Norcold DE-0061 User manual

PART NO.624380
NORCOLD 03/28/2007
EV0061
DE0061T
DV0061 SERIES
DE0061
PARTS LIST

DV0061 SERIES PARTS LIST - PAGE 2
DOOR - UPPER (FREEZER) - DV0061 SERIES
NO. PART # DESCRIPTION DE0061 DE0061T EV0061
1 621560 DOORLINERASSY-FOAMED/UPPER X X X
2 618510 HINGE-DOOR SIDE/TOP LH/BTM RH/BLACK X X X
3 621519 PANEL RETAINER-BLACK/UPPER DOOR/HINGESIDE X X X
4 618511 HINGE-DOOR SIDE/TOP RH/BTM LH/BLACK X X X
5 618619 BIN-DOOR SHELF/SMALL/WHITE X X X
6 621520 DOOR HANDLE ASSY-VERTICAL X X X
7 621518 PANEL RETAINER-BLACK/UPPERDOOR/HANDLESIDE X X X
8 618160 CAP-HINGEPLUG/BLACK X X X
NS 619569 BOLT-CAP SHOULDER/TORX HEAD X X X
NS = NOT SHOWN

DV0061 SERIES PARTS LIST - PAGE 3
DOOR - LOWER (FRESH FOOD) - DV0061 SERIES
NO. PART # DESCRIPTION DE0061 DE0061T EV0061
1 621559 DOOR LINER ASSY-FOAMED/LOWER X X X
2 618510 HINGE-DOOR SIDE/TOP LH/BTM RH/BLACK X X X
3 621548 PANEL RETAINER-BLACK/LOWER DOOR/HINGESIDE X X X
4 618511 HINGE-DOOR SIDE/TOP RH/BTM LH/BLACK X X X
5 623696 BIN-DOOR-LARGE WHITE X X X
6 618619 BIN-DOOR SHELF/SMALL/WHITE X X X
7 621547 PANEL RETAINER-BLACK/LOWER DOOR/HANDLE SIDE X X X
8 621520 DOOR HANDLE ASSY-VERTICAL X X X
9 618160 CAP-HINGEPLUG/BLACK X X X
NS 619569 BOLT-CAP SHOULDER/TORX HEAD X X X
NS = NOT SHOWN

DV0061 SERIES PARTS LIST - PAGE 4
CABINET ASSEMBLY - FRONT VIEW - DV0061

DV0061 SERIES PARTS LIST - PAGE 5
CABINET ASSEMBLY - FRONT VIEW - DV0061
NO. PART # DESCRIPTION DE0061 DE0061T EV0061
1 169000600 POWER SUPPLY-AC (SP-298B) X X
169000610 POWERSUPPLY-AC (SP-298A) X
2 621634 GRILL-TOP/VENTILATION X X X
3 163011300 POWER SUPPLY-DC/SP-297 X X
163011310 POWERSUPPLY-DC/SP-296 X
4 FUSE-BLADE/15 AMP/DC POWER SUPPLY (AUTOMOTIVE SUPPLY) X X X
5 160220100 KNOB-THERMOSTAT X X X
6 623128 TRIM PIECE-SIDE/RH X X X
7 619336 HINGE-CABINET/3 POINT/TOP LH/BTM RH/PANEL/BLACK X X X
8 618144 HINGEBUSHING-DOOR HINGE/BLACK X X X
9 618145 HINGEPIN-DOOR/PANEL DOORS/BLACK X X X
10 61630422 ICECUBETRAY-PLASTIC X X X
11 621557 STRIKEPLATE-BLACK X X X
12 621534 DRIP TRAY-INSIDE/EVAPORATOR X X X
13 621580 SHELF-WIRE/FULL X X X
14 623135 SHELF-WIRE/WITH CUTOUT X X X
NS 623121 CLAMP-SHELF RETAINING LOOP 3/8" X X X
15 617756 TRAY-SHELF/WHITE/CUT OUT X X X
16 621691 CRISPER COVER-GLASS SHELF X X X
NS 61580322 RETAINER-GLASS SHELF (NOT SHOWN) X X X
17 621692 CRISPER-DV0061 SERIES X X X
18 621573 GRILL ASSY-BOTTOM X X X
19 619335 HINGE-CABINET/3 POINT/TOP RH/BTM LH/PANEL/BLACK X X X
20 623133 CHANNEL-BOTTOM RAIL X X X
21 621697 COVER-STRIKEPLATE/BLACK X X X
22 621621 HINGECAP-CENTERPOST/BLACK X X X
23 621563 HINGE-CENTER X X X
24 621620 HINGE CENTERPOST-STUD/CENTER HINGE X X X
25 623129 TRIM PIECE-SIDE/LH X X X
26 621625 DIVIDER ASSY-FOAMED X X X
NS 61629722 LAMP BRACKET ASSY X X X
NS 61628922 LAMP-GE#214-2/DC LIGHT BULB X X X
NS 621827 COVER-LAMP BRACKET X X X
NS 623119 SWITCH-CABINET LIGHT X X X
27 160929310 FANONLY-50 CYCLE/LARGE X X X
28 169000700 CIRCUIT BOARD-LIGHT CONTROL X X X
29 161013500 COOLING UNIT-DE0061/EV0061 X X X
NS = NOT SHOWN

DV0061 SERIES PARTS LIST - PAGE 6
CABINET ASSEMBLY - REAR VIEW - COOLING UNIT AREA - DV0061 SERIES

DV0061 SERIES PARTS LIST - PAGE 7
CABINET ASSEMBLY - REAR VIEW - COOLING UNIT AREA - DV0061 SERIES
NO. PART # DESCRIPTION DE0061 DE0061T EV0061
1 169000600 POWERSUPPLY-AC (SP-298B) X X
169000610 POWERSUPPLY-AC (SP-298A) X
2 163011300 POWER SUPPLY-DC/SP-297 X X
163011310 POWER SUPPLY-DC/SP-296 X
3 FUSE-BLADE/15 AMP/DC POWER SUPPLY (AUTOMOTIVE SUPPLY) X X X
4 169000700 CIRCUIT BOARD-LIGHT CONTROL X X X
5 621634 GRILL-TOP/VENTILATION X X X
6 623133 CHANNEL-BOTTOM RAIL X X X
7 320101300 HOLDER-CONDENSER X X X
8 322249400 HOLDER-CONDENSER/UPPER X X X
9 160929310 FANONLY-50 CYCLE/LARGE X X X
10 161013500 COOLING UNIT-DE0061/EV0061 X X
11 621529 FOAM PLUG PANEL ASSY-EVAPORATOR ACCESS X X X
12 621570 GASKET-EVAPORATORPLUG X X X
NS 192116604 CORD WITH TERMINAL-GROUND CORD X X X
NS 190264700 COUPLER ASSY-COOLING UNIT TO EXTENSION X X X
NS 605505440 THERMISTER-EVAPORATOR X X X
NS 190282010 COUPLER ASSY-DC INPUT CORD X X X
NS FUSE-GLASS/15 AMP/DC CORD (AUTOMOTIVE SUPPLY) X X X
NS 601064730 COUPLER ASSY-DC POWER SUPPLY TO CORD/COOLING UNIT X X X
NS 601064800 COUPLER ASSY-DC POWER SUPPLY TO FAN X X X
NS 601064600 COUPLER ASSY-DC POWER SUPPLY TO THERMISTER X X X
NS - NOT SHOWN
