NODEXON NX-5610-24F8G User manual
NX-5610-24F8G
Core Aggregation Switch
Product Guide
Statement of Copyright
Nodexon Networks©2021
All copyrights in this document are reserved by Nodexon Networks. Without Nodexon Networks'
prior written approval, any reproduction, excerption, backup, modification, transmission,
translation, or commercial use of this document or any portion of this document, in any form or by
any means, is forbidden.
Statement of Exemption
This material is being distributed "as is." This document's contents are subject to change at any
time without notice. Please visit the Nodexon Networks website for the most up-to-date
information. Nodexon Networks makes every effort to guarantee content accuracy, but cannot be
held liable for any losses or damages incurred as a result of content omissions, inaccuracies, or
mistakes.
Preface
Thank you for using our products. This manual will guide you through the installation of the device.
This manual describes the functional and physical features and provides the device installation
steps, hardware troubleshooting, module technical specifications, and specifications and usage
guidelines for cables and connectors.
The product user's manual mainly introduces the software
and hardware parameters, installation method and matters needing attention in the installation
process of
NX-5610-24F8G
switch.
Audience
It is intended for the users who have some experience in installing and maintaining network
hardware. At the same time, it is assumed that the users are already familiar with the related terms
and concepts
Obtaining Technical Assistance
Website:https://www.nodexon.com/
Technical Support Website:https://nodexon.com/support
Community:http://www.nodexon.com/community
Case Portal :https://www.nodexon.com/caseportal
Website:https://www.nodexon.com/
This Manual Includes The Following Chapters
Chapter 1: product introduction. Describe the basic functional characteristics of the switch, detailed
hardware and software specifications and appearance information.
Chapter 2: hardware connectivity. Instruct the connection between switch and other equipment
and matters needing
attention.
Chapter 3: product installation. Instruct switch hardware installation method and matters needing
attention.
Chapter 4: product packaging and usage recommendations.
Chapter 1 product introduction
1.1 product introduction
The NX-5610-24F8G three-tier, stackable administrative switch is designed for small and medium
enterprises (SMEs), large enterprises and Internet service providers (ISPs). They offer high
performance, flexibility, fault tolerance, and advanced software capabilities to achieve maximum
return on investment. NX-5610-24F8G switches with gigabit Ethernet RJ45 and SFP ports, 10G SFP+
ports, advanced security features and advanced quality of service (QoS), can be used as core,
distribution or access layer switches, with high-end port density, switch stack and easy
management, is an ideal choice for all kinds of commercial
network applications.
1. 2 Product features
Full gigabit port full gigabit RJ45 Combo ports, 4 10 gigabit SFP optical fiber ports, 24 gigabit SFP
ports, breaking the traditional 100 MB limit, data transmission does not slow down
Broadcom high-end chip, performance is more stable and strong
Broadcom's high-end chips can greatly improve the speed of network data processing
Support stacked function
Support physical stack of 9 switches, virtual stack of 32 switches, support ring/Daisy chain stack link
Support Apollo cloud platform one-stop management
Support the cloud platform to visually manage the resources of switches and PD devices, making
operation and maintenance management simpler
1.3 Product software and hardware technical specifications
Hardware
Chip
Broadcom high performance chip
Flash
16MB
storage
256MB DDR
Port
8 10/100/1000Mbps RJ45 ports (Combo）
4 10G SFP ports
24 Gigabit SFP ports
1 RJ45 Console port，1 10/100/1000Mbps
management RJ45 port
1 USB 2.0,1 Mini-usb Console port
performance
Forward mode: store and forward
Back width：128Gbps
Rate：96Mpps
Support 16K MAC
Thunder Proof
±6KV
ESD
touch：±6KV air：±8KV
Input
100-240V/50-60Hz
Size (L×W×H）
440mm×320mm×44mm
Software Features
Route
Support RIP V1/V2, OSPFv1\OSPFv2dynamic
routing
Support static route
DHCP
Support DHCP Service
Support DHCP Relay
Support DHCP Snooping
VLAN
Support 4K VLAN
Support 802.1Q VLAN MAC VLAN, IP VLAN
Voice VLAN
MAC List
Follow IEEE 802.1d standard
Support MAC Address automatic learning
and aging
Support static, dynamic, filter address table
Safety performance
password protection
Support user access restrictions based on
port number, IP address, MAC address
Support HTTPS、SSL V3、TLS V1、SSH
V1/V2
Support IP-MAC-PORT 3 in one
Support ARP protect, IP protect, DoS
protect
Support DHCP Snooping, DHCP attack
protect
Support 802.1X AC, AAA
Support port security and port isolation
Support CPU protect function
Support L2(Layer 2)-L4(Layer 4)Packet
ACL
filtering function
Support port mirroring, port redirection,
flow speed limit, QoS remarking
QoS
Supports 8 port queues
Support port priority, 802.1p priority, DSCP
priority
Support SP, WRR, WFQ priority scheduling
algorithm
Support automatic identification,
management and acquisition of information
Tree
Support STP(IEEE 802.1d)，RSTP(IEEE
802.1w) and MSTP(IEEE 802.1s)standard
Support loop protection, root bridge protection, TC protection,
BPDU protection,
BPDU filtering
Multicast
Support IGMP v1/v2 Snooping
Support for quick exit mechanism
Support Multicast VLAN
Supports multicast filtering, message
statistics and unknown multicast discarding
Storm
Control
Support multicast control
Support broadcast control
Support Unknown unicast control
Link
Together
Support static aggregation
Support dynamic convergence
Support IP, MAC, mixed load balancing
mode
Maximum support is 32 aggregation groups
IPv6
Support IPv6 Ping、IPv6 Tracert、IPv6 Telnet
Support IPv6 SSH 、IPv6 SSL
Support WEB Management (HTTP、
HTTPS、SSL V3）
Support CLI (Telnet,SSH V1/V2, Local
port）
Support SNMP V1/V2/V3
Manage and
Support LLDP、RMON
Maintain
Support ARP protect IP protect bDoS
protect
Support Apollo
Support CPU monitoring 、Storage
monitoring
Support system log, grading warning
Support Ping. Tracert test, line test
1.4 Product appearance
The front panel
Contains indicator light, RJ45 port, SFP port, CONSOLE port & USB port
PWR
Power
light
red
on
Power normal
off
Power out, power switch
not open, power abnormal
LINK/AC
T
Device
connect
light
green
flicker
The corresponding RJ45
port is connected
off
The corresponding RJ45
port is unconnected
SYS
System
light
green
flicker
System working normal
off
System working
abnormally, System
damaged
XG
SFP
light
green
flicker
The corresponding RJ45
port is unconnected
off
The corresponding RJ45
port is unconnected
RJ45 port
NX-5610-24F8G support 8 10/100/1000mbps adaptive RJ45 Combo port, 1 RJ45 Console port, 1
gigabit RJ45 management port
SFP port
The NX-5610-24F8G provides 4 10G SFP uplink port and 24 gigabit SFP ports, which can be inserted
into gigabit SFP modules
RST button
When the switch is powered on, press the button with a needle and release the device to enter the
restart state.
When the SYS lamp lights up and the device is restarted, press the button for longer than 5S with a
needle and the device enters the reset state. When SYS lights up and the device is reset
successfully.
The Console Port
Console port is used to connect to serial ports on computers or other terminals to manage or
configure switches.
Rear panel
Includes: power socket, power switch, grounding terminal
Power socket
Connect the power cord to the switch NX-5610-24F8G
and the access power should be 100-240v ~ 50/60hz ac power
Ground terminal
Please ground the wire in case of lighting strike. To avoid lightning strike and extend the service life
of products
Chapter 2: hardware connection
2.1 Connect the RJ45 port
Connect the network cable to the RJ45 port of the switch and the opposite network device
2.2 Connect to the SFP port
The NX-5610-24F8G SFP port only supports gigabit fiber modules. It is recommended to use
standard SFP module products. The installation process of fiber optic module of switch is as follows:
Grasp the fiber module from the side and insert it smoothly along the SFP port slot of the switch
until the fiber module is in close contact with the switch;
Confirm the Rx and Tx ports of the fiber module when connecting, insert one end of the fiber into
the Rx and Tx ports, ensure that the Tx and Rx ends of the interface are correctly connected, and
the other end of the fiber is connected to another device;
After power-on, check the status of the corresponding indicator. If the indicator is on, the link is up.
If the indicator is off, the link is down. Check the line and confirm that the peer device is enabled.
It is not allowed to excessively bend the fiber, and its radius of curvature should be no less than
10cm ;
Ensure the cleanliness of the fiber end face;
Please do not look directly into the fiber optic connector with your eyes, as this may cause eye
damage.
2.3 Check Before Power-On
Check that the power supply of the power outlet meets the switch
specifications.
Check that the power supply, switch, and rack are properly grounded.
Check whether the switch is connected to other network devices.
2.4 device initialization
The switch will automatically initialize after the power is turned on and the power switch is turned
on.
The indicator light will appear as follows:
After the power is turned on, the power indicator remains steady. When SYS enters the flashing
state, the system runs normally.
The indicator of each port indicates the connection status of each port, indicating that the switch
has started to work normally.
Note: To avoid damage to the equipment and personal injury caused by improper use, please
observe the following precautions.
Safety precautions
Power supply remains off during the installation process.
Wear an esd-preventive wrist strap and ensure that the esd-preventive wrist strap is in good
contact with the skin to avoid
Chapter 3 Product Installation
3.1 Installation Precautions
Potential safety hazards.
Witch only can work normally under the correct power supply. Please confirm that the power
supply voltage matches the
Voltage indicated by the switch.
Before powering on the switch, please make sure that the power circuit is not overloaded, so as not
to affect the normal
Operation of the switch and cause unnecessary damage.
To avoid the risk of electric shock, do not open the case while the switch is working, even if it is not
charged, do not open it yourself;
Before cleaning the switch, first pull out the power plug of the switch. Do not wipe with a moist
fabric. Do not use liquid to clean.
Humidity
In order to ensure long-term stable operation of the switch and prolong its service life, please
maintain a certain temperature and humidity in the environment. Too high or too low ambient
humidity is likely to cause leakage, deformation and even corrosion of metal parts. If the
temperature is too high, the aging process of the insulation material will be accelerated, which will
seriously affect the service life of the equipment. The normal operation and storage temperature /
humidity of this series of switches are as follows
Environmental
Description
temperature
Relative humidity
Working
Environment
0°C~40°C
10% to 90% RH does not condense
Storage
environment
-40 ° C ~
70 ° C
5% to 90% RH does not condense
Elevation
Products with this mark are only suitable for safe use in areas below 2000m above sea level .
Dustproof
Dust falling on the surface of the switch can cause electrostatic adsorption and poor contact of the
metal contacts. Although the device itself has made certain measures in anti-static, when the
static electricity exceeds a certain intensity, it will still cause fatal
damage to the electronic components on the internal circuit board. To avoid the static electricity
affecting the normal operation of the
device, please pay attention to the following:
Regular dust removal to keep indoor air clean;
Make sure that the equipment is well grounded to ensure the smooth transfer of static electricity.
Interface
Electromagnetic interference will affect the electronic components such as capacitors and inductors
inside the device by means of capacitive coupling, inductive coupling, impedance coupling, etc. To
reduce the adverse effects caused by electromagnetic
interference, please pay attention to the following:
The power supply system takes necessary measures against grid interference
The switch should be away from high-frequency, high- power, high-current equipment, such as
wireless transmitters;
Take electromagnetic shielding measures when necessary.
Lighting Protection
When a lightning strike occurs, a strong current is generated in an instant, and the air in the
discharge path is instantaneously heated to 20,000 degrees Celsius, and an instantaneous large
current is enough to cause fatal damage to the electronic device. For better lightning protection,
please note the following:
Confirm that the rack is in good contact with the ground
Make sure the power outlet is in good contact with the ground;
Reasonable wiring to avoid internal induction lightning;
When using outdoor wiring, it is recommended to use a signal lightning arrester.
Installation Rack Requirements
Regardless of whether the switch is installed in a rack or other horizontal workbench, please note
the following:
Verify that the rack or table is stable, strong, and capable of withstanding a weight of at least 5.5 kg
Confirm that the rack itself has a good cooling system, or keep the room well ventilated;
Make sure the rack is well grounded, and the distance between the power socket and the switch is
less than 1.5 meters.
Tool Preparation
The Phillips screwdriver, electrostatic wrist strap, and cable fiber may be used during installation.
3.2 The product installation
19 "standard rack mounting
The NX-5610-24F8G is designed in accordance with the standard 19-inch rack size and can be easily
installed on
the rack. The specific installation steps are as follows:
Check the grounding and stability of the rack;
Install the two L -shaped brackets in the accessories on both sides of the switch panel and fix them
with the screws provided in the accessories.
The switch is placed in position within the frame, is supported by the carriage; screw the L -shaped
bracket fixed to the fixed rack guide slot ends, the switch to ensure a stable, horizontally mounted
on the machine frame,
Good grounding of the rack is an important guarantee for antistatic, anti-leakage, lightning
protection and anti-interference of the equipment. Therefore, ensure that the grounding wire of
the rack is properly installed.
The equipment installed in the rack is generally from bottom to
top to avoid overload installation;
Avoid placing other heavy objects on the surface of the switch to avoid accidents;
Ensure heat dissipation and air circulation.
3.3 Login management interface
Step1
Connect the network cable connected to the computer to the RJ45 port of the switch when the
equipment is working normally
Step2
Manually change the computer IP address to 192.168.254.X (X is 2~254), and the subnet mask:
255.255.255.0
Note
:
Step3
Open the computer's browser, enter 192.168.254.1 in the address box, and hit enter
Step4、Enter the Web administrator login interface of the switch, enter the default username and
password admin in the input fields of username and password, and then click login
Step5
You have entered the web administration interface of the switch and are ready to start configuring
the switch
Chapter 4 Packing List And Usage Suggestion
4.1 Open the package and check the following list
Carefully
items
quantity
instruction
switch
1
\
adapter
1
power
hanger
2
Use to install
Warranty card
1
After sale
User manual
1
Use to install
Use Advice
For safety, non-professionals should not open the shell;
When the product is powered on, pay attention to the danger of strong power and safety
protection;
Please select the right power adapter to power the switch, and confirm whether it conforms to the
requirements of the switch before use;
Do not use the switch in a humid environment to avoid water entering the fuselage through the
shell and causing damage to the machine;
Please start the power after the circuit connection is completed;
When the product is powered on, please do not plug or unplug the cable at will unless in special
circumstances;
Do not use the switch in places with dust and electromagnetic radiation, and do not use the switch
in places with high temperature and no ventilation.
Please do not place heavy objects on the switch to avoid accidents;
It is recommended to use switches indoors and waterproof water tanks outdoors.
Note: the pictures in the instruction manual are for reference only
Table of contents
Other NODEXON Switch manuals
