Norton Clipper CFP16W User manual

CFP16W
COMPACTOR
OPERATING INSTRUCTIONS
Translation of the original Instructions

VERS. 01.09.2019 CFP16W _MAN_EN
2
The undersigned manufacturer: SAINT - GOBAIN ABRASIVES S.A.
190, BD. J. F. KENNEDY
L-4930 BASCHARAGE
Declares that this product: Norton Clipper Compactors CFP16 W
Code: 70184608011 Honda GX 160
Is in conformity with the following Directives:
"MACHINES" 2006/42/CE
"NOISE" 2000/14/CE
And European standard :
•EN 500-1 Mobile road construction machinery. Safety - Part 1: Common requirements
•En 500-4 Mobile road construction machinery - Safety - Part 4: Specific requirements for
compaction machines
Valid for machines as of serial number : 450xxxxxxx
Storage site for the technical documents :
Saint-Gobain Abrasives 190, Bd. J. F. Kennedy 4930 BASCHARAGE, LUXEMBOURG
This declaration of conformity loses its validity when the product is converted or modified without agreement.
Bascharage, Luxembourg, le 01.09.2019 :
François Chianese, executive officer.
Declaration of conformity

VERS. 01.09.2019 CFP16W _MAN_EN
3
Norton Clipper CFP16W
OPERATING INSTRUCTIONS
TABLE OF CONTENTS
1BASIC SAFETY INSTRUCTIONS
1.1 Symbols
1.2 Machine plate
1.3 Safety instructions for particular operating phases
2MACHINE DESCRIPTION
2.1 Short description
2.2 Purpose of use
2.3 Layout
2.4 Technical Data
2.5 Statement regarding the vibration emission
2.6 Statement regarding noise emission
3ASSEMBLY AND COMMISSIONING
4TRANSPORT AND STORING
4.1 Securing for transport
4.2 Transport procedure
4.3 Long period of inactivity
5OPERATING THE MACHINE
5.1 Site of work
5.2 Preparing the site
5.3 Floating and finishing operation
6MAINTENANCE AND SERVICING
6.1 Maintenance of the machine
7FAULTS: CAUSES AND CURES
7.1 Fault-finding procedures
7.2 Trouble-shooting guide
7.3 Spare parts
1-BASIC SAFETY INSTRUCTIONS

VERS. 01.09.2019 CFP16W _MAN_EN
4
The Norton Clipper CFP16W is exclusively designed for compaction mainly on construction sites.
Uses other than the manufacturer's instructions shall be considered as contravening the regulations.
The manufacturer shall not be held responsible for any resulting damage. Any risk shall be borne
entirely by the user. Observing the operating instructions and compliance with inspection and
servicing requirements shall also be considered as included under use in accordance with the
regulations.
1.1 Symbols
Important warnings and pieces of advice are indicated on the machine using symbols. The following
symbols are used on the machine:
Read operator's instructions
Ear protection must be worn
Hand protection must be worn
Eye protection shall be worn

VERS. 01.09.2019 CFP16W _MAN_EN
5
1.2 Machine plate
Important data can be found on the following plate located on the machine:
1.3 Safety instructions for particular operating phases
Before starting the work
•Before commencing work, make yourself familiar with the working environment at the place
of use. The working environment includes: obstacles in the area of work and manoeuvre, the
firmness of the floor, necessary protection at the site relating to public thoroughfares and the
availability of help in the event of accidents..
•Plate compactors must only be used for compaction jobs observing safety and operating
instructions.
•People who work with plate compactors must know everything regarding safety instructions.
•Do not take drugs or drink alcohol before using plate compactors.
•Always wear appropriate protective clothes (ear protections, gloves, protecting shoes and
helmet).
•Do not alterate the operation devices of the plate compactor.
•Do not leave control elements during compaction.
•Store the compactor with engine off in a safe place.
•Always refill fuel tank when the engine is off. Do not allow fuel to come into contact with the
hot parts of compactor and engine.
•Do not smoke when using compactor. Keep the compactor out of open flames.
•Always check fuel tank cap. If there is a fuel cock, shut it off when the engine is not working.
•Do not use the compactor in places where there are gaseous exhalations.
•Do not use the machine indoors or in an enclosed area unless inadequate ventilation.
•Always wear appropriate protective clothes.
Machine model
Machine code
Machine Weight
Year of production
Serial number

VERS. 01.09.2019 CFP16W _MAN_EN
6
•When the work area is near slopes, the compactor could turn over.
•When you use compactor in reverse and in a narrow place, the operator must be sideways
from the handle in order to avoid stumbling.
•Always operate in safe conditions in order to avoid accidents.
•Always operate in maximum stability conditions.
•Use transport wheels only for movements in yard. In all the other situations they must be
removed.
•Always make sure of the proper functioning of the safety and control devices.
•If there are any problems, stop immediately the machine and inform the person responsible
of the yard.
•Attention is drawn to the use of BS2092 safety goggles in conformity with specified
Processes No.8 of the Protection of Eyes Regulation 1974, Regulation 2(2) Part 1. and
additional dusk mask for dry cutting (only in exceptionally cases).
CLIMBING ABILITY
2-MACHINE DESCRIPTION
Any modification, which could lead to a change in the original characteristics of the machine, may
be done only by Saint-Gobain Abrasives who shall confirm that the machine is still in conformity with
the safety regulations.

VERS. 01.09.2019 CFP16W _MAN_EN
7
2.1 Short description
The compactor CPF16W is suitable for repairing asphalted surfaces, for small compacting jobs and
for preparing green areas
As with all other NORTON products, the operator will immediately appreciate the attention given to
detail and quality of materials used in construction. The machine and its component parts are
assembled to high standards assuring long life and minimum maintenance.
2.2 Purpose of use
The vibration required for tamping is produced by the exciter which is on the compacting plate.
The engine starts the exciter and the torque is transmitted by the centrifugal clutch and by the belt.
In order to allow the idling of the drive engine, the centrifugal clutch, at low engine speeds, interrupts
the flow of power to exciter. The compactor must always be used with the gas handle in the
“OPERATIVE” position.
The engine supporting and the compacting plates are connected by 4 shockmount, which are
mounted to avoid that vibrations reach the operator.
Only use the machine for the purpose for which it is intended.
2.3 Layout
6
2
3
8
5
1
7
4

VERS. 01.09.2019 CFP16W _MAN_EN
8
Handle (1)
Jig welded steel construction is connected by 4 shockmount on the frame of the machine to reduce
the vibrations reach the operator
Belt drive and belt cover (2)
A centrifugal clutch inside the engine pulley drives the gear shaft through V-Belts. It allows to
gradually engaging the vibration of the machine. The drive assembly is enclosed in a metal guard.
Water tank (3)
Resistant plastic water tank
Thermal Engine (4)
The machine has a GX160 Honda engine with 4,8HP (3.6kw)
Lifting eye (5)
To lift the machine easily and safely, a lifting eye is located over the engine. This allows a balanced
lifting of the machine.
Eccentric element (6)
In the our compactors the system of eccentric elements has been optimized by moving the weight to
the right side of the axle, so that less weight counteracts the movement at start-up.
Less power is required to initiate the vibratory action, reducing energy consumption at start-up by
50% and thus using less fuel.
Plate (7)
The plates have rounded edges and raised to avoid marking the surface
Shock absorbers (8)
The engine supporting and the compacting plates are connected by 4 shockmount, which are
mounted to avoid that vibrations reach the operator.

VERS. 01.09.2019 CFP16W _MAN_EN
9
2.4 Technical DATA
2.4 VIBRATION MEASUREMENTS
The engine supporting and the compacting plates are connected by 4 shockmount, which are
mounted to avoid that vibrations reach the operator.
Products are tested for hand/arm vibration level in accordance with annex D prEN500-4:2001
The hand/harm vibration level is 9,2 m/s2
The plate compactor has been tested on a “macadam” surface, produced with not cleaned stone
crusher grit, with 16 mm medium diameter (with components which have diameter that goes from 10
to 20 mm).
2.5 SOUND MEASUREMENTS
The product has been produced in accordance with the standard 2000/14/CE, procedure I annex VI.
Measured sound power level 99 [dB(A)] and guaranteed sound power level 103 [dB(A)] on a
significant equipment.

VERS. 01.09.2019 CFP16W _MAN_EN
10
3-ASSEMBLY AND COMMISSIONING
Starting the machine
Turn the fuel valve to the ON position. Fully press
the dead-man handle against the main handle.
Move the choke lever to the CLOSED position.
NOTE: do not use the choke if the engine is warm or the
air temperature is high.
Move the throttle control lever slightly to the left.
Put the engine switch on ON.
Pull the starter grip lightly until you feel resistance, then
briskly.
CAUTION: Do not allow the starter grip to snap back
against the engine. Return it gently to prevent damage to
the starter.
As the engine warms up, gradually move the
choke lever to the OPEN position.
Position the throttle control lever for the
Maximum engine speed.
To stop the engine, release the dead-man handle, move the throttle control lever fully to the right,
then turn the engine switch to the OFF position. Turn the fuel valve to the OFF position.

VERS. 01.09.2019 CFP16W _MAN_EN
11
CAUTION: when the machine is switched off, the tools will continue turning slowly to complete stop.
Be therefore very careful to avoid injuries.
4-Transport and storing
4.1 Securing for transport
Conform yourself to work regulations, in order to transport the machine safely. To help you transport
the machine, you can remove the transport tube from under the handle and located in the front hole
of the machine.
4.2 Transport procedure
Conform yourself to work regulations, in order to transport the machine safely. To help you transport
the machine, you can remove the transport tube from under the handle and located in the front hole
of the machine.
4.3 Long period of inactivity
If the machine is not going to be used for a long period, completely clean the machine and
disassemble the tools. The storage site must be clean, dry and at a constant temperature.
5- OPERATING THE MACHINE
5.1 Site of work
•Remove from the site anything, which might hinder the working procedure!
•Make sure the site is sufficiently well lit!
•Make sure you have a continual adequate view of the working area so you can intervene in the
working process at any time!
•Keep other staff out of the area, so you can work securely.
5.2 Preparing the site
Ad equation to compaction, it will be necessary to identify the characteristics of soils and material, to
study their ability

VERS. 01.09.2019 CFP16W _MAN_EN
12
6- MAINTENANCE AND SERVICE
6.1 Maintenance of the machine
To ensure a long-term quality from the use of the Clipper compactors CPF16W, please follow the
maintenance plan below:
7-FAULT : CAUSES AND CURES
7.1 Fault –finding procedures
Should any fault occur during the use of the machine, turn it off. Any works dealing with the engine
of the machine can only be carried out by a qualified technician.
7.2 Troubles-shooting guide
TROUBLE
POSSIBLE CAUSE
SOLUTION
The engine works properly but the
machine does not vibrate
The transmission belt is broken
Replace the belt
The wear and tear has caused the
belt to
loosen up
The centrifugal clutch has broken Replace the centrifugal clutch
Reduced or irregular speed The engine rpm is not correct Verify that during compaction gas lever is in
“OPERATIVE” position

VERS. 01.09.2019 CFP16W _MAN_EN
13
Reset the number of engine rpm
The transmission belt has loosened up Tension the transmission belt and, if
necessary, replace it
The engine rpm are low but the exciter
does not stop Centrifugal clutch malfunction Repair the centrifugal clutch and, if
necessary, replace it
The exciter heats up to over 90° (bath oil
only) There is too much of oil in the exciter
Top up the oil level. Check whether the oil
seal has been damaged; if necessary replace
it
The engine works with difficulty and the
exciter is too noisy and it stops or slows
down
Mechanical block of the exciter (bearings,
shaft)
Remove the element causing the failure or, if
necessary, replace the exciter
The engine turns off or does not work
properly
Fuel tank empty Add fuel
Oil lack Add oil
Dirty air filter
Clean air filter, if necessary replace it
Engine damaged
Contact an engine service center

VERS. 01.09.2019 CFP16W _MAN_EN
14
7.3 Spare parts
In order to consult the spare parts lists, we invite you to visit the after-sales website of Norton
Clipper by using the following address:
https://spareparts.nortonabrasives.com
For a quick access, you can also use the QR Code shown below using your mobile phone:
This electronic catalogue provides exploded views and spare parts lists for different machines
designed by Norton Clipper so you can find references you need.
When ordering spare parts, please mention:
•The serial number.
•The code of the part.
•The exact denomination.
•The number of parts required.
•The delivery address.
•Please indicate clearly the means of transportation required such as "express" or "by air".
Without specific instructions, we will forward the parts through the means which seem
appropriate to us --- but which is not always the quickest way.
Clear instructions will avoid problems and faulty deliveries.
If not sure, please send us the defective part. In the case of a warranty claim, the part must always
be returned for evaluation. Spare parts for the motor can be ordered with the manufacturer of the
motor or with their dealer, which is often quicker and cheaper.
This machine has been manufactured by Saint-Gobain Abrasives S.A.
190, Bd. J.F. Kennedy
L- 4930 BASCHARAGE
Grand-Duché de Luxembourg.
Tel.: [phone]
http://www.construction.norton.eu
e-mail: [e-mail]

VERS. 01.09.2019 CFP16W _MAN_EN
15
Guarantee can be claimed and technical support obtained from your local distributor where
machines, spare parts and consumables can be ordered as well:
SAINT-GOBAIN ABRASIVES
INDUSTRIEWEG 21
9420 ERPE-MERE
BELGIUM
TEL: [phone]
SAINT-GOBAIN ABRASIVES, S.R.O.
POČERNICKÁ 272/96, MALEŠICE
108 00 PRAHA 10
CZECH REPUBLIC
TEL: [phone]
FAX: [phone]
SAINT-GOBAIN ABRASIVES A/S
DYBENDALSVÆNGET 2,
DK-2630 TAASTRUP
DENMARK
TEL: [phone]
PO BOX 643706
FORTUNE TOWER OFFICE 2106
JLT BLOCK C
(NEXT TO METRO STATION)
JUMEIRA LAKE TOWER, DUBAI
UNITED ARAB EMIRATES
TEL: [phone]
FAX: [phone]
SAINT-GOBAIN ABRASIFS
RUE DE L’AMBASSADEUR - B.P.8
78 702 CONFLANS CEDEX
FRANCE
TEL: [phone]
FAX: [phone]
SAINT-GOBAIN ABRASIVES GMBH
BIRKENSTRASSE 45-49
D-50389 WESSELING
GERMANY
TEL: [phone]
[phone]
[phone]
FAX: [phone]
[phone]
[phone]
FÜR DEN FACHHANDEL
ÖSTERREICH
TEL: [phone]
SAINT-GOBAIN ABRASIVES KFT.
1225 BUDAPEST
BÁNYALÉG U. 60/B.
HUNGARY
TEL: [phone]
FAX: [phone]
SAINT-GOBAIN ABRASIVI S.P.A
VIA PER CESANO BOSCONE 4
I-20094 CORSICO MILANO
ITALY
TEL: [phone]
FAX: [phone]
SAINT-GOBAIN ABRASIVES S.A.
190 RUE J.F. KENNEDY
L-4930 BASCHARAGE
GRAND DUCHE DE LUXEMBOURG
TEL: [phone]
FAX: [phone]
NO. VERT (FRANCE): 0800 906 903
SAINT-GOBAIN ABRASIFS, S.A.
2 ALLÉE DES FIGUIERS
AIN SEBAÂ - CASABLANCA
MOROCCO
TEL: [phone]
FAX: [phone]
SAINT-GOBAIN ABRASIVES BV
GROENLOSEWEG 28
7151 HW EIBERGEN
P.O. BOX 10
7150 AA EIBERGEN
THE NETHERLANDS
TEL: [phone]
FAX: [phone]
SAINT-GOBAIN ABRASIVES AS
POSTBOKS 11, ALNABRU,
0614 OSLO
BROBEKKVEIEN 84,
0582 OSLO
NORWAY
TEL: [phone]
FAX: [phone]
SAINT-GOBAIN HPM POLSKA SP. Z O.O.
UL. NORTON 1, 62-600 KOŁO
62-600 KOŁO
POLAND
TEL: [phone]
FAX: [phone]
SAINT-GOBAIN ABRASIVOS, L. DA
ZONA INDUSTRIAL DA MAIA
I-SECTOR VIII, NO. 122
APARTADO 6050
4476 - 908 MAIA
PORTUGAL
TEL: [phone]
FAX: [phone]
SAINT-GOBAIN GLASS
BUSINESS UNIT ABRASIVI
PUNCT DE LUCRU: LOC.VETIS,JUD.
SATU MARE 447355
STR. CAREIULUI 11
PARC INDUSTRIAL RENOVATIO
ROMANIA
TEL: [phone]
FAX: [phone]
SG HPM RUS
58, F. ENGELS STR.
STROENIE 2
105082 MOSCOW
RUSSIA
TEL: [phone]
FAX: [phone]
SAINT-GOBAIN
ABRASIVES (PTY) LTD
2 MONTEER ROAD
ISANDO 1600
P.O. BOX 67
SOUTH AFRICA
TEL: [phone]
FAX: [phone]
SAINT-GOBAIN ABRASIVOS, S.A.
CTRA. DE GUIPÚZCOA, KM. 7,5
E-31195 BERRIOPLANO (NAVARRA)
SPAIN
TEL: [phone]
FAX: [phone]
SAINT GOBAIN ABRASIVES AB
GÅRDSFOGDEVÄGEN 18A
168 66 BROMMA • SVERIGE
SWEDEN
TEL: [phone]
FAX: [phone]
SAINT-GOBAIN INOVATIF MALZEMELER
VE ASINDIRICI SAN. TIC. AS.
ALTAYÇEŞME MAH. ÇAML
I SOK. NO:21
ESAS OFISPARK KAT:9 34843
MALTEPE, İSTANBUL • TURKEY
TEL: [phone]
FAX: [phone]
SAINT-GOBAIN ABRASIVES LTD.
DOXEY RD
STAFFORD
ST16 1EA

VERS. 01.09.2019 CFP16W _MAN_EN
16
UNITED KINGDOM
TEL: [phone]
FAX: [phone]
