Nortek Security & Control GoControl GD00BLE-1 User manual

GD00BLE-1
EXCLUSIVELY
FOR WALMART ©
GARAGE DOOR
OPENER
REMOTE COMMAND
TRANSCEIVER
with TILT SENSOR
Installation Instructions
1PRODUCT DESCRIPTION 2SAFETY NOTES
3PRODUCT COMPONENTS 4TILT SENSOR INSTALLATION AND BATTERY 5PAIRING TILT SENSOR & RESETTING TO FACTORY DEFAULTS
PRINTER’S INSTRUCTIONS:
INSTR,INSTL,GD00BLE-1 - P/N: 10026532 X8 - INK: BLACK - MATERIAL: 20 LB. MEAD BOND - SIZE: 11.000” X 8.500” - TOL. +/-.125" - SCALE: 1-1 - FOLDING: 2-FOLD ALTERNATE - SIDE 1 OF 2
GD00BLE-1
POWER
INPUT
JACK
WARNING
LIGHT
LINK
BUTTON
CONNECTION
WIRES
MOUNTING SCREWS
AND ANCHORS
FOR GD00BLE-1
POWER
SUPPLY
TILT
SENSOR
STATUS
INDICATOR
OPTIONAL
ADJUSTABLE
GD00BLE-1 MOUNTING
BRACKET
SCREWS AND
MOUNTING TAPE
FOR TILT SENSOR
WIRE
TIES
SCREW AND
MOUNTING HARDWARE
FOR ADJUSTABLE
BRACKET
WALL
OUTLET
POWER
SUPPLY POWER
INPUT
JACK
LINK
BUTTON
GD00BLE-1
CR2032
PLUS SIDE UP !!!
The system will notify you
when the battery is low,
replace the battery with
a type CR2032 coin cell
Insert the
battery
into the
transmitter
To open the case, twist
a small screwdriver
in case slot
SLOT
Use double sided tape or
the two mounting screws supplied
(drill 1/16" pilot holes if required)
POST ON
BOTTOM
"UP"
ARROWS
Snap the sensor onto
the mounting plate
To activate the tilt sensor,
remove the battery protection pull strip
2
ARROWS ON PLATE
& SENSOR POINT UP
LOW BATTERY REPLACEMENT
1
2
1
3
Attach the mounting plate
to the top panelof the door
GD00BLE-1 Summary of Operation
• GD00BLE-1 connects to the garage
door opener’s pushbutton wall console
terminals.
• A wireless tilt sensor mounts on garage
door and reports door’s position to
GD00BLE-1.
• GD00BLE-1 uses BLE for communication
to open or close the garage.
• A warning indicator light ashes and a
beeper sounds for 5 seconds before the
door begins to move.
• If the door does not completely open or
close, a second open or close command
can be sent after 30seconds.
• If the door does not completely open
or close after the second attempt, the
GD00BLE-1 operation is suspended until a
local garage door pushbutton is activated.
WARNING
This operator system is equipped with an unattended
operation feature. This door could move unexpectedly. NO
ONE SHOULD CROSS THE PATH OF A MOVING DOOR!
WARNING
The Remote Command Transceiver must be mounted in the
garage, in sight of the garage door, where the visual and audible
movement warning indicators can be clearly seen and heard.
WARNING
Do not install the Remote Command Transceiver on garage
door operators manufactured prior to 1993 (models without
an operational safety beam entrapment detection system).
WARNING
This system can be installed on sectional type doors only per
(UL-325). DO NOT INSTALL ON ONE-PIECE DOORS!
The GD00BLE has already been set to factory defaults and pre-paired with the
tilt sensor. NO RESET OR PAIRING IS REQUIRED. The following instructions are
provided for reference only
• Quickly pressing the LINK button 5 times will reset the GD00BLE to the factory
defaults (Tilt pairing will be preserved).
• Long pressing with LINK button (3-5 seconds) until an audible beep is heard will
re-pair/learn the Tilt Sensor.
Please download the Walmart©InHome
app from the Apple or Android PlayStore.
Reserved for Bluetooth QR Code
Reserved for HomeKit QR Code and labelAvailable if needed
Reserved for
Walmart URL pointer
on-boarding text and
QR Code

6GD00BLE-1 MOUNTING 7GD00BLE-1 CONNECTIONS 8SYSTEM OPERATION & SETUP
9OPERATION NOTES
1. The warning light will ash and the warning beeper will sound for ve seconds
before the door opener is activated. STAY CLEAR OF THE DOOR AND DOOR
OPENER. THEY ARE ABOUT TO MOVE!
2. If the door does not completely open or close after remote activation, the
GD00BLE-1 will allow user to try to operate the door one more time. If the
second attempt fails, the GD00BLE-1 will go into lock-out mode.
3. If the GD00BLE-1 is in lock-out mode and will not accept remote commands,
activate the door from the pushbutton wall console.
4. Once the GD00BLE-1 has initiated the movement of the garage door, another
command cannot be sent for 30 seconds. This eliminates the chance of
“bouncing” the garage door and possibly damaging the garage door opener.
10 TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION
The GD00BLE-1
ashes and
beeps when
activated but
the door does
not move.
Obstruction
blocking the door
or incorrect wiring.
1. Make sure that there are no obstacles
preventing the door from moving.
2. Make sure that the GD00BLE-1 connection
wires are connected to the proper terminals
on the garage door opener. Trace the wires
from the garage door opener’s pushbutton
wall console to the door opener. This is where
the GD00BLE-1 connection wires should be
connected.
The GD00BLE-1
ashes and
beeps when
activated but
the door does
not move.
The tilt sensor
signal is not being
received by the
GD00BLE-1.
1. Pair the tilt sensor with the GD00BLE-1 Garage
Door Controller.
a. Press and hold the pair button on the side
of the GD00BLE-1 main unit for about 7
seconds. It will emit a short chirp.
b. Release the button.
c. Rotate the tilt sensor 90 degrees to trigger a
transmission. A short chirp should be heard.
d. If a short short chirp is not heard, rotate the
tilt sensor again.
2. Make sure the tilt sensor is mounted correctly
on the garage door, with the arrow pointing up.
3. Make sure the battery pull tab has been
removed from the tilt sensor.
4. Replace the battery in the tilt sensor.
Walmart Nortek Smart Garage Door Controller One (1) Year Limited Warranty
WALMART as the seller of the Nortek Smart Garage Door Controller (the “Product”) provides this limited warranty against
defects in materials and/or workmanship under normal use for a period of ONE (1) YEAR from the date of purchase by
the original purchaser (“Warranty Period”). If a defect arises and valid claim is received within the Warranty Period, then
as your sole remedy (and WALMART’s sole liability), WALMART will either 1) repair the defect at no charge, using new or
refurbished replacement parts, or 2) replace the Product with a new product that is functionally equivalent to the original,
in each case within 30 days following receipt of the returned Product. A replacement product assumes the remaining
warranty of the original Product. When a Product is exchanged, any replacement item becomes your property and the
replaced Product or part becomes WALMART property. Software and rmware upgrades, modications, patches and/or
new releases provided as part of the Product and InHome App Support shall not extend the One (1) Year Limited Warranty.
Obtaining Service: Please contact us at 1-833-235-2111
REGULATORY NOTICES
Changes or modications not expressly approved by the manufacturer could void the user’s authority to operate the equipment.
Les changements ou modications non approuvés expressément par la partie responsable de la conformité pourrait
annuler l’autorité de l’utilisateur à faire fonctionner l’équipement.
This equipment has been tested and found to comply with the limits for Class B Digital Device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures.
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
We, Nortek Security & Control, LLC of 5919 Sea Otter Place, Carlsbad, CA 92010, declare under our sole responsibility that
the device, GD00BLE-1 complies with Part 15 of the FCC rules.
This device complies with Part 15 of the FCC Rules and Industry Canada license exempt standard(s). Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference received that may cause undesired operation.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence.
L’exploitatio n est autorisée aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’e
n compromettre le fonctionnement.
This Class B digital apparatus complies with Canadian ICES-003
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada
KEEP AWAY FROM SMALL CHILDREN. IF BATTERY IS SWALLOWED, PROMPTLY SEE A DOCTOR. DO NOT TRY TO RECHARGE
THIS BATTERY. DISPOSAL OF USED BATTERIES MUST BE MADE IN ACCORDANCE WITH THE WASTE RECOVERY AND RECYCLING
REGULATIONS IN YOUR AREA.
The GD00BLE-1 typically
mounts on the ceiling
near the opener and
the power outlet
Tilt sensor
mounted on
the top panel
of the door
THE GD00BLE-1 WARNING
LAMP MUST BE VISIBLE IN
ALL DOOR POSITIONS
3/16" HOLES
FOR ANCHORS
Use the four screws
and anchors to mount
the GD00BLE-1 above
the opener
REMOVE POWER FROM THE
GARAGE DOOR OPENER
BEFORE CONTINUING
! WARNING !
1
PUSHBUTTON
PUSHBUTTON
GARAGE
DOOR
OPENER
Connect the GD00BLE-1 connection
wires to the pushbutton wall console
terminals on the garage door opener.
The terminals may be named "PWC", "WC",
"PB", "PUSHBUTTON", or "RED and WHITE".
Terminal names and locations vary by model.
DO NOT DISCONNECT
ANY WIRES CURRENTLY
CONNECTED TO THE
GARAGE DOOR OPENER !!!
USE WIRE TIES TO SECURE
EXCESS WIRING CLEAR
OF ALL MOVING PARTS
OF THE GARAGE
DOOR AND OPENER
Either wire can
connect to either
terminal
Plug the power cord
Plug into the outlet.
into the power input
jack on the GD00BLE-1
2
1
3
FLASH
FLASH
FLASH
BEEP
BEEP
BEEP
Use the previously downloaded
Walmart InHome app to configure,
activate and operate your garage door.
The Walmart InHome app QR code can
be found in this set of instructions in
panel 1. The Bluetooth QR code can be
found in Panel 5.
The GD00BLE-1 will activate
the door opener and open
or close the door
3
Optional HomeKit configuration is supported.
The HomeKit app QR code can be found in
Panel 1.
6
The GD00BLE-1 will beep and
flash for five seconds before
the door moves
4
5
Restore power to your
garage door opener
1
To synchronize the system,
use the garage door opener's
pushbutton to manually open
and close the door
2
STAY CLEAR
OF THE DOOR !!!
STAY CLEAR
OF THE DOOR !!!
Copyright © 2019 Nortek Security & Control LLC 10026532 X8
GD00BLE-1 Specications
Power Supply: Input: 120 VAC, 0.35 A, Output: 12 VDC, 1 A
Operating Temperature: -4°—122° F (-20°—50° C)
Audible Alarm: 85 db @ 10 feet
Strobe: 360 Lumens
Communications: Bluetooth
Mounting: Screws and anchors to the ceiling.
Tilt Sensor Specications
Power Supply: Type CR2032 Coin Cell Battery
Operating Temperature: -4°—122° F (-20°—50° C)
Battery Life: 24 Months (typical)
Communications: Proprietary 345 MHz
Range: 100 feet line-of-sight to GD00BLE-1
Mounting to Garage Door: Double-sided tape or two mounting screws
(Specications subject to change without notice)
