PARTS LIST
N300 SERIES
N400 SERIES

PARTS LIST N300/N400 SERIES PAGE 2
CABINET AREA (FRONT VIEW) - N300 SERIES/N400 SERIES
NO. PART # DESCRIPTION N300 N302 N400 N402.3
1 619147 CONTROL ASSY-GAS X X
620196 CONTROL ASSY-GAS XX
2 619196 CONTROL PANEL ASSY-EG2/BEIGE EG2
619145 CONTROL PANEL ASSY-EG3/BEIGE EG3
620159 CONTROL PANEL ASSY-EG2/BEIGE EG2
620873 CONTROL PANEL ASSY-EG3/BEIGE EG3
627458 CONTROL PANEL ASSY-EG2/BLACK EG2
627459 CONTROL PANEL ASSY-EG3/BLACK EG3
627463 CONTROL PANEL ASSY-EG2/BLACK EG2
627464 CONTROL PANEL ASSY-EG3/BLACK EG3
3 619070 KNOB-SELECTOR/TAUPE(SUBSTITUTE629357 - WARM GRAY) X X
CONTINUED ON NEXT PAGE

PARTS LIST N300/N400 SERIES PAGE 3
CABINET AREA (FRONT VIEW) - N300/N400 SERIES (CONTINUED FROM PAGE 2)
NO. PART # DESCRIPTION N300 N302 N400 N402.3
619070 KNOB-SELECTOR/BLACK X X
4 619117 EVAPORATOR DOOR ASSY (FREEZER) X X X X
5 619103 LATCH-DOOR/BEIGE X X
627627 LATCH-DOOR/BLACK X X
6 619123 SHELF-WIRE/TOP X X
620156 SHELF-WIRE/TOP/SHORT XX
7 61409622 CLIP-SHELF X X X X
8 619033 BIN-DOOR SHELF (3 PER REFRIGERATOR) X X
624863 BIN-DOOR SHELF (2 PERREFRIGERATOR) X X
9 619030 DOOR ASSY-CABINET/BEIGE X
620164 DOOR ASSY-CABINET/BEIGE X
627461 DOOR ASSY-CABINET/BLACK X
627465 DOOR ASSY-CABINET/BEIGE X
10 619102 SHELF-WIRE/BOTTOM X X
620178 SHELF-WIRE/LOWER/FLIPPER/N4/N5 X X
NS 618065 CAP-CLEAR/FORFLIPPER SHELF (NOT SHOWN) X X
11 61550722 HINGEPIN-BOTTOM X X X X
12 619095 HINGE-CABINET/UPPERRH/LOWERLH/BEIGE (FORSERIAL # 881605 & BELOW USE621497 & 621498 AS A PAIR) X
621497 HINGE-CABINET/UPPERRH/LOWERLH/BEIGE(SN881606 & ABOVE) X
620187 HINGE-CABINET/UPPERRH/LOWERLH/BEIGE X
626716 HINGE-CABINET/UPPERRH/LOWERLH/BLACK X
626728 HINGE-CABINET/UPPERRH/LOWERLH/BLACK X X
13 619097 BREAKER-CABINET/BEIGE X
626715 BREAKER-CABINET/BLACK X
14 61114600 HINGEPIN-TOP X X
623899 HINGEPIN-TOP/BLACK X X
15 619096 HINGE-CABINET/UPPERLH/LOWERRH/BEIGE (FORSERIAL # 881605 & BELOW USE621497 & 621498 AS A PAIR) X
621498 HINGE-CABINET/UPPERLH/LOWERRH/BEIGE X
620188 HINGE-CABINET/UPPERLH/LOWERRH/BEIGE X
626717 HINGE-CABINET/UPPER LH/LOWER RH/BLACK X
626729 HINGE-CABINET/UPPER LH/LOWER RH/BLACK X
16 619041 SPRING HOLDER ASSY-RH/EVAP DOOR/SILVERSPRING X X X X
17 619042 SPRING HOLDER ASSY-LH/EVAP DOOR/YELLOW SPRING X X X X
NS 61630422 ICECUBETRAY-PLASTIC (NOT SHOWN) X X X X
NS 61619930 DRIP TRAY-INSIDE(NOT SHOWN) X X
NS 622858 DRIP TRAY-INSIDE (NOT SHOWN)(USE WITH DRAIN HOSE ASSY 622394) X X
NS 622754 PLUG-DRIP TRAY/WHITE (NOT SHOWN)(INSERT FOR DRIP TRAY 622858) X X
NS 621426 BREAKER TRIM/SEAL ASSY-BOTTOM TRIM/BEIGE(NOT SHOWN) X
NS 627467 BREAKERTRIM/SEAL ASSY-BOTTOM TRIM/BLACK (NOT SHOWN) X

PARTS LIST N300/N400 SERIES PAGE 4
CABINET ASSEMBLY - REAR VIEW N300/N400 SERIES
NO. PART # DESCRIPTION N300 N302 N400 N402.3
1 619196 CONTROL PANEL ASSY-EG2/BEIGE EG2
619145 CONTROL PANEL ASSY-EG3/BEIGE EG3
620159 CONTROL PANEL ASSY-EG2/BEIGE EG2
620873 CONTROL PANEL ASSY-EG3/BEIGE EG3
627458 CONTROL PANEL ASSY-EG2/BLACK EG2
627459 CONTROL PANEL ASSY-EG3/BLACK EG3
627463 CONTROL PANEL ASSY-EG2/BLACK EG2
627464 CONTROL PANEL ASSY-EG3/BLACK EG3
2 619147 CONTROL ASSY-GAS X X
620196 CONTROL ASSY-GAS XX
3 619122 BAFFLE-CABINET X X
4 619156 BURNER TUBE (FOR SERIAL # 738383 AND BELOW) X X
621073 BURNER TUBE (FOR SERIAL # 738384 AND ABOVE) X X
620223 BURNER TUBE XX
5 619052 FINS XX
61686823 FINS XX
CONTINUED ON NEXT PAGE

PARTS LIST N300/N400 SERIES PAGE 5
CABINET ASSEMBLY - REAR VIEW N300/N400 SERIES (CONTINUED FROM PAGE 4)
NO. PART # DESCRIPTION N300 N302 N400 N402.3
NS 61728722 CLIP-FIN (NOT SHOWN) X X X X
6 619084 CAP-HEAT DEFLECTOR X X
61695022 CAP-HEAT DEFLECTOR XX
7 619088 NSC SYSTEM PACK-COOLING UNIT X X
621462 NSC SYSTEM PACK-COOLING UNIT X X
NS 621237 SPACER-CONDENSER/FOR COOLING UNIT (NOT SHOWN) X X
8 619065 HEATER-DC/150W/14VDC (PRODUCTION PRIOR TO APRIL 1999) X X
620451 HEATER-DC/150W/14VDC (PRODUCTION AFTER MARCH 1999) X X
620884 HEATER-DC/EG3 XX
9 619063 HEATER-AC/180W/120VAC (PRODUCTION PRIOR TO APRIL 1999) X X
620461 HEATER-AC/120VAC (PRODUCTION AFTER MARCH 1999) X X
61562522 HEATER-AC/200W/110VAC XX
10 61712637 COVER ASSY-BURNER BOX X X X X
11 61606522 BUSHING-OPEN/CLOSED 1/2" X X X X
12 619086 BAFFLE-BLOWOUT X X
13 617976 MANUAL SHUTOFF VALVEASSY X X
61692322 MANUAL SHUT OFF VALVE ASSY X X
14 61694022 BRACKET-MOUNTING/MANUAL SHUT OFF VALVE X X X X
15 619177 COVER-TERMINAL BLOCK X X X X
16 619173 TERMINAL BLOCK X X X X
17 620199 BRACE-CORNER/CABINET/RH X X
619124 BRACE-CORNER/CABINET/RH X X
18 620198 BRACE-CORNER/CABINET/LH X X
619119 BRACE-CORNER/CABINET/LH X X
19 619157 INLET TUBE-GAS X X
620225 INLET TUBE-GAS XX
NS 622394 DRAIN HOSE ASSY (NOT SHOWN) X X
622389 PLUG-DRAIN HOSE/BLACK XX
NS 622546 DRIP CUP-REAR/PLASTIC (NOT SHOWN) X X
NS 617918 CORD-AC POWER (NOT SHOWN) X X X X
NS 620881 SHROUD-UPPER CONTROL AREA (NOT SHOWN) X X
NS 61583322 FUSECOVER (NOT SHOWN) X X
NS 61584222 FUSEHOLDER(NOT SHOWN) X X
NS 621227 FUSE-GLASS/25 AMP/EG3 (NOT SHOWN) EG3 EG3
NS 61654622 FUSE-GLASS/3 AMP/32V OR LESS (NOT SHOWN) X X
NS 621228 PLATE-FUSEHOLDER (NOT SHOWN) X X
NS 619072 WIRE HARNESS-N300 (NOT SHOWN) X X
NS 620423 WIRE HARNESS-N400 (NOT SHOWN) X X
NS 621220 WIRE-12"/BLACK/CONTROL (NOT SHOWN) X X
NS 621219 WIRE-14"/WHITE/CONTROL/EG3 (NOT SHOWN) X
NS 619166 WIRE-39.5"/YELLOW (NOT SHOWN) X
NS 620234 WIRE-55"/YELLOW/CONTROL/EG3 (NOT SHOWN) EG3 EG3
NS 621223 WIRE-61"/WHITE/CONTROL/EG3 (NOT SHOWN) EG3 EG3

PARTS LIST N300/N400 SERIES PAGE 6
GAS CONTROL ASSEMBLY AREA - N300 N400 SERIES
NO. PART # DESCRIPTION N300 N302 N400 N402.3
619147 CONTROL ASSY-GAS X X
620196 CONTROL ASSY-GAS XX
1 617952 BRACKET-MOUNTING/THERMOSTAT/GAS VALVE X X X X
2 61621622 BRASS ELBOW-UNION TUBE X X X X
3 623297 GAS VALVE-THERMOSTAT CONTROL X X
621298 GAS VALVE-THERMOSTAT CONTROL X X
4 619055 ADAPTOR-PIPE X X
5 622746001 KIT-SAFETY VALVE/EXTENSION PLUG X X X X
6 619044 PLUG-SAFETY VALVEEXTENSION(USE622746001) X X
622396 PLUG-SAFETY VALVEEXTENSION(USE622746001) X X
7 623249 O RING-SAFETY VALVE X X
8 622098 SAFETY VALVE(USE622746001) X X X X
9 621737 INTERRUPTER X X X X
NS 619073 TAB ADAPTER-INTERRUPTER (NOT SHOWN) X X X X
10 619154 THERMOCOUPLE X X
620424 THERMOCOUPLE XX

PARTS LIST N300/N400 SERIES PAGE 7
CONTROL PANEL ASSEMBLY AREA - N300/ N400 SERIES
NO. PART # DESCRIPTION N300 N302 N400 N402.3
619196 CONTROL PANEL ASSY-EG2/BEIGE EG2
619145 CONTROL PANEL ASSY-EG3/BEIGE EG3
620159 CONTROL PANEL ASSY-EG2/BEIGE EG2
620873 CONTROL PANEL ASSY-EG3/BEIGE EG3
627458 CONTROL PANEL ASSY-EG2/BLACK EG2
627459 CONTROL PANEL ASSY-EG3/BLACK EG3
627463 CONTROL PANEL ASSY-EG2/BLACK EG2
627464 CONTROL PANEL ASSY-EG3/BLACK EG3
1 619205 CONTROL PANEL-EG2/BEIGE EG2
619146 CONTROL PANEL-EG3/BEIGE EG3
620160 CONTROL PANEL-EG2/BEIGE EG2
620205 CONTROL PANEL-EG3/BEIGE EG3
626707 CONTROL PANEL-EG2/BLACK EG2
626708 CONTROL PANEL-EG3/BLACK EG3
626721 CONTROL PANEL-EG2/BLACK EG2
626720 CONTROL PANEL-EG3/BLACK EG3
2 61645622 SPARK IGNITOR-MANUAL X X X X
3 619152 BRACKET-SPARK IGNITOR X X
620886 BRACKET-SPARKIGNITER XX
4 61481322 METER-FLAMEINDICATOR X X X X
5 619168 SWITCH-SELECTOR/4 POSITION X X
620863 SWITCH-SELECTOR XX
6 619087 COMBUSTION SEAL STRIP X X
NS 619203 RETAINER-FLAMEMETER(NOT SHOWN) X X X X

PARTS LIST N300/N400 SERIES PAGE 8
FREEZER DOOR ASSEMBLY AREA - N300/N400 SERIES
8
NO. PART # DESCRIPTION N300 N302 N400 N402.3
1 619117 EVAPORATOR DOOR ASSY (FREEZER) X X X X
2 61632930 MOUNTING CLIP-RH/WHITE/EVAPORATOR DOOR X X X X
3 61633030 MOUNTING CLIP-LH/WHITE/EVAPORATOR DOOR X X X X

PARTS LIST N300/N400 SERIES PAGE 9
DOOR ASSEMBLY - N300/N400 SERIES
NO. PART # DESCRIPTION N300 N302 N400 N402.3
1 619030 DOORASSY-CABINET/BEIGE X
620164 DOORASSY-CABINET/BEIGE X
627461 DOORASSY-CABINET/BLACK X
627465 DOORASSY-CABINET/BEIGE X
2 61742022 HINGEBUSHING X X X X
3 619035 PANEL RETAINER-BEIGE X
620167 PANEL RETAINER-BEIGE X
626712 PANEL RETAINER-BLACK X
626725 PANEL RETAINER-BLACK X
4 619048 PLUG-HANDLE SCREW/BEIGE X
618173 PLUG-HANDLESCREW/BLACK X
5 619104 LATCHPLATE-DOOR/BEIGE X X
627571 LATCHPLATE-DOOR/BLACK X X
NS 620200 PLATE-FILLER/DOOR ASSY/BEIGE(NOT SHOWN) X
NS 620200 PLATE-FILLER/DOORASSY/BLACK(NOT SHOWN) X

PARTS LIST N300/N400 SERIES PAGE 10
BURNER ASSEMBLY AREA - N300 / N300.3 / N400 / N400.3
9
10
8
7
NO. PART # DESCRIPTION N300 N302 N400 N402.3
1 61695322 BASE-BURNER BOX X X X X
2 61606522 BUSHING-OPEN/CLOSED 1/2" X X X X
3 61712637 COVER ASSY-BURNER BOX X X X X
4 619153 ELECTRODE-SPARK IGNITION ASSY X X
620227 ELECTRODE-SPARK IGNITION ASSY X X
5 619154 THERMOCOUPLE X X
620424 THERMOCOUPLE XX
6 618448 BRACKET-THERMOCOUPLE (USE 622547 ON N300) X X X X
622547 BRACKET-THERMOCOUPLE/N300 X X
7 621953 KIT-BURNER/ORIFICE ADAPTER ASSY X X
621955 KIT-BURNER/ORIFICE ADAPTER ASSY X X
8 61445322 PLUG-1/8"/FORPRESSURETAP X X X X
9 61755322 PRESSURE TAP (CALL NORCOLD) X X
621054 PRESSURETAP X X X X
10 621079 CONNECTOR-SWIVEL NUT X X X X
