Norcold N300 Installation instructions

WARNING: Improper installation, adjustment, alteration, service or maintenance
can cause personal injury or property damage. Refer to this manual.
For assistance or additional information, contact a qualified installer,
service agency, or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors and liquid in the
vicinity of this or any other appliance.
FOR YOUR SAFETY
If you smell gas:
1. Open windows.
2. Don’t touch electrical switches.
3. Extinguish any open flame.
4. Immediately call your gas supplier.
Installation and Owner’s Manual
For model N300X - a 2.7 cu. ft., 2-way or 3-way, refrigerator.
The models numbers of 3-way refrigerators contain “.3”. The model numbers of 2-way
refrigerators do not.
The letter “X” in the model number above, stands for a letter or a numeral which means a
refrigerator option.
NORCOLD, Inc.
P.O. Box 4248
Sidney, OH 45365-4248
Part No. 620840N(5-07)
English
French
Norcold Customer Support Dept.
Telephone: [phone]
Fax: [phone]
Web Site: www.norcold.com
WARNING: DO NOT install this refrigerator in below deck
marine applications. Do not install this refrigerator in fixed
indoor cabin or other dwelling applications. This refrigerator
must use only NORCOLD designed and approved outside air
intake and exhaust ventilation for correct and safe operation.
Any other ventilation could cause lethal combustion exhaust
fumes and/or explosive propane gas fumes to be in the living
area and/or to be below deck.

Installation and Owner’s Manual 2
Table of Contents
Owner’s Manual ........................................................................ 2
Gas Absorption 3 Year Limited Warranty Policy.................. 2
Gas Absorption Warranty Information ................................. 3
Gas Absorption Warranty Questions .................................. 3
Safety Awareness................................................................ 4
Safety Instuctions ................................................................ 4
About Your Refrigerator ....................................................... 4
Storage volume ............................................................ 4
Leveling........................................................................ 4
Food compartment ...................................................... 4
Freezer compartment................................................... 5
Operation during travel ................................................ 5
Door latch for travel and storage ................................. 5
Ignition and Start Up............................................................ 5
Controls........................................................................ 5
Ignition - propane gas operation ................................. 5
Do a test of the gas safety valve .................................. 6
Start up -AC operation ................................................. 5
Start up - DC operation (3-way models only)............... 6
DC operation precautions ........................................... 6
DC operation guidelines ............................................. 6
Shut down .................................................................... 6
Effects of High Altitude on Propane Gas Operation............ 6
Refrigerator Care Checklist ................................................ 6
Defrosting............................................................................ 7
Cleaning.............................................................................. 7
Drip tray ........................................................................ 7
Door Sealing ....................................................................... 7
Refrigerator Maintenance Checklist ................................... 8
Refrigerator Maintrenance .................................................. 8
Gas flame appearance ................................................ 8
Remove and clean the burner orifice .......................... 8
Remove the Refrigerator..................................................... 9
Reinstall the Refrigerator.................................................... 9
Wiring Pictorial .................................................................. 10
Wiring Diagram ................................................................. 10
Replacement Parts ........................................................... 10
Installation Manual ...................................................................11
Safety Awareness...............................................................11
Safety Instructions..............................................................11
Certification and Code Requirements...............................11
Ventilation Requirements ................................................. 12
Assemble the Enclosure .................................................. 12
Install the Lower and Upper Vents.................................... 12
Install the Refrigerator....................................................... 14
Installation Options ........................................................... 14
Install the decorative door panel ............................... 14
Reverse the door swing............................................. 14
Connect the Electrical Components................................. 15
Connect the 120 volts AC supply ............................... 15
Connect the 12 volts DC supply (3-way models only)15
Connect the Propane Gas Components.......................... 16
Connect the gas supply system ................................ 16
Examine the gas supply system for leaks ................ 16
Norcold • P.O. Box 4248 • Sidney, OH • USA • 45365-4248
Provided it is properly installed, properly maintained and placed
under normal service and use, Norcold, Inc. warrants its
refrigeration equipment to be free from defects in material and
workmanship for three years with respect to the equipment’s
component parts, and for two years with respect to the labor to
repair or replace such parts, commencing from the original date
of purchase.
Limitations of warranty
1. This Warranty applies only to Norcold gas absorption
refrigerator operating equipment. This Warranty does not
extend to glassware, electric light bulbs, and replaceable
fuses.
2. This warranty does not apply to parts and assemblies that
have been subjected to misuse, improper installation,
improper or abnormal service, transit damage, recharging of
the cooling system, accident, fire, improper repair, tampering
or abuse.
3. Irrespective of the nature of the warranty protection offered or
claimed, the period of warranty shall in no case extend
beyond three years for component parts and two years for the
labor to repair or replace such parts, commencing from the
original date of purchase of the new equipment.
4. In order to obtain the remedy of repair and replacement, the
refrigerator must be brought to any Norcold Service Center for
warranty service. The end consumer is responsible for all
expenses resulting from any remote service call if the
refrigerator cannot be brought into the Norcold service center.
5. It is the responsibility of the end consumer to have mainte-
nance performed upon the warranted equipment one time
during the second year or before the beginning of the third
year after original purchase. Such maintenance is required to
maintain this warranty in effect and failure to perform such
maintenance will void the remainder of the warranty. Re-
quired maintenance during the second year or before the
third year after purchase is cleaning and checking of the
following: Burner, Flue, Spiral Baffle, Roof Cap Screen, and
Control Board Sequence.
LIMITATION OF REMEDY
1. THERESPONSIBILITYOFNORCOLDUNDERTHISORANY
WARRANTYISLIMITEDTOTHEREPAIRORREPLACEMENT
(ATNORCOLD’SOPTION)OFTHEDEFECTIVEPART OR
ASSEMBLY.
NORCOLD - GasAbsorption 3 Year Limited
Warranty Policy

Installation and Owner’s Manual 3
GasAbsorption Warranty Information
2. INNOEVENTANDUNDERNOCIRCUMSTANCESSHALL
NORCOLDBERESPONSIBLEUNDERTHISLIMITEDWAR-
RANTYFORANYOTHERCHARGEWHATSOEVER,INCLUDING
BUTNOTLIMITEDTOCHARGESORCLAIMSFORLABOR,
LOSTBUSINESS, LOST TIME,LOSTPROFITS, LOSS OFUSE,
ORANYKINDOFINCIDENTALORCONSEQUENTIALDAM-
AGES,HOWEVERDENOMINATED ORDESCRIBED. THE
REMEDYUNDER THIS WARRANTYISLIMITEDTOREPLACE-
MENTORREPAIR.
3. SOMESTATES DO NOTALLOW THE EXCLUSIONOR
LIMITATIONOFINCIDENTALORCONSEQUENTIALDAMAGES,
SOTHEABOVE EXCLUSIONMAYNOTAPPLYTOYOU.
DISCLAIMEROFOTHER WARRANTIES
THISWARRANTYISEXPRESSLYINLIEUOFALLOTHER
WARRANTIES EITHEREXPRESSEDORIMPLIED. ALLOTHER
WARRANTIES,EXPRESSEDORIMPLIED,INCLUDINGANY
WARRANTYOFMERCHANTABILITYORFITNESSFORAPAR-
TICULARPURPOSE,AREHEREBYDISCLAIMEDANDEX-
CLUDED.
Legal rights
This warranty gives you specific legal rights, and you may have
other legal rights, which vary from state to state.
Your refrigerator is made to provide the ultimate in cooling
satisfaction and will serve you reliably in the years to come.
Norcold refrigerators are the only RV refrigerators made in the
United States and offer a standard limited three-year warranty.
Norcold also offers an additional warranty coverage plan which
extends the standard limited three-year warranty. To activate
your three-year limited warranty and to receive an invitation to
participate in the extended warranty plan, complete and mail the
warranty registration supplied.
Help us to help you.
Write the model number and serial number below for future
reference. These numbers are on the serial plate in the
refrigerator. The serial plate is located in the fresh food
compartment on the top right hand side. Use these numbers
when receiving service or in any correspondence concerning
your refrigerator.
Model number ___________ Serial number ___________
If a problem occurs with your refrigerator, contact any of the
service centers throughout the United States and Canada. To
find an authorized Norcold Service Center near you, please
telephone the Norcold Customer Support Dept. at 800-543-
1219 (option-1) or visit our web site at www.norcold.com.
Norcold is committed to providing products that are in harmony
with the environment. Your Norcold refrigerator meets all
environmental safety standards.
GasAbsorption Warranty Questions
About your warranty
Thiswarranty coverage begins on the original dateof purchase by the
consumerpurchaser and is the only warranty for the Norcold refrigera-
tor. In no case will the Limited Warranty extend beyond two (2) years
for labor and three (3) years for parts and freight. Norcold reserves
theright to change design or specifications of a refrigerator without
obligationto modify previouslyproduced refrigerators. Thereare no
otherwarranties, either expressed or implied.
What is coverd by this warranty?
- Defectsin material andworkmanship.
- Parts and labor for two (2) years
- Partsonly forthe thirdyear if therequired maintenance is performed.
- Freight(ground service only) for shipment ofa replacement part
and for return of the defective part.
What is not covered by this warranty?
- Shippingmethods other thanground service.
- Defectsin glassware,electric light bulbs, and replacement fuses.
- Adjustmentof theburner electrode.
- Cleaningof the burner.
- Feesfor mobilerepair service.
- Mileageor travel expenses to obtainwarranty service.
- Expensesfor requiredmaintenance asspecified inthe Limited
Warrantyandin theOwner’s Manual.
- Incidentalorconsequential loss ordamageincluding but notlimitedto
chargesor claims for labor (including labor whenno parts are used
fora repair), lost business, lost time, lostprofits, lost food, and lost
use.
- Replacementparts that arenot manufactured orsupplied by Norcold.
- Defectof a part or assembly when the defect originates from misuse,
improperinstallation,improperorabnormal service, transit damage,
rechargingof the coolingsystem, accident,fire, improper repair,
tampering,orabuse.
What will Norcold do?
Fora refrigerator thatis properly installed,maintained, andused as
specifiedin the Installation/Owner’sManuals, Norcoldresponsibilities
are:
- Limitedto the repairand replacementof parts.
- To provide no charge parts and labor for two (2) years.
- To provide no charge parts only for year 3 if the required mainte-
nanceis performed.
- To provide freight (ground service only) for shipment of a replace-
ment part and for return of a defective part for three (3) years.
What will the refrigerator owner do?
To obtain warranty service, the refrigeratorowner responsibilities are:
- To use, service, and maintain therefrigerator asspecified in the
Installation/Owner’sManuals.
- To deliver the warranted product to anauthorized NorcoldService
Center for warranty repair.
- To show proof that the refrigerator is within warranty coverage.
- To have therequired maintenance performed by anauthorized
NorcoldService Center one time duringyear 2of the Limited
Warranty.
- To pay to havethe required maintenanceperformed.
- To mail paidreceipt to Norcoldshowing requiredperformed before
expirationof year 2 of the Limited Warranty.
- To show proof of therequired maintenance before requesting
warranty service in year 3 of the Limited Warranty.
What rights do you have?
The warranty gives you specific legal rights. You may also have other
rights which vary from state to state.

Installation and Owner’s Manual 4
About Your Refrigerator
- The refrigerator cooling system is under pressure. Do
not try to repair or to recharge a defective cooling
system. The cooling system contains sodium chro-
mate. The breathing of certain chromium compounds
can cause cancer. The cooling system contents can
cause severe skin and eye burns, and can ignite and
burn with an intense flame. Do not bend, drop, weld,
move, drill. puncture, or hit the cooling system.
- At regular intervals, make sure that the refrigerator flue
the burner, the vent areas, and the ventilation air
pathway between the vents are completely free from
any flammable material or blockage. After a period of
storage, it is especially important to check these areas
for any flammable material or blockage caused by
animals.
CAUTION:
- The rear of the refrigerator has sharp edges and
corners. To prevent cuts or abrasions when working
on the refrigerator, be careful and wear cut resistant
gloves.
Storage Volume:
This refrigerator is made to store fresh and frozen foods and for
making ice.
Total capacity...................................................... 2.7 cubic feet
Freezer capacity ................................................... .4 cubic feet
Food compartment capacity ..............................2.3 cubic feet
Leveling:
CAUTION: The refrigerator is made to operate within 3°
off level side-to-side and 6° off level front-to-back (as
looking at the front of the refrigerator). Operating it at
more than these limits can cause damage to the cooling
system and create a risk of personal injury or property
damage. Make sure the vehicle is level before you
operate the refrigerator.
Operation during travel:
While the refrigerator should be level when the vehicle is
stopped, performance during travel is not usually effected.
Food compartment:
Ignite or start up the refrigerator and let it cool for eight hours
before loading with food. If the refrigerator does not start to cool
down after about two hours, contact your dealer or a Norcold
authorized service center.
WARNING:
- The storage of flammable materials behind or around
the refrigerator creates a fire hazard. Do not use the
area behind the refrigerator to store anything, espe-
cially flammable materials (gasoline, cleaning
supplies, etc.)
- Do not remove the round ground prong from the
refrigerator AC power cord. Do not use a two prong
adapter or extension cord on the AC power cord.
- A circuit overload can result in an electrical fire if the
wires and/or fuses are not the correct size. Either use
the wire and fuse sizes as writtten in the “Installation
Manual” or refer to your local codes or the applicable
RVIA Standards for the correct wire and fuse sizes.
- Incorrect installation, adjustment, change to, or
maintenance of this refrigerator can cause personal
injury, property damage, or both. Have service and
maintenance work done by your dealer or by an
Norcold authorized service center.
- Disconnect both the AC and DC power sources before
doing any maintenance work on the refrigerator. All
service work on this refrigerator must be done by a
qualified service technician.
- Do not bypass or change the refrigerator’s electrical
components or features.
- When you discard an appliance, remove all doors to
prevent accidental entrapment and suffocation.
- Do not spray liquids near electrical outlets, connec-
tions, or the refrigerator components. Many liquids are
electrically conductive and can cause a shock hazard,
electrical shorts, and in some cases fire.
Safety Instructions
Read this manual carefully and understand the contents before
you use the refrigerator.
Be aware of possible safety hazards when you see the safety
alert symbol on the refrigerator and in this manual. A signal
word follows the safety alert symbol and identifies the danger of
the hazard. Carefully read the descriptions of these signal
words to fully know their meanings. They are for your safety.
WARNING: This signal word means a hazard, which if
ignored, can cause dangerous personal injury, death, or
much property damage.
CAUTION: This signal word means a hazard, which if
ignored, can cause small personal injury or much
property damage.
Safety Awareness

Installation and Owner’s Manual 5
Controls:
Thermostat...........................................................................1
Selector switch.....................................................................2
Gas safety valve ................................................................... 3
Piezo lighter .........................................................................4
Flame meter ........................................................................5
For the best cooling performance:
- Let air move freely inside the entire food compartment.
- Do not cover the shelves with plastic, paper, etc.
To decrease the amount of ice that collects on the cooling fins:
- Cover all liquids and moist foods.
- Let all hot foods cool before putting them in the refrigerator.
- Do not open the door any longer than necessary.
Freezer compartment:
The freezer compartment is made to keep pre-frozen food
frozen and not to quick freeze food. Keep pre-frozen foods in the
freezer compartment.
NOTE: Do not put other items on the ice tray while the water is
freezing. The water freezes more rapidly if the thermo-
stat is at the coldest temperature setting.
Door latch for travel and storage:
During travel, the door latch prevents the door from opening.
There are no chains, slides, or any devices that you must
engage.
During storage, the door latch prevents the door from com-
pletely closing. Use it to prevent odors when the refrigerator is
shut down for a long period of time.
To use the door latch for storage (See Art00979):
- Open the door just so the door latch [1] is between the ribs
[2] of the latch plate [3].
Ignition and Start Up
The thermostat [1] (See Art00976) changes the amount of
propane gas that goes to the burner. This acts as the tempera-
ture control of the refrigerator. Number 5 is the coldest tem-
perature setting.
When the outside air temperature is below 50° F, the refrigera-
tor may have a tendency to freeze food at the colder temperature
settings. To reduce the tendency to freeze food:
- Turn the thermostat to a warmer temperature setting.
- Keep the refrigerator full.
- Put foods that are more likely to freeze on the lower shelf.
The selector switch [2] changes the energy source of the
refrigerator between propane gas ( ), AC electric ( ), DC
electric ( ), and OFF ( ).
The gas safety valve [3] is built into the control panel. As long as
a flame is present, the valve is open and allows propane gas to
flow into the burner. Any loss of flame (empty gas tank, blow
out, etc.) closes the safety valve and stops the flow of gas.
The piezo igniter [4] makes a spark which ignites the flame in
the burner.
The flame meter [5] shows if a flame is present in the burner.
Ignition - propane gas operation:
1. Open the valve at the gas storage tank.
2. Turn the thermostat to the 5 position.
3. Turn the selector switch to the propane gas position ( ).
4. Push and hold in the safety valve and push in the igniter
several times in rapid succession, for about five seconds:
WARNING: Do not hold in the safety valve for more than
30 seconds. If there is no flame in this time, wait at least
five minutes before you try ignition again. If you continue
to hold in the safety valve, gas will collect in the burner
area. This could cause a fire or explosion and result in
dangerous personal injury or death.
- When a flame is present and the flame meter moves into
the green area, release the safety valve.
- If the flame meter does not move into the green area, do
this step again.
5. Turn the thermostat to the temperature setting that you wish.

Installation and Owner’s Manual 6
Effects of High Altitude on Propane Gas
Operation
When you operate the refrigerator on propane gas at altitudes
higher than 5500 feet above sea level:
- You may experience reduced cooling performance of the
refrigerator.
- You may experience burner outages.
To avoid these possible problems, Norcold recommends that
you operate the refrigerator on AC when at altitudes higher than
5500 feet above sea level.
Refrigerator Care Checklist
Your refrigerator will give you years of trouble free service if you
do these simple checks every three to six months:
- Keep the food compartment and the freezer clean. See
“Cleaning”.
- Defrost the refrigerator as necessary. See “Defrosting”.
- Make sure the door seals correctly. See “Door Sealing“.
Do a test of the gas safety valve:
With an established flame in GAS mode:
1. Close the manual gas shutoff valve [2] of the refrigerator
(SeeArt01254].
2. After the flame is extinguished, you should hear a sharp
“click” sound within three minutes.
NOTE: The gas safety valve should close with a sharp “click“
sound.
3. Open the manual gas shutoff valve of the refrigerator.
4. Without pushing in the gas control, push the igniter several
times rapidly in succession. The burner flame should not
ignite. This means that the gas safety valve is working
correctly.
Start up - AC operation:
- Make sure that 120 voltsAC is available.
- Turn the selector switch to the AC position ( ).
- Turn the thermostat to the temperature setting that you
wish.
Start up - DC operation (3-way models only):
- Make sure that 12 volts DC is available.
- Turn the selector switch to the DC position ( ).
DC operation precautions:
This refrigerator is made to operate on DC power while your
vehicle is “in transit” and AC power or propane gas sources
are not available. Operate the refrigerator on DC power only
when the vehicle engine is running.
For the refrigerator to operate correctly on DC power, the battery
must be maintained in a fully charged condition.
For the battery to be fully charged at all times during refrigerator
operation on DC, the vehicle engine must be running and the
battery charging system must be in good operating condition.
Keep in mind the following electrical precautions for DC
operation of the refrigerator:
- Good battery condition is necessary for correct DC opera-
tion.
- The capacity of the battery charging system must be more
than what is necessary for the refrigerator and other DC
appliances.
- While the vehicle engine is running, have a qualified service
technician make sure the voltage of the DC power supply
leads at the refrigerator is more than 11.5 VDC.
DC operation guidelines:
DC operation is intended only to maintain the temperature of
the refrigerator and its contents when they are already cool.
The DC operation is not intended for the initial start up and
cooling of the refrigerator. Always use either the AC operation or
propane gas operation to initially start up and cool the refrigera-
tor. The refrigerator must be cooled and the temperature must
be steady before you operate the refrigerator on DC.
Keep in mind the following guidelines for DC operation of the
refrigerator:
- Use DC operation of the refrigerator while the vehicle is in
transit.
- Do not use DC operation until the refrigerator and its
contents are completely cooled.
- Only use DC operation if the vehicle battery and battery
charging system are in good operating condition.
Shut down:
- Turn the selector switch to the OFF position ( ).

Installation and Owner’s Manual 7
Defrosting
A good time to clean the refrigerator is just after you defrost it.
Clean the inside of the refrigerator as often as necessary to
avoid food odors:
Cleaning
- Be aware of any cooling changes that are not because of
weather, loading, or thermostat changes. If changes occur,
contact your dealer or service center.
- Make sure the gas supply is propane gas only and is not
butane or a butane mixture.
- Remove all food from the refrigerator.
NOTE: Do not use abrasive cleaners, chemicals, or
scouring pads because they can damage the
interior of the refrigerator.
- Wash the interior with a solution of liquid dish detergent
and warm water.
Drip tray:
To remove and clean the drip tray:
- Make sure that the drip tray is empty of water.
- Pull the drip tray forward to remove from the slots in the
refrigerator cabinet.
- Clean the drip tray.
- Push the drip tray back into the original position.
Door Sealing
If the door does not seal correctly, excess frost will collect inside
the refrigerator. Make sure the door seals correctly:
- Close the door on a piece of paper that is about the size of
a dollar bill (See Art00980).
- Gently pull the paper.
- You should feel a slight drag between the gasket and
the cabinet.
- Do this on all four sides of the door.
- If you do not feel a slight drag on the
paper, the door is not sealing correctly:
- Make sure the screws of the hinges are tight.
- Make sure the door gasket does not touch the door
latch:
- If the door gasket touches the door latch,
loosen the screws of the door latch.
- Raise the door latch just so it does not touch
and tighten the screw s of the door latch.
- Make sure the door latch holds the door closed.
The cooling fins of the refrigerator operate at below freezing
temperature and will naturally form frost from humidity, which is
always present in the air. The humidity inside the refrigerator
increases:
- with higher outside temperature and humidity.
- with the storage of non-sealed fresh foods or warm foods.
- with the amount of time that the door(s) are open.
- with any air leakage into the refrigerator.
It is normal for frost to collect inside the refrigerator. Excess
frost decreases the cooling performance of the refrigerator.
Defrost the refrigerator as necessary:
- Remove all food from the refrigerator.
- Turn the refrigerator OFF.
NOTE: Defrosting the refrigerator makes excess water inside
the refrigerator.
- Put dry towels (etc.) inside the refrigerator to absorb melted
frost.
CAUTION: High temperatures can cause the inside
surfaces of the refrigerator to warp or melt. Do not use
pans of HOT water, a hair dryer, or any other high
temperature devices to defrost the refrigerator. Do not
use any hard or sharp objects to remove frost. Damage
to the interior of the refrigerator can occur.
- To increase the speed of defrosting, put pans of WARM
water in the refrigerator.
- Remove the wet towels (etc.) and dry the interior.
- Start up the refrigerator.
- Allow the refrigerator to cool down.
- Return all food to the refrigerator.

Installation and Owner’s Manual 8
Refrigerator Maintenance
Refrigerator Storage
Before the refrigerator is stored for an extended (seasonal)
period of time:
- Defrost and clean the interior of the refrigerator.
- Close the doors with the storage latch.
If the refrigerator is stored for an extended period of time, before
start up:
- Make sure there are no obstructions in the vents, the
ventilation air pathway, the burner, the orifice, or the flue
area.
Gas flame appearance:
While in propane gas operation, examine the appearance of the
gas flame:
- Turn the thermostat to the 5 position.
- Open the lower intake vent.
CAUTION: The burner box cover can be hot. Wear
gloves to avoid burns.
- Open the burner box door [3] and look at the gas flame [1]
(See Art00955 and Art01255).
The flame should be:
- a darker blue color on the inside of the flame and
a lighter blue color on the outside of the flame.
- a constant shape without flickering.
- Contact your dealer or Norcold authorized service
center if the flame is:
- yellow
- flickering or changing shape.
- If the flame is yellow or has an erratic and unstable
shape, contact your dealer or Norcold authorized
service center.
- Make sure the flame does not touch the inside of the
flue tube [2].
- If the flame touches the inside of the flue tube, contact
your dealer or Norcold authorized service center.
- Close the burner box door.
Remove and clean the burner orifice:
NOTE: Your dealer or Norcold authorized service center must
do this procedure.
To remove and clean the burner orifice:
- Close the valve at the gas tank(s).
- Close the manual shut off valve of the refrigerator.
- Turn the selector switch to the OFF position ( ).
- Open the lower intake vent.
Read and understand the following maintenance sections of
this manual.
NOTE: Norcold is not responsible for installation, adjustment,
alteration, service, or maintenance performed by
anyone other than a qualified RV dealer or a Norcold
authorized service center.
Have a qualified RV dealer or a Norcold authorized service
center do these annual safety and maintenance checks:
- Examine the gas supply lines for leaks.
- Replace or repair if necessary.
- Make sure the propane gas pressure is 11 inches of water
column.
- Adjust if necessary.
- Make sure the combustion seal is complete and intact.
- Replace or repair it if necessary.
- Make sure the burner and the burner orifice are clean (See
Art00956).
- Clean if necessary.
- Make sure the electrode spark gap [3] is 1/8 - 3/16 inch
(See Art00955).
- Adjust if necessary.
- Make sure the AC voltage is 108 - 132 volts and the DC
voltage is 10.5 - 15.4 volts.
- Make sure the thermocouple tip is clean and secure.
- Make sure the area at the rear of the refrigerator is free of
any combustible materials, gasoline, and other flammable
vapors and liquids.
Refrigerator Maintenance Checklist

Installation and Owner’s Manual 9
Reinstall the Refrigerator
NOTE: Your dealer or Norcold authorized service center must
do this procedure.
WARNING: Make sure the combustion seal is not
broken, is completely around the refrigerator mounting
flanges, and is between the mounting flanges and the
wall of the enclosure. If the combustion seal is not
complete, exhaust fumes can be present in the living
area of the vehicle. The breathing of exhaust fumes can
cause dizziness, nausea, and in extreme cases, death.
1. Push the refrigerator completely into the enclosure.
2. Remove the door from the refrigerator.
3. Put the screws though the mounting flanges and into the
wall.
4. Put the plastic plugs into the mounting flanges of the
refrigerator.
5. Attach the door to the refrigerator
CAUTION: The rear of the refrigerator has sharp edges
and corners. To prevent cuts or abrasions when working
on the refrigerator, be careful and wear cut resistant
gloves.
Remove the Refrigerator
NOTE: Your dealer or Norcold authorized service center must
do this procedure.
CAUTION: The rear of the refrigerator has sharp edges
and corners. To prevent cuts or abrasions when working
on the refrigerator, be careful and wear cut resistant
gloves.
1. Close the valve at the gas tank(s).
WARNING: To avoid possible propane gas leaks,
always use two wrenches to loosen and tighten the gas
supply line at the refrigerator’s manual shut off valve.
2. Open the lower intake vent and remove the gas supply line
from the manual shut off valve of the refrigerator.
3. Remove the AC power cord from the receptacle.
4. Remove the DC wiring from the refrigerator:
- Remove the DC wiring from the battery or the converter of
the vehicle.
- Put a mark on the DC wires so you can put them back in the
correct location.
- Remove the DC wires from the refrigerator.
5. Remove the screws which fasten the refrigerator to the floor.
6. Remove the plastic plugs from the mounting flanges of the
refrigerator.
7. Remove the door from the refrigerator.
8. Remove the screws which fasten the refrigerator to the wall.
9. Remove the refrigerator from the opening.
10. Attach the door to the refrigerator.
CAUTION: The burner box cover can be hot. Wear
gloves to avoid burns.
- Remove the burner box cover by removing one screw.
WARNING: To avoid possible propane gas leaks,
always use two wrenches to loosen and tighten the
gas supply line at the refrigerator’s manual shut off
valve.
- Remove the flare nut from the orifice assembly [1] (See
Art00956).
- Remove the orifice assembly from the burner [2].
WARNING: Do not try to remove the orifice [3] from the
orifice adapter [4] when cleaning. Removal will
damage the orifice and seal of the orifice and can
cause a propane gas leak. Leaking propane gas can
ignite or explode which can result in dangerous
personal injury or death. Do not clean the orifice with a
pin or other objects.
- Clean the orifice assembly with air pressure and alcohol
only.
- Using a wrench, assemble the orifice assembly to the the
burner.
- Assemble the flare nut to the orifice assembly.
- Tighten the flare nut by hand.
- Hold the orifice assembly securely and, using a
wrench, tighten the flare nut 1/4 revolution only.
- Examine all of the connections for gas leaks.

Installation and Owner’s Manual 10
Replacement Parts
You may purchase replacement parts through your local RV
dealer or authorized Norcold Service Center.
Wiring Pictorial
Wiring Diagram
The parts of the wiring pictorial are (Art01020):
1 ............................................................ 120VAC Power cord
2 ..................................................................... Terminal block
3 .......................................................................... 3 Amp fuse
4 .................................................................... Selector switch
5 ......................................................................Thermocouple
6 ............................................. Thermostat / gas safety valve
7 .................................................... Thermocouple interrupter
8 ........................................................................ Flame meter
9 ............................................................................ AC heater
10 .................... -12 VDC Power supply (3-way models only)
11 ....................+12 VDC Power supply (3-way models only)
12 .....................................20 Amp fuse (3-way models only)
16 .........................................DC heater (3-way models only)
The parts of the wiring diagram are (See Art01021):
1 .............................................................................. 120 VAC
2 .......................................................................... 3 Amp fuse
3 .......................................................................... Thermostat
4 ............................................................................ AC heater
5 .............................................................................. 120 VAC
6 ..................................................................Gas safety valve
7 .................................................... Thermocouple interrupter
8 ........................................................................ Flame meter
10 ....................................................................... Piezo lighter
11 .......................................................................... Spark gap
12 .......................................... +12 VDC (3-way models only)
13 .....................................20 Amp fuse (3-way models only)
14 .........................................DC heater (3-way models only)
15 ...................................-12 VDC Com (3-way models only)
17 .................................................................. Selector switch
6. Open the lower intake vent and put the screws through
refrigerator and into the floor.
WARNING: To avoid possible propane gas leaks,
always use two wrenches to loosen and tighten the gas
supply line at the refrigerator’s manual shut off valve.
7. Attach the gas supply line to the manual shut off valve of the
refrigerator.
8. Open the valve at the gas tank(s).
WARNING: Do not allow the leak checking solution to
touch the electrical components. Many liquids are
electrically conductive and can cause a shock
hazard,electrical shorts, and in some cases fire.
9. Examine the gas supply line for leaks.
10. Connect the DC wiring to the refrigerator:
- Install the DC fuse or connect the DC wiring to the battery or
the converter.
- Connect the DC wires from the refrigerator.
11. Connect the AC power cord to the receptacle.

Installation and Owner’s Manual 11
Safety Instructions
Safety Awareness
Read this manual carefully and understand the contents before
you install the refrigerator.
Be aware of possible safety hazards when you see the safety
alert symbol on the refrigerator and in this manual. A signal
word follows the safety alert symbol and identifies the danger of
the hazard. Carefully read the descriptions of these signal
words to fully know their meanings. They are for your safety.
WARNING: This signal word means a hazard, which if
ignored, can cause dangerous personal injury, death, or
much property damage.
CAUTION: This signal word means a hazard, which if
ignored, can cause small personal injury or much
property damage.
WARNING:
- This refrigerator is not approved for use as a free
standing refrigerator. It is equipped for the use of
propane gas only and can not be changed to use any
other fuels (natural gas, butane, etc.).
- Incorrect installation, adjustment, alteration, or mainte-
nance of this refrigerator can cause personal injury,
property damage, or both.
- Obey the instructions in this manual to install the intake
and exhaust vents.
- Do not install the refrigerator directly on carpet. Put the
refrigerator on a metal or wood panel that extends the full
width and depth of the refrigerator.
- Do not allow anything to touch the refrigerator cooling
system.
- Propane gas can ignite and cause an explosion that can
result in property damage, personal injury, or death. Do
not smoke or create sparks while working on the gas
supply system. Do not use an open flame to examine
the gas supply piping or fittings for leaks. Always use two
wrenches to tighten or loosen the propane gas supply
line connections.
- Make sure the electrical installation obeys all applicable
codes. See “Certification and Code Requirements”
section.
- Do not bypass or change the refrigerator’s electrical
components or features.
- Do not spray liquids near electrical outlets, connections,
or the refrigerator components. Many liquids are
electrically conductive and can cause a shock hazard,
electrical shorts, and in some cases fire.
Installation Manual - The refrigerator cooling system is under pressure. Do
not try to repair or to recharge a defective cooling system.
- The cooling system contains sodium chromate. The
breathing of certain chromium compounds can cause
cancer. The cooling system contents can cause severe
skin and eye burns, and can ignite and burn with an
intense flame. Do not bend, drop, weld, move, drill,
puncture, or hit the cooling system.
CAUTION:
- The rear of the refrigerator has sharp edges and corners.
To prevent cuts or abrasions when working on the
refrigerator, use caution and wear cut resistant gloves.
Certification and Code Requirements
This refrigerator is certified by CSA International as meeting the
latest edition of ANSI Z21.19 / CAN 1.4 standards for installation
in mobile homes or recreational vehicles.
The installation must obey these standards and this
“Installation Manual” for the NORCOLD limited warranty to be in
effect. Installation must conform with the following as
applicable:
In the United States and Canada:
- Local codes, or in the absence of local codes, the National
Fuel Gas Code, ANSI Z223.1/NFPA 54, the Natural Gas and
Propane installation Code, CSA B149.1, ANSI A119.2
Recreational Vehicles Code, and CSA Z240 RV Series,
Recreational Vehicles.
- A manufactured home (mobile home) installation must
conform with the Manufactured Home Construction and
Safety Standard, Title 24 CFR, Part 3280 [formerly the
Federal Standard for Mobile Home Construction and Safety,
Title 24 (part 280), and the current CSA Z240.4, Gas-
equipped Recreational Vehicles and Mobile Housing.
- If an external power source is utilized, the appliance, when
installed, must be electrically grounded in accordance with
local codes or, in the absence of local codes, the National
Electrical code, and ANSI/NFPA 70, or the Canadian
Electrical Code, CSA C22.2. Parts 1 and 2.

Installation and Owner’s Manual 12
Assemble the Enclosure
1. Make sure the enclosure is 29.75 - 29.88 inches high x 20.50
- 20.63 inches wide x 21.38 inches deep.
2. Make sure the floor is solid and level.
- The floor must be metal or a wood panel and extend the full
width and depth of the enclosure.
- The floor must be able to support the weight of the refrigera-
tor and its contents.
3. Make sure there are no adjacent heat sources such as a
furnace vent, a hot water heater vent, etc.
4. If there is more than 1/2 inch between either side of the
refrigerator and the inside of the enclosure:
- Fill the space with fiberglass (batt-type) insulation or add a
baffle to eliminate the clearance.
- The rear of the batt-type insulation must be between 14
-15inches from the face of the enclosure.
- Securely attach the batt-type insulation to the enclo-
sure, so that it remains in this position during refrigera-
tor installation, if it becomes wet, and in windy condi-
tions.
Install the Lower and Upper Vents
1. Using the following chart, decide which vents and rough
opening (RO) sizes to use.
Certified Vent P/N RO Height RO Width
Upper Roof 622293 24 in. 5 1/4 in.
Exhaust Vent
Upper Side 617485 7 1/4 in. 18 in.
Exhaust Vent
Lower Side 617484 9 3/4 in. 19 3/8 in.
Intake Vent
Universal Upper 620505 6 3/16 in. 17 15/16 in.
and Lower Vent
2. Install the lower intake vent (See Art01629):
NOTE: The lower intake vent is also the service access
opening for the components on the rear of the refrig-
erator.
Ventilation Requirements
WARNING: The completed installation must:
- Make sure there is sufficient intake of fresh air for
combustion.
- Make sure the living space is completely isolated from
the combustion system of the refrigerator.
- Make sure there is complete and unrestricted ventila-
tion of the flue exhaust which, in gas mode, can
produce carbon monoxide. The breathing of carbon
monoxide fumes can cause dizziness, nausea, or in
extreme cases, death.
- Make sure the refrigerator is completely isolated from
its heat generating components through the correct
use of baffles and panel construction.
Certified installation needs one lower intake vent and one upper
exhaust vent. Install the upper exhaust vent either through the
roof or through the side wall of the vehicle exactly as written in
this manual. Any other installation method voids both the
certification and the factory warranty of the refrigerator.
The bottom of the opening for the lower intake vent, which is
also the service access door, must be even with or immediately
below the floor level. This allows any leaking propane gas to
escape to the outside and not to collect at floor level.
CSA International certification allows the refrigerator to have
zero (0) inch minimum clearance at the sides, rear, top, and
bottom. While there are no maximum clearances specified for
certification, the following maximum clearances are necessary
for correct refrigerator performance:
Bottom 0 inch min. 0 inch max.
Each Side 0 inch min 1/4 inch max.
Top 0 inch min. 1/4 inch max.
Rear 0 inch min. 1 inch max.
These clearances plus the lower and upper vents cause the
natural air draft that is necessary for good refrigeration. Cooler
air comes in through the lower intake vent, goes up around the
refrigerator coils where it removes the excess heat from the
refrigerator components, and goes out through the upper
exhaust vent. If this air flow is blocked or decreased, the
refrigerator will not cool correctly.
Each NORCOLD model is certified by CSA International for
correct ventilation. Install only the certified vents that are listed
in this manual.
All propane gas supply piping and fittings must obey local,
state, and national codes about type and size. These
components must also obey the current NFPA 501C section 2-
4, and in Canada with the current CAN 1-6.10 Standard.

Installation and Owner’s Manual 13
WARNING: Make sure the bottom of the opening of the
lower intake vent is even with or immediately below the
floor level. This allows any leaking propane gas to
escape to the outside and not to collect at floor level.
- Make sure the bottom of the opening of lower intake vent is
even with or immediately below the floor level.
- Align the lower intake vent [1] vertically below the coils [2]
and the condenser [3] of the refrigerator.
3. Install the upper exhaust vent (see Art01630):
- If you install the upper side exhaust vent:
- Make sure the distance [4] from the bottom of the
enclosure to the top of the rough opening for the upper
exhaust vent is at least 37 inches or poor cooling
performance can occur.
- Align the upper exhaust vent [5] horizontally above the
lower intake vent [1] of the refrigerator.
- Install a baffle [6] to prevent stagnant hot air in the area
[7] above the refrigerator.
- Make sure there is less than 1/4 inch clearance [8]
between the baffle and the top of the refrigerator.
- Make sure the baffle is the full width of the inside of
the enclosure.
- If the construction of the vehicle does not allow the
distance [4] to be 37 inches, the distance (optional
only) can be as little as 30 3/4 inches (See Art01633) if
you:
- Install a bent aluminum or galvanized steel sheet
baffle [15] to the rear of the enclosure.
- Make sure that the bend of the baffle [18] is flush
with the bottom edge of the upper exhaust vent
opening
- Make sure the baffle is not below the top edge of
the condenser fins.
- Install a baffle [14] from the upper edge of the
lower exhaust vent that is firmly against the
absorber coils [2] of the refrigerator.
- Install a baffle [10] to prevent any stagnant hot air in
the area above the refrigerator.
- If you install the roof exhaust vent (See Art01631):
CAUTION: Make sure that no sawdust, insulation, or
other construction debris is on the refrigerator or in the
enclosure. Debris can cause a combustion hazard
and prevent the refrigerator from operating correctly.
NOTE: Tighten the screws of the roof cap to 10 inch-pounds
max. Also make sure that the air flow around the
upper roof exhaust cap is not blocked or decreased
by other roof mounted features such as a luggage
carrier, an air conditioner, a solar panel, etc.
- If the design of the vehicle allows, install the roof
exhaust vent [9] directly above the condenser [3] of the
refrigerator.
- Install a baffle [10] to prevent stagnant hot air in the
area [7] above the refrigerator.
- Make sure there is less than 1/4 inch clear-
ance [11] between the baffle and the top of the
refrigerator.
- Make sure the baffle is the full width of the
inside of the enclosure.
- If the design of the vehicle does not allow you to install
the roof exhaust vent directly above the condenser of
the refrigerator (See Art01632):
- Align the roof exhaust vent [9] above the lower
intake vent and move it inboard as necessary.
- Install two baffles [12] and [13] to prevent stagnant
hot air in the area [7] above the refrigerator.
- Make sure both baffles are the full width of the
inside of the enclosure.
- Make sure that both baffles are no more than
45° from vertical.
- Put one baffle between the top rear edge of the
refrigerator and the inside edge of the upper
exhaust vent opening.
- Put the other baffle between the outside edge
of the upper exhaust vent opening and the
side wall of the vehicle.
- If there is more than 1 inch of clearance between the
rear of the refrigerator and the enclosure, add two
baffles [14] to the rear of the enclosure (See Art01630,
Art01632 and Art01633):
- Put the baffle at the top edge of the lower intake
vent [1].
- Put the other baffle at the lower edge of the
condenser [3] of the refrigerator.
- Make sure the baffles are less than 1/4 inch
from the coils [2] and condenser of the
refrigerator.
- Make sure the baffles are the full width of the
inside of the enclosure.

Installation and Owner’s Manual 14
2. Change the position of the hinges:
- Remove and save the plastic bushings that are in the holes
on the ends of the door..
- Remove the screws from the upper hinge [3].
- Put this hinge on the other side as the lower hinge.
- Attach the hinge with the screws.
- Turn the lower hinge pin down into this hinge.
- Remove the screws from the lower hinge [4].
- Remove the screw from the travel latch [5].
- Put this hinge on the other side as the upper hinge.
- Attach the hinge with the screws.
- Push the bushings into the empty holes in the ends of the
door.
3. Change the position of the travel latch (See Art00978 and
Art00979):
- Put the travel latch on the other side of the refrigerator.
- Attach the travel latch with the screw.
- Remove the screw from the travel latch plate [7] on the
door.
- Pull each hinge bushing [8] out of the hole in the door.
- Pull the plastic plug out of the top of the door.
- Push the plastic plug into the other hole in the top of the
door.
- Put the travel latch plate on the other side of the door.
- Attach the travel latch plate with the screw.
- Push each hinge bushing into the hole on the other side of
the door.
4. Install the door:
- Put the door down onto the lower hinge pin.
- Align the holes in the upper hinge and the hinge bushing
and hold in this position.
- Screw the upper hinge pin down into the upper hinge and
into the door.
- Tighten all of the screws.
Install the Refrigerator
Put the refrigerator in position (see Art01253):
WARNING: Make sure the combustion seal [15] is not
broken, is completely around the refrigerator mounting
flanges [16], and is between the mounting flanges and
the wall of the enclosure. If the combustion seal is not
complete, exhaust fumes can be present in the living
area of the vehicle. The breathing of exhaust fumes can
cause dizziness, nausea, or in extreme cases, death.
- Remove the door from the refrigerator (See “Reverse the
door swing” section).
- Put screws through the holes of the refrigerator mounting
flanges and into the enclosure wall.
- Attach the door to the refrigerator.
- Put a screw through the holes [17] in the braces at the lower
rear corners of the refrigerator and into the floor.
Install the decorative door panel:
NOTE: The decorative panels must be 3/16 inch or less in
thickness.
- Make a decorative door panel [1] that is 25 15/16 inches
high x 20 1/8 inches wide (See Art00977).
- Push the decorative door panel into the slots [4] of the door
end caps [2].
- Push each panel retainer [3] into the slot on the edge of the
door.
Reverse the door swing:
This refrigerator has door hinges that allow you to change the
direction that the door opens by moving the hinges to the
opposite corner (See Art00981).
1. Remove the door:
- Turn out and save the upper hinge pin [1].
- Open the door a small amount and pull the top of the door
away from the upper hinge of the refrigerator.
- Lift the door off of the lower hinge pin [2].
- Turn out and save the lower hinge pin.
Installation Options

Installation and Owner’s Manual 15
Connect the Electrical Components
AC Operation 120 volts AC voltage
(108 volts min. - 132 volts max.)
Current Draw 1.4Amps at 110 VoltsAC
1.5Amps at 120 VoltsAC
DC Operation 12 volts DC voltage
(3-way models only) (11.5 volts min. - 15.4 volts max.)
Current Draw 12 Amps at 12 Volts DC
14 Amps at 14 Volts DC
This refrigerator operates on these electrical sources. Opera-
tion out of these limits may damage the refrigerator’s electrical
circuit parts and will void the warranty.
WARNING: The rear of the refrigerator cooling system
has hot surfaces and sharp surfaces that can damage
electrical wiring. Make sure that there is a good clear-
ance between all electrical wiring and the cooling system
of the refrigerator. Position any electrical wiring within the
refrigerator enclosure opposite the burner side of the
refrigerator. Do not put any electrical wiring through the
roof exhaust vent. Failure to correctly position electrical
wiring can result in electrical shock or fire.
Connect the 120 volts AC supply:
WARNING: Connect theAC power cord only to a
grounded three-prong receptacle. Do not remove the
round ground prong from the power cord. Do not use a
two-prong adapter or an extension cord. Operation of the
refrigerator without correct ground can cause dangerous
electrical shock or death if you are touching the metal
parts of the refrigerator.
Put the AC power cord into a grounded three-prong receptacle:
- Make sure the receptacle is positioned within easy reach of
the lower intake vent.
- Make sure the power cord does not touch the burner cover,
the flue pipe, or any hot component that could damage the
insulation of the power cord.
- Make sure the travel latch engages the travel latch plate.
- If not, loosen the screw and adjust the height of the
travel latch plate.
- Tighten the screw.
Connect the 12 volts DC supply (3-way models only):
As the distance from the vehicle battery to the refrigerator
increases, the correct AWG wire size and fuse size also
increases. If the wire size is too small for the distance, a
voltage drop occurs. The voltage drop decreases the output of
the system heater and causes decreased cooling performance.
1. Determine the min. wire size and the max. fuse size to use:
WARNING: If you use an incorrect wire size and/or fuse
size, electrical fire can result.
- Measure the distance from the vehicle battery to the
refrigerator:
- If the distance is 0 - 20 feet, use a minimum of 12 AWG
wire and a maximum 20 amp fuse.
- If the distance is more than 20 feet, use a minimum 10
AWG wire and a maximum 30 amp fuse.
- If the wire size is larger than the min. size, use the correct
fuse per RVIAA119.2 standard or local codes.
The wire connections must be clean, tight and free of corrosion.
If any of these items are not correct:
- A voltage drop to the refrigerator will occur.
- The voltage drop will reduce the cooling performance of the
refrigerator.
The terminals for connecting the DC power supply are marked
positive (+) and negative (-) on the terminal block of the refrig-
erator. Make sure that:
- Each DC power supply wire is attached to the correct
polarity terminal.
- The chassis or the vehicle frame is not used as one of the
conductors.
- The DC power supply wires including the fuses are routed
directly from the battery to the refrigerator.
2. Connect the D.C. power supply wires:
- Attach a 1/4 inch female Quick Connect terminal to each DC
power supply wire.
- Push each power wire onto the terminal block [1] at the rear
of the refrigerator (See Art01254).
- Make sure each DC power supply wire is on the correct
polarity terminal.

Installation and Owner’s Manual 16
Connect the Propane Gas Components
This refrigerator operates on propane gas at a pressure of 11
inches Water Column Propane.
Connect the propane gas supply system:
WARNING: Be very careful when working on or near the
propane gas system.
- Do not smoke or use an open flame near the propane
gas system.
- Do not use an open flame to examine for leaks.
- Do not connect the refrigerator to the gas tank without a
pressure regulator between them.
- To avoid an propane gas leak, always use two
wrenches to tighten or loosen the gas supply line
connections.
- Leaking propane gas can ignite or explode and result
in dangerous personal injury or death.
Connect the gas supply line to the refrigerator:
- Make sure all tubing and fittings obey all local, state, and
national codes about size and type.
- Make sure that all flexible metal connectors obey the current
CAN1-6.10 Standard.
- Make sure that the materials used for the gas supply line
obey both the currentANSIA119.2 (NFPA1192) and CSA
Z240 Standards on Recreational Vehicles. Norcold
recommends the use of 3/8 inch copper tubing as the gas
supply line and requires a 3/8 inch SAE (UNF 5/8-18) male
flare fitting as the connection to the refrigerator.
- Put the propane gas supply line up through the floor of the
enclosure.
- Make sure the hole through the floor is large enough to
allow clearance for the gas supply line.
- Put a weather resistant seal (grommet, sealant, etc.)
around the gas supply line where it goes through the floor
to prevent vibration and abrasion.
- To prevent vibration and abrasion, make sure that the gas
supply line is not against anything in the enclosure.
- Attach the gas supply line to the bulkhead fiting [2] of the
refrigerator (See Art01254).
Examine the gas supply system for leaks:
WARNING: Do not allow the leak detecting solution to
touch the electrical components. Many liquids are
electrically conductive and can cause a shock hazard,
electrical shorts, and in some cases, fire.
Use a leak detecting solution to examine the gas supply line
and all propane gas connections for leaks..
If you use compressed air for the test:
- The pressure at the manual shut off valve of the refrigerator
must not be more than 1/2 psig (14 inches Water Column).
- If the air pressure is more than 1/2 psig (14 inches Water
Column), remove the gas supply line from the bulkhead
fitting of the refrigerator before the test.
- If the air pressure is equal to or less than 1/2 psig (14
inches Water Column), close the manual shutoff valve of
the refrigerator before the test.

Installation and Owner’s Manual 17
