PARTNO,619703
NORCOLD 03/26/2008
PARTS LIST
3163 SERIES
3163G
3163T
3163VWG
3163HBV
3163LG
3163LGB16
3163LGHBV
3163LGHHB
3163LGR
3163LGH26R

3163SERIESPARTSLIST - PAGE2
FRONT VIEW - 3163 SERIES

3163SERIES PARTSLIST - PAGE3
FRONT VIEW - 3163 SERIES
CONTINUEDONPAGE4
NO. PART # DESCRIPTION
3163G 3163T 3163VWG 3163HBV 3163LG 3163LGB16 3163LGHBV 3163LGHHB 3163LGR 3163LGH26R
1 617989 BURNERTUBE XXXXXXXXXX
2 618073 FAN-12VDC XXXXXXXXXX
3 618403 BRACKET-FANSUPPORT/FRONT XXXXXXXXXX
4 618404 BRACKET-FANSUPPORT/BACK XXXXXXXXXX
5 618093 THERMOSTAT-DCFAN/THERMODISC XXXXXXXXXX
6 618021 CONTROLPANELASSY XXXXXXXXXX
7 618083 WIRE-DIFFUSER/FORMED XXXXXXXXXX
8 617960 BAFFLE-FLUE/SPIRAL XXXXXXXXXX
9 61745422 HEATER-DC/EG3(COOLINGSERIAL#11200050&BEFORE) XXXXXXXXXX
630806 HEATER-DC/EG3/BACKER (COOLING SERIAL# 11200051 & AFTER) X X X X X X
10 61745322 HEATER-AC(COOLINGSERIAL#11200050&BEFORE) XXXXXXXXXX
630805 HEATER-AC/BACKER(COOLING SERIAL# 11200051 & AFTER) X X X X X X
11 617998 CONTROLASSY-3163 XXXXXXXXXX
12 61583322 FUSECOVER XXXXXXXXXX
13 618079 FUSE-GLASS/1AMP XXXXXXXXXX
14 61440522 FUSE-GLASS/20AMP XXXXXXXXXX
15 61654622 FUSE-GLASS/3AMP/32VORLESS XXXXXXXXXX
16 61584222 FUSEHOLDER XXXXXXXXXX
17 617918 CORD-ACPOWER XXXXXXXXXX
18 617979 TERMINALBLOCK XXXXXXXXXX
19 619868 RELIGHTER XXXXXXXXXX
20 617971 KNOB-GASVALVE/THERMOSTAT XXXXXXXXXX
21 617947 MOUNTINGANGLE-RIGHT XXXXXXXXXX
22 61728722 CLIP-FIN XXXXXXXXXX
23 617948 FINASSY-3163 XXXXXXXXXX
24 617977 GASKET-BURNER BOX COVER X XXXXXXXXX
25 617936 BURNERASSY(USE621951) XXXXXXXXXX
26 618067 HEATSHIELD XXXXXXXXXX
27 617908 BRACKET-BOTTOMSUPPORT(USE622097) XXXXXXXXXX
28 617938 GRILLE-AIRINLET/BLACK XXXXXXXXXX
29 618063 SHELF-WIRE XXXXXXXXXX
30 618047 CHAIN-TRAVELLATCH XXXXXXXXXX
31 618046 PIN-TRAVELLATCH XXXXXXXXXX
32 617910 HINGE-RHBOTTOM/LHTOP XXXXXXXXXX
33 617912 BREAKER-BLACKTRIM XXXXXXXXXX
34 617911 HINGE-LHBOTTOM/RHTOP XXXXXXXXXX
35 61550722 HINGEPIN-BOTTOM XXXXXXXXXX

3163SERIES PARTSLIST - PAGE4
FRONT VIEW - 3163 SERIES CONTINUED FROM PAGE 5
NO. PART # DESCRIPTION
3163G 3163T 3163VWG 3163HBV 3163LG 3163LGB16 3163LGHBV 3163LGHHB 3163LGR 3163LGH26R
36 617915 DOOR ASSY-GRAY (USE620297/3163LG) X
617914 DOOR ASSY-TAUPE(USE620297/3163LG) X
620342 DOOR ASSY-VWG (USE620297/3163LG) X X
618678 DOOR ASSY-VWG/DARK GRAY (USE620297/3163LG) X X
620297 DOORASSY-LG XXXXXX
37 617999 DOOR LINER ASSY-GRAY (USE 620297/3163LG) X
618000 DOOR LINER ASSY-TAUPE (USE620297/3163LG) X
618679 DOOR LINER ASSY-VWG/DARK (USE 620297/3163LG) X X
620341 DOOR LINER ASSY-VWG/DARK GRAY (USE620297/3163LG) X X
620296 DOOR LINER ASSY-LIGHT GRAY X XXXXX
38 618064 DOORRAIL-WHITE XXXXXXXXXX
39 617906 DOORGASKET XXXXXXXXXX
40 61742022 HINGEBUSHING XXXXXXXXXX
41 61114600 HINGEPIN-TOP XXXXXXXXXX
42 617905 SYSTEM COVER (USE 620299/3163LG) X
617904 SYSTEM COVER (USE 620299/3163LG) X
618676 SYSTEM COVER (USE 620299/3163LG) X X
620343 SYSTEM COVER (USE 620299/3163LG) X X
620299 SYSTEM COVER-3163LG/LH X X X X
625113 SYSTEM COVER-3163LG/RH XX
43 617909 BRACKET-MOUNTING/LEFTFRONT/LSHAPED XXXXXXXXXX
44 617946 MOUNTINGANGLE-LEFT XXXXXXXX

3163SERIES PARTSLIST - PAGE5
CONTROL PANEL ASSEMBLY - 3163 SERIES
NO. PART # DESCRIPTION
3163G 3163T 3163VWG 3163HBV 3163LG 3163LGB16 3163LGHBV 3163LGHHB 3163LGR 3163LGH26R
618021 CONTROLPANELASSY-3163 XXXXXXXXXX
1 621328 CONTROLPANEL XXXXXXXXXX
2 617945 SWITCH-PUSHBUTTON XXXXXXXXXX
3 61609022 INDICATORLIGHT-FLAME XXXXXXXXXX
4 617981 HOLEPLUG-1"BLACK/CONTROLPANEL XXXXXXXXXX
NS 620623 NAMEPLATE-BLUE(NOTSHOWN) XXXXXX

3163SERIES PARTSLIST - PAGE6
CONTROL ASSEMBLY - 3163 SERIES
NO. PART # DESCRIPTION
3163G 3163T 3163VWG 3163HBV 3163LG 3163LGB16 3163LGHBV 3163LGHHB 3163LGR 3163LGH26R
1 61445322 PLUG-FORPRESSURETAP/1/8" XXXXXXXXXX
2 61594422 PRESSURETAP XXXXXXXXXX
3 622746001 KIT-SAFETYVALVE/EXTENSIONPLUG XXXXXXXXXX
4 621737 INTERRUPTER XXXXXXXXXX
5 617976 MANUALSHUTOFFVALVEASSY XXXXXXXXXX
6 61749822 BRACKET-MANUALSHUTOFFVALVE XXXXXXXXXX
7 617952 BRACKET-MOUNTING/THERMOSTAT/GASVALVE XXXXXXXXXX
8 61694622 UNIONTUBE XXXXXXXXXX
9 61546822 CONNECTOR-MALE XXXXXXXXXX
10 617944 GASVALVE-THERMOSTATCONTROL XXXXXXXXXX

3163SERIES PARTSLIST - PAGE7
BURNER AREA - 3163 SERIES
NO. PART # DESCRIPTION
3163G 3163T 3163VWG 3163HBV 3163LG 3163LGB16 3163LGHBV 3163LGHHB 3163LGR 3163LGH26R
1 617995 SIGHTGLASS-3163 XXXXXXXXXX
2 617933 GROMMET-SIGHTGLASS/3163 XXXXXXXXXX
3 617927 BRACKET-BURNER MOUNTING X XXXXXXXXX
4 621951 KIT-BURNER/ORIFICEADAPTERASSY XXXXXXXXXX
5 617997 GROMMET-THERMOCOUPLE XXXXXXXXXX
6 617983 THERMOCOUPLE XXXXXXXXXX
7 617966 ELECTRODE-SPARK/3163 XXXXXXXXXX
8 617996 GROMMET-BURNER/3163 XXXXXXXXXX
9 617925 BURNER BOX X X X X
620414 BURNER BOX ASSY-B16 X
618956 BURNER BOX ASSY-HBV X X
618977 BURNER BOX ASSY-HHB X
625149 BURNER BOX ASSY-3163LGH26R/26" X
10 617977 GASKET-BURNER BOX X XXXXXXXXX
