NOKIAN TYRES INTUITU User manual
NOKIAN TYRES INTUITU™
Sensor User Manual
Version 1.0
May 2020
2 (7)
Contents
Product description ..............................................................................................................................3
General safety instructions...................................................................................................................4
Installation............................................................................................................................................4
General usage instructions ..................................................................................................................4
Faults and repairs ................................................................................................................................4
Disposal...............................................................................................................................................4
Declarations of Conformity and Compliance ........................................................................................5
Manufacturer’s address........................................................................................................................6
Appendix A: EU Declaration of Conformity...........................................................................................7
This User Manual is copyrighted. This User Manual may not be duplicated either wholly or in part
without the express permission of Nokian Tyres Plc.
3 (7)
Product description
Product name:
Intuitu sensor
Product description:
The Intuitu sensor is a measurement device that is used as a component in
the Intuitu Digital Platform by Nokian Tyres Plc.
The sensor measures pressure, temperature and acceleration inside the
tire. The sensor is permanently fixed inside the tire and it uses a low-power
radio to transmit the measurement data.
Once installed, the sensor does not require the user’s attention. It activates
itself upon movement and resumes power-saving mode after the
movement has ceased.
Operating ambient temperature:
-40 to 80°C (-40 °C to -20 °C with limited functionality and performance)
Storage temperature:
-40 to +125°C
Frequency bands in which the radio equipment operates:
2.4GHz to 2.483GHz ISM band
433.050MHz to 434.790MHz ISM band
30 kHz to 300 kHz Low frequency (LF) band
Maximum radio-frequency power transmitted in the frequency bands in which the radio equipment
operates:
The maximum power for all bands is less than the highest limit value
specified in the related Harmonized Standard.
The frequency bands and transmitting power nominal limits applicable to this radio equipment are as
follows:
Bluetooth: 5.1 dBm, 433 MHz: 8 dBm
4 (7)
General safety instructions
The Intuitu sensor is always factory-installed. Installation is permanent, and
the sensor should not be dismounted from the tire to avoid damaging the
tire or causing other safety risks.
Installation
The Intuitu sensor is always factory-installed.
General usage instructions
The Intuitu sensor is used together with the Nokian Tyres Intuitu mobile
application or a Nokian Tyres Intuitu vehicle gateway.
Faults and repairs
If you have problems with an Intuitu sensor, please contact customer
service at intuitu.support@nokiantyres.com.
Disposal
Private households
This symbol (figure 1) on the product(s) and / or accompanying documents
means that used electrical and electronic equipment (WEEE) should not be
mixed with general household waste. For proper treatment, recovery and
recycling, please take this product(s) to designated collection points where
it will be accepted free of charge. Alternatively, in some countries, you may
be able to return your products to your local retailer upon purchase of an
equivalent new product. Disposing of this product correctly will help save
valuable resources and prevent any potential negative effects on human
health and the environment, which could otherwise arise from
inappropriate waste handling. Please contact your local authority for further
details of your nearest designated collection point. Penalties may be
applicable for incorrect disposal of this waste, in accordance with your
national legislation. The Intuitu sensor can be disposed of together with the
tire it is attached to.
Figure 1. WEEE Symbol – Crossed out wheeled bin
5 (7)
Professional users within the European Union
If you wish to discard electrical and electronic equipment (EEE), please
contact your dealer or supplier for further information.
All users outside the European Union
The WEEE symbol is only valid in the European Union (EU). If you wish to
discard this product, please contact your local authorities or dealer and ask
for the correct method of disposal.
Declarations of Conformity and Compliance
Nokian Tyres Plc declares that the Intuitu sensor fulfills the Radio
Equipment Directive 2014/53/EU (RED). See Appendix A for the full text of
the EU declaration of conformity.
FCC Compliance Statement
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This device complies with 47 CFR part 15 (the FCC Rules). This
equipment has been tested and found to comply with the limits for a digital
device, pursuant to part 15 of the FCC Rules.
This device complies with the FCC RF exposure limits and has been
evaluated in compliance with portable exposure condition.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
6 (7)
ISED Canada compliance statement
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
This device complies with ISED Canada RSS standard(s).
This device complies with ISED license-exempt RSS(s). Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This device complies with the ISED RF exposure limits and has been
evaluated in compliance with portable exposure condition.
This Class B digital apparatus complies with Canadian ICES-003.
Manufacturer’s address
Nokian Tyres Plc, Pirkkalaistie 7, 37101 Nokia, Finland
7 (7)
Appendix A: EU Declaration of Conformity
1. Product: NOKIAN TYRES INTUITUTM SENSOR, Product Type: Intuitu
Sensor 9Bar V001, Firmware:1.0.0
2. Manufacturer: Nokian Tyres Plc, Pirkkalaistie 7, 37101 Nokia, Finland
3. This declaration of conformity is issued under the sole responsibility of the
manufacturer.
4. Object of the declaration is the Intuitu Sensor
5. The object of the declaration described above is in conformity with the
relevant Community harmonization:
a. Directive 2014/53/EU
6. The conformity with the essential requirements of the following directives
has been demonstrated against the following standards:
Standard reference
Essential requirements
EN 62368-1:2014 + AC:2015 +
A11:2017
EN 62479:2010
Article 3.1 (a): Health and Safety of
the User
Draft EN 301 489-1 V2.2.0
Draft EN 301 489-3 V2.1.1
Draft EN 301 489-17 V3.1.1
Article 3.1 (b): Electromagnetic
Compatibility
EN 300 328 V2.2.2
Draft EN 300 220-1 V3.1.1
Draft EN 300 220-2 V3.1.1
Article 3.2: Effective use of spectrum
allocated
7. “The Notified Body DEKRA Testing and Certification S.A.U., with number
1909 performed the conformity assessment procedure and issued the EU-
Type Examination Certificate according to Directive 2014/53/EU:
(reference)”
8. Thus, is placed on the product. The Technical Documentation
(TD) relevant to the product described above and which supports this
Declaration of Conformity, is held at: (Nokian Tyres Plc, Pirkkalaistie 7,
37101 Nokia, Finland)
9. Signed for and on behalf of Nokian Tyres Plc, Nokia, April 22nd, 2020:
Mika Penttilä Jukka Kasi
Head of Digital Technology SVP, Product and Marketing
Nokian Tyres plc Nokian Tyres plc
