Nordyne T5BD Series User manual

Please read this information thoroughly and become familiar with the capabilities and
use of your appliance before attempting to operate or maintain this unit. Keep this
literature where you have easy access to it in the future. If a problem occurs, check the
instructions and follow recommendations given. If these suggestions don’t eliminate
the problem, call your servicing contractor.
The Installation Instructions are primarily intended to assist qualified individuals
experiencedintheproperinstallationofthisappliance.Somelocalcodesrequirelicensed
installation/service personnel for this type of equipment. Please read all instructions
carefully before starting the installation.
DO NOT DESTROY. PLEASE READ CAREFULLY AND
KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.
IMPORTANT
SPLIT SYSTEM HEAT PUMP - R-22
USER’S MANUAL / INSTALLATION INSTRUCTIONS
T5BD Series 13 SEER

2
Important Safety Information ....................................5
Heat Pump Installation...............................................6
General Information...................................................6
BeforeYou Install this Unit.........................................6
Locating the Heat Pump............................................6
Packaging Removal...................................................6
Ground Level.............................................................6
Connecting Refrigerant Tubing between the
Indoor & Outdoor Unit ...............................................7
ElectricalWiring..........................................................7
Pre - Electrical Checklist ...........................................7
Line Voltage...............................................................7
Grounding..................................................................8
Thermostat Connections...........................................8
Startup & Adjustments ..............................................9
Pre - Start Checklist..................................................9
Start-up Procedures..................................................9
Air Circulation - Indoor Blower ...............................9
System Cooling......................................................9
System Heating......................................................9
Refrigerant Charging..................................................9
Charging R-22 Units in AC Mode with
Outdoor Temperatures Above 55° F........................10
Heat Pump Maintenance..........................................10
Replacement Parts...................................................10
Figures &Tables.......................................................11
Figure 4. Unit Dimensions ...................................11
Refrigerant Charging Charts...................................11
Figure 5.T5BD-018K (1.5 Ton Units) ..................11
Figure 6.T5BD-024KA (2 Ton Units) ...................12
Figure 7.T5BD-030KA (2.5 Ton Units) ................12
Figure 8.T5BD-036K (3 Ton Units) .....................13
Figure 9.T5BD-042K (3.5 Ton Units) ..................13
Figure 10.T5BD-048K (4 Ton Units) ...................14
Figure 11.T5BD-060K (5 Ton Units) ...................14
Refrigerant Charging Tables - Cooling Mode ..........15
Table 3.T5BD-018K (1.5 Ton Units) ....................15
Table 4.T5BD-024KA (2 Ton Units) .....................15
Table 5.T5BD-030KA (2.5 Ton Units) ..................16
Table 6.T5BD-036K (3 Ton Units) .......................16
Table 7.T5BD-042K (3.5 Ton Units) ....................17
Table 8.T5BD-048K (4 Ton Units) .......................17
Table 9.T5BD-060K (5 Ton Units) .......................18
Refrigerant Charging Tables - Heating Mode..........19
Table 10.T5BD-018K (1.5 Ton Units) ..................19
Table 11.T5BD-024KA (2 Ton Units) ...................19
Table 12.T5BD-030KA (2.5 Ton Units) ................20
Table 13.T5BD-036K (3 Ton Units) .....................20
Table 14.T5BD-042K (3.5 Ton Units) ..................21
Table 15.T5BD-048K (4 Ton Units) .....................21
Table 16.T5BD-060K (5 Ton Units) .....................22
Electrical Information...............................................23
Figure 12.T5BD Wiring Diagram .........................23
Table 17.Electrical Specs & Physical Data..........24
USER INFORMATION
INSTALLER INFORMATION
Important Safety Information ....................................3
About the Heat Pump.................................................3
Operating Instructions...............................................3
Cooling Operation .....................................................3
Heating Operation.....................................................3
Emergency Heat........................................................3
Defrost Operation......................................................3
Operating the Heat Pump for Automatic
Cooling & Heating .....................................................4
Operating the Indoor Blower Continuously................4
Turning the Heat Pump Off........................................4
Heat Pump Maintenance............................................4
Regular Cleaning.......................................................4
Troubleshooting..........................................................4
WARRANTY INFORMATION
A warranty certificate with full details is included with the
Heat Pump. Carefully review these responsibilities with
yourdealerorservicecompany.Themanufacturerwillnot
be responsible for any costs found necessary to correct
problems due to improper setup, improper installation,
adjustments, improper operating procedure on the part
of the user, etc.Some specific examples of service calls
which are not included in the limited warranty are:
•Correcting wiring problems in the electrical circuit
supplying the Heat Pump.
•Resetting circuit breakers or other switches.
•Adjusting or calibrating of thermostat.

3
ABOUTTHE HEAT PUMP
Your heat pump is a unique, all weather comfort-control
appliance that will heat and cool your home year round
and provide energy saving comfort. It’s an unknown fact
that heat is always in the air, even when the outside
temperature is below freezing.The heat pump uses this
basiclaw ofphysics toprovide energysaving heatduring
thewintermonths.Forexample,Iftheoutdoortemperature
is47° F(8°C),your heatpump candeliverapproximately
3.5 units of heat energy per each unit of electrical energy
used, as compared to a maximum of only 1 unit of heat
energy produced with conventional heating systems.
Incoldertemperatures,theheatpumpperformslikeanair
conditioner run in reverse.Available heat energy outside
the home is absorbed by the refrigerant and exhausted
inside the home.This efficient process means you only
pay for“moving”the heat from the outdoors to the indoor
area.You do not pay to generate the heat, as is the case
with more traditional furnace designs.
During summer, the heat pump reverses the flow of the
heat-absorbingrefrigeranttobecomeanenergy-efficient,
central air conditioner. Excess heat energy inside the
home is absorbed by the refrigerant and exhausted
outside the home.
IMPORTANT SAFETY INFORMATION
Safety markings are used frequently throughout this
manualtodesignateadegreeorlevelofseriousnessand
should not be ignored.WARNING indicates a potentially
hazardous situation that if not avoided, could result in
personalinjuryordeath.CAUTIONindicatesapotentially
hazardoussituationthatifnotavoided,mayresultinminor
or moderate injury or property damage.
USER INFORMATION
OPERATING INSTRUCTIONS
Pleaserefertothethermostatmanufacturer’sUsermanual
for detailed programming instructions.
Cooling Operation
1.Set the thermostat’s system mode to COOL or AUTO
and change the fan mode to AUTO. See Figure 1
2.Setthetemperatureselectortothedesiredtemperature
level.Theoutdoorfan,compressor,andblowermotorwill
all cycle on and off to maintain the indoor temperature
at the desired cooling level.
NOTE: If the temperature level is re-adjusted, or the
system mode is reset, the fan and compressor in the
outdoor unit may not start immediately. A protective
timercircuitholdsthecompressorandtheoutdoorfan
off for approximately 5 minutes following a previous
operation or the interruption of the main electrical
power.
Heating Operation
1.Set the thermostat’s system mode to HEAT or AUTO
and change the fan mode to AUTO. See Figure 1.
2.Setthetemperatureselectortothedesiredtemperature
level.The compressor, outdoor fan, and blower motor
willcycleonand off to maintaintheindoor temperature
at the desired heating level.
NOTE: If the temperature level is re-adjusted, or the
system mode is reset, the fan and compressor in the
outdoor unit may not start immediately. A protective
timercircuitholdsthecompressorandtheoutdoorfan
off for approximately 5 minutes following a previous
operation or the interruption of the main electrical
power.
Emergency Heat
SomethermostatsmayincludeasystemmodecalledEM
HT or AUX HT, etc.This is a back-up heating mode that
should only be used if a problem is suspected.With the
modesetto EMHT, etc.,thecompressor andoutdoorfan
willbelockedoffandsupplementalheat(electricresistance
heating) will be used as a source of heat.Sustained use
of electric resistance heat in place of the heat pump will
result in an increase in electric utility costs.
Defrost Operation
During cold weather heating operation, the outdoor unit
willdevelopa coatingofsnowandiceontheheattransfer
coil.This is normal and the unit will defrost itself.This unit
monitors ambient and coil temperatures to regulate the
defrost function accordingly.
Figure 1. DigitalThermostat
Fan
Mode Temperature
Selector
System
Mode

4
At the beginning of the defrost cycle, both the outdoor
condenser fan and compressor will turn off. After
approximately 30 seconds, the compressor will turn on
and begin to heat the outdoor coil causing the ice and
snow to melt.
NOTE: While the ice and snow is melting, some steam
mayrisefromtheoutdoorunitasthewarmcoilcausesthe
meltingfrosttoevaporate.Whendefrostiscompleted,the
outdoor fan motor will start, and the compressor will turn
off again. In approximately 30 seconds the compressor
will start up again and continue normal operation.
HEAT PUMP MAINTENANCE
CAUTION:
Shut off all electrical power to the unit before
performing any maintenance. Failure to comply
may result in personal injury or death.
Propermaintenanceismostimportanttoachievethebest
performancefromtheapplianceandshouldbeperformed
byaqualifiedservicetechnicianatleastonceayear.Read
the maintenance items below and follow the instructions
for years of safe, trouble free operation.
Regular Cleaning
WARNING:
Do not place combustible material on or against
the unit cabinet. Do not place combustible
materials, including gasoline and any other
flammable vapors and liquids, in the vicinity of
the unit.
•Cleanor replacetheindoorairfilteratthestartofeach
heatingandcoolingseason,andwhenanaccumulation
of dust and dirt is visible on the air filter.
• Removeanyleavesandgrassclippingsfromaround
thecoiloftheoutdoorunit,beingcarefulnottodamage
the aluminum fins.
• Check and remove any obstructions, such as twigs,
sticks, etc.
TROUBLESHOOTING
If the unit fails to operate, check the following:
•Thethermostatisproperlyset.SeeCoolingOperation
for air conditioning or Heating Operation for furnace.
•The unit disconnect fuses are in good condition and
the electrical power to the unit is turned on.
Operating the Heat Pump for Automatic Cooling
and Heating
1.Set the thermostat system switch to AUTO and the
thermostat fan switch to AUTO.See Figure 1.
NOTE: Thermostat styles vary. Some models will
not include the AUTO mode and others will have the
AUTO in place of the HEAT and COOL. Others may
include all three. Refer to the instructions supplied
with your thermostat for specific instructions.
2.Set the thermostat temperature to the desired
temperaturelevel.Theoutdoorunitandtheindoorblower
willthencycleonandoffineithertheheatingorcooling
modeofoperationasrequiredtoautomaticallymaintain
the indoor temperature within the desired limits.
Operating the Indoor Blower Continuously
Thecontinuousindoorbloweroperationistypicallyusedto
circulatetheindoorairtoequalizeatemperatureunbalance
due to a sun load, cooking, or fireplace operation.
Setthe thermostatfanmode toON (Figure1).The indoor
blower starts immediately, and will run continually until
the fan mode is reset to AUTO.
The continuous indoor blower operation can be obtained
with the thermostat system mode set in any position,
including OFF.
Turning the Heat Pump Off
Changethethermostat’ssystemmodetoOFFandthefan
mode to AUTO.See Figure 1.NOTE:The system will not
operate, regardless of the temperature selector setting.
USER INFORMATION

5
INSTALLER INFORMATION
IMPORTANT SAFETY INFORMATION
INSTALLER:Pleasereadallinstructionsbeforeservicing
this equipment. Pay attention to all safety warnings and
any other special notes highlighted in the manual. Safety
markings are used frequently throughout this manual to
designateadegreeorlevelofseriousnessandshouldnot
be ignored.WARNING indicates a potentially hazardous
situationthatifnotavoided,couldresultinpersonalinjury
or death. CAUTION indicates a potentially hazardous
situationthatifnotavoided,mayresultinminorormoderate
injury or property damage.
WARNING:
Shut off all electrical power to the unit before
performing any maintenance or service on the
system.Failuretocomplymayresultinpersonal
injury or death.
WARNING:
Unless noted otherwise in these instructions,
only factory authorized parts or accessory
kits may be used with this product. Improper
installation,service,adjustment,ormaintenance
may cause explosion, fire, electrical shock or
other hazardous conditions which may result in
personal injury or property damage
WARNING:
T5BD split system heat pumps leave the factory
withanitrogenholdingcharge.Followall charg-
ing instructions for maximum unit performance
andefficiency.Somelocalcodesrequirelicensed
installation/servicepersonneltoservicethistype
ofequipment.Refrigerantchargingmustbedone
by qualified personnel familiar with safe and en-
vironmentally responsible refrigerant handling
procedures. Under no circumstances should
the owner attempt to install and/or service this
equipment. Failure to comply with this warning
couldresultinpropertydamage,personalinjury,
or death.
CAUTION:
This unit uses R-22 refrigerant. DO NOT use
any other refrigerant in this unit.Use of another
refrigerant will damage the unit.
WARNING:
The information listed below must be followed
during the installation, service, and operation
of this unit. Unqualified individuals should
not attempt to interpret these instructions or
install this equipment. Failure to follow safety
recommendations could result in possible
damage to the equipment, serious per sonal
injury or death
.
• The installer must comply with all local codes and
regulations which govern the installation of this type
of equipment. Local codes and regulations take
precedence over any recommendations contained in
these instructions. Consult local building codes and
the National Electrical Code (ANSI CI) for special
installation requirements.
• Allelectricalwiringmustbecompletedinaccordance
with local, state and national codes and regulations
and with the National Electric Code (ANSI/NFPA 70)
or in Canada the Canadian Electric Code Part 1 CSA
C.22.1.
• Thisequipmentcontainsliquidandgaseousrefrigerant
underhighpressure.DONOTUSEANYPORTIONOF
THE CHARGE FOR PURGING OR LEAK TESTING.
Installation or servicing should only be performed by
qualifiedtrainedpersonnelthoroughlyfamiliarwiththis
type equipment.
• Fullyannealed,refrigerantgradecoppertubingshould
beusedwheninstallingthesystem.Refrigerantsuction
line tubing should be fully insulated.
• Installation of equipment may require brazing
operations. Installer must comply with safety codes
andwearappropriatesafetyequipment(safetyglasses,
work gloves, fire extinguisher, etc.) when performing
brazing operations.
• Thisunitisdesignedforoutdoorinstallationsonlyand
should be located as descibed on page 6.
• Followallprecautionsintheliterature,ontags,and
on labels provided with the equipment. Read and
thoroughly understand the instructions provided with
the equipment prior to performing the installation and
operational checkout of the equipment.

6
HEAT PUMP INSTALLATION
General Information
Split system heat pumps are designed only for outdoor
rooftop or ground level installations. This unit has been
tested for capacity and efficiency in accordance with
AHRI Standards and will provide many years of safe
and dependable comfort, providing it is properly installed
and maintained. Abuse, improper use, and/or improper
maintenance can shorten the life of the appliance and
create unsafe hazards.
Toachieveoptimumperformanceandminimizeequipment
failure, it is recommended that periodic maintenance be
performed on this unit. The ability to properly perform
maintenance on this equipment requires certain
mechanical skills and tools.
BeforeYou Install this Unit
√Thecooling loadoftheareatobeconditionedmustbe
calculatedandasystemofthepropercapacityselected.
It is recommended that the area to be conditioned be
completely insulated and vapor sealed.
√Checktheelectricalsupplyandverifythepowersupply
isadequateforunitoperation.Thesystemmustbewired
andprovidedwithcircuitprotectioninaccordancewith
localbuildingcodes.Ifthereisanyquestionconcerning
the power supply, contact the local power company.
√Theindoorsection(airhandler,furnace,etc)shouldbe
installed before routing the refrigerant tubing.Refer to
theindoorunit'sinstallationinstructionsforinstallation
details.
√Allunitsaresecurelypackedatthetimeofshipmentand
upon arrival should be carefully inspected for damage
prior to installing the equipment at the job site.Verify
coilfinsare straight.If necessary, combfinsto remove
flattened or bent fins.Claims for damage (apparent or
concealed)shouldbefiledimmediatelywiththecarrier.
√Pleaseconsultyourdealerformaintenanceinformation
andavailabilityof maintenancecontracts.Pleaseread
all instructions before installing the unit.
Locating the Heat Pump
• Survey the job site to determine the best location for
mounting the outdoor unit.See Figure 4 (page 11) for
unit dimensions.
• Overhead obstructions (Figure 2), poorly ventilated
areas, and areas subject to accumulation of debris
should be avoided.
• Sufcientclearanceforunobstructedairowthroughthe
outdoorcoilmustbemaintainedinordertoachieverated
performance.See Figure 2for minimumclearancesto
obstructions.
• Considerationshouldbegiventoavailabilityofelectric
power, service access, noise, and shade.
Packaging Removal
NOTE: To prevent damage to the tubing connections,
carefully remove the carton and user’s manual from the
equipment. Discard the shipping carton.
Ground Level
Ground level installations must be located according to
localbuildingcodesorordinancesandtheserequirements:
• Clearancesmustbeinaccordancewiththoseshown
in Figure 2.
• Asuitablemountingpadmustbeprovidedandseparate
from the building foundation. The pad must be level
and strong enough to support the weight of the unit.
Theslab heightmustbeaminimumof2”(5 cm)above
grade and with adequate drainage. See Figure 2.
Roof Mount
• The method of mounting should be designed so that it
does not overload roof structures or transmit noise to
theinteriorofthestructure.Theroofmustbestructurally
capable of handling the weight of the unit.
• Full perimeter support is required under the unit.
Support must be made of weather resistant materials
and installed prior to unit installation.
• Thesupportmustbebuilttoraisetheunit6"above
the roof.
24" for
Service Access
12" or 18”
See Note
DO NOT
OBSTRUCT
TOP OF UNIT
NOTE: Units require full perimeter clearances. Installer must maintain
18” between two units or 12”between single unit and structure.
6” from Building
or Structure
12" or 18”
See Note
Figure 2. Clearance Requirements
2” Mounting Pad
48”

7
Connecting RefrigerantTubing Between the Indoor
& Outdoor Unit
CAUTION:
This system uses R-22 refrigerant which may
contain mineral oil or POE oil. See page 9 for
additional info. When servicing, cover or seal
openings to minimize the exposure of the
refrigerantsystemtoairtopreventaccumulation
of moisture and other contaminants.
After outdoor and indoor unit placement has been
determined, route refrigerant tubing between the
equipmentinaccordancewithsoundinstallationpractices.
• When connecting refrigerant linesets together, it is
recommended that dry nitrogen be flowing through
the joints during brazing to prevent internal oxidation
and scaling.
• Refrigeranttubingshouldberoutedinamannerthat
minimizesthelengthoftubingandthenumberofbends
in the tubing. If precise forming of refrigerant lines is
required, a copper tubing bender is recommended.
Avoid sharp bends and contact of the refrigerant lines
with metal surfaces.
• Refrigeranttubingshouldbesupportedinamanner
thatthe tubingwillnotvibrateor abradeduring system
operation.
• Tubingshouldbekeptcleanofforeigndebrisduring
installation.
• Everyeffortshouldbemadebytheinstallertoensure
thatthefieldinstalledrefrigerantcontainingcomponents
of the system have been installed in accordance with
these instructions and sound installation practices to
insure reliable system operation and longevity.
• The maximum recommended interconnecting
refrigerantlinelengthsis75ft.andtheverticalelevation
difference between the indoor and outdoor sections
should not exceed 20 ft.
ELECTRICALWIRING
WARNING:
To avoid risk of electrical shock,personal injury,
ordeath,disconnectallelectricalpowertotheunit
before performing any maintenance or service.
The unit may have more than one electrical
supply.
Label all wires prior to disconnection when
servicing the unit. Wiring errors can cause
improper and dangerous operation.
• Allelectricalconnectionsmustbeincompliancewith
all applicable local codes and ordinances, and with
the current revision of the National Electric Code
(ANSI/NFPA 70).
• ForCanadianinstallationstheelectricalconnections
andgroundingshallcomplywith thecurrentCanadian
Electrical Code (CSA C22.1 and/or local codes).
Pre-Electrical Checklist
√Verify that the voltage, frequency, and phase of the
supply source match the specifications on the unit
rating plate.See Table 17 (page 24).
√Verifythattheserviceprovidedbytheutilityissufficient
tohandletheadditionalloadimposedbythisequipment.
Refer to the unit wiring label for proper voltage wiring.
√Verify factory wiring is in accordance with the unit
wiring diagram or Figure 12 (page 23). Inspect for
loose connections.
LineVoltage
• Awiringdiagramislocatedontheinsidecoverofthe
electrical box of the outdoor unit.The installer should
becomefamiliarwiththewiringdiagrambeforemaking
any electrical connections to the outdoor unit.
• An electrical disconnect must be located within
sight of and readily accessible to the unit. This
switch shall be capable of electrically de-energizing
the outdoor unit.
• Line voltage to the unit should be supplied from a
dedicated branch circuit containing the correct fuse
or circuit breaker for the unit. Incoming field wiring
and minimum size of electrical conductors and circuit
COPPERWIRE SIZE — AWG
(1%Voltage Drop)
SupplyWire Length-Feet Supply Circuit
Ampacity
200 150 100 50
6 8 10 14 15
4 6 8 12 20
4 6 8 10 25
4 4 6 10 30
3 4 6 8 35
3 4 6 8 40
2 3 4 6 45
2 3 4 6 50
2 3 4 6 55
1 2 3 4 60
Wire Size based on N.E.C. for 60° type copper conductors.
Table 1. Copper Wire Size
• To maintain the unit's warranty, it is required that a
filter drier be installed when the system is open to
the atmosphere. This includes, but is not limited to,
replacingtheevaporatorand/orcondenserofasystem.
The filter drier must be installed in strict accordance
with the manufacturer’s installation instructions.
• Optional equipment such as liquid line solenoid
valves, low ambient, etc., should be installed in
strict accordance with the manufacturer’s installation
instructions.

8
protectionmustbeincompliancewithinformationlisted
ontheoutdoorunitdatalabel.Anyotherwiringmethods
must be acceptable to authority having jurisdiction.
• Theoutdoorunitrequiresbothpowerandcontrolcircuit
electrical connections. Refer to the wiring diagram /
schematicforidentificationandlocationofoutdoorunit
field wiring interfaces Figure 12 (page 23). Make all
electricalconnectionsinaccordancewithallapplicable
codes and ordinances.
• Overcurrentprotectionmustbeprovidedatthebranch
circuitdistributionpanelandsizedasshownontheunit
rating label and according to applicable local codes.
See the unit rating plate for minimum circuit ampacity
and maximum overcurrent protection limits.
• Providepowersupplyfortheunitinaccordancewiththe
unit wiring diagram, and the unit rating plate.Connect
theline-voltageleadstotheterminalsonthecontactor
inside the control compartment.
• Useonlycopperwireforthelinevoltagepowersupply
tothisunitaslistedinTable1.Usepropercodeagency
listed conduit and a conduit connector for connecting
the supply wires to the unit. Use of rain tight conduit
is recommended.
• 208/230Voltunitsareshippedfromthefactorywired
for 230voltoperation.For 208Voperation,remove the
lead from the transformer terminal marked 240V and
connect it to the terminal marked 208V.
• Optionalequipmentrequiringconnectiontothepower
or control circuits must be wired in strict accordance
of the NEC (ANSI/NFPA 70), applicable local codes,
and the instructions provided with the equipment.
Grounding
WARNING:
The unit cabinet must have an uninterrupted or
unbroken electrical ground to minimize personal
injury if an electrical fault should occur. Do not
use gas piping as an electrical ground!
This unit must be electrically grounded in accordance
with local codes or, in the absence of local codes, with
the National Electrical Code (ANSI/NFPA 70) or the CSA
C22.1Electrical Code.Use the groundinglug providedin
the control box for grounding the unit.
Thermostat Connections
• Thermostatconnectionsshouldbemadeinaccordance
with the instructions supplied with the thermostat and
the indoor equipment.
• Theoutdoor unitis designedto operatefroma24VAC
Class II control circuit.The control circuit wiring must
comply with the current provisions of the NEC (ANSI/
NFPA 70) and with applicable local codes having
jurisdiction.
• The low voltage wires must be properly connected
to the units low voltage terminal block (Figure 3).
GRW2CEOY
Thermostat
Green
Red
White
G
R
Black
O Y
R
C
Air Handler Heat Pump OD
Section
Typical Heat Pump with
OutdoorThermostat and Air Handler
W2
C
W
E
GRW2CEOY
Thermostat
Green
Red
White
G
R
Black
O Y
R
C
Air Handler Heat Pump OD
Section
Typical Heat Pump with
OutdoorThermostat and Air Handler
W2
C
W
E
Figure 3.TypicalThermostat Connections

9
Table 2.Thermostat Wire Gauge
Thermostat
Wire Gauge
RecommendedT-Stat Wire
Unit toT-Stat (Length in FT)
2-Wire
(Heating) 5-Wire (Heating/Cooling)
24 55 25
22 90 45
20 140 70
18 225 110
Recommendedwiregaugeandwirelengthsfortypical
thermostat connections are listed in Table 2.
• The thermostat should be mounted about 5 feet
above the floor on an inside wall. DO NOT install the
thermostat on an outside wall or any other location
whereitsoperationmaybeadverselyaffectedbyradiant
heat from fireplaces, sunlight, or lighting fixtures, and
convective heat from warm air registers or electrical
appliances. Refer to the thermostat manufacturer’s
instructionsheetfordetailedmountingand installation
information.
START UP & ADJUSTMENTS
Pre-Start Check List
√Verify the indoor unit is level and allows proper
condensate drainage.
√Verify the outdoor coil and top of the unit are free from
obstructions and debris, and all equipment access/
control panels are in place.
√Verify air filters are cleaned and properly installed.
√Verify duct work is sealed to prevent air leakage.
√Verifylinevoltagepowerleadsaresecurelyconnected
and the unit is properly grounded.
√Verify low voltage wires are securely connected to the
correct leads on the low voltage terminal strip.
√Verifypowersupplybranchcircuitovercurrentprotection
is sized properly.
√Verify the thermostat is wired correctly.
Start-Up Procedures
Thethermostat'sfunctionmodeshouldbesettoOFFand
the fan mode should be set to AUTO. Close all electrical
disconnects to energize the system.
Air Circulation - Indoor Blower
1.Set the thermostat system mode on OFF and the fan
mode to ON.
2.Verifytheblowerrunscontinuously.Checktheairdelivery
at the supply registers and adjust register openings for
balanced air distribution. If insufficient air is detected,
examine ductwork for leaks or obstructions.
3.Set the thermostat fan mode to AUTO and verify the
blower stops running.
System Cooling
1.Set the thermostat’s system mode to COOL and the
fan mode to AUTO. Gradually lower the thermostat
temperature setpoint below room temperature and
verify the outdoor unit and indoor blower energize.
2.Verifyblowerwheelisspinningindirectionindicatedby
arrow.Feeltheairbeingcirculatedbytheindoorblower
and verify that it is cooler than ambient temperature.
Listenforany unusualnoises.Ifunusualsoundsoccur,
determine the source of the noise and correct as
necessary.
3.Verify HI and LO refrigerant pressures.
4.Allowthesystemtooperateforseveralminutesandthen
set the temperature selector above room temperature.
Verify the fan and compressor cycle off with the
thermostat.NOTE:The blowershould alsostop unless
fan mode is set to the ON position.
System Heating (optional)
1.Set the thermostat's system mode to HEAT and the
temperature mode above room temperature.
2.Verify the optional heating equipment (furnace or
electric heat) and indoor blower energize. Feel the air
being circulated by the indoor blower and verify that
it is warmer than ambient temperature. Listen for any
unusualnoises.Ifunusualsoundsoccur,determinethe
source of the noise and correct as necessary.
Refrigerant Charging
WARNING:
T5BD split system heat pumps leave the
factory with a nitrogen holding charge. DO NOT
operate any unit while it contains a Nitrogen
holding charge. Doing so may damage the units
compressor.Followthesecharginginstructions
for maximum unit performance and efficiency.
Some local codes require licensed installation/
service personnel to service this type of
equipment. Refrigerant charging must be done
by qualified personnel familiar with safe and
environmentallyresponsiblerefrigeranthandling
procedures. Under no circumstances should
the owner attempt to install and/or service this
equipment. Failure to comply with this warning
couldresultinpropertydamage,personalinjury,
or death.
ThisunitmaycontainacompressorwithPOEoilormineral
oil.If the compressor model contains an E before the first
hyphen, then it is a POE oil compressor. If it does not
then it is a mineral oil compressor. (Example:ZR42K5E-
PFV-130isaPOEoilcompressor,whileZR42K5-PFV-130
is a mineral oil compressor).
To properly charge these units:
1.Read all Installation Instructions first.
2.Complete any brazing operations. (e.g. Split system
line-sets)
3. Leakcheckandevacuatethewholesystemusingproper
methods.

10
4.Purge the nitrogen holding charge.
5.Evacuate the unit to 350-500 microns.
6.Allow the unit to remain under vacuum for at least 30
min.
7.Weigh-Intheproperamountofnew(orreclaimed)R-22
refrigerant.Todeterminethe correctamount ofcharge,
refer to the units rating label or the Quick Reference
Data sheet provided with the unit.
• Refrigerant charging charts are applicable only to
matched assemblies of NORDYNE equipment and
listed airflows for the indoor coil. Refer to Figures 5
- 11 (pages 11 - 14) and Tables 3 - 9 (pages 15 - 18)
for correct system charging.
• T5BD outdoor units with indoor coils not listed are not
recommended.Deviations from rated airflows or non-
listed combinations may require modification to the
expansiondeviceandrefrigerantchargingprocedures
for proper and efficient system operation.
• The refrigerant charge can be checked and adjusted
through the service ports provided external to the
outdoor unit. Use only gage line sets which have a
“Schrader” depression device present to actuate the
valve.
Charging an R-22 system in AC mode at outdoor
temperatures above 55° F for optimized sub-cooling of
10° F - 12° F.
1. With the system operating at steady-state, measure
the liquid refrigerant pressure (in psig) at the outdoor
unit service valve.
2. Measure the liquid refrigerant temperature (in
Fahrenheit) at the service valve.
3. Determinetherequiredliquidrefrigerantpressure.Refer
to Tables 10 - 16 (pages 19 - 22) for correct system
charging.
•IfthepressuremeasuredinStep1isgreaterthan
therequiredliquidrefrigerantpressuredeterminedin
Step3,thenthereistoomuchchargeinthesystem.
Remove refrigerant and repeat Steps 1 through 3
until the system is correctly charged.
•IfthepressuremeasuredinStep1islessthanthe
required liquid refrigerant pressure determined in
Step 3, there is too little charge in the system.Add
refrigerant and repeat Steps 1 through 3 until the
system is correctly charged.
HEAT PUMP MAINTENANCE
WARNING:
To prevent electrical shock, personal injury, or
death,disconnect all electrical power to the unit
before performing any maintenance or service.
Theunitmayhavemorethanoneelectricalsupply.
Proper maintenance is important to achieve optimum
performance from the Heat Pump.The ability to properly
perform maintenance on this equipment requires certain
mechanical skills and tools. If you do not possess these
skills, contact your dealer for maintenance. Consult your
localdealerabouttheavailabilityofmaintenancecontracts.
Routine maintenance should include the following:
• Inspectandcleanorreplaceairltersatthebeginning
ofeachheatingandcoolingseason,ormorefrequently
if required.
• Inspectthecondensatedrainandoutdoorcoilatthe
beginningofeachcoolingseason.Removeanydebris.
Cleantheoutdoorcoilandlouversasnecessaryusing
amilddetergentandwater.Rinsethoroughlywithwater.
• Inspecttheelectricalconnectionsfortightnessatthe
beginningofeachheatingandcoolingseason.Service
as necessary.
CAUTION:
The unit should never be operated without a
filterinthereturnairsystem.Replacedisposable
filters with the same type and size.
• Do not attempt to add additional oil to motors
unequipped with oil tubes. The compressor is
hermeticallysealedatthefactoryanddoesnotrequire
lubrication.
REPLACEMENT PARTS
ReplacementpartsareavailablethroughallNordyne distributors.
Please have the complete model and serial number of the unit
when ordering replacement parts.
ELECTRICAL:
Capacitors Temperature Limit Switches
Compressors Thermostats
Contactors Time Delay Relays
Pressure Switches Transformers
Relays MOTORS:
Blower Motor Fan Motor
COMPONENTS:
Blower Assembly Fan Grille
Cabinet Panels Filter/Driers
Expansion Valves

11
Figure 4. Unit Dimensions
Model NumberT5BD- Height -H- Width -W- Depth -D-
018K 27" 303/4" 303/4"
024KA 27" 303/4" 303/4"
030KA 39" 303/4" 303/4"
036K 43" 303/4" 303/4"
042K 39" 303/4" 303/4"
048K 43" 303/4" 303/4"
060K 43" 303/4" 303/4"
DW
H
DO NOT OBSTRUCTTOP OF UNIT
Allow adequate clearance for airflow
REFFRIGERANT CHARGING CHARTS
Figure 5. Charging Chart for 1.5 Ton Units
125
150
175
200
225
250
275
300
325
350
375
75 80 85 90 95 100 105 110 115 120 125 130
Liquid Temperature (F)
Liquid Pressure (psig)
Add refrigerant when below curve
Remove refrigerant when above curve
T5BD-018K Charging Chart
FIGURES &TABLES

12
Figure 6. Charging Chart for 2 Ton Units
T5BD-024KA Charging Chart
150
175
200
225
250
275
300
325
350
75 80 85 90 95 100105 110 115 120125 130
Liquid Temperature (F)
Liquid Pressure (psig)
Add refrigerant when below curve
Remove refrigerant when above curve
Figure 7. Charging Chart for 2.5 Ton Units
T5BD-030KA Charging Chart
150
175
200
225
250
275
300
325
350
75 80 85 90 95 100 105 110 115 120 125 130
Liquid Temperature (F)
Liquid Pressure (psig)
Add refrigerant when below curve
Remove refrigerant when above curve

13
Figure 8. Charging Chart for 3 Ton Units
T5BD-036K Charging Chart
150
175
200
225
250
275
300
325
350
75 80 85 90 95 100 105 110 115 120125 13
01
35
Liquid Temperature (F)
Liquid Pressure (psig)
Add refrigerant when below curve
Remove refrigerant when above curve
Figure 9. Charging Chart for 3.5 Ton Units
T5BD-042K Charging Chart
150
175
200
225
250
275
300
325
350
75 80 85 90 95 100 105 110115 120 125 13
01
35
Liquid Temperature (F)
Liquid Pressure (psig)
Add refrigerant when below curve
Remove refrigerant when above curve

14
Figure 10. Charging Chart for 4 Ton Units
150
175
200
225
250
275
300
325
350
75 80 85 90 95 100105 110115 120 125 130 135
Liquid Temperature (F)
Liquid Pressure (psig)
Add refrigerant when below curve
Remove refrigerant when above curve
T5BD-048K Charging Chart
Figure 11. Charging Chart for 5 Ton Units
150
170
190
210
230
250
270
290
310
330
350
75 80 85 90 95 100105 110115 120125 13
01
35
Liquid Temperature (F)
Liquid Temperature (psig)
Add refrigerant when below curve
Remove refrigerant when above curve
T5BD-060K Charging Chart

15
Shaded boxes indicate flooded conditions.
Rated design values.The suction pressure will vary from design value if indoor air flow, entering dry bulb,
or entering wet bulb temperatures are lower than design.
1.All pressures are listed in psig and all temperatures in ° F
2.Discharge temperatures greater than charted values indicate an undercharged system.
3.In Cooling Mode suction pressure will be lower than design value if indoor air flow, entering dry bulb, or entering
wet bulb temperatures are lower than design.
4.In Heating Mode, charge should be weighed in. It is strongly recommended to verify charge in Cooling Mode
at ambient above 70°F.
REFRIGERANT CHARGINGTABLES - COOLING MODE
Table 3. ChargingTable forT5BD-018K Series (1.5 Ton Units)
Suct.
Press.
OUTDOORTEMPERATURE (° F)
70 75 80 85 90 95 100 105
Liq.
Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp.
73 140 135
75 143 140 155 137
77 145 146 157 143 170 140
79 147 150 160 148 172 145 185 142
81 151 153 162 152 175 150 187 147 200 144
83 166 155 177 154 189 151 202 149 215 147
85 181 157 192 155 204 153 217 151 230 149
87 196 159 207 157 219 155 232 153 244 151
89 199 163 211 161 222 159 234 157 246 154
91 214 165 226 163 237 161 248 158
93 229 167 241 165 252 163
95 244 169 256 167
97 259 172
99
Table 4. ChargingTable forT5BD-024KA Series (2 Ton Units)
Suct.
Press.
OUTDOORTEMPERATURE (° F)
70 75 80 85 90 95 100 105
Liq.
Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp.
71 149 137
73 151 143 164 141
75 154 148 166 146 176 145
77 156 153 169 151 181 150 194 149
79 160 155 171 156 184 155 196 153 209 152
81 175 159 186 159 198 158 211 157 224 156
83 190 162 202 162 213 161 226 160 239 160
85 205 166 217 165 228 164 241 164 254 163
87 208 169 220 169 232 168 243 168 256 167
89 224 173 235 173 247 172 258 171
91 239 177 250 176 262 175
93 254 180 265 180
95 269 184
97

16
Table 5. ChargingTable forT5BD-030KA Series (2.5 Ton Units)
Suct.
Press.
OUTDOORTEMPERATURE (° F)
70 75 80 85 90 95 100 105
Liq.
Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp.
70 143 136
72 145 141 158 139
74 147 147 160 144 173 142
76 150 152 162 149 175 147 188 145
78 153 155 165 154 177 152 190 149 202 147
80 168 157 180 156 192 154 204 152 217 150
82 183 159 195 158 207 156 219 154 232 152
84 198 161 210 160 221 158 234 156 247 154
86 202 165 213 164 225 162 236 160 249 158
88 217 168 228 166 240 164 251 162
90 232 170 243 169 255 167
92 247 173 258 171
94 261 176
96
Table 6. ChargingTable forT5BD-036K Series (3 Ton Units)
Suct.
Press.
OUTDOORTEMPERATURE (° F)
70 75 80 85 90 95 100 105
Liq.
Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp.
71 148 144
73 150 149 164 147
75 152 155 166 152 179 149
77 155 158 168 157 181 154 195 152
79 159 161 171 161 183 159 197 156 210 154
81 174 164 187 163 199 161 212 158 226 156
83 190 166 202 165 214 163 228 161 241 159
85 206 168 218 167 230 165 243 163 257 161
87 209 172 221 171 233 169 245 167 259 165
89 225 174 237 173 249 171 261 169
91 240 177 252 175 264 173
93 256 180 268 178
95 271 182
97
Shaded boxes indicate flooded conditions.
Rated design values.The suction pressure will vary from design value if indoor air flow, entering dry bulb,
or entering wet bulb temperatures are lower than design.
1.All pressures are listed in psig and all temperatures in ° F
2.Discharge temperatures greater than charted values indicate an undercharged system.
3.In Cooling Mode suction pressure will be lower than design value if indoor air flow, entering dry bulb, or entering
wet bulb temperatures are lower than design.
4.In Heating Mode, charge should be weighed in. It is strongly recommended to verify charge in Cooling Mode
at ambient above 70°F.
REFRIGERANT CHARGINGTABLES - COOLING MODE

17
Table 7. ChargingTable forT5BD-042K Series (3.5 Ton Units)
Suct.
Press.
OUTDOORTEMPERATURE (° F)
70 75 80 85 90 95 100 105
Liq.
Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp.
71 144 150
73 146 155 159 152
75 148 161 161 157 175 153
77 152 163 164 162 177 158 191 154
79 155 165 167 164 179 163 193 159 206 156
81 171 167 183 166 195 164 208 160 222 157
83 186 169 198 167 210 165 224 162 237 159
85 202 171 214 169 226 166 239 163 253 160
87 205 174 217 172 229 170 241 167 255 164
89 221 176 233 174 245 171 257 168
91 236 178 248 175 260 172
93 252 180 264 177
95 267 181
97
Table 8. ChargingTable forT5BD-048K Series (4 Ton Units)
Suct.
Press.
OUTDOORTEMPERATURE (° F)
70 75 80 85 90 95 100 105
Liq.
Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp.
69 132 130
71 134 136 149 135
73 136 141 151 140 166 140
75 137 149 153 145 168 145 183 145
77 140 152 154 152 170 150 185 149 200 149
79 158 155 172 155 188 154 203 153 218 153
81 176 158 190 158 205 158 220 157 235 157
83 193 162 207 162 222 162 237 161 252 161
85 197 166 211 166 225 166 239 165 254 165
87 214 170 229 170 243 170 256 169
89 232 174 246 174 260 174
91 250 178 264 178
93 267 183
95
Shaded boxes indicate flooded conditions.
Rated design values.The suction pressure will vary from design value if indoor air flow, entering dry bulb,
or entering wet bulb temperatures are lower than design.
1.All pressures are listed in psig and all temperatures in ° F
2.Discharge temperatures greater than charted values indicate an undercharged system.
3.In Cooling Mode suction pressure will be lower than design value if indoor air flow, entering dry bulb, or entering
wet bulb temperatures are lower than design.
4.In Heating Mode, charge should be weighed in. It is strongly recommended to verify charge in Cooling Mode
at ambient above 70°F.
REFRIGERANT CHARGINGTABLES - COOLING MODE

18
Table 9. ChargingTable forT5BD-060K Series (5 Ton Units)
Suct.
Press.
OUTDOORTEMPERATURE (° F)
70 75 80 85 90 95 100 105
Liq.
Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp. Liq. Press. Dis. Temp.
66 143 146
68 145 152 159 149
70 147 157 161 154 175 152
72 148 164 163 159 178 157 192 155
74 152 167 165 165 180 162 194 159 208 157
76 169 168 182 167 196 164 210 161 224 159
78 185 170 198 168 212 166 226 164 240 161
80 202 172 215 170 228 168 242 165 256 163
82 205 175 218 174 232 172 244 169 258 167
84 222 178 235 176 248 174 260 171
86 238 180 252 178 265 176
88 255 182 268 180
90 271 185
92
Shaded boxes indicate flooded conditions.
Rated design values.The suction pressure will vary from design value if indoor air flow, entering dry bulb,
or entering wet bulb temperatures are lower than design.
1.All pressures are listed in psig and all temperatures in ° F
2.Discharge temperatures greater than charted values indicate an undercharged system.
3.In Cooling Mode suction pressure will be lower than design value if indoor air flow, entering dry bulb, or entering
wet bulb temperatures are lower than design.
4.In Heating Mode, charge should be weighed in. It is strongly recommended to verify charge in Cooling Mode
at ambient above 70°F.
REFRIGERANT CHARGINGTABLES - COOLING MODE

19
OUTDOORTEMPERATURE
(° F)
0 10 20 30 40 50 60
Suc.
Press Liquid
Press. Disch.
Temp. Suc.
Press. Liquid
Press. Disch.
Temp. Suc.
Press. Liquid
Press. Disch.
Temp. Suc.
Press. Liquid
Press. Disch.
Temp. Suc.
Press. Liquid
Press. Disch.
Temp. Suc.
Press. Liquid
Press. Disch.
Temp. Suc.
Press. Liquid
Press. Disch.
Temp.
13 111 113 23 132 120 32 152 127 41 173 134 51 181 149 61 201 172 70 221 195
14 118 111 24 138 118 33 157 125 42 176 132 52 188 146 62 208 167 71 228 188
15 125 109 25 144 116 34 162 123 43 180 130 53 195 143 63 215 163 72 235 182
16 132 107 26 149 114 35 167 121 44 184 128 54 202 140 64 222 158 73 242 176
17 139 105 27 155 112 36 171 119 45 187 126 55 209 138 65 229 154 74 249 170
18 146 103 28 161 110 37 176 117 46 191 124 56 216 135 66 236 149 75 256 164
19 153 101 29 167 108 38 181 115 47 195 122 57 223 132 67 243 145 76 263 158
OUTDOORTEMPERATURE
(° F)
0 10 20 30 40 50 60
Suc.
Press Liquid
Press. Disch.
Temp. Suc.
Press. Liquid
Press. Disch.
Temp. Suc.
Press. Liquid
Press. Disch.
Temp. Suc.
Press. Liquid
Press. Disch.
Temp. Suc.
Press. Liquid
Press. Disch.
Temp. Suc.
Press. Liquid
Press. Disch.
Temp. Suc.
Press. Liquid
Press. Disch.
Temp.
12 120 107 21 135 119 29 150 131 37 165 142 46 169 158 56 184 177 66 200 196
13 127 105 22 141 117 30 155 129 38 169 140 47 176 155 57 191 172 67 207 189
14 134 103 23 147 115 31 160 127 39 173 138 48 183 152 58 198 168 68 214 183
15 141 101 24 153 113 32 165 125 40 176 136 49 190 149 59 205 163 69 221 177
16 148 99 25 159 111 33 169 123 41 180 134 50 197 146 60 212 159 70 228 171
17 155 97 26 165 109 34 174 121 42 184 132 51 204 144 61 219 154 71 235 165
18 162 95 27 171 107 35 179 119 43 187 130 52 211 141 62 226 150 72 242 159
Table 10. ChargingTable forT5BD-018K Series Heat Pump (1.5 Ton Units)
Table 11. ChargingTable forT5BD-024KA Series Heat Pump (2 Ton Units)
REFRIGERANT CHARGINGTABLES - HEATING MODE
Shaded boxes indicate flooded conditions.
Rated design values. Suction pressure will vary from design value if outdoor air flow, entering dry bulb, or entering wet bulb temperatures vary.
1. All pressures are listed psig and all temperatures in °F 2. Discharge temperatures greater than charted values indicate an undercharged system.

20
OUTDOORTEMPERATURE
(° F)
0 10 20 30 40 50 60
Suc.
Press Liquid
Press. Disch.
Temp. Suc.
Press. Liquid
Press. Disch.
Temp. Suc.
Press. Liquid
Press. Disch.
Temp. Suc.
Press. Liquid
Press. Disch.
Temp. Suc.
Press. Liquid
Press. Disch.
Temp. Suc.
Press. Liquid
Press. Disch.
Temp. Suc.
Press. Liquid
Press. Disch.
Temp.
13 115 110 22 137 119 30 159 129 39 181 138 48 191 153 56 211 174 65 230 196
14 122 108 23 143 117 31 164 127 40 185 136 49 198 150 57 218 170 66 237 190
15 129 106 24 149 115 32 169 125 41 189 134 50 205 147 58 225 165 67 244 183
16 136 104 25 155 113 33 174 123 42 192 132 51 212 145 59 232 161 68 251 177
17 143 102 26 161 111 34 179 121 43 196 130 52 219 142 60 239 157 69 258 171
18 150 100 27 167 109 35 183 119 44 200 128 53 226 139 61 246 152 70 265 165
19 157 98 28 173 107 36 188 117 45 203 126 54 233 136 62 253 148 71 272 159
OUTDOORTEMPERATURE
(° F)
0 10 20 30 40 50 60
Suc.
Press Liquid
Press. Disch.
Temp. Suc.
Press. Liquid
Press. Disch.
Temp. Suc.
Press. Liquid
Press. Disch.
Temp. Suc.
Press. Liquid
Press. Disch.
Temp. Suc.
Press. Liquid
Press. Disch.
Temp. Suc.
Press. Liquid
Press. Disch.
Temp. Suc.
Press. Liquid
Press. Disch.
Temp.
13 116 120 22 136 125 31 156 130 40 176 136 49 183 151 59 201 175 68 218 199
14 123 118 23 142 123 32 161 128 41 180 134 50 190 148 60 208 170 69 225 193
15 130 116 24 148 121 33 166 126 42 183 132 51 197 145 61 215 166 70 232 187
16 137 114 25 154 119 34 171 124 43 187 130 52 204 142 62 222 161 71 239 181
17 144 112 26 160 117 35 175 122 44 191 128 53 211 139 63 229 157 72 246 174
18 151 110 27 166 115 36 180 120 45 194 126 54 218 136 64 236 152 73 253 168
19 158 108 28 172 113 37 185 118 46 198 124 55 225 134 65 243 148 74 260 162
Table 12. ChargingTable forT5BD-030KA Series Heat Pump (2.5 Ton Units)
Table 13. ChargingTable forT5BD-036K Series Heat Pump (3 Ton Units)
REFRIGERANT CHARGINGTABLES - HEATING MODE
Shaded boxes indicate flooded conditions.
Rated design values. Suction pressure will vary from design value if outdoor air flow, entering dry bulb, or entering wet bulb temperatures vary.
1. All pressures are listed psig and all temperatures in °F 2. Discharge temperatures greater than charted values indicate an undercharged system.
