North Ridge Pumps NOVA ROTORS DIAMOND DX Series User guide

OMI.EN-PCP044 R00 08/07/13 Pag.1
OPERATING, USE AND
MAINTENANCE ISTRUCTIONS
FOR PROGRESSING CAVITY PUMPS
SERIES:
DIAMOND
PUMP MODEL : DXC
SERIAL NUMBER :
CUSTOMER:
North Ridge Pumps Registered in England and Wales 03652700.
Registered Office: 12 Bridgford Road, West Bridgford, Nottingham, NG2 6AB . VAT No. GB324963488
X-Cel House, Chrysalis Way, Langley Bridge, Nottinghamshire, NG16 3RY
Tel: [phone] | Email: [email protected] | Website: www.northridgepumps.com

OM.EN-GEN038 R00 08/07/13 Pag.2
INDEX
1 FOREWORD ................................................................................................................................................................................ 5
1.1 Manufacturer’s details .......................................................................................................................................................... 5
1.2 Purpose of the Operating Instructions .................................................................................................................................. 5
1.3 Use of the Operating Instructions ......................................................................................................................................... 5
1.4 Intellectual property rights .................................................................................................................................................... 5
1.5 Warranty and voiding of warranty ......................................................................................................................................... 5
2 GENERAL INFORMATION ........................................................................................................................................................... 7
2.1 Conventions and symbols used in these Operating Instructions ........................................................................................... 7
2.1.1 Textual conventions...................................................................................................................................................................... 7
2.1.2 Terminology and symbols ............................................................................................................................................................. 7
2.2 Target audience for these Operating Instructions and duties ................................................................................................ 7
3 SAFETY ........................................................................................................................................................................................ 8
3.1 Failure to comply with the safety regulations ........................................................................................................................ 8
3.2 Startup, operation and maintenance ..................................................................................................................................... 8
3.3 Intended conditions of use .................................................................................................................................................... 8
3.4 General rules – Safety in the workplace and for machines intended for use in potentially explosive atmospheres (ATEX) ... 8
3.5 General rules – Training of personnel and guidelines for safe use of the machine ................................................................ 8
3.6 Spare parts and design modifications ................................................................................................................................... 9
3.6.1 How to request Technical Assistance ........................................................................................................................................... 9
3.6.2 How to request Spare Parts .......................................................................................................................................................... 9
3.6.3 Design modifications .................................................................................................................................................................... 9
3.7 Noise emission ..................................................................................................................................................................... 9
3.8 Leakage of dangerous fluids and other emissions ................................................................................................................ 9
3.9 General rules – Work area and protective clothing ............................................................................................................... 9
3.10 General rules for machine maintenance ............................................................................................................................... 9
3.11 General rules - Prohibitions ................................................................................................................................................ 10
3.12 Fire emergency procedures ................................................................................................................................................ 10
3.13 Description of the residual risks .......................................................................................................................................... 10
3.14 Affixed information and warning signs ................................................................................................................................ 10
4 DESCRIPTION OF THE PUMP .................................................................................................................................................. 11
4.1 Main technical characteristics of the pump ......................................................................................................................... 11
4.2 Operating Principle ............................................................................................................................................................. 11
4.3 Structure of the pump ......................................................................................................................................................... 11
4.4 Pump with bypass (optional) .............................................................................................................................................. 12
4.5 Safety, pressure relief, check valves .................................................................................................................................. 12
4.6 Dry run protection ............................................................................................................................................................... 12
4.7 Drives ................................................................................................................................................................................. 13
5 ORDER IDENTIFICATION .......................................................................................................................................................... 14
5.1 Product identification .......................................................................................................................................................... 14
5.2 Supplied documentation and technical specifications ......................................................................................................... 14
5.3 Data plate........................................................................................................................................................................... 14
5.4 Model identification ............................................................................................................................................................ 15
6 DATASHEET .............................................................................................................................................................................. 17
7 TRANSPORTATION AND STORAGE ........................................................................................................................................ 18
7.1 Transportation, handling and positioning ............................................................................................................................ 18
7.1.1 Instructions for transportation ..................................................................................................................................................... 18
7.1.2 Precautions to be taken upon receipt of the pump ...................................................................................................................... 18
7.1.3 Ambient conditions required for storage ..................................................................................................................................... 18
7.1.4 Instructions for handling and positioning the pump ..................................................................................................................... 18
North Ridge Pumps Registered in England and Wales 03652700.
Registered Office: 12 Bridgford Road, West Bridgford, Nottingham, NG2 6AB . VAT No. GB324963488
X-Cel House, Chrysalis Way, Langley Bridge, Nottinghamshire, NG16 3RY
Tel: [phone] | Email: [email protected] | Website: www.northridgepumps.com

OM.EN-GEN038 R00 08/07/13 Pag.3
7.1.5 Instructions for subsequent handlings and positionings .............................................................................................................. 19
7.1.6 For machines that are not trolley-mounted there are no particular instructions, simply refer to 1.1.4 - Instructions for handling and
positioning the pump. ............................................................................................................................................................................... 19
7.2 Unpacking and disposal of packaging materials ................................................................................................................. 19
8 INSTALLATION AND ASSEMBLY .............................................................................................................................................. 20
8.1 Positioning the machine ..................................................................................................................................................... 20
8.2 Mounting the pump ............................................................................................................................................................ 21
8.3 Installation .......................................................................................................................................................................... 21
8.3.1 Connection to tubing................................................................................................................................................................... 21
9 PUMP OPERATING INSTRUCTIONS ........................................................................................................................................ 22
9.1 Filling the pump .................................................................................................................................................................. 22
9.2 Electrical connection for pumps equipped with electric motor ............................................................................................. 22
9.3 Other connections .............................................................................................................................................................. 23
9.4 Preparation for putting into service ..................................................................................................................................... 23
9.4.1 Lubrication .................................................................................................................................................................................. 23
9.4.2 Adjustments ............................................................................................................................................................................... 23
9.4.3 Testing ....................................................................................................................................................................................... 23
9.4.4 Pre-use checks ........................................................................................................................................................................... 23
9.4.5 Startup ....................................................................................................................................................................................... 24
9.5 First startup ........................................................................................................................................................................ 24
9.5.1 Precautionary checks ................................................................................................................................................................. 24
9.5.2 First startup operations ............................................................................................................................................................... 25
9.6 Periods of inactivity ............................................................................................................................................................ 25
9.6.1 General guidelines ..................................................................................................................................................................... 25
9.6.2 Storage for periods of inactivity ................................................................................................................................................... 25
9.6.3 Restarting after periods of inactivity ............................................................................................................................................ 26
9.7 Pump operation .................................................................................................................................................................. 26
9.7.1 Pump work cycle ........................................................................................................................................................................ 26
9.8 Stop functions .................................................................................................................................................................... 26
9.9 Reset functions .................................................................................................................................................................. 26
9.10 Scrapping and disposal instructions ................................................................................................................................... 26
10 MAINTENANCE .......................................................................................................................................................................... 27
10.1 Put the pump in “Maintenance Mode” ................................................................................................................................. 27
10.2 Maintenance Operations .................................................................................................................................................... 27
10.3 Cleaning operations ........................................................................................................................................................... 28
10.4 Wear and tear of pump parts .............................................................................................................................................. 28
10.4.1 Rotor and stator ..................................................................................................................................................................... 28
10.4.2 Joints and transmission shaft ................................................................................................................................................. 28
10.4.3 Seal ....................................................................................................................................................................................... 29
10.4.4 Bearing housing (pump with support type J) .......................................................................................................................... 29
10.5 Disassembly of the stator and pump body .......................................................................................................................... 30
10.6 Disassembly of the joint protector ....................................................................................................................................... 32
10.7 Disassembly of the joints .................................................................................................................................................... 33
10.8 Disassembly of the coupling flange and the seal G0K9/Q0K9 ............................................................................................ 35
10.9 Disassembly of the coupling flange and the seal B01/B02 .................................................................................................. 36
10.10 Disassembly of the connections to the coupling flange and the seal D0K9/D0S9 ............................................................... 37
10.11 Disassembly of the connections to the coupling flange and the seal K0K9/K0S9 ................................................................ 38
10.12 Assembly of the stator and pump body ............................................................................................................................... 39
10.13 Assembly of the joints ........................................................................................................................................................ 41
10.14 Assembly of the joint protectors .......................................................................................................................................... 44
10.15 Lubrication of balanced joints ............................................................................................................................................. 45
North Ridge Pumps Registered in England and Wales 03652700.
Registered Office: 12 Bridgford Road, West Bridgford, Nottingham, NG2 6AB . VAT No. GB324963488
X-Cel House, Chrysalis Way, Langley Bridge, Nottinghamshire, NG16 3RY
Tel: [phone] | Email: [email protected] | Website: www.northridgepumps.com

OM.EN-GEN038 R00 08/07/13 Pag.4
10.16 Assembly of the connections to the coupling flange and the seal G0K9/Q0K9.................................................................... 46
10.17 Assembly of the connections to the coupling flange and the sea B01/B02 .......................................................................... 47
10.18 Assembly of the connections to the coupling flange and the seal D0K9/D0S9 ................................................................... 48
10.19 Assembly of the connections to the coupling flange and the seal K0K9/K0S9 ................................................................... 49
10.20 Disassembly of the stator jacket ......................................................................................................................................... 51
10.21 Assembly of the stator jacket .............................................................................................................................................. 51
11 TROUBLESHOOTING TABLE .................................................................................................................................................... 52
12 SPARE PARTS ........................................................................................................................................................................... 53
12.1 Spare parts for machine DXC L1/K2/K4 ............................................................................................................................. 53
12.2 Datasheet tenuta meccanica singola AK9 serie XC - Tenuta tipo 110-16 / Datasheet single mechanical seal AK9 XC series - Seal
Type 110-16 ..................................................................................................................................................................................... 56
12.3 Datasheet tenuta meccanica singola AK9 serie XC - Tenuta tipo 120-9 / Datasheet single mechanical seal AK9 XC serie - Seal
Type 120-9 ....................................................................................................................................................................................... 57
12.4 Datasheet tenuta meccanica singola AK9 serie XC - Tenuta tipo 52-10 / Datasheet single mechanical seal AK9 XC series - Seal
Type 52-10 ....................................................................................................................................................................................... 58
12.5 Datasheet tenuta meccanica singola flussata FK9 serie XC - Tenuta tipo 110-16 / Datasheet single mechanical seal with quench
FK9 XC series - Seal Type 110-16 ................................................................................................................................................... 59
12.6 Datasheet tenuta meccanica singola flussata FK9 serie XC - Tenuta tipo 52-10 / Datasheet single mechanical seal with quench FK9
XC series - Seal Type 52-10............................................................................................................................................................. 60
12.7 Datasheet tenuta meccanica flussata doppia back to back B1X9 serie XC - Tenuta tipo 172-9/16 / Datasheet flushed double
mechanical seal back to back B1X9 XC series - Seal Type 172-9/16 ............................................................................................... 61
12.8 Datasheet tenuta meccanica flussata doppia tandem T1X9 serie XC - Tenuta tipo 52-10 / 172-9/16 / Datasheet flushed double
mechanical seal tandem T1X9 XC series - Seal Type 52-10 / 172-9/16 ............................................................................................ 62
12.9 Datasheet tenuta meccanica flussata doppia tandem T1X9 serie XC - Tenuta tipo 110-16 / 172-9/16 / Datasheet flushed double
mechanical seal tandem T1X9 XC series - Seal Type 110-16 / 172-9/16 .......................................................................................... 63
North Ridge Pumps Registered in England and Wales 03652700.
Registered Office: 12 Bridgford Road, West Bridgford, Nottingham, NG2 6AB . VAT No. GB324963488

OM.EN-GEN001 R00 08/07/13 Pag.5
1 FOREWORD
1.1 Manufacturer’s details
NOVA ROTORS S.r.l.
36040 Sossano (VI)
–
Italy
via C. Cattaneo, 19/25
Tel.: [phone]
Fax: [phone]
Mail:
[email protected]
Web:
www.novarotors.com
1.2 Purpose of the Operating Instructions
These Operating Instructions are an integral part of the machine and are directed to all those persons that operate on the machine or that
interact with its users, for the purpose of providing all the information necessary to:
 correctly perform all the operations involved in the set up, running, maintenance and scrapping stages;
 ensure protection of the health and safety of all persons involved in working with the machine;
 ensure the efficient operation of the machine.
1.3 Use of the Operating Instructions
The Operating Instructions must be read carefully in their entirety prior to carrying out any operation on the machine; if in doubt about the correct
interpretation of any of the instructions, contact the Manufacturer.
The Operating Instructions must be stored with care for the entire life of the machine and they must accompany the machine in all its transfers,
of any kind, and made available to the users.
The Operating Instructions must be stored in the immediate vicinity of the machine, in a place that is easy to access and known to all users; it
must be treated with care during consultation, pages must not be removed and its contents must not be altered in any way; it must be stored in
a place that is protected from the weather, heat, humidity, corrosive agents, and preferably enclosed in a protective cover.
CAUTION!
The Manufacturer shall not be liable for consequences resulting from improper use of the machine caused by the failure of the
user to read these Operating Instructions and shall not be liable for any civil or criminal liability arising from the user’s failure to
comply with th
ese instructions
.
1.4 Intellectual property rights
The rights on the entire contents of these Operating Instructions and of the documents supplied with the machine, including information,
drawings and diagrams, are reserved. No information contained in these Instructions may be reproduced or communicated to third parties
without the written consent of the Manufacturer, who retains all proprietary rights .
Only the Customer to whom the Operating Instructions are supplied as an integral part of the machine, for the sole purpose of ensuring that all
the operations related to the various stages in the life cycle of the machine are carried out correctly, is authorised to use this information.
1.5 Warranty and voiding of warranty
The Manufacturer warrants that the machine and all the equipment supplied with it are free from flaws, defects in material or workmanship and
comply strictly with the declared technical specifications and quality standards.
The warranty covers the replacement of defective materials for a period 12 months from the date of shipment unless otherwise specified in
writing in the order confirmation. The rotor, the stator and the components of the seal system, which are subject to wear and tear, are excluded
from the warranty except for workmanship defects.
The warranty will only be valid if the machine has been used in the strictest observance of the provisions and instructions contained in these
Operating Instructions and if operational limits agreed in the Order Confirmation have been complied with.
The warranty will not be valid if the machine is installed incorrectly, or for any changes, replacements, repairs or alterations made by the
Customer or third parties.
For machines supplied without a drive system, in close-coupled configuration, the warranty is not valid for damage caused by a drive that has
been incorrectly mounted by the Customer or third party. It is advisable to contact the Manufacturer for information about mounting the drive
system.
All tools and consumables supplied by the Manufacturer together with the machine are not covered by warranty.
The Manufacturer is not liable for damage or removal of parts that might occur during transit.
To ensure that material and workmanship defects and flaws are dealt with under warranty they must be reported in writing to the Manufacturer
at the above address.
If judged by the Manufacturer to be defective the part will be replaced or repaired free of charge.
However, the Customer will be required to pay for costs of transport and/or shipment of parts and/or for travel expenses incurred by the
Manufacturer’s personnel if required to travel to the Customer’s factory. The replaced parts will remain the property of the Manufacturer.
Parts repaired or replaced under warranty will be covered by a new warranty for a period of 12 months from the date of the replacement or
repair, but this , however, does not apply to any parts that are not replaced or repaired.
North Ridge Pumps Registered in England and Wales 03652700.
Registered Office: 12 Bridgford Road, West Bridgford, Nottingham, NG2 6AB . VAT No. GB324963488
X-Cel House, Chrysalis Way, Langley Bridge, Nottinghamshire, NG16 3RY
Tel: [phone] | Email: [email protected] | Website: www.northridgepumps.com

OM.EN-GEN001 R00 08/07/13 Pag.6
Nova Rotors S.r.l
Via Carlo Cattaneo, 19/25
–
36040 Sossano (VI)
-
ITALY
Phone [phone]
151 Fax [phone]
www.novarotors.com
–
[e-mail]
P.IVA
-
VAT:
02149270247
–
REA: VI
-
209864
Capital : €1.000.000
Declaration of Conformity / Dichiarazione di conformità
Manufacturer’s name / NOVA ROTORS S.r.l.
Nome del costruttore
Manufacturer’s address / Via Carlo Cattaneo, 19/25 – 36040 Sossano (VI) – Italy
Indirizzo del costruttore
Herewith declares conformity of the Products
Dichiara con la presente la conformità del prodotto
MODEL :
DXC
SERIAL NUMBER :
Product description: Progressing cavity pumps with vertical and horizontal axis
Descrizione del prodotto Pompe monovite ad asse verticale e orizzontale
Complies with the essential requirements stipulated by the following applying directives:
E’ conforme ai requisiti essenziali di sicurezza previsti dalle seguenti direttive:
2006/42/CE (Direttiva Macchine / machinery Directive)
In according to the following harmonized standards / In accordo alle seguenti norme armonizzate:
UNI EN ISO 12100-1:2005 Sicurezza del macchinario Parte 1 / Safety of machinery. Part 1
UNI EN ISO 12100-2:2005 Sicurezza del macchinario Parte 2 / Safety of machinery Part 2
UNI EN ISO 809:2009 Pompe e gruppi di pompaggio per liquidi / Pumps and pump unit for liquids
UNI EN ISO 13857:2008 Distanze di sicurezza per impedire il raggiungimento di zone pericolose con
gli arti superiori e inferiori - Safety distance to prevent danger zones being
reached by the upper and lower limbs
2004/108/CE (Direttiva sulla Compatibilità Elettromagnetica / Electromagnetic Compatibility Directive)
2006/95/CE (Direttiva Bassa Tensione / Low Voltage Equipment Directive)
In according to the following harmonized standards / In accordo alle seguenti norme armonizzate
CEI EN 60204-1:2006 Equipaggiamento elettrico delle macchine - Regole generali.
Electric equipment of machinery - General requirements
In compliance with Regulations (CE) n° 1935/2004 relating to the part in contact with foodstaff
In conformità al Regolamento (CE) n° 1935/2004 riguardante i materiali a con i prodotti alimentari
Le istruzioni operative riportano importanti informazioni per la sicurezza, l'uso, l'installazione e la manutenzione
della macchina.
Operating instructions includes important information for safety, use, installation and maintenance for the
machinery
Sossano, 23/02/17 Sigra. Carla Dovigo
Amministratore Delegato – Chief executive officer
Nova Rotors S.r.l.
North Ridge Pumps Registered in England and Wales 03652700.
Registered Office: 12 Bridgford Road, West Bridgford, Nottingham, NG2 6AB . VAT No. GB324963488
X-Cel House, Chrysalis Way, Langley Bridge, Nottinghamshire, NG16 3RY
Tel: [phone] | Email: [email protected] | Website: www.northridgepumps.com

OM.EN-GEN039 R00 08/07/13 Pag.7
2 GENERAL INFORMATION
2.1 Conventions and symbols used in these Operating Instructions
2.1.1 Textual conventions
Bold type is used to highlight important information. References to the figures are indicated in bold type, using the abbreviation "Fig." and a
number that identifies the figure (e.g. Fig.1). Sometimes a letter or a number is added to identify a particular component of a figure (e.g. A - Fig
1 or 1 – Fig.1).
NOTE!
The illustrations in these Operating Instructions are simply by way of example; the pumps illustrated in the figures with different
dimensions, optional accessories or different types of construction may differ in some details, however the general contents of
the Operating Instructions apply to all the pumps.
2.1.2 Terminology and symbols
The terminology used in the Operating Instructions is based on the definitions and glossary included in the Machinery Directive : 2006/42/EC.
The following symbols are used throughout these Operating Instructions to ensure correct and safe use of the machine:
CAUTION!
This symbol alerts the user to hazardous situations or situations that could cause damage to the machine.
CAUTION! SUSPENDED LOAD!
The symbol alerts the user to dangerous situations related to the presence of suspended loads during machine handling and
positioning procedures.
CAUTION! ROTATING PARTS HAZARD!
The symbol alerts the user to dangerous situations due to rotating parts in motion.
PROHIBITED!
The symbol draws the user’s attention to actions that are prohibited.
NOTE!
The symbol draws the user’s attention to information that is particularly important.
PERSONAL PROTECTIVE EQUIPMENT
Indicates that protective gloves must be worn when carrying out the operations to which it is associated.
PERSONAL PROTECTIVE EQUIPMENT
Indicates that protective footwear must be worn when carrying out the operations to which it is associated.
PERSONAL PROTECTIVE EQUIPMENT
Indicates that a safety helmet must be worn when carrying out the operations to which it is associated.
2.2 Target audience for these Operating Instructions and duties
SUPERVISOR
Customer’s employee who oversees all operations related to the machine to ensure they are carried out correctly, in compliance
with the instructions contained in these Operating Instructions and with general safety regulations.
OPERATOR
Customer’s employee who is responsible for operating the machine under normal conditions.
QUALIFIED TECHNICIAN
Customer’s employee who has the technical-professional qualifications to carry out specialist operations in the various stages of
the machine’s life cycle. The specialization required for particular operations that requiring the assistance of the qualified
technician will be indicated each time.
MANUFACTURER’S TECHNICIAN
Manufacturer’s employee or personnel authorised by the Manufacturer, or by the Reseller/Distributor, who has the technical-
professional qualifications to carry out specialist operations that require a thorough knowledge of the machine and its operation.
North Ridge Pumps Registered in England and Wales 03652700.
Registered Office: 12 Bridgford Road, West Bridgford, Nottingham, NG2 6AB . VAT No. GB324963488
X-Cel House, Chrysalis Way, Langley Bridge, Nottinghamshire, NG16 3RY
Tel: [phone] | Email: [email protected] | Website: www.northridgepumps.com

OM.EN-SAF001 R00 08/07/13 Pag.8
3 SAFETY
3.1 Failure to comply with the safety regulations
NOTE!
Failure to comply with the safety regulations described in these Operating Instructions and common sense safety rules could
result in hazards to persons, the environment and the machine.
Specifically, this could lead to:
 failure of the machine and/or system to carry out key functions
 damage to the machine and/or system
 electrical, mechanical and/or chemical danger to persons
 environmental hazards caused by leakage of dangerous substances.
Failure to observe or comply with the safety regulations will invalidate warrant
ies and lead to loss of compensation for damages.
3.2 Startup, operation and maintenance
The plant of destination for the progressing cavity pump is not an integral part of the supply, consequently the customer is required to verify the
suitability of the machine for the specific requirements, to provide the process data necessary to ensure that the right pump is selected and to
ensure that any accessories required to guarantee the safety of the plant are included in the order. If the user maintains that certain accessories
he considers useful or essential have not been included in the Order Confirmation, it is the customer’s responsibility to inform the Manufacturer
and to request that the parts in question be installed on the machine.
3.3 Intended conditions of use
The machine is designed pumping a product, referred to as “fluid”, of the type specified in the Order Confirmation.
NOTE!
The machine must always observe the operating limits for which it was constructed and those declared in the Order
Confirmation.
The main limits to observe relate to: temperature, pressure, capacity, viscosity and speed.
Only 1 Operator is required to run the machine. The work station is in the vicinity of the drive unit.
NOTE!
If the machine is required to work with a different rotating direction to the one indicated in the order, contact the Manufacturer to
verify the possibility of changing the direction and to define the operating limits.
3.4 General rules – Safety in the workplace and for machines intended for use in potentially explosive atmospheres (ATEX)
The ATEX directives concern the use of machines in potentially explosive atmospheres and the standards for accessories and protection
systems to be used in these atmospheres.
If the pump is intended to be used in a potentially explosive atmosphere the ATEX mark is included on the data plate, and a separate ATEX
annex in compliance with Directive 94/9 EC is supplied with these Operating Instructions. The order must specify if the machine is to be used in
a potentially explosive atmosphere.
The ATEX Directive 94/9 EC applies specifically to electrical and non-electrical accessories; the conditions of use must comply with the limits
of the operating conditions laid down and described in the directive.
ATTENTION!
The Customer’s personnel must have the following technical-professional requirements if working with ATEX machines:
 ITT certification and authorization
 awareness of the electrical hazards and the hazards related to the chemical and physical characteristics of the gas
and/or vapour present in the danger zones
 knowledge of the European Machinery Directive and its transposition into Italian law, of the European Standard EN
12100:2005, and the safety standards in force in the country of installation.
3.5 General rules – Training of personnel and guidelines for safe use of the machine
It is the Customer’s responsibility to provide their personnel with the necessary general training in the following areas:
 safety and health hazards related to the activities carried out in the company’s plant
 measures and devices adopted for the prevention of accidents and for the protection of worker safety and health
 specific hazards to which the workers are exposed in relation to their duties, the safety regulations and the corporate health and safety
provisions
 general safety rules laid down in the European Directive 89/391/EEC and in the regulations in force in the country of installation
 first aid procedures, use of fire-fighting equipment and emergency evacuation procedures.
It is the Customer’s responsibility:
 to provide workers with the necessary training on the contents of these Operating Instructions
 to identify which of their workers should be given this training
 to verify that the worker has achieved the required knowledge and understanding to perform his assigned duties
 to verify that the application of these Operating Instructions becomes routine practice in all machine operating stages.
Personnel training must be updated as new hazards arise connected to changes in the configuration of the machine or its use.
North Ridge Pumps Registered in England and Wales 03652700.
Registered Office: 12 Bridgford Road, West Bridgford, Nottingham, NG2 6AB . VAT No. GB324963488
X-Cel House, Chrysalis Way, Langley Bridge, Nottinghamshire, NG16 3RY
Tel: [phone] | Email: [email protected] | Website: www.northridgepumps.com

OM.EN-SAF001 R00 08/07/13 Pag.9
3.6 Spare parts and design modifications
3.6.1 How to request Technical Assistance
The Manufacturer’s sales office is at the Customer’s disposal:
 for explanations and information
 to provide expert technical personnel on site at the Customer’s premises for geographically limited areas
 to send spare parts.
For technical assistance requests, the Customer is required to contact the Manufacturer directly using the details provided ln 1.1 –
Manufacturer’s identification data. To enable the Manufacturer to identify the machine see 6.1 – Product identification.
3.6.2 How to request Spare Parts
Only genuine spare parts supplied by the Manufacturer or those authorised in writing by the Manufacturer may be used.
The Manufacturer accepts no liability for any damage to objects and/or personal injury or any other damages arising from the Customer’s use of
non-genuine spare parts or parts not authorised by the Manufacturer.
Follow the instructions provided by the Manufacturer to disassemble the parts to be replaced and to assemble the replacement parts. For the
spare parts list see 13 – Spare parts.
3.6.3 Design modifications
PROHIBITED!
It is strictly prohibited to make structural changes to the machine without the written authorization of the Manufacturer.
3.7 Noise emission
The machine is designed and constructed to reduce the sound emission level at the source.
The A-weighted sound power level emitted by the machine does not exceed 85dB(A).
This value is guaranteed if the pump is installed correctly, in stable conditions and with the appropriate fixings and it is measured at a distance
of 1 metre from the pump. It does not include any other external noise sources or reverberation of the pipes connected to the pump while it is
operating.
The Manufacturer does not guarantee this value if the pump is used in working conditions that do not comply with those specified in the work
order and stated in the Order Confirmation.
3.8 Leakage of dangerous fluids and other emissions
CAUTION!
If the pump is used to pump dangerous fluids (toxic, corrosive, etc…), the fluids leaking from the seal must be collected and
disposed of without endangering persons or the environment.
3.9 General rules – Work area and protective clothing
The work area and the surrounding area must be kept free of objects that could cause trips or falls. The work area must be well-illuminated,
clean, free of grease, oils, water or any other liquid that could make the floor around the machine slippery and therefore represent a slip or falls
hazard.
Access to the work area must be prohibited to persons who are not authorised to work on the machine during any of its various working stages;
prohibition signs to this effect must be displayed in the vicinity of the pump. Adequate fire-fighting equipment must be provided in the work area
and it must be indicated by suitable signs.
Suitable protective equipment must be worn to protect the parts of the body:
 safety gloves to protect hands against various hazards: mechanical, electrical, chemical and hot temperature
 appropriate clothing and safety footwear to protect the foot against drop hazards.
3.10 General rules for machine maintenance
Before beginning any maintenance work it is mandatory to put the machine in “MAINTENANCE MODE” as described in 11 – Maintenance,
unless otherwise indicated in these Operating Instructions.
CAUTION!
Do not disassemble the machine until the fluid has been emptied from the tubes. Even if the tubes are empty, some
fluid may remain in the machine. The fluid could be a hazard to persons and to the environment, and it could be
extremely hot. In servicing operations that require the machine to be running at least 2 people must be present so that
in the event of a dangerous situation one person can disconnect the power supply or
sound the alarm.
CAUTION! ROTATING PARTS HAZARD!
The machine contains rotating parts in motion. Do not insert limbs while the machine is in operation.
North Ridge Pumps Registered in England and Wales 03652700.
Registered Office: 12 Bridgford Road, West Bridgford, Nottingham, NG2 6AB . VAT No. GB324963488
X-Cel House, Chrysalis Way, Langley Bridge, Nottinghamshire, NG16 3RY
Tel: [phone] | Email: [email protected] | Website: www.northridgepumps.com

OM.EN-SAF001 R00 08/07/13 Pag.10
CAUTION! RISK OF ELECTRIC SHOCK!
For machines fitted with an electric motor, the drive is powered.
PROHIBITED!
Do not carry out any operation on the safety systems while the machine is in operation. While the machine is in operation the
safety systems must be must be installed and mounted properly on the pump.
3.11 General rules - Prohibitions
PROHIBITED!
The following prohibitions apply to all workers.
Do not use the pump for operations other than those intended.
Do not use the pump in ambient conditions other than those intended.
Do not use accessories, tools, lubricants, consumables other than those intended.
Do not make any changes to the machine without the Manufacturer’s approval.
Do not use the machine in a configuration different from that authorised by the Manufacturer.
Do not remove, tamper with, deactivate or bypass the safety devices unless required in specific foreseen situations.
Do not run the machine dry.
Do not remove or deface danger or prohibition labels affixed to the machine.
Do not climb onto the machine.
Do not use the machine or the protections as work tables.
Do not store inflammable material such as petrol, solvents, gas cylinders, etc, in the vicinity of the machine.
Do not perform any repairs, adjustment, cleaning, lubrication or maintenance action on moving parts.
Do not wear clothing with loose sleeves, ties, scarves, rings, watches, bracelets, chains or any other object or item of clothing
that could catch on the moving parts.
3.12 Fire emergency procedures
Use carbon dioxide extinguishers to put out electrical equipment fires. Do not use dry powder extinguishers or water jets, as they could cause a
short circuit or electrocute the firefighter during the firefighting procedure. If the fire is not extinguished immediately, be alert to the possible
dispersion of air, water, oil and heating fluids. If the machine is fitted with pressurised tanks and tubes, exposure to flames for an extended
period of time could lead to an explosion: consequently make sure you are not showered by the fluids contained in the tanks or tubes.
CAUTION!
Carbon dioxide and dry powder extinguishers must be stored in the vicinity of the machine. To prevent the onset of
fire, the machine must be kept free of oils, solvents, cloths, etc…
Dry powder extinguishers cause serious damage to the machine, so only use one in the event of actual necessity and
not on the electrical parts or parts that may accidently have been left under voltage.
When using carbon dioxide extinguishers, the firefighters (minimum of 2) must wear suitable protective gloves and use
self
-
contained breathing apparatus
.
3.13 Description of the residual risks
Pursuant to European Community Directive 2006/42/EC the danger zones and the residual risk zones for the Operator, that could not be
eliminated so as not to compromise the functionality of the pump, are listed below:
 Danger zone 1: electric motor while the machine is operational being an electric shock hazard due to the presence of voltage.
 Danger zone 2: machine while operating being a burn hazard due to possible contact with hot surfaces.
 Danger zone 3: for the construction types with hopper H, HB, HE, HP, HS, HSB when the pump is running the hopper is a trapping,
impact hazard for upper limbs.
 Danger zone 4: for special applications when the fixed Plexiglas shield of the transmission shaft has been removed, transmission
shaft rotating during operation of the machine with risk of trapping, impact of the upper limbs on the transmission shaft.
3.14 Affixed information and warning signs
The machine is supplied with warning signs and decals. These signs do not replace the information and the warnings contained in these
Operating Instructions nor must they be considered the only ones to be observed.
PROHIBITED!
Do not remove, damage or deface the signs affixed to the machine.
North Ridge Pumps Registered in England and Wales 03652700.
Registered Office: 12 Bridgford Road, West Bridgford, Nottingham, NG2 6AB . VAT No. GB324963488
X-Cel House, Chrysalis Way, Langley Bridge, Nottinghamshire, NG16 3RY
Tel: [phone] | Email: [email protected] | Website: www.northridgepumps.com

OM.EN-GEN002 R00 08/07/13 Pag.11
4 DESCRIPTION OF THE PUMP
4.1 Main technical characteristics of the pump
The main characteristics of the pump are:
 uniform flow rate proportional to the rpm of the pump;
 minimum suction capacity of 4 mWC (NPSH), depending on the size, the number of stages and rpm of the pump;
 capacity to pump heterogeneous products, containing gases, abrasives, solid and fibrous materials in the liquid matrix;
 capacity for pumping high or low viscosity liquids;
 liquid metering capacity;
 pulse-free pumping with minimum tensile stress on the fluid;
 high pumping pressure of 6 bar per stage,
 1-2-4-and 8 number of stages depending on the required pressure .
4.2 Operating Principle
The progressing cavity pump is a self priming rotary positive displacement machine. The hydraulic part of the pump consists of a rotor (11 -
Fig.1) and a stator (12 - Fig.1).
The rotor, typically made of metal, is a single- or multi-start screw with round thread, extremely large pitch, considerable height and high
eccentricity in relation to the core diameter.
The stator, typically made of elastic material, is impressed with a cavity in the shape of a two or more start screw, double thread compared to
the rotor and with the same eccentricity.
The rotor, rotating within the stator, is forced to perform a hypocycloid roto-translational movement. This coupling of the two elements always
creates a line of contact along the profile that guarantees the seal between them. This movement creates an airtight chamber that shifts with a
helical movement, from the suction casing to the delivery casing.
The theoretical flow rate (Qt) is directly proportional to the number of revolutions of the pump and it can be calculated using the following
equation:
Qt = theoretical flow rate [m³/h]
D = rotor diameter [mm]
e = rotor eccentricity [mm]
P = rotor pitch [mm]
n = revolutions per minute [rpm]
The absorbed power is calculated using the following equation: ::
P = absorbed power [kW]
Q = flow rate [m³/h]
H = differential pressure [bar]
ɳ = overall efficiency (is the product of the volumetric efficiency and the mechanical efficiency)
In progressing cavity pumps the axis of rotation of the rotor does not coincide with the axis of rotation of the drive (3 - Fig.1). The rotor receives
motion from a double-jointed drive shaft (1 - Fig.1). The function of the rotating unit, consisting of drive shaft, hollow shaft (2 - Fig.1) and rotor, is
to transfer the torque given by the drive, support the eccentricity of the pumping unit (rotor + stator), bear the axial loads generated by back
pressure and the reaction generated by the roto-translation between rotor and stator.
4.3 Structure of the pump
For a description of the pump see Fig.1.
The pump can be coupled to the drive (3) with 2 types of coupling, defined as:
 type D: the drive is coupled directly to the coupling flange (4) and the hollow shaft (2); in this case the pump stress is absorbed by the
drive.
 type J: the bearing housing (6) is positioned between the drive (3) and the coupling flange (4). The drive is connected to the male shaft
with a flexible coupling fitted with a protective shield. The bearing support absorbs the pump stress and consequently increases its
reliability and sturdiness. This solution includes high performance bearings that require correct lubrication to work properly.
The pump can be made in various construction types, depending on the type of pump body (7) for pumps N and V or hopper for pumps H, HB,
HE, HP, HS. The HB and HP constructions include bridge breaker hopper with additional motor-driven product pushers. Various shapes and
sizes of connections are available, flanged or with quick couplings, terminal, threaded or special. Additional connections can also be made for
C.I.P. applications (Cleaning In Place).
The dimensions of each construction type of pump/hopper body are optimised for the type of fluid to be pumped guaranteeing suitability for high
viscosity fluids containing solids.
There are two joints (9) inside the pump body that enable the transmission of torque in presence of eccentricity. They are sealed with a rubber
protection and filled with oil to ensure perfect lubrication of the internal components.
The standard shaft has a single mechanical type seal (10), but the pump can also be configured with PTFE gland packing seals or double
mechanical seals. On request, cartridge or other types of seals can also be used. For both mechanical and gland packing seals suitable
housings are available for flushing the seals..
NOTE!
All variations must be defined and agreed with the Manufacturer at both the Offer and the Order Confirmation stage. The
operational limits of the pump are agreed at the Order Confirmation stage.
North Ridge Pumps Registered in England and Wales 03652700.
Registered Office: 12 Bridgford Road, West Bridgford, Nottingham, NG2 6AB . VAT No. GB324963488
X-Cel House, Chrysalis Way, Langley Bridge, Nottinghamshire, NG16 3RY
Tel: [phone] | Email: [email protected] | Website: www.northridgepumps.com

OM.EN-GEN002 R00 08/07/13 Pag.12
Fig.
1
–
General description
4.4 Pump with bypass (optional)
The bypass (Fig.2) is an overpressure protection device. It consists of a valve (on request pre-calibrated or not), tubing and flanges which
connect the delivery casing to the suction casing. When the delivery pressure exceeds valve calibration pressure, the valve opens and the fluid
returns to the suction casing. The valve calibration pressure depends on process requirements, the type of pumped product and the number of
pump stages.
Fig.
2
–
Bypass operating principle
CAUTION!
The calibration pressure of the bypass valve must be agreed with the Manufacturer. The operating limits must comply with those
specified at the Order Confirmation stage.
With the bypass installed, the pump can only operate in one direction depending on how the bypass is installed, see
Fig.
2
.
4.5 Safety, pressure relief, check valves
The Manufacturer recommends installing the following devices:
 safety valve on the delivery casing to prevent operating pressures exceeding the pump’s specifications;
 check valve on the delivery casing to prevent return flow through the system.
NOTE!
If both a safety valve and a check valve are installed then the safety valve should be positioned closer to the pump than the
check valve.
4.6 Dry run protection
CAUTION!
Running the pump dry, even for just a few seconds, can ruin or even irreparably damage it.
When a continuous flow of liquid is not guaranteed, it is advisable to use special protection against dry running to protect the stator.
For pumps fitted with electric motors, a typical protection that prevents damage to the stator cause by lack of fluid, involves installing a
temperature sensor in the stator and connecting it to the electric panel that powers the motor. If fluid does not arrive, the rubber of the stator
overheats and increased temperature acts on the electrical circuit and shuts off the motor; this device can even be fitted after the pump has
been installed.
Alternatively, flow switches or other systems suitable for specific requirements can be used to directly control product presence; in this case
contact the Manufacturer.
North Ridge Pumps Registered in England and Wales 03652700.
Registered Office: 12 Bridgford Road, West Bridgford, Nottingham, NG2 6AB . VAT No. GB324963488
X-Cel House, Chrysalis Way, Langley Bridge, Nottinghamshire, NG16 3RY
Tel: [phone] | Email: [email protected] | Website: www.northridgepumps.com

OM.EN-GEN017 R00 08/07/13 Pag.13
4.7 Drives
Various types of drives can be applied to the pump, but the most commonly used combinations include electric motors, hydraulic motors,
gearmotors or variable speed motors.
For pumps with J type support, refer to the dimensional drawing for the dimensions of the independent output shaft and for the drive refer to the
Manufacturer’s specifications.
For pumps with D type support, the drive must be coupled to the pump with the special coupling pin and the drive output shaft must be made to
the Manufacturer’s specifications. With reference to Fig.3, Tab.1 below lists the dimensions of the drive connections for the input flange and the
hollow shaft.
Size Model Input flange
[mm]
A (±0,05)
[mm]
B
[mm]
d (F8)
[mm]
D (h7)
[mm]
1L1
D020 05K2 160/200 16 8,1 20 30
025K4
2L1
D025 1K2 160/200 20 8,1 24 35
05K4
4L1
D030 2K2 160/200 20 8,1 24 35
1K4
05K8
10L1
4K2
D040 2K4 200 30 12,1 30 45
1K8
16L1
8K2
20L1
10K2
D060 4K4 200/250 35 16,1 35 55
2K8
30L1
16K2
40L1
20K2
D120 10K4 250/300 35 18,1 40 65
4K8
60L1
30K2
80L1
40K2
D300 20K4 250/300 38 20,1 50 70
10K8
120L1
60K2
Tab.
1
–
Dimensions of the drive connections
Fig.
3
–
Dimensions of the drive connectio
ns
North Ridge Pumps Registered in England and Wales 03652700.
Registered Office: 12 Bridgford Road, West Bridgford, Nottingham, NG2 6AB . VAT No. GB324963488
X-Cel House, Chrysalis Way, Langley Bridge, Nottinghamshire, NG16 3RY
Tel: [phone] | Email: [email protected] | Website: www.northridgepumps.com

OM.EN-COM001 R00 08/07/13 Pag.14
5 ORDER IDENTIFICATION
5.1 Product identification
To enable the Manufacturer to identify the pump you must quote the following details that are marked on the data plate:
 model and version (marked on the data plate in the “PUMP TYPE” field)
 serial number (marked on the data plate in the “SERIAL NUMBER” field)
5.2 Supplied documentation and technical specifications
The documents listed in Tab.2 are provided together with these Operating Instructions.
NOTE!
Specific documentation relating to special pumps or pumps with features made to customer specifications must be requested
prior to signing the order.
All documents relating to a job order are certified by the Manufacturer
solely for the pump specified in that job order
.
Document Description
Datasheet / Order Confirmation Technical specification of the pump and the drive (if installed), operating conditions,
operational limits, product configuration
Dimensional Drawing Size configuration, operational dimensions, connection sizes
Performance Curve (Performance Data) The pump’s performance characteristics
Performance Test (on request) Performance and functional testing of the pump
Third Party Documents Technical documents, instructions for use and maintenance for third party
components installed on the pump
Declaration of Conformity Compliance with Pump Directive 2006/42/EC
Supplementary ATEX Instruction (for ATEX
pumps) Operating Instructions for potentially explosive atmospheres
Tab.2 – Supplied Documentation
5.3 Data plate
The data plate is made of aluminium and is affixed to the coupling flange with rivets.
There are two types of data plate:
 for standard pumps (Fig.4);
 for ATEX pumps (Fig.5).
Fig.4 – Data plate for standard pump Fig.5 - Data plate for ATEX pump
The ATEX marking consists of the following elements (14 - Fig.5):
 CE 1131: CE mark with the identification number of the notified body
 II: equipment group: surface
 2: (equipment) category: high protection
 G: type of explosive atmosphere: gas vapours
 IIB: explosion group: type of gas present in the atmosphere where the pump is used
 TX: Max surface temperature class
North Ridge Pumps Registered in England and Wales 03652700.
Registered Office: 12 Bridgford Road, West Bridgford, Nottingham, NG2 6AB . VAT No. GB324963488
X-Cel House, Chrysalis Way, Langley Bridge, Nottinghamshire, NG16 3RY
Tel: [phone] | Email: [email protected] | Website: www.northridgepumps.com

OM.EN-COM001 R00 08/07/13 Pag.15
Det. Description of standard pump data plate Det. Description of ATEX pump data plate
1 Manufacturer’s details 1 Manufacturer’s details
2 Country of manufacture 2 Country of manufacture
3 Model and version 3 Model and version
4 Serial number 4 Serial number
5 Year of manufacture 5 Year of manufacture
6 Capacity [m3/h] 6 Capacity [m3/h]
7 Maximum pressure [bar] for counterclockwise rotation
direction 7 Maximum pressure [bar] for counterclockwise rotation direction
8 CE certification symbol 8 CE certification symbol
9 Customer ref. no. (if necessary) 9 Customer ref. no. (if necessary)
10 Speed [R.P.M.] 10 Speed [R.P.M.]
11 Maximum pressure [bar] for counterclockwise rotation
direction 11 Maximum pressure [bar] for counterclockwise rotation direction
12 ATEX certification sysmbol
13 Certification body identification
14 ATEX marking
15 Certificate number
Tab.3- Data plate
5.4 Model identification
The pump is identified with the following code number, corresponding to the “SIZE PUMP” section on the data plate (3 - Fig.4 and Fig.2):
 pump type (D or J)
 construction type (N - X - V - H - HB - HE- HP – HS- HSB)
 model (corresponding to Model column in Tab.4)
 complete assembly ( E )
The technical characteristics for the different sizes and models are given in Tab.4.
Size Model Qmax 2 bar
[m³/h] rpm max P max [bar]
1L1 4.9 1400 6
D020 05K2 2.5 1400 12
025K4 0.7 800 24
2L1 10 1400 6
D025 1K2 5.1 1400 12
05K4 1.5 800 24
4L1 14 1000 6
D030 2K2 7.2 1000 12
1K4 2.9 800 24
05K8 1.5 800 48
10L1 22 800 6
4K2 11.5 800 12
D040 2K4 4.2 600 24
1K8 2.9 800 48
16L1 32.5 800 4
8K2 16.8 800 8
20L1 39.1 700 6
10K2 17.2 600 12
D060 4K4 7.2 500 24
2K8 4.2 500 48
30L1 46 700 4
16K2 21.5 600 8
40L1 65.5 600 6
20K2 31 600 12
D120 10K4 11.7 400 24
4K8 7.3 500 48
60L1 82 500 4
30K2 40.5 500 8
80L1 88 400 6
40K2 43 400 12
D300 20K4 22 400 24
10K8 11.7 400 48
120L1 120 400 4
60K2 64.5 400 8
Tab.4 – Performance of each model
North Ridge Pumps Registered in England and Wales 03652700.
Registered Office: 12 Bridgford Road, West Bridgford, Nottingham, NG2 6AB . VAT No. GB324963488
X-Cel House, Chrysalis Way, Langley Bridge, Nottinghamshire, NG16 3RY
Tel: [phone] | Email: [email protected] | Website: www.northridgepumps.com

OM.EN-COM001 R00 08/07/13 Pag.16
NOTE!
The data in Tab.4 are merely intended as a guide and only serve to give a rough indication of the range of use for each size. For
the actual operating data always refer to the supplied Datasheet and Performance Curves.
Depending on the construction type some models are not avail
able or are limited to different pressure and capacity values.
The pump can be:
 D: close coupled, where the pump is directly coupled to the drive by means of a coupling flange
 J: bearing housing, where the pump is coupled to the drive with a flexible coupling
The construction type can be:
 N: pump with pump body and outlet flange with couplings for connection to the system tubes
 X: machine for the healthcare industry with body pump and vents with sanitary connections for connecting to the plant piping
 V: pump for vertical installation with pump body and coupling for connection to the system tubes and outlet flange immersed in the
product to be pumped
 H: pump with hopper, auger feed screw and outlet flange with coupling for connection to the system tubes
 HB: pump with hopper, auger feed screw and outlet flange with coupling for connection to the system tubes and equipped with two
bridge breaker blades
 HE: pump with hopper, auger feed screw and outlet flange with coupling for connection to the system tubes, designed specifically for the
winemaking industry
 HP: pump with hopper, auger feed screw, outlet flange and coupling for connection to the system tubes, fitted with product pushers
 HS: pump with hopper and auger feed screw reinforced for heavy duty applications and outlet flange with coupling for connection to the
system tubes
 HSB: HS pump equipped with bridge breaker module
The various models have been grouped according to size as indicated in Tab.4, and each model belonging to the size group has the same:
 transmission (excluding the rotor)
 connection to the drive
 seal system
 hopper or pump body
 bearing housing, if present
The type of assembly corresponds to the type of standard accessory supplied:
 E: if the pump is equipped with a food-grade bypass assembly and trolley
An example of “PUMP TYPE” is DN 120L1 – E: Close-coupled pump, construction type N, size 120L1 equipped with food-grade bypass
assembly and trolley.
North Ridge Pumps Registered in England and Wales 03652700.
Registered Office: 12 Bridgford Road, West Bridgford, Nottingham, NG2 6AB . VAT No. GB324963488
X-Cel House, Chrysalis Way, Langley Bridge, Nottinghamshire, NG16 3RY
Tel: [phone] | Email: [email protected] | Website: www.northridgepumps.com

OM.EN-TRA001 R00 08/07/13 Pag.17
6 DATASHEET
Company:
Order confirm. N.: of:
Offer N°: Rev. of:
Your Order N.: of:
Serial number:
PROGRESSIVE CAVITY PUMP
mod.: DXC 20L1 DIAMOND SERIES
Wetted casing and rotating parts material:
Classification:
Series FD - Food sector
FLUID CHARACTERISTICS
Pumped fluid:
Viscosity:
Solids concentration:
Solids size:
Specific gravity:
Abrasiveness:
PH:
Working temperature:
OPERATING CONDITIONS
Service:
Rotation:
Differential pressure:
Suction pressure:
CONSTRUCTION AND PUMP MATERIALS
Installation:
Pump body::
Outlet connection:
Stator:
Rotor:
Joint:
Transmission shaft:
Drive shaft:
Seal housing:
Seal:
Coupling:
Painting:
Static seal
North Ridge Pumps Registered in England and Wales 03652700.
Registered Office: 12 Bridgford Road, West Bridgford, Nottingham, NG2 6AB . VAT No. GB324963488
X-Cel House, Chrysalis Way, Langley Bridge, Nottinghamshire, NG16 3RY
Tel: [phone] | Email: [email protected] | Website: www.northridgepumps.com

OM.EN-TRA001 R00 08/07/13 Pag.18
7 TRANSPORTATION AND STORAGE
7.1 Transportation, handling and positioning
7.1.1 Instructions for transportation
Progressing cavity pumps are packed in special containers (boxes on pallets, crates) unless the user/purchaser specifies a different type of
packaging in the order.
The Manufacturer is not liable for damages or lost parts that could occur following transportation of the machine.
7.1.2 Precautions to be taken upon receipt of the pump
On receipt of the pump the Customer must:
 check against the delivery note that all the machine parts have been delivered;
 check that the information on the data plate corresponds to the specifications set out in the order;
 check for damages incurred during transit;
 inform the carrier and the Manufacturer immediately if you discover any damage incurred during transit;
 check that you have received all the documents listed in 6.2 – Supplied documentation and technical specifications, if any are
missing contact the Manufacturer for a copy.
7.1.3 Ambient conditions required for storage
The pump must be stored in a safe, cool and dry location, sheltered from the weather.
7.1.4 Instructions for handling and positioning the pump
QUALIFIED TECHNICIAN – Person in charge of handling the machine
All the handling/positioning operations are the responsibility of the Customer.
These operations are the responsibility of the Person in charge of handling the machine, who has been adequately trained on
the use of lifting and handling equipment.
The following instructions must be observed when handling and positioning the machine:
 prohibit access to unauthorised persons;
 move away from the loads before carrying out lifting and lowering operations;
 prohibit vehicles that are not used for lifting/handling the pump from circulating in the installation area to prevent accidental collision with
protruding parts.
CAUTION!
The equipment used, including the ropes, must be approved for lifting and handling the specific weight of the pump
(use the dimensional drawing as reference).
NOTE!
Use suitable lifting and handling equipment and always observe appropriate safety measures.
The pump must be transported manually or with suitable transportation or lifting equipment, depending on: the construction type
and size, its mass and distribution (barycentre) and the lug points provided on the pump.
Avoid collisions with and/or application of pressure on the protruding parts, particularly the protection guards.
Some medium and small sized models are trolley-mounted for easy handling.
The individual packages are marked with the name of the part and handling instructions are affixed to each one.
Refer to the dimensional drawing for the weight and dimensions of the machine.
PROHIBITED!
It is prohibited to lift the machine with its barycentre shifted with respect to the lift point.
It is prohibited to lift the whole machine using the eyebolts on the motor or gearbox. These are intended solely for the purpose
of lifting the motor or the gearbox.
CAUTION! RISK OF TIP-OVER!
Abrupt or reckless manoeuvres can cause the pump to tip over with serious consequences.
Operators must ensure that the pump will not tip over while being transported and positioned, and that it is handled safely and in
a stable position.
The pump must always and only be placed in a horizontal position.
Vertical axis machines (V) must never be left in an uprig
ht position without adequate fixing.
PERSONAL PROTERCTIVE EQUIPMENT
It is mandatory to wear a safety helmet when handling and positioning the machine.
PERSONAL PROTERCTIVE EQUIPMENT
It is mandatory to wear protective gloves when handling and positioning the machine.
North Ridge Pumps Registered in England and Wales 03652700.
Registered Office: 12 Bridgford Road, West Bridgford, Nottingham, NG2 6AB . VAT No. GB324963488
X-Cel House, Chrysalis Way, Langley Bridge, Nottinghamshire, NG16 3RY
Tel: [phone] | Email: [email protected] | Website: www.northridgepumps.com

OM.EN-TRA001 R00 08/07/13 Pag.19
PERSONAL PROTERCTIVE EQUIPMENT
It is mandatory to wear protective footwear when handling and positioning the machine.
As the pump configurations are all very different, the following instructions are of a general nature, but they do provide sufficient guidelines on
how to correctly handle the pump. If in doubt contact the Manufacturer for more detailed instructions.
Once the packaging has been removed from the horizontal axis pump, it must only be lifted by means of the base (1 - Fig.6). The external fixing
holes or the eyebolts on the base (2 - Fig.6) can be used to lift it.
NOTE!
If the pump is not supplied with a base or eyebolts, use ropes. The ropes must be placed around the pump in such a way to
ensure a balanced lift (3 - Fig.6).
Fig.
6
–
Handling and positioning
7.1.5 Instructions for subsequent handlings and positionings
Subsequent handlings and positionings differ depending on whether the machine is trolley-mounted or not.
7.1.6 For machines that are not trolley-mounted there are no particular instructions, simply refer to 7.1.4 - Instructions for handling and
positioning the pump.
For subsequent handlings and positionings, if the pump is trolley-mounted, proceed as follows:
 put the machine in “MAINTENANCE MODE” as described in 11 - Maintenance;
 verify that the machine is not connected to any plant;
 release the wheel brakes;
 shift the trolley-mounted pump manually, slowly and carefully, and position it in its new position;.
 apply the brakes to the wheels;
 return the machine to normal operating mode as described in 11 - Maintenance.
7.2 Unpacking and disposal of packaging materials
Packaging requirements are discussed and agreed with the Customer at the ordering stage. They can include:
 boxes;
 pallets;
 crates.
Once the pump has been unpacked, check that all machine parts are intact. Contact the Manufacturer if there is evidence of damage and/or
defects. Unpacking and disposal of the packaging are the responsibility of the Customer, who is required to comply with the applicable
regulations in the country of installation.
North Ridge Pumps Registered in England and Wales 03652700.
Registered Office: 12 Bridgford Road, West Bridgford, Nottingham, NG2 6AB . VAT No. GB324963488
X-Cel House, Chrysalis Way, Langley Bridge, Nottinghamshire, NG16 3RY
Tel: [phone] | Email: [email protected] | Website: www.northridgepumps.com

OM.EN-INS001 R00 08/07/13 Pag.20
8 INSTALLATION AND ASSEMBLY
8.1 Positioning the machine
QUALIFIED TECNICIAN – Plant engineer
The Customer is must adhere to the applicable regulations in the country of installation and employ a Plant engineer to perform
this operation .
CAUTION!
The Customer is responsible for assessing the space available in their facility for the installation of the pump. Unless
otherwise specified at the ordering stage, the machine must not be used in environments that are subject to the
formation of a potentially explosive atmosphere.
The Customer must provide an installation area that is adequate for the dimensions of the pump, while also allowing for the movement of the
handling equipment. There must not be any obstacles along the route required for the placement of the machine.
The foundations of the installation site must be capable of absorbing the weight of the machine.
CAUTION!
Stator maintenance operations require the amount of space illustrated below (L – Fig.7) for disassembly and replacement. For the
overall dimensions of the stator refer to Tab.5.
Size Model L
[mm]
1L1 220
D020 05K2 220
025K4 300
2L1 270
D025 1K2 270
05K4 420
4L1 340
D030 2K2 340
1K4 520
05K8 520
10L1 420
4K2 420
D040 2K4 660
1K8 660
16L1 490
8K2 490
20L1 530
10K2 530
D060 4K4 810
2K8 810
30L1 600
16K2 600
40L1 645
20K2 645
D120 10K4 1060
4K8 1060
60L1 780
30K2 780
80L1 840
40K2 840
D300 20K4 1280
10K8 1280
120L1 960
60K2 960
Fig.
7
–
Space required for maintenance of the stator
Tab.
5
–
Overall dimensions of stators
CAUTION!
The entire base, whether provided by the Customer or supplied by the Manufacturer, must lie flat against the foundations. The
pump must not be installed on a base that is larger than the foundations. For the dimensions of the base refer to the supplied
dimensional drawing.
The pump should be placed and positioned in such a way that the access and escape routes are practical and easy to use in an emergency.
Lighting must comply with applicable regulations in the country of installation; in any case, it must be uniform and provide good visibility in all
points of the pump.
In addition, take into account :
 the space required for maintenance of the pump and for any additional devices
