Nordson PatternCoat Series User manual

NORDSON ENGINEERING GMBH DLÜNEBURG DGERMANY
Applicators
Series PatternCoat
(PCT)
Manual P/N 7135308_08
- English -
Issued 05/15

P/N 7135308_08 E2014 Nordson Corporation PatternCoat
Note
This document applies to the entire series.
Order number
P/N = Order number for Nordson products
Notice
This is a Nordson Corporation publication which is protected by copyright. Original copyright date 2007.
No part of this document may be photocopied, reproduced, or translated to another language without the prior
written consent of Nordson Corporation. The information contained in this publication is subject to change
without notice.
E2014 All rights reserved.
- Translation of Original -
Trademarks
AccuJet, AeroCharge, Apogee, AquaGuard, Asymtek, Automove, Autotech, Baitgun, Blue Box, Bowtie, Build‐A‐Part, CanWorks, Century, CF,
CleanSleeve, CleanSpray, Color‐on‐Demand, ColorMax, Control Coat, Coolwave, Cross‐Cut, cScan+, Dage, Dispensejet, DispenseMate, DuraBlue,
DuraDrum, Durafiber, DuraPail, Dura‐Screen, Durasystem, Easy Coat, Easymove Plus, Ecodry, Econo‐Coat, e.DOT, EFD, Emerald, Encore, ESP, e
stylized, ETI‐stylized, Excel 2000, Fibrijet, Fillmaster, FlexiCoat, Flexi‐Spray, Flex‐O‐Coat, Flow Sentry, Fluidmove, FoamMelt, FoamMix, Fulfill,
GreenUV, HDLV, Heli‐flow, Helix, Horizon, Hot Shot, iControl, iDry, iFlow, Isocoil, Isocore, Iso‐Flo, iTRAX, JR, KB30, Kinetix, KISS, Lean Cell, Little Squirt,
LogiComm, Magnastatic, March, Maverick, MEG, Meltex, Microcoat, Micromark, Micromedics, Micro‐Meter, MicroSet, Microshot, Millenium, Mini Blue,
Mini Squirt, Moist‐Cure, Mountaingate, MultiScan, NexJet, No‐Drip, Nordson, Optimum, Package of Values, Paragon, PatternView, PermaFlo, PICO,
PicoDot, PluraFoam, Porous Coat, PowderGrid, Powderware, Precisecoat, PRIMARC, Printplus, Prism, ProBlue, Prodigy, Pro‐Flo, Program‐A‐Bead,
Program‐A‐Shot, Program‐A‐Stream, Program‐A‐Swirl, ProLink, Pro‐Meter, Pro‐Stream, RBX, Rhino, Saturn, Saturn with rings, Scoreguard, SC5, S.
design stylized, Seal Sentry, Sealant Equipment & Engineering, Inc., SEE and design, See‐Flow, Select Charge, Select Coat, Select Cure, Servo‐Flo,
Shot‐A‐Matic, Signature, Slautterback, Smart‐Coat, Smart‐Gun, Solder Plus, Spectrum, Speed‐Coat, Spraymelt, Spray Squirt, Super Squirt, SureBead,
Sure Clean, Sure Coat, Sure‐Max, Sure Wrap, Tela‐Therm, Tip‐Seal, Tracking Plus, TRAK, Trends, Tribomatic, TrueBlue, TrueCoat, Tubesetter, Ultra,
UniScan, UpTime, u‐TAH, Value Plastics, Vantage, Veritec, VersaBlue, Versa‐Coat, VersaDrum, VersaPail, Versa‐Screen, Versa‐Spray, VP Quick Fit,
Walcom, Watermark, When you expect more., X‐Plane are registered trademarks - ®- of Nordson
Accubar, Active Nozzle, Advanced Plasma Systems, AeroDeck, AeroWash, Allegro, AltaBlue, AltaSlot, Alta Spray, AquaCure, Artiste, ATS, Auto‐Flo,
AutoScan, Axiom, Best Choice, BetterBook, Blue Series, Bravura, CanNeck, CanPro, Celero, Chameleon, Champion, Check Mate, ClassicBlue, Classic
IX, Clean Coat, Cobalt, ContourCoat, Controlled Fiberization, Control Weave, CPX, cSelect, Cyclo‐Kinetic, DispensLink, DropCure, Dry Cure, DuraBraid,
DuraCoat, e.dot+, E‐Nordson, Easy Clean, EasyOn, EasyPW, Eclipse, Equalizer, Equi=Bead, Exchange Plus, FillEasy, Fill Sentry, Flow Coat, Fluxplus,
Freedom, G‐Net, G‐Site, Genius, Get Green With Blue, Gluie, Ink‐Dot, IntelliJet, iON, Iso‐Flex, iTrend, KVLP, Lacquer Cure, Maxima, Mesa, MicroFin,
MicroMax, Mikros, MiniEdge, Minimeter, MonoCure, Multifil, MultiScan, Myritex, Nano, OmniScan, OptiMix, OptiStroke, Optix, Origin, Partnership+Plus,
PatternJet, PatternPro, PCI, PharmaLok, Pinnacle, Plasmod, PluraMix, Powder Pilot, Powder Port, Powercure, Process Sentry, Pulse Spray, PURBlue,
PURJet, PurTech, Quad Cure, Quantum, Ready Coat, RediCoat, RollVIA, Royal Blue, Select Series, Sensomatic, Shaftshield, SheetAire, Smart, Smartfil,
SolidBlue, Spectral, Spectronic, SpeedKing, Spray Works, StediFlo, StediTherm, Summit, Sure Brand, SureFoam, SureMix, SureSeal, Swirl Coat, TAH,
Tempus, ThruWave, TinyCure, Trade Plus, Trilogy, Ultra FoamMix, UltraMax, Ultrasaver, Ultrasmart, Universal, ValueMate, Versa, Viper, Vista,
WebCure, YESTECH, 2 Rings (Design) are trademarks - T- of Nordson Corporation.
Designations and trademarks stated in this document may be brands that, when used by third parties for their own purposes,
could lead to violation of the owners' rights.

Table of Contents I
P/N 7135308_08
E2014 Nordson Corporation PatternCoat
Table of Contents
Safety Instructions 1.....................................
Note on Manual 1........................................
Definition of Term(s) 1......................................
Applicator 1............................................
Introduction 2............................................
Intended Use 2............................................
Sample Application: Cut and Stack Labeling 2...............
Unintended Use - Examples - 3...........................
Residual Risks 3..........................................
Components of the Applicator 4.............................
Explanation of Type Designation 5...........................
ID Plate 5..............................................
Installation 6.............................................
Unpacking 6..............................................
Transport 6...............................................
Storage 6.................................................
Disposal 6................................................
Changing Direction of Application 7..........................
Installation 9..............................................
Adapter Plates 9........................................
Installation without adapter plate 10.......................
Installation with adapter plate P/N 7133073 10.............
Installation with adapter plate P/N 7133074 10.............
Positioning Applicator 11..................................
Exhausting Adhesive Vapors 11............................
Electrical Connection 12.....................................
Laying Cable 12..........................................
Connecting Applicator 12..................................
Heating 12............................................
Solenoid Valves 12.....................................
Pneumatic Connection 13....................................
Connecting Control Air 13.................................
Operating with Lubricated Compressed Air 13.............
Connecting Heated Hose 14.................................
Using Second Open‐end Wrench 14........................
Connecting 14...........................................
Disconnecting 14.........................................

Table of Contents
II
P/N 7135308_08 E2014 Nordson Corporation PatternCoat
Operation 15..............................................
Triggering Solenoid Valves 15................................
Setting Temperatures 15....................................
Maximum Operating Temperature 15.......................
Setting Application Width 16.................................
Maintenance 17...........................................
Relieving Pressure 17.......................................
Changing Type of Adhesive 17...............................
Daily Maintenance 18.......................................
Visual Inspection for External Damage 18....................
External Cleaning of Applicator 18..........................
Regular Maintenance 19.....................................
Check detection hole 19...................................
Replacing Filter Cartridge 19...............................
Cleaning Nozzle 20.......................................
Disassembling Nozzle 20...............................
Assembling Nozzle 21..................................
Lubricating Adjusting Device 21............................
Troubleshooting 22........................................
Technical Data 23.........................................
Operating Data 23..........................................
Electrical Data 23...........................................
Operating Voltage Solenoid Valves 23.......................
General Data 23............................................
Processing Materials 23...................................
Parts 24..................................................
Accessories 24............................................

Applicators PatternCoat 1
P/N 7135308_08
E2014 Nordson Corporation PatternCoat
Safety Instructions
WARNING: Allow only qualified personnel to perform the following tasks.
Observe and follow the safety instructions in this document and all other
related documentation.
Note on Manual
The position numbers in the illustrations do not correspond to the position
numbers in the technical drawings and parts lists.
The illustrations show only the essential unit components. All other
components and details can be found in the included technical drawings.
Definition of Term(s)
Applicator
Applicator is also referred to as Application head in Nordson literature.

2Applicators PatternCoat
P/N 7135308_08 E2014 Nordson Corporation PatternCoat
Introduction
Intended Use
Applicators in the series PatternCoat may be used only for the application of
hot melt adhesives. The series is designed particularly for Labeling
applications.
Any other use is considered to be unintended. Nordson will not be liable for
personal injury or property damage resulting from unintended use.
Intended use includes the observance of Nordson safety instructions.
Nordson recommends obtaining detailed information on the materials to be
used.
Sample Application: Cut and Stack Labeling
1
2
3
Fig. 1 Principle drawing
1 Applicator, e.g. LEP 34 S
2 Labels to be glued
3 Applicator PatternCoat

Applicators PatternCoat 3
P/N 7135308_08
E2014 Nordson Corporation PatternCoat
Unintended Use - Examples -
The applicators may not be used under the following conditions:
SIn defective condition
SWhen changes or modifications have been made by the customer
SIn a potentially explosive atmosphere
SWhen hot melt adhesives not suitable for the unit are used
SWhen the values stated under Technical Data are not complied with.
The applicators may not be used to process the following materials:
SPolyurethane hot melt adhesive
SExplosive and flammable materials
SErosive and corrosive materials
SFood products.
Residual Risks
In the design of the unit, every measure was taken to protect personnel from
potential danger. However, some residual risks can not be avoided.
Personnel should be aware of the following:
SRisk of burns on the hot applicator: from hot adhesive, when replacing
the filter and when making adjustments.
SMaterial fumes can be hazardous. Avoid inhalation.

4Applicators PatternCoat
P/N 7135308_08 E2014 Nordson Corporation PatternCoat
Components of the Applicator
The series contains applicators of different maximum application widths,
each of which is also available in a splash‐proof (Water‐Wash) version
(IP 54). The application width can be adjusted in increments of 3 mm.
PCT140 W‐B‐...
134
6
PCT140 T‐S‐...
5 7 9
10
2
8
Fig. 1 Examples, assembled for Application from the left (The actual model can deviate from the illustration)
1 Cordset
2 Filter
3 Hose connection
4 Adjusting device Application
width
5 Solenoid valve
6 Control module
7 Holder
8 Body
9 Nozzle
10 Seal (only on model
PCTnnn W‐...)

WV
Nordson Engineering GmbH
D 21337 Lüneburg - Germany
Made in Germany
Applicators PatternCoat 5
P/N 7135308_08
E2014 Nordson Corporation PatternCoat
Explanation of Type Designation
Example: PCT140 T-S-AW20-140
Abbreviated designation
PCT = PatternCoat
140 = Maximum application width in mm
Model
T = Standard
W = Splash‐proof (Water‐Wash)
Control module / solenoid valve type
S = Standard
B = Booster
Application width in mm
min - max
ID Plate
1st field Type of applicator
2nd field Nordson order number
3rd field Serial number
4th field Operating voltage V = Volt
5th field Power consumption W = Watt

6Applicators PatternCoat
P/N 7135308_08 E2014 Nordson Corporation PatternCoat
Installation
WARNING: Allow only qualified personnel to perform the following tasks.
Observe and follow the safety instructions in this document and all other
related documentation.
Unpacking
Unpack carefully. Then check for any damage caused during shipping.
Reuse packaging materials or dispose of properly according to local
regulations.
Transport
NOTE: The applicator is a high precision, valuable part. Handle very
carefully! Protect the nozzle from damage.
Storage
Do not store outside! Protect from humidity and dust. Do not lay unit on the
nozzle. Protect the nozzle from damage.
Disposal
When your Nordson product has exhausted its purpose and/or is no longer
needed, dispose of it properly according to local regulations.

AB
Principle drawing
6
Applicators PatternCoat 7
P/N 7135308_08
E2014 Nordson Corporation PatternCoat
Changing Direction of Application
The applicator can be modified from Application from the left (A) to
Application from the right (B) without additional components.
1. Disassemble nozzle. Refer to page 20, Cleaning Nozzle.
NOTE: The nozzle need only be heated and cleaned if adhesive has
already been processed with the head.
Reassemble the nozzle beginning with step 4..
2. Move the adjusting device.
a. Detach the adjusting device from the body (1).
b. Detach guide (2), slide (3) and stud holder (4), turn 180° and reinstall.
2
3
4
1
5
Adjusting device for
Application from left
Adjusting device for
Application from right
3. Put the adjusting device back into place. Ensure that the adjusting ring (5)
has clicked into place.
4. Place the mouthpiece receptacle (6) on the body as needed for the
desired direction of application.
Continued...

10
11
8Applicators PatternCoat
P/N 7135308_08 E2014 Nordson Corporation PatternCoat
5. Hang the piston rod in the adjusting device slide.
6. The lower edge of the piston should just reveal a groove (7). This
effectively seals the next groove. Otherwise the adjusting device must be
adjusted.
a. Set the application width on the adjusting ring such that the piston is
approximately in the center of the adjustment range. Ensure that the
adjusting ring has clicked into place.
b. Release the adjusting ring clamp (8).
c. Hold the adjusting ring in the locked in position and turn only the
spindle until the lower edge of the piston just reveals a groove (7). To
turn the spindle, e.g. insert a thin hexagon key into the bore (9) and
use it as a lever.
d. Tighten the adjusting wheel clamp.
8
79
7. Complete nozzle reassembly.
8. Attach the brackets (11) and insulation (10) to the desired side.

Bracket - example
Applicators PatternCoat 9
P/N 7135308_08
E2014 Nordson Corporation PatternCoat
Installation
Install the applicator in the appropriate place in the production machine.
Observe the following:
SDo not operate in a potentially explosive atmosphere
SProtect from humidity, vibrations, dust and drafts
NOTE: Model PCTnnn-W... is splash‐proof (Water‐Wash)
SEnsure access to parts relevant for maintenance and operation
SProtect the nozzle from damage.
NOTE: Several different brackets with pneumatic swiveling function are
available from Nordson. Refer to page 25, Bracket.
Adapter Plates
The PatternCoat applicators can be installed in all Labeling systems.
Observe the following:
SIf replacing a Nordson LabelCoat gun, the PatternCoat applicator can be
mounted directly onto the Nordson bracket P/N 735184 (CW) or
P/N 735201 (CCW). No adapter plate is needed.
SIf replacing a Nordson LabelCoat gun installed on a bracket P/N 735182
(CW) or P/N 735181 (CCW), an adapter plate may be necessary.
SIf the customer uses his own bracket or an OEM supplied bracket which
is not Nordson standard, an adapter plate may be necessary.
Continued...

10 Applicators PatternCoat
P/N 7135308_08 E2014 Nordson Corporation PatternCoat
Installation without adapter plate
53
77
12,95
77,5
Installation with adapter plate P/N 7133073
21
129
129
61
Installation with adapter plate P/N 7133074
26
121
121
66

Principle drawing
Applicators PatternCoat 11
P/N 7135308_08
E2014 Nordson Corporation PatternCoat
Positioning Applicator
Align the nozzle perpendicular to the substrate.
Exhausting Adhesive Vapors
Ensure that adhesive vapors do not exceed the prescribed limits. Exhaust
adhesive vapors when necessary. Provide sufficient ventilation of the
location where the unit is installed.

12 Applicators PatternCoat
P/N 7135308_08 E2014 Nordson Corporation PatternCoat
Electrical Connection
WARNING: Risk of electrical shock. Failure to observe may result in
personal injury, death, or equipment damage.
Laying Cable
WARNING: Ensure that cables do not touch rotating and/or hot unit
components. Do not pinch cables and check regularly for damage. Replace
damaged cables immediately!
Connecting Applicator
Heating
1. Connect cordset to the heated hose receptacle.
2. Use safety clips (when available) to secure the plug connection.
Solenoid Valves
The solenoid valves for the control modules are usually triggered by a control
unit (e.g. Eclipse). Refer to separate control unit manual.
WARNING: Observe operating voltage:
PCTnnn x‐B‐...
24 VDC, overexcitation not permitted
CAUTION: The solenoid valves, model PCTnnn x‐B‐..., may be connected
only to PLCs or control units that supply a stabilized 24 VDC signal without
overexcitation. Higher voltage causes damage to the solenoid valve. Also,
an additional solid state relay with a shunted protective diode must be
used between the control unit and solenoid valve to cover the increased
power consumption! Refer to page 24, Accessories.
PCTnnn x‐S‐...
24 VDC, overexcitation permitted up to 48 VDC

1
Applicators PatternCoat 13
P/N 7135308_08
E2014 Nordson Corporation PatternCoat
Pneumatic Connection
Connecting Control Air
The applicator may only be connected to pressure controlled and
conditioned compressed air.
The quality of the compressed air must be at least class 2 as stipulated by
ISO 8573-1. This means:
SMax. particle size 1 mm
SMax. particle density 1 mg/m3
SMax. pressure dewpoint -40°C / -40°F
SMax. oil concentration 0.1 mg/m3.
1. Connect a controllable air supply to the control air fitting (1).
2. Set control air pressure to approx. 4 to 6 bar (0.4 to 0.6 MPa /
58 to 87 psi). The exact pressure must be determined for each
application.
Operating with Lubricated Compressed Air
The applicators / control modules can also be operated with lubricated
compressed air.
NOTE: Once the air has been lubricated, it must always be lubricated; the
lubricated compressed air will wash out the original lubricant on the solenoid
valves and the control modules. Nordson recommends:
Oil P/N
Klüber Unisilkon TK002/50 316578

1 2 3
14 Applicators PatternCoat
P/N 7135308_08 E2014 Nordson Corporation PatternCoat
Connecting Heated Hose
WARNING: Hot! Risk of burns. Wear heat‐protective gloves.
Using Second Open‐end Wrench
Use a second open‐end wrench when connecting and disconnecting the
heated hose. This prevents the unit's hose connection from turning.
Connecting
If cold material can be found in the hose connection, these components (1, 2)
must be heated until the material softens (approx. 80°C, 176°F).
1. First connect the hose (3) electrically to the unit. For more than one hose:
Every hose connection is allocated to a corresponding receptacle. Do not
mistakenly exchange!
2. Heat the system and hose to approx. 80°C (176°F).
3. Screw on heated hose.
NOTE: Close unused hose connections with Nordson port plugs.
Disconnecting
WARNING: System and material pressurized. Relieve system pressure
before disconnecting heated hoses. Failure to observe can result in serious
burns.
WARNING: Hot! Risk of burns. Wear safety goggles and heat‐protective
gloves.
1. Turn off material supply.
2. Place a container under the nozzle(s) of the applicator.
3. Activate the solenoid valves electrically or manually. Repeat this
procedure until no more adhesive flows out.
4. Properly dispose of material according to local regulations.

Applicators PatternCoat 15
P/N 7135308_08
E2014 Nordson Corporation PatternCoat
Operation
WARNING: Allow only qualified personnel to perform the following tasks.
Observe and follow the safety instructions in this document and all other
related documentation.
Triggering Solenoid Valves
CAUTION: Observe the installation instructions: Refer to page 12, Solenoid
Valves.
The solenoid valves for the control modules are usually triggered by a control
unit (e.g. Eclipse). Refer to separate control unit manual.
CAUTION: Trigger the solenoid valve only when the applicator is heated to
operating temperature! Seals in the control module can become damaged if
the adhesive is too cold.
Setting Temperatures
The procedure for setting the temperatures is described in the temperature
controller manual. Temperature controllers are not part of the applicator.
They can be located e.g. in the electrical cabinet of the melter or in a
separate electrical cabinet.
Maximum Operating Temperature
200°C / 392°F.
NOTE: The maximum operating temperature may not be exceeded.
Nordson will assume no warranty or liability for damage resulting from
incorrect temperature settings.

16 Applicators PatternCoat
P/N 7135308_08 E2014 Nordson Corporation PatternCoat
Setting Application Width
CAUTION: Adjust the application width only when the applicator is heated.
Otherwise cold material will damage the applicator.
1. Release piston rod clamp (2).
2. Use the adjusting ring (1) to adjust the application width. Ensure that the
adjusting ring clicks into place.
NOTE: The adjusting device is set at the factory such that the lower
edge of the piston just reveals a groove (3) when the adjusting ring is
locked in place. This effectively seals the next groove. If the application
width deviates 3 mm during application: Adjust the adjusting device
again. Refer to Changing Direction of Application (page 7, step 6.).
3. Tighten the piston rod clamp.
1
3
3 mm
2
Cross‐section
