Noritz GQ-2457WS-FFA US User manual

SBB80YQ-1
Rev.11/20
Models : NR83DVC (GQ-2457WS-FFA US)
NR83OD (GQ-2457WS US)
TANKLESS GAS WATER HEATER
Owner’s Guide
NORITZ America Corporation
-Donotstoreorusegasolineorotherammablevaporsandliquidsinthe
vicinityofthisoranyotherappliance.
- WHAT TO DO IF YOU SMELL GAS
•Donottrytolightanyappliance.
•Donottouchanyelectricalswitch;donotuseanyphoneinyourbuilding.
•Immediatelycallyourgassupplierfromaneighbor’sphone.Followthe
gassupplier’sinstructions.
•Ifyoucannotreachyourgassupplier,calltheredepartment.
-Installationandservicemustbeperformedbyaqualiedinstaller,service
agencyorthegassupplier.
If the information in this manual is not followed exactly, a re or explosion
may result causing property damage, personal injury, or death.
WARNING
FOR USE IN RESIDENTIAL OR MANUFACTURED HOME APPLICATIONS.
*SBB80YQ*
Thank you for purchasing this Noritz Tankless Gas Water Heater.
Before using, please:
Read this manual completely for operation instructions.
See the warranty registration card (included separately), and then visit
the Noritz website (www.noritz.com/warranty) to register your product.
Keep this manual (and the warranty registration card) where it can be
found whenever necessary.
Installation must conform with local codes, or in the absence of local
codes, the National Fuel Gas Code, ANSI Z223.1/NFPA 54 - latest edition
and/or the Natural Gas and Propane Installation Code CSA B149.1 -
latest edition.
When applicable, installation must conform with the Manufactured
Home Construction and Safety Standard, Title 24 CFR, Part 3280 or the
Canadian Standard CAN/CSA-Z240 MH Mobile Homes, Series M86.
Noritz America reserves the right to discontinue, or change at any
time, the designs and/or specications of its products without notice.
Low NOx Approved
by SCAQMD
14 ng/J or 20 ppm
(Natural Gas Only)

2
Prohibited Don’t
touch.
Don’t
disassemble
the equipment.
Don’t touch
with a wet
hand.
No ame.
High
Temperature.
To prevent damage to property and injury to the user, the icons shown below will be used to warn of
varying levels of danger.
Every indication is critical to the safe operation of the water heater and must be understood and observed.
Potential dangers from accidents during installation and use are divided into the following four
categories. Closely observe these warnings; they are critical to your safety.
Other icons
DANGER
WARNING
CAUTION
DANGER indicates an imminently hazardous situation which,
if not avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
CAUTION used without the safety alert symbol indicates a potentially
hazardous situation which, if not avoided, may result in property damage.
CAUTION
Be sure
to do. Ground.
Electric
Shock.
DANGER
 Iconswarningofrisklevel
ImportantSafetyInformation-1
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
Vaporsfromammableliquidswillexplodeandcatchrecausingdeathorsevereburns.
Do not use or store ammable products such as gasoline, solvents or
adhesives in the same room or area near the water heater.
Prohibited
Keepammableproducts:
1.Farawayfromthewater
 heater.
2.Inapprovedcontainers.
3.Tightlyclosed.
4.Outofchildren’sreach.
Vapors:
1.Cannotbeseen.
2.Vaporsareheavierthanair.
3.Goalongwayontheoor.
4.Canbecarriedfromotherrooms
tothemainburnerbyaircurrents.
HotWaterHeatertemperaturesover125°F(52°C)cancausesevereburns
instantlyordeathfromscalding.
Children, disabled and elderly are at the highest risk of being scalded.
Feel water temperature before bathing or showering.
Temperature limiting valves are available, ask professional person.
Prohibited
(Continued)

3
No ame.
(Continued)
WARNING
Be sure
to do.
Whenagasleakisnoticed:
1. Stopuseimmediately
2. Closethegasvalve
3. [NR83DVC]
 Openwindowsanddoors.
Ifyoudetectabnormalcombustion
orabnormalodors,orduringan
earthquake,tornadoorre:
1. Turno󰀨thehotwatersupply
2. Turno󰀨thepowertothewater
heater
3. Turno󰀨gasandwatersupply
valve.
4. CallthenearestNoritzagent
Be sure
to do.
Donotallowanyonetochangethe
water temperature while hot water is
beingused.
To prevent scalding, do not change the
water temperature to a higher setting.
Prohibited
A.Thiswaterheaterdoesnothave
apilot.Itisequippedwithan
ignitiondevicethatautomatically
lightstheburner.Donottryto
lighttheburnerbyhand.
B. BEFORE OPERATING smell all
aroundthewaterheaterareafor
evidenceofleakinggas.Besure
tosmellnexttotheoorbecause
somegasisheavierthanairand
willsettleontheoor.
 WHATTODOIFYOUSMELLGAS.
•Donottrytolightany
appliance.
•Donottouchanyelectrical
switch;donotuseanyphone
inyourbuilding.
• Immediatelycallyourgas
supplierfromaneighbor’s
phone.Followthegassupplier’s
instructions.
• Ifyoucannotreachyourgas
supplier,calltheredepartment.
C. Useonlyyourhandtoturn
thegasvalveknob.Neveruse
tools.Iftheknobwillnotturnby
hand,don’ttrytorepairit.Call
aqualiedservicetechnician.
Forceorattemptedrepairmay
resultinareorexplosion.
D. Donotusethiswaterheaterif
anyparthasbeenunderwater.
lmmediatelycallaqualied
servicetechniciantoinspectthe
waterheaterandtoreplaceany
damagedparts. (Continued)
Checkthetemperature
oftherunninghotwater
beforeenteringthe
shower.
Checkthetemperature
beforesteppinginto
thebathtub.
High
Temperature.
ExplosionHazard;
Ifthetemperatureandpressurerelief
valveisdrippingorleaking,havea
qualiedservicetechnicianreplaceit.
Donotplugorremovethevalve.
Failure to follow these instructions can
result in fire or explosion, and personal
injury or death
Prohibited
Prohibited
[NR83OD]
DoNotInstallIndoors.
This will cause carbon
monoxide poisoning and
a potential re hazard. Indoor
Prohibited
[NR83DVC]
Do not use the water
heateriftheconcentric
pipeisdisplaced,has
holes,iscloggedoris
corroded.

4
Donotplacetheunitortheueterminal
inanindoorenvironmentbymeansof
adding walls and ceiling (Do not enclose
usingcorrugatedsheets,etc.)
Carbon monoxide poisoning or re may
occur as a result.
ImportantSafetyInformation-2
(Continued)
Ifthisunitwillbeinstalledina
locationwherehairsprayoraerosols
willbeused,locatetheunitina
separate area that is supplied with
freshairfromoutdoors.
Prohibited
Be sure the gas/power
supplied matches the
gasontheratingplate.
Ex.ForNaturalGas
(NR83DVC (GQ-2457WS-FFA US))
Installationandservicemustbe
performedbyaqualiedinstaller,
serviceagencyorthegassupplier.
Be sure
to do.
Be sure
to do.
(Continued)
Prohibited
Do not store or use gasoline or other
ammablevaporsandliquidsinthe
vicinityofthisoranyotherappliance.
Prohibited
Donotplaceoruseaspraycan near
thewaterheaterortheueterminal.
Donotusehairsprayorspray
detergentinthevicinityofthe
heater.
Prohibited
Prohibited
[NR83DVC]
Do not place outdoors
Rain may enter the unit or the
burner re may be blown by the
wind, causing malfunction
or
re as a result.
Prohibited
Donotplacecombustiblessuchas
laundry,newspapers,oilsetc.near
theheaterortheueterminal.
Prohibited
Donotusecombustiblechemicals
suchasoil,gasoline,benzeneetc.in
theneartheheaterortheueterminal.
Prohibited
Prohibited
WARNING
CarbonMonoxidePoisoningHazard.
Do not install this water heater in a
recreationalvehicleoronaboat.
Unit
Flue terminal
Unit
Flue terminal
Leavetheproperclearancebetween
thewaterheaterandnearbyobjects
(trees,timber,boxeswithammable
materialsetc.).
Be sure
to do.
*Indicates suggested clearances for maintenance.
Left side:
Min. 6" (150mm)
Right side:
Min. 6" (150mm)
Upper:
Min. 36" (900mm)
Front:
Sug. 24" (600mm)*
Left side:
Min. 2" (50mm) Right side:
Min. 2" (50mm)
Front:
Sug. 24" (600mm)*
Sug. 3" (75mm)
from vent pipe*
Upper: Min.
12" (300mm)
[NR83OD]
[NR83DVC]

5
(Continued)
Donotallowsmallchildrentoplay
unsupervisedinthebathroom.
Do not allow small children to
bathunsupervised.
Do not touch the power
cordwithwethands.
Electric
Shock.
Don’t touch
with a wet
hand.
Prohibited
ContactNoritzbeforeusingwith
asolarpre-heater.
Contactaqualiedservice
technicianforanynecessary
repairs,serviceormaintenance.
ConsultthenearestNoritzagentif
the water heater location needs to
bechanged.
Don’t
disassemble
the equipment.
Be sure
to do.
Be sure
to do.
CaliforniaProposition65listschemical
substancesknowntothestatetocause
cancer,birthdefects,death,seriousillness
orotherreproductiveharm.Thisproduct
maycontainsuchsubstances,betheir
originfromfuelcombustion(gas,oil)or
componentsoftheproductitself.
CAUTION
Besuretoelectricallygroundthe
unit.
Keeppowercordfreeofdust.
Ground.
Be sure
to do.
Donotusethewaterheaterfor
otherthanhotwatersupply,shower
andbath.
Prohibited
Prohibited
Donotcoverthewaterheaterand
theueterminal,storetrashor
debrisnearit,orinanywayblock
theowoffreshairtotheunit.
Iftheunitisinstalledinalocationwith
veryhighhumidity,condensatemayform
inside the unit and/or cause incomplete
combustion,damagetotheelectrical
components,orelectricleakage.
Donotturno󰀨thewaterheater
whilesomeoneisbathing.
Donotuseabrokenormodied
powercord.Donotbind,bendor
stretchpowercords.
Donotscratch,modify,orsubject
themtoimpactorforce.
Donottouchtheueterminal
and concentric pipe during or
immediatelyafteroperationofthe
waterheater.
Do not install in locations where
excessivedustordebriswillbe
intheair.
Prohibited
Prohibited
Don’t
touch.
Prohibited
Be sure
to do.
Topreventburnsorscalding,
turno󰀨thepowerbuttonandwait
untiltheequipmentcoolsbefore
performingmaintenance.
Thegasconversionkitshallbeinstalledbya
qualiedserviceagencyinaccordancewith
themanufacturer’sinstructionsandall
applicablecodesandrequirementsofthe
authorityhavingjurisdiction.The
informationintheinstructionsmustbe
followedtominimizetheriskofreor
explosionortopreventpropertydamage,
personalinjury,ordeath.Thequalied
serviceagencyisresponsiblefortheproper
installationofthiskit.Theinstallationisnot
properandcompleteuntiltheoperationof
theconvertedapplianceischeckedas
speciedinthemanufacturer’sinstructions
suppliedwiththekit.
[NR83OD] [NR83DVC]

6
ImportantSafetyInformation-3
CAUTION
Donotdrinkwaterthathasbeeninsidethe
unitforanextendedperiodoftime.Donot
drinktherstuseofhotwaterfromthe
unitinthemorning.
Cleanthelteronthewaterinletas
frequentlyasrequiredbythequalityof
yourlocalwater.( p.20andp.21)
Keeptheareaaroundtheunitclean.
If boxes, weeds, cobwebs, cockroaches etc. are in
the vicinity of the unit, damage or re can result.
Donotinstalltheequipmentwherethe
exhaustwillblowonwallsorwindows.
Problemsresultingfromscaleformation
arenotcoveredbythewarranty.
Thisunitisonlyapprovedforinstallation
upto4500ft.(1350m)abovesealevel.
For installations at higher elevations, contact Noritz
America for Instructions.
Checkignitionduringuseandextinction
afteruse.
Do not run water through the unit when
unitisnoton.
When discharging hot water, make sure the unit is ON.
If water is run through the unit with the unit
OFF, water may condense inside the unit and cause
incomplete combustion or damage to the internal
electrical components.
For single-handle xtures, you’d turn the handle to
the left.
Ifthewatersupplyisinexcessof12grains
per gallon (200 mg/L) of hardness, acidic
or otherwise impure, treat the water with
approved methods in order to ensure full
warrantycoverage.( p.21) Preventingdamagefromfreezing( p.18)
Damage can occur from frozen water within the
device and pipes even in warm environments.
Be sure to read below for appropriate measures.
Repairs for damage caused by freezing are not
covered by the warranty.
Takenecessarymeasurestoprevent
freezingofwaterandleakageofgaswhen
leavingtheunitunusedforlongperiodsof
time.( p.19)
Donotusepartsotherthanthosespecied
forthisequipment.
Ifitissnowing,checktheairinlet,ue
terminalforblockage.
DonotdisassembletheRemoteController.
Donotusebenzene,oilorfatdetergents
tocleantheRemoteController.
This may cause deformation.
DonotgettheRemoteControllerwet.
Although it is water resistant, too much water can
cause damage.
Do not splash water on the Remote
Controller.DonotexposetheRemote
Controllertosteam.
Do not locate the Remote Controller near stoves or
ovens, this may cause damage or failure.

7
 ImportantSafetyInformation....................................................................... 2
Contents......................................................................................................... 7
General Parts
Main Unit.................................................................................................... 8
Remote Controller.................................................................................... 10
Initial Operation............................................................................................ 11
How to Use
Setting and Using the Water Heater........................................................ 12
Flow Meter Alarm...................................................................................... 14
Muting the Remote Controller.................................................................. 16
 AdjustingtheMaximumOutputTemperature........................................ 17
 PreventingDamagefromFreezing............................................................. 18
Regular Maintenance................................................................................... 20
 Troubleshooting........................................................................................... 22
 Follow-upService........................................................................................ 26
 Specications............................................................................................... 28
Contents

8
NR83DVC (GQ-2457WS-FFA US)
(IndoorWallMounted,PowerVent/SealedModel)
* Theaboveillustrationshowsanexampleofinstallation.
The exact installation conguration may be slightly di󰀨erent.
Main Unit
FrontCover
WaterSupplyValve
GasSupplyValve
WaterDrainValve
(with Water Filter)
(Inside Water Inlet)
(p.20)
In this Owner’s Guide, this
panle will be referred to as
the “Remote Controller”.
PressureReliefValve
GeneralParts-1
Operation Panel
Concentric Pipe

9
Main Unit
NR83OD (GQ-2457WS US)
(OutdoorWallMounted,PowerVentedModel)
Air Inlet
GasSupplyValve
PressureReliefValve
ExhaustVent
FrontCover
WaterDrainValve
(with Water Filter)
(Inside Water Inlet)
(p.20)
WaterSupplyValve
* Theaboveillustrationshowsanexampleofinstallation.
The exact installation conguration may be slightly di󰀨erent.

10
RemoteController(RC-7651M)
For setting the hot
water temperature,
the ow meter alarm,
and other settings.
PowerOn/O󰀨Button
For turning the
heater on and o󰀨.
Flow Meter Alarm Set Button
For setting the ow
meter alarm.
(p.14-15)
Setting Buttons
* Before use, remove the protective sheet from the Remote Controller surface.
Temperature Setting
(Ex.:115°F)
Flow Meter Setting
The display will ash
after hitting the ow
meter alarm set button.
(p.15)
Error Code
When this indicator is lit,
the hot water temperature
can be set. (p.12)
Whatisactuallydisplayeddependsonhowthewaterheaterisset.
A number will ash if
a failure occurs.
(p.25)
PriorityIndicator
Burner On Indicator
When burning, the
indicator is lit.
( p.13and15)
Note: As shipped from the factory, the remote controller is set to display in °F and gallons.
To adjust the display to °C and liters, refer to the Installation Manual.
General Parts-2
