL 6703。如果组装或拆卸 A4 连接器时，不按照
安装手册作业，小牛将免除任何保证。
The connector is considered to be in compliance with UL 6703 only when assembled in the manner
specified by assembly instructions. NIU Power will be exempted from any warranty if A4 connector
was assembled or disassembled without following the User Manual.

www.niu-power.com [e-mail] A4 MAX Manual 2021 V3
A4 Installation Manual
2. 技术参数 Product Specifications
连接器系统 Connector system Φ4mm
额定电压 Rated voltage IEC 1500V&UL 1500V
额定电流 Rated current @IEC（85℃）
25A（2.5mm2 / 14AWG）
35A（4.0mm2 / 12AWG）
40A（6.0mm2 / 10AWG）
50A（10.0mm2 / 8AWG）
70A（16.0mm2 / 6AWG）
额定脉冲电压 Rated impulse voltage 16KV
环境温度范围 Ambient temperature range -40℃~+85℃
接触电阻 Contact resistance ≤0.25mΩ
应用等级 Application degree Class A
防护类别 Protection class Class Ⅱ
污染等级 Pollution degree 2
防护等级 Degree of Protection
IP68（1m，1h），mated
IP2X，unmated
阻燃等级 Flame class UL94-V0
3. 产品选型表 Product Selection Form
A4 Max Series:A4 Max 系列光伏铜线连接器型号表
Connector Male Housing
连接器负极本体选型表
Connector Female Housing
连接器正极本体选型表
Male Terminal
负极导电体选型表
Female Terminal
正极导电体选型表
TYPE 型号 Cable OD TYPE 型号
(1)
TYPE 型号
(2)
Cable OD TYPE 型号 Conduct Spec
导体规格
TYPE 型号 Conduct Spec
导体规格
A4-M6
M6 型本体 4.7mm~6.0mm
A4-F6
F6 型本体
A4-F6-2
F6-2 型本体
4.7mm~6.0mm
A4-MU
U型公端子
2.5mm2~6mm2
A4-FU
U型母端子
2.5mm2~6mm2
A4-M7
M7 型本体
5.6mm~7.0mm
A4-F7
F7 型本体
A4-F7-2
F7-2 型本体
5.6mm~7.0mm
A4-MO-10
O型公端子
6mm2~10mm2
A4-FO-10
O型母端子
6mm2~10mm2
A4-M8
M8 型本体
7.0mm~8.0mm
A4-F8
F8 型本体
A4-F8-2
F8-2 型本体
7.0mm~8.0mm
A4-MO-16
O型公端子
16mm2
A4-FO-16
O型母端子
16mm2
A4-M10
M10 型本体
8.0mm~10mm
A4-F10
F9 型本体
A4-F10-2
F10-2 型本体
8.0mm~10mm

www.niu-power.com [e-mail] A4 MAX Manual 2021 V3
A4 Installation Manual
4. 连接器结构及外观尺寸图 Connector Size Drawing
4.1正极连接器 Positive Connector Housing
型号列表 TYPE list： A4-F6，A4-F7，A4-F8，A4-F10
4.2 负极连接器 Negative Connector Housing
型号列表 TYPE List with NEC lock（1型Type1）: A4-M6，A4-M7，A4-M8，A4-M10
型号列表 TYPE List without NEC lock（2型 Type2）:
A4-M6-2，A4-M7-2，A4-M8-2，A4-M10-2

www.niu-power.com [e-mail] A4 MAX Manual 2021 V3
A4 Installation Manual
4.2 连接器 U 型端子尺寸 Type U Terminals
5. 组装 Assembled by machine
5.1 剥线 Stripping
剥线尺寸Stripping size：6±0.5mm
5.2 铆接 Crimping
4mm2/12AWG 上刀尺寸Tool Size(Up)

www.niu-power.com [e-mail] A4 MAX Manual 2021 V3
A4 Installation Manual
4mm2/12AWG 下 刀 尺寸 Tool Size(Down)
典型电缆
Cable Spec
铆接高度
Crimping (H) REF
铆接宽度
Crimping (W) REF
4mm2 2.1±0.1mm 4.1±0.1mm

www.niu-power.com [e-mail] A4 MAX Manual 2021 V3
A4 Installation Manual
5.3 线束组装 Cable Assembly
将铆接好的线束插入正极负极绝缘本体，直至金属件与本体啮合，轻轻拉动导线，检查金属
件是否啮合牢固。
Push the crimped terminal into the housing until they engage. Pull lightly on the lead to
check that the metal part has engaged.
5.4 螺帽组装 Nut Assembly
在锁紧连接器螺帽时，定位治具须有导正结构(治具见下图)，方可使用。
When locking the nut of the connector, the positioning fixture shall be provided with a guide
structure, see below figures.
连接器型号
Connector
Housing
线缆外径
Cable OD
扭力要求
Screw Force
torque
螺帽参考间隙
Reference Nut Gap
备注
Remark
A
4 max-6 5.0≤OD≤6.0 mm
3.5±0.5 N*m
0＜X≤1.0 mm (REF) 操作前请校准设备的扭
力，根据扭力定间隙.
Please calibration
equipment before
production, define the
gap by screw torque.
A
4 max-7 5.6≤OD≤7.0 mm
0＜X≤1.5 mm (REF)
A
4 max-8 7.0≤OD≤8.0 mm
A
4 max-10 8.0≤OD≤10.0 mm
装配好后需要检查负极pin 针与负极本体的同轴度。要求圆心距≤1mm。
After assembled, check the coaxiality of the negative pin and the negative body.
Requirements of the center distance ≤ 1mm.

www.niu-power.com [e-mail] A4 MAX Manual 2021 V3
A4 Installation Manual
6. 人工安装 Manual Installation
6.1 工具要求 Requirements of Tools
6.1.1 剥线钳
Strip Tool
料号 P/N 钳口 Jaw 剥线范围 Strip Range
S2546
上边Top 2.5mm2 14AWG
中间 Middle 4.0mm2 12AWG
下边 Bottom 6.0mm2 10AWG
6.1.2 铆接钳 Crimping Tool
料号 P/N 钳口 Jaw 铆接范围 Crimping Range
A2546
上边Top 2.5mm2 14AWG
中间 Middle 4.0mm2 12AWG
下边 Bottom 6.0mm2 10AWG

www.niu-power.com [e-mail] A4 MAX Manual 2021 V3
A4 Installation Manual
6.1.3 塑料板手 Plastic Spanner
1套 =2片 ， 料 号 ：A4W-A; A4W-B
1 set=2pcs, P/N: A4W-A; A4W-B
6.1.4 工具箱 Tool Box
料号
P/N
数量
Qty.
Tools 1 set
6.2 组装步骤 Assembly Steps
（1） 剥 线 Stripping
剥离电缆绝缘层。Strip the insulating layer of cable.L=6±0.5mm.
注意不要切断绝缘层下的线芯。Be attention and not to cut off the wire core.

www.niu-power.com [e-mail] A4 MAX Manual 2021 V3
A4 Installation Manual
(2) 铆接插针插套 Crimping pin and socket
首先，将金属端子放在铆接工具孔内，铆接孔朝外，调节背面的限位机构， 使金属端子
的最外侧边缘与铆接工具齐平。然后将剥好线的线芯插入金属端子铆接孔内，需确保所有
芯线都在孔内。需保证金属件和电缆线的同轴度。最后提拉铆接工具手柄，一直按到
底，完成铆接。铆接后线缆拉力参照下表。铜丝都要被包扎。
Firstly, the terminal is placed in the crimping tool jig, the jig faces outward, and the
limiting mechanism of the back is adjusted so that the outermost edge of the terminal
is flush with the crimping tool. Then insert the wire core into the tool’s jig of the
terminal, and make sure all the cores are in the hole. Ensure the coaxiality of metal
parts and cables. Finally, pull the crimping tool handle and press it to the end to
complete the crimping. The cable tension after crimping is referenced to the following
table. All copper wires should be bandaged
线缆规格
Cable specifications
拔出力
Cable pull-out force
4.0mm2 / 12AWG ≥312N
6.0mm2 / 10AWG ≥356N
10.0mm2 / 8AWG ≥401N
16.0mm2 / 6AWG ≥450N

www.niu-power.com [e-mail] A4 MAX Manual 2021 V3
A4 Installation Manual
（3）插入 Pushing
将铆接好的插头插入插座或插头的绝缘套，直至其齿合。轻轻拉动导线，检查金属件是否
齿合牢固。确认负极 pin 针和负极本体同轴。
After assembled, check the coaxiality of the negative pin and the negative body.
Requirements of the center distance ≤ 1mm.
（1） 安装螺帽Install the cable gland
先用手预拧紧，再用塑料扳手旋紧电缆螺帽。
First screw it by hands, then lock tightly by plastic spanner.
型号
Type
电缆外径范围
Cable OD range
扭力要求
Screw Force torque
螺帽参考间隙
Reference Nut Gap
A4 Max 6 4.7-6.0mm
3.5±0.5 N*m
0
＜
X≤1.0
mm
(
REF
)
A4 Max 7 5.6-7.0mm
0＜X≤1.5 mm (REF)
A4 Max 8 7.0-8.0mm
A4 Max 10 8.0-10mm
注意 1：拧螺帽时，需保证电缆线与螺帽同心。
Remark1：Ensure the concentricity of cable and cable gland when screw cable gland.
注意 2：须确认负极 pin 针和负极本体同轴，再锁紧螺帽。
Remark2：Make sure the negative pin and the negative body are coaxial and then lock the nut.

www.niu-power.com [e-mail] A4 MAX Manual 2021 V3
A4 Installation Manual
7.连接器对插及解锁 Connecting and Disconnecting
7.1 连接器对插
Connecting
将连接器正负极对插，直到啮合。轻轻拉动，以检查是否啮合牢固。插入力≤80N。
Plug the coupling together until they engage. And pull lightly to check correct engagement.
Insertion force ≤80N.
7.2 连接器解锁
Disconnecting
此插头连接，只能使用塑料板手工具解锁。
This connection can only be unlocked with plastic spanner.
8. 线缆状态
Cable Status
8.1 线缆接线 Connection of Cable
电缆根部建议保留 20mm 未折弯长度，以免因线缆折弯产生的外力引起连接器密封件变形。
In order to avoid the cable bend force lead to a visible deformation in the sealing portion of
the insulation, the cable need keep at least 20mm straight length.

www.niu-power.com [e-mail] A4 MAX Manual 2021 V3
A4 Installation Manual
备注：请参考电缆生产商的最小弯曲半径的详细要求。
Remarks：Please refer to the detailed instruction of the min bend radius given by cable
manufacturer.
8.2 接合状态 The State after Connection
9. 包装方式
Packing
9.1 散件包装 Spare Parts Packing
一般每纸箱（590*390*200mm）自封袋装500个正极连接器，自封袋装 500个负极连接器。500 个插针和
500 个插套各装一小塑料袋。
Generally, there are 500 pcs positive connector housing, 500 pcs negative connector housing, 500
pcs male terminals and the 500 pcs female terminals in one box.

www.niu-power.com [e-mail] A4 MAX Manual 2021 V3
A4 Installation Manual
9.2 配件袋包装
Accessory Bag Packing
每个包装袋含 2 对连接器和 1 个扳手，放置在光伏组件箱内。
One pair spanner and one pair A4 connectors are in PE bag for every pallet of pv modules.
10. 警告 Warning
10.1 耐化学品附表 Chemical Resistance Form
10.1.1 对产品有影响的常见化学品清单 Common Chemicals which Lead to Product
Failure Easily.
备注：对于上表未列明的化学品，需经确认无影响后再使用。
Note: Chemicals which is not contained in the table should only be used after confirm it
has no influence to the product.
化学品名 Chemical Name 测试结果 Test Result
润滑油 Lubricating oil 不兼容 Incompatible
防锈油 Rust-proof oil 不兼容 Incompatible
冲压油 Stamping oil 不兼容 Incompatible
黄油 Grease 不兼容 Incompatible
机油 Engine oil 不兼容 Incompatible
柴油 Diesel 不兼容 Incompatible
食用油 Cooking oil 不兼容 Incompatible
WD40 不兼容 Incompatible
香蕉水 Banana oil 不兼容 Incompatible
油性 封孔Oil sealing agent 不兼容 Incompatible
乙酸乙酯 Ethyl acetate 不兼容 Incompatible

www.niu-power.com [e-mail] A4 MAX Manual 2021 V3
A4 Installation Manual
10.2 连接器责任免除条款 The Connector Liability Exemption Clause
有违反下列情况之一者，并导致产品出问题，造成任何损失，我公司将不承担任何责任。
There exist following case, and lead to product goes wrong, any loss caused, product manufacturers
will not take any responsibility.
10.2.1 产品运输和仓储 Product Transportation and Storage
1）产品在运输、仓库过程中，不可与 10.1.1 表中有关化学品存放在一起，使产品经受这些化学品污
染；
Products in the process of transportation, warehouse, cannot store with "10.1.1" in the table of
chemicals together that lead the product pollution with these chemicals;
2）产品在运输、仓库过程中，不可对产品进行过分承压、撞击等破坏产品行为；
Products in the process of transportation, warehouse, cannot pressure too much on products and
such as impact damage behavior;
3）产品在运输、仓库过程中，常温存储，应注意避光、防水、防尘等方面防护，以免降低产品性能
电站现场应特别注意；
Products in the process of transportation, warehouse, should room temperature storage,
avoid light, should waterproof, dustproof, and should be paid attention to protection, so as not to
reduce product performance, pay special attention to product when in power station;
4）产品正常存储时间 1 年。
Product is recommendation finished installation in one year.
10.2.2 产品安装和使用 Product Installing and Operating
1. 产品正常工作环境温度-40~+90℃；
The product health working environment temperature - 40 ~ + 90 ℃;
2. 2.2 产品现场安装，需按照本手册操作；
The Product installing should be in accordance with the Trina Solar product installation instructions;
3. 产品在沿海、沙漠等粉尘、粉尘、灰尘多的地域使用，产品出厂前必须带防尘塞；
Products in the coastal, desert dust, dust more regional use, before the products leave the factory,
they must take the dust cap;
4. 产品在屋顶电站使用时，连接器不可直接放在屋顶表面。
Products used in roof power station, the connector shall not directly on the surface of the roof.
5. 产品与化学品兼容性见耐化学品附表。
Products and chemical compatibility see Chemical resistance form.
6. 连接器在未耦合情况下，产品将不能满足任何 IP 防护等级，也不能正常使用。
The connector under the condition of disconnect, the product will not be able to meet any IP
protection grade, also can't normal use.
7. 产品插合后满足 IP68 防护等级要求，但不能长期置于水下或屋顶上工作。
Products meet IP68 degree of protection requirement after connects, while it can't work under water
for a long time, and it can’t be put on the surface of roof to avoid the strong sunlight.
8. 连接器在未对插的情况下，不可长时间放置于户外，这样可能会造成金属件腐蚀，并使连接器性
能降低。
Connector in the case of disconnect, should not place in the outdoor for long time, so may be the
cause of the corrosion of the metal, and lower the connector performance.
9. 连接器在户外安装、使用过程中，如果不能及时对插，请做好连接器防护工作，将连接器端口插
上防尘塞，防止连接器受到水、尘等的污染， 影响产品使用性能。
Connector in the process of outdoor installation and use, if not to connect in time, please do a good
job in the connector protection, put on the dust cap and protect the connector from water, dust and

www.niu-power.com [e-mail] A4 MAX Manual 2021 V3
A4 Installation Manual
other pollution, affect the product performance.
10. 连接器在安装、使用过程中，不可将连接器过分碰撞，拖在水中、草丛中、地上等。防止连接器
使用前，内部受到污染，降低产品性能。
Connector in the process of installation and use should not be collision, drag in the water, grass,
and the ground to prevent the pollution of inside the connector before use, reduce the product
performance.
11. 小牛的连接器必须与小牛指定的连接器，进行正、负极对插。
Connectors of NIU Power brand must be connected with connectors appointed by NIU Power.
此免责条款最终解释权归小牛电器（苏州）有限公司。
This disclaimer final
explanation right belongs to the Niu Power (Suzhou)
Corporation.
小牛电气（苏州）有限公司有权随时对本说明书中可能出现的打印错误，产品技术改进和创新
等方面作出修改，这些改动恕不另行通知。同时各语言版本翻译的
不详之处，请以中文版为
准。
NIU Power has the rights to make certain correction for the printing errors,
improvements and innovation for the products, and there will be no prior
notice when these changes happen. If there was any misunderstanding for the
version in different language, please regard Chinese version as the right one.
可 以 在
http://www.niu-power.com/
下载和打印相应的文件。
The
appropriate instructions can be viewed, downloaded, and printed at http://www.niu-
power.com/.
小牛电气（苏州）有限公司 NIU Power Suzhou Corporation
地址 ADD：中国江苏省苏州市辛庄镇北查家浜路16号
No. 16 North Chajiabang Road,Suzhou City, Jiangsu, PRC
邮编 PO No：215555
网址 Website：http://www.niu-power.com/
