Norcold DC0788B Installation instructions

120/220/240 VOLTS AC and 12/24 VOLTS
DC DUAL VOLTAGE REFRIGERATORS
INSTALLATION AND OWNER’S
MANUAL
12/24 VDC only 120 VAC and 220/240 VAC and
12/24 VDC 12/24 VDC
DC0788B DE0788B EV0788B
DC0788S DE0788S EV0788S
DCF788B DEF788B EVF788B
DCF788S DEF788S EVF788S
DCR788B DER788B EVR788B
DCR788S DER788S EVR788S
Service Information
If service or parts are required, contact the nearest Norcold Service Center. To
nd an authorized Norcold Service Center near you, please telephone the Norcold
Customer Support Dept. at 800-543-1219 (option-1) or visit our web site at www.
norcold.com.
Norcold Customer Support Dept.
Telephone : [phone]
Fax : [phone]
Web Site: www.norcold.com
Serial No.
09/16/2015
Part No. 632329D
#5490 176 5300

2
NORCOLD AC/DC Models - Two Year Limited Warranty
Norcold, Inc. warrants for a period of two (2) years from the date of purchase that
Norcold, Inc. will repair or replace its AC/DC refrigerators.
Limitations of Warranty
1. This warranty is the only warranty for Norcold AC/DC refrigerators. This warranty
does not cover glassware, electric light bulbs or replaceable fuses.
2. This warranty does not apply to refrigerators or component parts that have been
subjected to misuse, improper installation, abnormal service, transit damage,
recharging of cooling unit system, accident, re, improper repair, tampering or
abuse.
3. The duration of any implied warranty is limited to two (2) years.
4. Some states do not allow limitations on how long an implied warranty lasts, so the
above limitation may not apply to you.
Limitations of Remedy
1. The responsibility of Norcold under this or any warranty is limited to the repair or
replacement (at Norcold’s option) of any defective refrigerator or component part.
2. In no event and under no circumstances shall Norcold be responsible for
any other charge whatsoever, including but not limited to charges or claims
for labor, lost business, lost time, lost prots, loss of use, or any kind of
incidental or consequential damages, however denominated or described.
3. Some states do not allow for the exclusion or limitation of incidental or
consequential damages, so the above exclusion may not apply to you.
To obtain warranty service, contact Norcold Customer Service at [phone] or
visit our website at www.norcold.com.
Legal Rights
This warranty gives you specic legal rights, and you may have other legal rights which
vary from state to state.
Safety Awareness
Read this manual carefully and understand the contents before
you install the refrigerator.

3
Be aware of possible safety hazards when you see the safety
alert symbol on the refrigerator and in this manual. A signal word
follows the safety alert symbol and identies the danger of the
hazard. Carefully read the descriptions of these signal words to
fully know their meanings. They are for your safety.
This signal word means a hazard, which if ignored, can cause
dangerous personal injury, death, or much property damage.
This signal word means a hazard, which if ignored, can cause
small personal injury or much property damage.
Model No. and Serial No.
The model and serial number are on a label which is inside the refrigerator on the
left side and on the cover of this manual.
Operation
This refrigerator is made for refrigerating purposes and operates on 120/220/240
VAC or 12/24 VDC power when installed as written in this manual. The correct
supply voltage(s) is located on the serial plate.
AC is the primary power source. When an AC source is not available, a built-in relay
automatically switches the refrigerator operation to the DC power source. If the
refrigerator is operating on the DC power source and AC power becomes available,
the relay switches the refrigerator operation to the AC power source.
Never store combustible materials near the refrigerator.
Storing combustible materials near the refrigerator creates a
safety hazard and also decreases the ventilation of the cooling
system which decreases the refrigerator performance.
Do not store explosive substance such as aerosol cans with
ammable propellant in this appliance.
WARNING
!
CAUTION
!
CAUTION
!

4
WARNING
!
Do not touch the evaporator or other metal parts inside the
refrigerator cabinet with wet hands because they can freeze to
the refrigerator.
Always disconnect all power sources from the refrigerator
when doing routine maintenance. Have service work done only
by a qualied service technician.
This refrigerator can be used by children aged 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of
the refrigerator in a safe way and understands the hazards
involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be done by children
without supervision.
Avoid using ammable sprays near the refrigerator. The
electric contacts may catch re.
When there is a leak of utility gas around you, do not touch the
refrigerator or its cable plug. Open the windows and maintain
good ventalation. Failing to do so may lead to a re and or a
burn from the explosion.
Do not use the refrigerator if its power cable is damaged or
the catch of its plug is loose. Failing to comply may lead to an
electric shock, short or re.

5
Check if the voltage noted on the type plate on the refrigerator
matches the one applied by an external power source.
The refrigerator temperature is controlled by a thermostat, located in the
refrigerator. A light, located on the panel comes on when the refrigerator is “ON”.
Number “1” is the warmest and number “5” is the coldest thermostat position. For
efcient operation, change the thermostat according to the types of food stored and
the ambient temperature.
If you are not going to use the refrigerator for an extended period of time, put the thermostat
to the “OFF” position (full counterclockwise position).
Protection System
Your refrigerator has an over current protection system in the electronic circuit to
prevent damage to the inverter which may occur due to a reverse polarity connection.
If the refrigerator does not operate and the interior light does not come on, check
the fuse, which is located on the side of the inverter case, and the polarity of the DC
power supply. If the refrigerator still does not operate, another problem can exist in the
inverter. Have an authorized Norcold Service Center check the refrigerator.
Cleaning and Defrosting
Defrosting
It is normal for frost to collect on the freezer plate inside the refrigerator. Excess frost
decreases the cooling performance of the refrigerator. Defrost the refrigerator as
necessary.
Do not use sharp objects, a hair dryer, a heat gun, etc.
to defrost the refrigerator. Damage to the interior of the
refrigerator can occur.
- Turn the thermostat to “OFF”.
- Remove all food from the refrigerator.
Defrosting the refrigerator makes excess water inside the refrigerator.
- Put dry towels (etc.) inside the refrigerator to absorb the excess water.
- Put trays of hot water in the freezer until the frost is melted.
- Empty the drip tray.
- Remove the wet towels (etc.) and dry the inside of the refrigerator
NOTICE
CAUTION
!
NOTICE

6
- Put dry towels (etc.) inside the refrigerator to absorb the excess water.
- Put trays of hot water in the freezer until the frost is melted.
- Empty the drip tray.
- Remove the wet towels (etc.) and dry the inside of the refrigerator
Cleaning
- Turn the thermostat to the desired setting.
- Put the drip tray and all food in the refrigerator.
A good time to clean the refrigerator is just after you defrost it.
Clean the inside of the refrigerator as often as necessary to avoid food odors:- Remove
all food from the refrigerator.
Do not use abrasive cleaners, chemicals, or scouring pads because
they can damage the inside of the refrigerator.
- Wash the inside of the refrigerator and the door gasket with a solution of liquid dish
detergent and warm water.
- Rinse with clean water and dry.
- After cleaning, put a thin coating of petroleum jelly on the hinge side of the gasket to
keep it soft and to prevent it from rolling.
Battery Maintenance
Over cooling drains your battery
When the ambient temperature is between 70° and 90° F, keep the thermostat at the “3“
position to avoid an excessive drain of the battery. When making ice, or storing frozen
foods, turn the thermostat to the coldest setting “5“.
Maintain the battery
If the charge of your battery is not sufcient, the cooling performance of your refrigerator
decreases.
Only use a “quick charger” on the battery if the thermostat is
turned to “OFF”.
NOTICE
CAUTION
!

7
Check the Battery charge Level
A fully charged battery will have a specic gravity reading of between 1.260 and 1.280.
The battery voltage is best indicated when the refrigerator is “ON” and the battery
charging system is “OFF”. Charge the battery when the specic gravity reading is less
than 1.200.
For your reference
The wiring diagram shown below is recommended for dual battery hookup (See
Art01516).
*Recommended source:
Sure Power Industries, Inc.
1-800-845-6269
www.Surepower.com

WARNING
!
Disposal
To prevent the risk of child entrapment, before you discard
your old refrigerator:
- Remove the doors from the refrigerator.
- Let the shelves stay in position so that a child may not easily climb inside the
refrigerator.
- This refrigerator is marked with this symbol. It means that used electrical and
electronic refrigerators should not be mixed with general household waste.
If you wish to dispose this refrigerator, contact your local authoriteis
and ask for the correct method of disposal, or specialist dealer for
details about how to do this in accordance with the applicable disposal
regulations.
- Cyclopentane is used in the insulation. The gases in the insulation material require
a special disposal procedure. Please contact your local authorities in regard to the
environmentally safe disposal of the refrigerator.
Installation
The refrigerator must be located and secured on a solid surface in the vehicle or
watercraft.
Before installing the refrigerator into the opening, make sure the DC supply is
properly connected.
Measure the opening to determine if you have proper clearance for installation.
Additional insulation space around the refrigerator is not necessary.
Be sure the refrigerator is not in direct sunlight or near a gas stove, a heater, or other
heat-generating appliances. Avoid installing your refrigerator close to warm water lines
or warm air ducts.
Your refrigerator was thoroughly cleaned before shipment from the factory. It is
advisable, however, to clean the interior once more before using. Wipe the interior with
a cloth and warm water. Then wipe with a dry cloth.

9
Ventilation
Sufcient ventilation (airow) over the rear mounted condenser of the refrigerator
is necessary for the refrigerator to operate correctly. Use any of the following
combinations of vent openings: A-D, A-I, A-J, B-C, B-F, B-H, C-D, C-I, C-J, D-F, D-H,
F-I, F-J, G-I, G-J, H-I, H-J (See Art01129 - for 0788 models only).
For the minimum required ventilation, each individual vent opening should be no less
than 50 square inches. However, the vent openings should be larger, to allow as much
ventilation as possible. The more air that circulates over the refrigerator condenser, the
more efciently the refrigerator will operate.
A
B
C
D
E
F
G
H
I
J
Art01129

10
Do not remove the bottom
rails from the refrigerator
cabinet. The rails supply
space under the refrigerator
that is necessary for correct
ventilation.
If you do not make sure that
the ventilation is correct, a
shortened refrigerator life
expectancy, poor refrigeration,
continuous operation,
accelerated battery discharge
and a void warranty will result.
If the refrigerator is installed in an unvented enclosure,
separate the intake air and the exhaust air by a bafe.
You may construct a foam bafe from 0.5 inch foam
(See Art01982 - for R788 and F788 models only).
Installation Options
Install a decorative door panel
The decorative door panel must be 4
mm or less in thickness.
1. Remove the door from the refrigerator by removing the two (2) bolts that attach the
door hinge to the top of the refrigerator (See Art01983).
Door hinge Bolts
Art01983
Art01982
foam baffle
0.5 inch max.
0.5 inch min.
Panel retainer
Art01985
Door panel
CAUTION
!
NOTICE
