North Ridge Pumps Hose pump Series User manual

Product Specification Sheet
X-Cel House, Chrysalis Way, Langley Bridge, Eastwood, Nottinghamshire NG16 3RY
Tel: [phone] | Email: [email protected] | Website: www.northridgepumps.com
Hose Pump Series
SP/10, SP/15, SP/20, SP/25, SP/32,
SP/40, SP/50, SP/65, SP/80 and SP/100
Manual

3
Contents
1GENERAL.........................................................................................................................6
1.1 How to use this manual..............................................................................................6
1.2 Other supplied documentation ...................................................................................6
1.3 Service and support ...................................................................................................6
1.4 Used products and the environment ..........................................................................6
2SAFETY ............................................................................................................................7
2.1 Pictograms .................................................................................................................7
2.2 Intended use ..............................................................................................................7
2.3 Responsibility.............................................................................................................7
2.4 Qualification of the user .............................................................................................8
2.5 Regulations and instructions......................................................................................8
3WARRANTY CONDITIONS..............................................................................................9
4DESCRIPTION................................................................................................................10
4.1 Identification of the product......................................................................................10
4.2 Construction of the pump.........................................................................................10
4.3 Operation of the pump .............................................................................................11
4.4 Pump hose...............................................................................................................12
4.4.1 General .............................................................................................................12
4.4.2 Hose compression force adjustment (shimming). (not applicable for series
SP/10, SP/15 and SP/20). ................................................................................12
4.4.3 Lubrication and cooling.....................................................................................12
4.4.4 Gearbox ............................................................................................................12
4.4.5 Electric motor....................................................................................................13
4.4.6 Available options...............................................................................................13
5INSTALLATION..............................................................................................................14
5.1 Unpacking ................................................................................................................14
5.2 Inspections...............................................................................................................14
5.3 Installation conditions...............................................................................................14
5.3.1 Ambient conditions ...........................................................................................14
5.3.2 Set-up ...............................................................................................................14
5.3.3 Pipework ...........................................................................................................14
5.3.4 Pulsating flow....................................................................................................15
5.3.5 Pumping pressure (counter pressure) ..............................................................15
5.4 Lifting and moving the pump....................................................................................15
5.5 Placing the pump .....................................................................................................16

4
6COMMISSIONING ..........................................................................................................17
6.1 Preparations.............................................................................................................17
6.2 Commissioning ........................................................................................................17
7MAINTENANCE..............................................................................................................18
7.1 Maintenance and periodic inspections.....................................................................18
7.2 Cleaning pump hose ................................................................................................19
7.3 Changing lubricant ...................................................................................................19
7.4 Changing oil in gearbox ...........................................................................................19
7.5 Replacing pump hose ..............................................................................................19
7.5.1 Hose removal....................................................................................................19
7.5.2 Removal of lubricant .........................................................................................19
7.5.3 Removal of piping .............................................................................................19
7.5.4 Loosening of hose clamps ................................................................................19
7.5.5 Removal of flanges and/or inserts ....................................................................19
7.5.6 Removal of flange brackets ..............................................................................20
7.5.7 Removal of the hose.........................................................................................20
7.5.8 Cleaning of pump casing ..................................................................................20
7.5.9 Tighten drain plug (not applicable for SP/10, SP/15 and SP/20)......................20
7.5.10 Preparation of pump hose ................................................................................20
7.5.11 Insertion of the hose .........................................................................................20
7.5.12 Place hose clamps............................................................................................20
7.6 Hose connection ......................................................................................................20
7.6.1 Mount flange brackets (SP/25 to SP/100) ........................................................21
7.6.2 Positioning of pump hose .................................................................................21
7.6.3 Tighten hose clamps.........................................................................................21
7.6.4 Tighten bolts of all flange brackets ...................................................................21
7.6.5 Filling with lubricant ..........................................................................................21
7.6.6 Finally ...............................................................................................................21
7.7 Exchanging replacement parts ................................................................................22
7.7.1 Replacing pressing shoes (not applicable for SP/10, SP/15 and SP/20) .........22
7.7.2 Replacing seal and bearings ............................................................................22
7.8 Hose compression force adjustment (shimming) (not applicable for SP/10, SP/15
and SP/20). ..............................................................................................................23
7.9 Fitting options...........................................................................................................24
7.9.1 Fitting a high-level float switch..........................................................................24
7.9.2 Fitting a low level float switch (not applicable for SP/10, SP/15 and SP/20) ....24
8STORAGE ......................................................................................................................25
8.1 Hose pump...............................................................................................................25
8.2 Pump hose...............................................................................................................25
9TROUBLESHOOTING....................................................................................................26
10 SPECIFICATIONS ......................................................................................................28
10.1 Pumphead................................................................................................................28

5
10.1.1 Performance .....................................................................................................28
10.1.2 Materials ...........................................................................................................28
10.1.3 Lubricant ...........................................................................................................28
10.1.4 Surface treatment .............................................................................................29
10.1.5 Weights and dimensions...................................................................................29
10.1.6 Torques.............................................................................................................30
10.1.7 Shimming..........................................................................................................31
10.1.8 Parts list: SP/10-SP/15 .....................................................................................32
10.1.9 Parts list: SP/20 H-L .........................................................................................34
10.1.10 Parts list: SP/25, SP/32, SP/40 and SP/50 ...................................................36
10.1.11 Parts list: SP/65, SP/80 and SP/100 .............................................................39
10.1.12 Dimensional drawings ...................................................................................43
10.1.13 EG-Declaration of Conformity .......................................................................46
10.1.14 Manufacturer’s Declaration ...........................................................................47
10.1.15 Product Use and Decontamination Declaration ............................................48

6
1 GENERAL
1.1 How to use this manual
This manual is intended as a reference book by means of which qualified users are able to
install, commission and maintain the hose pumps mentioned on the front cover.
1.2 Other supplied documentation
In this manual the documentation of pump components i.e. engines, etc. is not included. But
if the documentation of a certain component is part of this manual, you must respect and act
according the instructions as given in the supplied documentation.
1.3 Service and support
For information with respect to specific adjustments, installation, maintenance or repair jobs
which fall beyond the scope of this manual, contact your Bredel representative. Make sure
you have the following data at hand:
•serial number hose pump
•article number pump hose
You will find these data on the identification plates or stickers of the pumphead and the pump hose. See “Description”:
“Identification of the product”, § 4.1.
1.4 Used products and the environment
ENVIRONMENT
Enquire with your local government about the possibilities for reuse or
environment friendly processing of packaging materials, (contaminated)
lubricant and oil.
Always observe the local rules and regulations with respect to processing
(non reusable) parts of the hose pump.

7
2 SAFETY
2.1 Pictograms
In this manual the following symbols are used:
WARNING
Procedures which, if not carried out with the necessary care, may result
in serious damage to the hose pump or in serious bodily harm.
CAUTION
Procedures which, if not carried out with the necessary care, may result
in serious damage to the hose pump, the surrounding area or the
environment.
Remarks, suggestions and advice.
2.2 Intended use
The hose pump is exclusively designed for pumping suitable products. Every other or further
use is not in conformance with the intended use. (1)
The manufacturer cannot be held responsible for damage or harm resulting from this. The
hose pump is designed in conformance with the valid standards and directives.
Only use the pump in conformance with the intended use described above. If you want to
change the application of your hose pump, contact your Bredel representative first.
cThe “Intended use” as laid down in EN 292-1 is “… the use for which the technical product is intended in
accordance with the specifications of the manufacturer, inclusive of his indications in the sales brochure”. In
case of doubt it is the use which appears to be its intended use judging from the construction, execution and
function of the product. Observing the instructions in the user’s documentation also belongs to intended use.
2.3 Responsibility
The manufacturer does not accept any responsibility for damage or harm caused by not
(strictly) observing the safety regulations and instructions in this manual and the also
supplied documentation, or by negligence during installation, use, maintenance and repair of
the hose pumps mentioned on the front cover. Depending on the specific working conditions
or accessories used, additional safety instructions can be required.
Immediately contact your Bredel representative, if you noticed a potential danger while using
your hose pump.
WARNING
The user of the hose pump is always fully responsible for observing the local
valid safety regulations and directives. Observe these safety regulations and
directives when using the hose pump.

8
2.4 Qualification of the user
The installation, use and maintenance of the hose pump is only reserved for well trained and
qualified users. Temporary staff and persons in training may only use the hose pump under
the supervision and responsibility of well trained and qualified users.
2.5 Regulations and instructions
•Everyone who will work with the hose pump must know the content of this manual and
observe the instructions with great care.
•Never change the order of the actions to be carried out.
•Always store the manual near the hose pump.

9
3 WARRANTY CONDITIONS
The manufacturer offers a one–year warranty on proper workmanship of all parts of the hose
pump. Exclusion is made for normal wear and tear of consumables, such as pump hoses,
lubricant, hose clamps, pressing shoes, ball bearings, wear ring, an seals, or parts which
have been misused or damaged through negligence.
This manufacturer’s warranty is null and void for any user who has substituted the parts of an
alternate manufacturer into a Bredel hose pump.
Damaged parts which are covered by the applicable warranty conditions can be returned to
the manufacturer. The parts must be accompanied by a fully filled in and signed safety form,
as present in the back of this manual. The safety form must be applied to the outside of the
shipping carton. Parts which have been contaminated or which have been corroded by
chemicals or other substances which can pose a health risk, must be cleaned before they
are returned to the manufacturer.
Furthermore, it should be indicated on the safety form which specific cleaning procedure has
been followed, and it should be indicated that the equipment has been decontaminated. The
safety form is required at all items, even if the parts have not been used.
Warranties purporting to be on behalf of Bredel Hose Pumps B.V. made by any person,
including representatives of Bredel Hose Pumps B.V., its subsidiaries, or its distributors,
which do not accord with the terms of this warranty shall not be binding upon
Bredel Hose Pumps B.V. unless expressly approved in writing by a Director or Manager of
Bredel Hose Pumps B.V.

10
4 DESCRIPTION
4.1 Identification of the product
The hose pump can be identified based on the identification plates or stickers on:
A. Pump hose
B. Pumphead
C. Gearbox
D. Electric motor
E. Pump hose
The identification plate on the pumphead contains the following data:
A. Type number
B. Serial number
If applicable: the identification plate on the gearbox contains (depending on the brand) the
following data:
A. Article number
B. Serial number
C. Type number
D. Reduction
E. Number of rounds per minute
F. Oil type upon delivery
If applicable: the identification plate on the electric motor contains (depending on the brand)
the following data:
A. Type number
B. Serial number
C. Article number
D. Mains
E. Frequency
F. Speed
G. Power
H. Power factor
I. Current
The identification sticker on the pump hose contains the following data:
A. Order number
B. Internal diameter
C. Type of material of inner liner
D. Maximum permissible working pressure
4.2 Construction of the pump
A. Pump hose
B. Pump housing
C. Rotor
D. Pressing shoes
E. Cover
F. Support
G. Gearbox
H. Electric motor

11
4.3 Operation of the pump
The heart of the pumphead consists of a specially constructed pump hose which lies
contorted against the inside of the pump housing. Both ends of the hose are connected to
the suction and discharge lines by means of a flange construction. A bearing-mounted rotor
with two facing pressing shoes is in the center of the pumphead.
In phase 1 the lower pressing shoe compressed the pump hose by the rotational movement
of the rotor, forcing the fluid through the hose. As soon as the pressing shoe has passed, the
hose recovers to its original shape due to the mechanical properties of the material.
In phase 2 the product is drawn into the hose by the (continuous) turning motion of the rotor.
In phase 3, the second pressing shoe will subsequently compress the pump hose. Due to the
continuous rotating movement of the rotor not only new product is sucked in, but also the
already present product is pressed out by the pressing shoe. When the first pressing shoe
runs from the pump hose, the second pressing shoe has already closed the pump hose and
the product is prevented from flowing back. This method of liquid displacement is also known
as the “positive displacement principle”.

12
4.4 Pump hose
4.4.1 General
The pump hose is made of special rubbers, reinforced with nylon cords and is constructed as
follows:
A. Outer extruded layer made of natural rubber
B. Nylon reinforcement layers
C. Inner extruded liner
The pump hose liner material should be chemically resistant with the product to be pumped.
Dependent on the specific requirements of your application a corresponding pump hose must
be selected. For each pump model various hose types are available.
The material of the inner liner of the pump hose determines the hose type. Each hose type is
marked by a unique colour code.
Hose type Material Colour code
NR Natural rubber Purple
NBR Perbunan Yellow
EPDM EPDM Red
CSM Hypalon©Blue
Consult your Bredel representative for more detailed information about the
chemical and temperature resistance of pump hoses.
The Bredel pump hoses have been carefully machined, therefore there are minimum
tolerances in wall thickness. It is very important to guarantee the correct compression of the
pump hose, because:
•When the compression is too high, it creates a too high load of the pump and pump
hose, which will result in a reduction of the life of the pump hose and bearings.
•When the compression is too low, this will result in loss of capacity and backflow.
Backflow results in a reduction of the life of the pump hose.
4.4.2 Hose compression force adjustment (shimming). (not applicable for series SP/10,
SP/15 and SP/20).
In order to achieve optimal life of the pump hose, the compression force of the pump hose
can be adjusted by placing a number of shims under the pressing shoes.
The shims are fitted between the rotor and the pressing shoe. The number of shims will vary
for each counter-pressure situation. See “Hose compression force adjustment” § 7.8 and
“Shimming table” §10.1.7. Caution: insufficient shimming reduces hose life.
4.4.3 Lubrication and cooling
The pumphead, in which the rotor and pump hose can be found are filled with a special
lubricant.The lubricant lubricates the movement between the hose and the pressing shoes
and transfers the generated heat from the hose to the pump housing and the cover.
4.4.4 Gearbox
The hose pump types described in this manual use various types of gearbox units. The
gearboxes are fitted with a foot rest.

13
4.4.5 Electric motor
The hose pump type described in this manual use various types of motors. If the pump is to
be used in potentially explosive atmospheres, please contact your Bredel representative, as
these type of pumps are not in compliance with ATEX.
4.4.6 Available options
The following options are available for the hose pump:
•High (lubricant) level float switch
•Low (lubricant) level float switch (not applicable for SP/10, SP/15 and SP/20)
•Epoxy pressing shoes (not applicable for SP/10, SP/15 and SP/20)
•Stainless steel 316 flanges, flange brackets, hose clamps, supporting and mounting
articles

14
5 INSTALLATION
5.1 Unpacking
When unpacking carefully follow the instructions as given on the packaging or on the hose
pump.
5.2 Inspections
Check that your delivery is correct and check it for any transport damage, see “Description:
“Identification of the product”, § 4.1. Report any damage immediately to your Bredel
representative.
5.3 Installation conditions
5.3.1 Ambient conditions
Make sure that the hose pump is in an area where the ambient temperature during operation
is not lower than –20° and not higher than +45°C.
5.3.2 Set-up
•The pump materials and protective layers are suitable for indoor set-up and a
protected outdoor set-up. Under certain conditions the pump is suitable for limited
outdoor set-up or a salty or aggressive atmosphere. Consult your Bredel
representative for more information.
•Make sure that the floor surface is horizontal and has a maximum slope of 1 mm per
meter.
•Make sure that there is sufficient room around the pump to carry out the necessary
maintenance activities.
•Make sure that the room is sufficiently ventilated, so that the heat developed by the
pump and drive can be discharged. Keep some distance between the ventilation
cover of the electric motor and wall to enable the supply of necessary cooling air.
5.3.3 Pipework
When determining and connecting suction and discharge lines consider the following points:
•The bore size of the suction line must be larger than the bore size of the pump hose.
The bore size of the discharge line must be minimal or larger than the bore size of the
pump hose. For more information consult your Bredel representative.
•Limit the presence of sharp bends. Make sure that the radius of the bends are as
large as possible (preferably 5S). It is recommended to use Y-connections instead of
T-connections.
•It is recommended to use a minimum of three quarter (3/4) of the hose length as
flexible hose in the suction or discharge line. In this way you prevent that connection
lines must be removed when changing a pump hose.
•Keep the delivery and suction lines as short and direct as possible.
•Prevent any possibilities of exceeding the maximum working pressure of the hose
pump, see “Specifications”: “Performance”, § 10.1.1. If necessary fit an overpressure
valve.

15
CAUTION
Consider the maximum permissible working pressure on the discharge side.
Exceeding the maximum working pressure may lead to serious damage to the pump.
•Make sure that the maximum forces on the flanges are not exceeded. The maximum
permissible loads on the pump flange are given in the table below:
5.3.4 Pulsating flow
Hose pumps have a pulsating flow that can result in vibrations of pump and lines under the
following circumstances:
•suction and discharge lines are not fixed correctly
•high pump speed in combination with long suction and discharge lines or high specific
gravity of the product
•diameter of suction and/or discharge line too small
In case of unacceptable pulsations, dampeners for suction and/or discharge line can be
supplied for the pump series SP/25 to SP/100. Please consult your Bredel representative for
literature on Inlet Pulsation Accumulators (IPA) or Pulsation Dampeners (PD). These
accumulators and dampeners are not available for SP/10, SP15 and SP/20.
5.3.5 Pumping pressure (counter pressure)
Should not go over maximum allowance (7,5 bar for SP/10, SP/15 and SP/20; 16 bar for
bigger models). If hose failure looks like explosion, check system for blocked lines, closed
valves or failing pressure relief valves.
5.4 Lifting and moving the pump
For lifting and moving the pumphead, it has been fitted with a lifting strip. This lifting strip is
fitted on the rear of the pumphead. For the weights of the pump, see “Specifications”:
“Weights”, § 10.1.5.
The complete hose pump, i.e. pumphead, gearbox and electric motor, must be lifted using
the lifting eyes in the pump support plus additional support on gearbox and motor using
suitably rated straps or slings, see “Specifications”: Weights, § 10.1.5.
Force
F1 [N] SP/10 SP/15 SP/20 SP25 SP/32 SP/40 SP/50 SP/65 SP/80 SP/100
F1 600 600 600 1000 1000 1000 1400 1400 2000 2000
F2 120 120 120 200 200 200 300 300 400 400
F3 300 300 300 500 500 500 700 700 1000 1000

16
WARNING
If the pump is to be lifted ensure that all standard lifting practices are
adhered to and carried out by qualified personnel only.
5.5 Placing the pump
Position the pump on a horizontal surface. Use suitable anchor bolts to attach the pump to
the floor surface.

17
6 COMMISSIONING
6.1 Preparations
•Connect the electric motor in conformance with the locally applicable rules and
regulations. Have the electrical installation work be carried out by qualified personnel.
•The pump casing is filled to half way level with a specially compounded hose
lubricant. If necessary refill Bredel lubricant via the breather/vent plug (also see:
“Maintenance”: “Changing lubricant”, § 7.3).
•Check the rotation of the rotor.
•Check that the correct number of shims (series SP/25 to SP/100) corresponds with
your application, see “Specifications”: “Shimming”, § 10.1.7.
•For adjusting the compression force of the hose, see “Maintenance”: “Hose
compression force adjustment (shimming)”, § 7.8.
6.2 Commissioning
•Connect the pipework. Make sure that there are no obstructions such as closed
valves.
•Switch on the hose pump.
•Check the rotation of the rotor.
•Check the capacity of the hose pump. If the capacity differs from your specification,
follow the instructions in chapter 9 “Troubleshooting” or consult your Bredel
representative.
•Check the hose pump in accordance with points 1 to 4 of the maintenance table from
section “Maintenance and periodic inspections”, § 7.1.

18
7 MAINTENANCE
WARNING
Only use original Bredel parts when maintaining the hose pump. Bredel cannot
guarantee a correct functioning and any consequential damage that occurs
from the use of non-original Bredel components, also see: “Safety” and
“Warranties”.
7.1 Maintenance and periodic inspections
In the diagram below it is indicated which maintenance and periodic inspections need to be
carried out on the hose pump to guarantee an optimal safety, operation and life of the pump.
Point Action To be carried out Remark
1 Check the lubricant
level
Before start up of
the pump and on a
scheduled interval
during operation.
Make sure that the pump casing is filled to half
way level with a specially compounded hose
lubricant. If necessary refill the lubricant (also
see “Maintenance”: “Changing lubricant”).
2 Check the pumphead
for any leakage of
lubricant around the
cover and the
flanges.
Before start up of
the pump and on a
scheduled interval
during operation.
See “Troubleshooting”.
3 Check pump for
deviating
temperature or
strange noises.
On a scheduled
interval during
operation.
See “Troubleshooting”.
4 Check pressing
shoes for excessive
damage.
When replacing the
pump hose.
See “Replacing pump hose’.
5 Internal cleaning of
the pump hose.
Cleaning of the
system or product
change.
See “Cleaning pump hose”.
6 Replacing pump
hose.
Preventive, this
means after 75% of
the hose life of the
first hose.
See “Replacing pump hose”.
7 Changing lubricant After every 2nd hose
change or after
5,000 service hours,
whichever comes
first or after hose
rupture.
See “Changing lubricant”.
8 Replacing pump
seal.
If necessary. See “Replacing seal ring, bearings and wear
ring”.
9 Replacing pressing
shoes.
Wear on the running
surface.
See “Replacing pressing shoes”.
10 Replacing bearings. If necessary. See “Replacing pressing shoes”.

19
7.2 Cleaning pump hose
With a lot of products it is necessary to have the pump hose cleaned immediately after
pumping to avoid hardening of the product inside. The inside of the pump hose can be easily
cleaned by rinsing the pump with clean water. If a cleaning fluid is added to the water, it must
be checked that the hose liner material is resistant to that. Also note that the pump hose can
resist the cleaning temperature. Special cleaning balls are also available; please consult your
Bredel representative).
7.3 Changing lubricant
•Place a tray under the drain plug (series SP/25 to SP/100) in the cover of the pump.
Remove the drain plug. Catch the lubricant from the pump housing in the tray.
Position the drain plug and tighten it firmly. In case of SP/10, SP/15 and SP/20
pumps: remove the hose and drain via the lower port.
•The pump housing can be filled with lubricant via the breather/vent on the cover. For
this purpose remove the breather cap and position a funnel in the breather. In order
to facilitate the filling with lubricant for the series SP/25 to SP/100 it is advised to
remove one or two bolts in the inspection window. Pour the lubricant in the pump
housing via the funnel.
•Keep on pouring until the lubricant level has risen at approx. half way of the pump
casing, or that the specified quantity has been filled. See “Lubricant” § 10.1.3.
7.4 Changing oil in gearbox
For information regarding the changing of oil in the gearbox and the type of oil to be used we
refer to the documentation of the manufacturer of this item.
7.5 Replacing pump hose
7.5.1 Hose removal
The pump hose can be changed without removing the pump cover. If applicable, close the
isolation valves on both the inlet and discharge of the pump to minimize fluid loss.
7.5.2 Removal of lubricant
Place a lubricant tray of sufficient capacity to contain the hose lubricant plus any process
fluid that might be contained within the pump housing. Remove the drain plug (not applicable
for SP/10, SP/15 and SP/20; lubricant will flow when hose is removed) . Ensure that the
breather vent in front is not blocked.
7.5.3 Removal of piping
Shut off the valves on both suction and discharge side and disconnect the piping of both the
ports.
7.5.4 Loosening of hose clamps
Loosen all hose clamps on both suction and discharge ports.
7.5.5 Removal of flanges and/or inserts
Pull the inserts from the hose (SP/10, SP/15 and SP/20) by removing the flanges (SP/25-
SP/100) on both the suction and discharge port.

20
7.5.6 Removal of flange brackets
Remove the flange bracket (SP/25-SP/100) or flange bracket and insert (SP/10, SP/15 and
SP/20) on both suction and discharge port.
7.5.7 Removal of the hose
The hose can be removed without removing the pump cover.
Simply remove the hose by jogging the drive motor.
7.5.8 Cleaning of pump casing
Flush out casing cavity to remove any contaminants. If necessary remove the pump cover to
clean casing completely (but isolate the pump from the electrical supply first).
WARNING
Never remove the pump cover whilst the hose is in place.
The front covers of the series SP/25 to SP/100 should not be removed whilst
the hose is in place. This can cause a deformation of the pump casing and a
non straight tension of the bolts. After fitting the cover and starting up the
pump, the bolts can be extremely forced and break.
When the pump cover was removed for cleaning purposes, refit it before installing the
hose Check the cover O-ring for damage and replace if necessary. Make sure that the bolts
are refitted and that they are tightened in the correct order, diagonally opposite each other,
see “Specifications”: ‘’Torques’’, § 10.1.6.
7.5.9 Tighten drain plug (not applicable for SP/10, SP/15 and SP/20)
Before the hose can be loaded the drain plug has to be mounted. Make sure that the drain
plug is mounted in such a way that no leakage of lubricant can occur.
7.5.10 Preparation of pump hose
Clean the outside of the pump hose and thoroughly lubricate the external surface of the hose
with the Bredel hose lubricant.
7.5.11 Insertion of the hose
•Switch on the electrical supply again and insert the hose into the upper port.
•Jog the drive motor to feed the hose through the housing.
•If necessary, help by pressing the hose firmly into the port opening.
•Stop the drive when the hose is equally extended from the ports.
7.5.12 Place hose clamps
Place on both the suction and discharge port the bushes, all hose clamps (do not tighten
yet!), the brackets, the flanges and the inserts.
7.6 Hose connection
Note: Always start hose connection at one port and finalize these actions completely. Then
repeat these actions for the other port. In this instruction we start from the suction port.

21
7.6.1 Mount flange brackets (SP/25 to SP/100)
•Mount the flange brackets on the suction port by replacing the bolts.
•Do not tighten the bolts at this stage!
•Mount the flange and the insert
•Mount the suction line
7.6.2 Positioning of pump hose
Jog the motor in the direction of the suction port to drive the hose against the flange face.
Ensure that the hose butts up against the flange face and that the insert is seated correctly.
7.6.3 Tighten hose clamps
•Tighten all the hose clamps.
•Make sure that hose clamp is mounted directly against the vertical part of the rubber
bush.
Now repeat step 7.6.1 to 7.6.3 for the discharge port
7.6.4 Tighten bolts of all flange brackets
Now tighten the bolts of all flange brackets.
7.6.5 Filling with lubricant
•Remove one screw from the inspection window (not applicable for SP/10, SP/15 and
SP/20) to vent the pump housing.
•Add lubricant until ½ of the pump housing is filled. See “Specifications”, “Lubricant”,
§ 10.1.3 for the required quantity of lubricant per pump type.
7.6.6 Finally
•Replace removed bolt(s) in inspection window (not applicable for SP/10, SP/15 and
SP/20).
•Open the suction and discharge valves.
•Switch on the electrical supply.
