Novell IDENTITY MANAGER DRIVER FOR ID PROVIDER 3.6.1 -... User manual

Novell®
www.novell.com
novdocx (en) 13 May 2009
AUTHORIZED DOCUMENTATION
Identity Manager 3.6 ID Provider Driver Implementation Guide
Identity Manager Driver for ID Provider
3.6.1
June 05, 2009
implementation Guide

novdocx (en) 13 May 2009
Legal Notices
Novell, Inc., makes no representations or warranties with respect to the contents or use of this documentation, and
specifically disclaims any express or implied warranties of merchantability or fitness for any particular purpose.
Further, Novell, Inc., reserves the right to revise this publication and to make changes to its content, at any time,
without obligation to notify any person or entity of such revisions or changes.
Further, Novell, Inc., makes no representations or warranties with respect to any software, and specifically disclaims
any express or implied warranties of merchantability or fitness for any particular purpose. Further, Novell, Inc.,
reserves the right to make changes to any and all parts of Novell software, at any time, without any obligation to
notify any person or entity of such changes.
Any products or technical information provided under this Agreement may be subject to U.S. export controls and the
trade laws of other countries. You agree to comply with all export control regulations and to obtain any required
licenses or classification to export, re-export or import deliverables. You agree not to export or re-export to entities on
the current U.S. export exclusion lists or to any embargoed or terrorist countries as specified in the U.S. export laws.
You agree to not use deliverables for prohibited nuclear, missile, or chemical biological weaponry end uses. See the
Novell International Trade Services Web page (http://www.novell.com/info/exports/) for more information on
exporting Novell software. Novell assumes no responsibility for your failure to obtain any necessary export
approvals.
Copyright © 2008-2009 Novell, Inc. All rights reserved. No part of this publication may be reproduced, photocopied,
stored on a retrieval system, or transmitted without the express written consent of the publisher.
Novell, Inc., has intellectual property rights relating to technology embodied in the product that is described in this
document. In particular, and without limitation, these intellectual property rights may include one or more of the U.S.
patents listed on the Novell Legal Patents Web page (http://www.novell.com/company/legal/patents/) and one or
more additional patents or pending patent applications in the U.S. and in other countries.
Novell, Inc.
404 Wyman Street, Suite 500
Waltham, MA 02451
U.S.A.
www.novell.com
Online Documentation: To access the latest online documentation for this and other Novell products, see
the Novell Documentation Web page (http://www.novell.com/documentation).

novdocx (en) 13 May 2009
Novell Trademarks
For Novell trademarks, see the Novell Trademark and Service Mark list (http://www.novell.com/company/legal/
trademarks/tmlist.html).
Third-Party Materials
All third-party trademarks are the property of their respective owners.

4Identity Manager 3.6 ID Provider Driver Implementation Guide
novdocx (en) 13 May 2009

Contents 5
Contents
novdocx (en) 13 May 2009
About This Guide 7
1 Understanding the ID Provider Driver 9
1.1 Why Use the Driver? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.2 Design Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.3 Schema Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2 Installing Driver Files 15
3 Creating a New Driver 17
3.1 Creating the Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.2 Creating ID Policies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4 Configuring ID Clients 23
4.1 ID Client . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.2 Standalone Client. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
5 Managing the ID Provider Driver 27
6 Troubleshooting 29
A Driver Properties 31
A.1 Driver Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
A.1.1 Driver Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
A.1.2 Driver Object Password (iManager Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
A.1.3 Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
A.1.4 Startup Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
A.1.5 Driver Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
A.1.6 ECMAScript (Designer Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
A.2 Global Configuration Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

6Identity Manager 3.6 ID Provider Driver Implementation Guide
novdocx (en) 13 May 2009

About This Guide 7
novdocx (en) 13 May 2009
About This Guide
This guide explains the purpose of the ID Provider driver and how to implement the driver.
Chapter 1, “Understanding the ID Provider Driver,” on page 9
Chapter 2, “Installing Driver Files,” on page 15
Chapter 3, “Creating a New Driver,” on page 17
Chapter 4, “Configuring ID Clients,” on page 23
Chapter 5, “Managing the ID Provider Driver,” on page 27
Audience
This guide is intended for Identity Manager administrators.
Feedback
We want to hear your comments and suggestions about this manual and the other documentation
included with this product. Please use the User Comments feature at the bottom of each page of the
online documentation, or go to www.novell.com/documentation/feedback.html and enter your
comments there.
Documentation Updates
For the most recent version of this guide, visit the Identity Manager Drivers Documentation Web
site (http://www.novell.com/documentation/idm36drivers).
Additional Documentation
For documentation on Identity Manager, see the Identity Manager Documentation Web site (http://
www.novell.com/documentation/idm36/index.html).
Documentation Conventions
In Novell documentation, a greater-than symbol (>) is used to separate actions within a step and
items in a cross-reference path.
A trademark symbol (®, TM, etc.) denotes a Novell trademark. An asterisk (*) denotes a third-party
trademark.
When a single pathname can be written with a backslash for some platforms or a forward slash for
other platforms, the pathname is presented with a backslash. Users of platforms that require a
forward slash, such as Linux* or UNIX*, should use forward slashes as required by your software.

8Identity Manager 3.6 ID Provider Driver Implementation Guide
novdocx (en) 13 May 2009

Understanding the ID Provider Driver
1
9
novdocx (en) 13 May 2009
1
Understanding the ID Provider
Driver
The ID Provider driver enables you to create and maintain a central source of unique IDs that can be
consumed by client applications or systems. When the driver receives an ID request from a client, it
generates an ID based on policies you define, passes it to the client, and then stores it in the Identity
Vaul t .
Section 1.1, “Why Use the Driver?,” on page 9
Section 1.2, “Design Architecture,” on page 9
Section 1.3, “Schema Architecture,” on page 11
1.1 Why Use the Driver?
There are many different reasons why you would want to use the ID Provider driver. For example:
For administrators it is convenient to have one basic ID for each objects in the system, and to
have complete control of the ID. No other system can change this ID.
You can use the ID Provider driver in conjunction with the WorkOrder driver to verify that each
WorkOrder ID that is created is unique.
You can use the driver to help manage UIDs and GIDs in Linux.
1.2 Design Architecture
Identity Manager drivers listen for events and then apply the proper Identity Manager policies for
the event. That information is then passed to the Metadirectory engine that executes the policies.
The ID Provider driver is different from all other Identity Manager drivers. It also listens for events,
but it has two sets of policies: the Identity Manager policies and the ID Provider policies. The ID
Provider policies allow the driver to generate and assign unique IDs to objects.
The driver has three major components:
ID Client: The ID client communicates with the ID Provider driver to obtain a unique ID. The
client can be another Identity Manager driver (for example, the WorkOrder driver) or a
standalone Java* application.
ID Provider Driver: The driver receives ID requests from clients, generates unique IDs that
are stored in the Identity Vault, and passes the unique IDs back to the client. The driver uses
LDAP to access the Identity Vault and uses Java RMI (Remote Method Invocation) to
communicate with ID clients.
Identity Vault: The Identity Vault provides the location for storing unique IDs and also
contains the policies used to generate the IDs. All IDs and policies are stored in the ID Policy
Container.

10 Identity Manager 3.6 ID Provider Driver Implementation Guide
novdocx (en) 13 May 2009
The ID Provider driver can be used in two different scenarios:
“Scenario 1: Using the Identity Vault to Store the ID Provider Policies” on page 10
“Scenario 2: Using an LDAP Database to Store the ID Provider Policies” on page 11
Scenario 1: Using the Identity Vault to Store the ID Provider Policies
This is the most commonly used scenario with the driver. The ID Provider policies are created and
stored in the Identity Vault when the driver is created and configured. Figure 1-1 shows how an
unique ID is generated.
Figure 1-1 Identity Vault Stores the ID Provider Policies
1. A new User object is created in the Identity Vault, then the ID Provider driver picks up the
Create event.
2. The ID Provider driver reads the last ID that was generated from the ID Provider polices in the
Identity Vault and generates a new ID. The ID is then written back to the ID Provider policies
in the Identity Vault to track the unique IDs.
3. The ID Provider driver then assigns the new ID to the new User object.
[root]
system data
services
ID Policies
users
user1
user2
policies1
policies2
policies3
2
New user 1
3
Identity Vault
LDAP Interface
IDM
Engine
read last ID from policy, generate new
ID and write back new ID to policy
add
event
ID

Understanding the ID Provider Driver 11
novdocx (en) 13 May 2009
All events are tracked and stored in the Identity Vault.
Scenario 2: Using an LDAP Database to Store the ID Provider Policies
This scenario allows you to use an LDAP database to store the ID Provider policies instead of using
the Identity Vault. Figure 1-2 shows how a unique ID is generated with the LDAP database.
Figure 1-2 LDAP Database Stores the ID Provider Policies
1. A new User object is created in the Identity Vault, then the ID Provider driver picks up the
Create event.
2. The ID Provider driver reads the last ID that was generated from the ID Provider policies in the
LDAP database. The ID is then written back to the ID Provider policies in the LDAP database
to track the unique IDs.
3. The ID Provider driver then assigns the new ID to the new User object in the Identity Vault.
1.3 Schema Architecture
The Identity Vault’s schema must be extended to support the ID Provider driver functionality. The
following two tables describe the schema attributes and classes.
[root]
data
users
user1
user2
New user
1
[root]
3
system
services
ID Policies
policies1
policies2
policies3
2
Identity
Vault
IDM
Engine
read last ID from
policy, generate new
ID and write back
new ID to policy
add
event
LDAP
Directory
ID

12 Identity Manager 3.6 ID Provider Driver Implementation Guide
novdocx (en) 13 May 2009
Table 1-1 Schema Attributes
Table 1-2 Schema Classes
Attribute Name Syntax Attribute Flags Description
DirXML-IDPolName Case Ignore String Single valued
Synchronize
immediately
ID Policy object name
DirXML-IDPolLastID Numeric String Single-valued
Synchronize
immediately
Last delivered ID
DirXML-IDPolMin Numeric String Single-valued Minimum value for an ID
DirXML-IDPolMax Numeric String Single-valued Maximum value for an ID
DirXML-IDPolPrefix Case Ignore String Single-valued Prefix for a new ID
DirXML-IDPolFill Boolean Single-valued True: Fill ID with 0 up to
maximum length
False or Empty: Do
nothing
DirXML-IDPolArea Case Ignore String Single-valued Exclude/Include list for
generated IDs
DirXML-IDPolAreaEI Boolean Single-valued True = IDPolArea =
Include list
False or Empty =
IDPolArea = Exclude list
DirXML-IDPolAccessControl Boolean Single-valued True = IDPolACL list is
used
False or Empty --
IDPolACL list is not used
DirXML-IDPolACL Case Ignore String Single-valued Comma-delimited list of
ID clients to be allowed to
request an ID from the ID
server
DirXML-IDPolicyContainerDN Distinguished
Name
Single-valued Link to the ID Policy
Container
Class Name Contained By Attributes Contained
ID Policy Container Country, Domain, Locality,
Organization, Organizational
Unit, Tree Root
OU

Understanding the ID Provider Driver 13
novdocx (en) 13 May 2009
ID Policy ID Policy Container IDPolACL
IDPolAccessControl
IDPolArea
IDPolAreaEI
IDPolFill
IDPolLastID
IDPolMax
IDPolMin
IDPolName
IDPolPrefix
Class Name Contained By Attributes Contained

14 Identity Manager 3.6 ID Provider Driver Implementation Guide
novdocx (en) 13 May 2009

Installing Driver Files
2
15
novdocx (en) 13 May 2009
2
Installing Driver Files
The ID Provider Driver is a service driver that is included with the base Identity Manager product.
The driver is installed when the Metadirectory engine and drivers are install. For the installation
instructions, see “ Installing Identity Manager” in the Identity Manager 3.6.1 Installation Guide.

16 Identity Manager 3.6 ID Provider Driver Implementation Guide
novdocx (en) 13 May 2009

Creating a New Driver
3
17
novdocx (en) 13 May 2009
3
Creating a New Driver
After the ID Provider driver files are installed on the server where you want to run the driver (see
Chapter 2, “Installing Driver Files,” on page 15), you can create the driver in the Identity Vault. You
do so by importing the basic driver configuration file and then modifying the driver configuration to
suit your environment. The following sections provide instructions:
Section 3.1, “Creating the Driver,” on page 17
Section 3.2, “Creating ID Policies,” on page 20
3.1 Creating the Driver
You can run the driver as a native Java module or as an Identity Manager driver on any supported
platform.
You can create the driver through Designer or iManager. It is recommended to use Designer during
the planning and implementation phases of the Identity Manager deployment.
1In Designer, drag and drop the ID Provider driver, from the Service folder, onto the Modeler.
2Select the ID Provider driver from the list, then click Run.
3Specify the following information:
Driver name: Specify the name of the driver object for your environment.
LDAP server: Specify the IP address of the LDAP server that contains the ID policies.
LDAP port: Specify the TCP port of the LDAP server. The default is 389 for non-SSL
and 636 for SSL.
Policy Container DN: Specify the DN of the policy container.
Authenication ID: Specify the LDAP DN of a user with read/write access to the ID
Policy container and its child objects.
Authenication Password: Specify the password of the user used in the Authenication ID
field.
4Click Next.
5Click Configure if you want to change additional settings on the driver, or click Close to create
the driver.
If you want to make additional changes to the driver, the following sections contain information
about the driver parameters.
“ID Policy Repository” on page 18
“Client Options” on page 18
“Server Options” on page 19

18 Identity Manager 3.6 ID Provider Driver Implementation Guide
novdocx (en) 13 May 2009
ID Policy Repository
The ID policy repository parameters contain information about the location and how to access any
ID policies.
Table 3-1 ID Policy Repository
Client Options
The client options are for the ID Provider clients. For more information, see Chapter 4,
“Configuring ID Clients,” on page 23.
Table 3-2 Client Options
Parameter Default Value Description
LDAP Server 127.0.0.1 The IP address or DNS name of the LDAP
server holding the ID policies
LDAP Port 636 The TCP port that the LDAP server listens
on.
The value is usually 389 for non-SSL
connections and 636 for SSL connections.
Use SSL True Specify whether or not you want to use
SSL.
Always trust True Specify whether or not you want to trust all
servers. If this option is set to True, the ID
provider trusts all LDAP servers even if the
server certificate is untrusted.
Policy Container DN LDAP DN for the policy
container under the driver
object. For example cn=id-
policies,cd=id-
provider,cn=driverset1,dc=idm,
dc=services,dc=system.
Specify or browse to the DN of the policy
container in your tree. The policy container
can only be created under the ID Provider
driver.
Parameter Default Value Description
Client name ID-Provider Driver This is the name the driver uses when it acts as an
ID client and requests and ID from the provider. This
is useful for tracing and if access control is enabled
on any of the ID policies.
If access control is enabled, a list of ID client names
can be specified that are allowed to obtain an ID
from the policy. If the client name associated with the
request is not in that list, the provider does not issue
an ID.

Creating a New Driver 19
novdocx (en) 13 May 2009
Server Options
Allow you to setup clients other than the ID Provider driver using Java remote method invocation
(RMI). It also allows you to set ID Provider trace level.
Table 3-3 Server Options
ID Generation Map workforceID=wfid Enter a comma-separated list of attribute=policy
pairs.
For example, workforceID=wfid,uniqueID=uid. This
example configures the driver to request IDs from
the wfid policy and stores them in the workforceID
attribute whenever a new object is created or
whenever someone tries to change this attribute.
Similarly, IDs from the UID policy are used from the
uid attribute. The driver only issues IDs for any
attribute if that attribute and the object class holding
the attribute are in both the Subscriber, Publisher,
Filter, and are set to synchronize.
Note: Attribute names must be in the Identity
Namespace (not LDAP) and must be case-exact.
Parameter Default Value Description
Start RMI True Controls whether the ID provider starts an RMI service or
not. You only need a running RMI service if you request
IDs from other clients than the driver (for example,
DirXMLScript policies.) If all IDs are managed through this
driver’s filter and ID Generation Map settings, then no RMI
service is needed.
RMI server 172.17.2.117 Specify the IP address the RMI server binds to. Leave this
field empty if you want the server to bind to all IP
addresses.
RMI port 1199 Specify the TCP port the RMI service listens on. The
defined standard port for RMI is 1099. If that port is already
in use (you see errors in the trace when you start the
driver), use a different port lower than 1024. This
configuration assumes a port of 1199 to avoid common
port conflicts.
Use legacy ID-server
schema?
False Enables the backward compatibility mode when migrating
an existing ID-Server configuration to run with the new ID
Provider driver. Setting this to True allows you to keep
using legacy ID policies, which do not use the new schema
that ships with the ID Provider.
Parameter Default Value Description

20 Identity Manager 3.6 ID Provider Driver Implementation Guide
novdocx (en) 13 May 2009
3.2 Creating ID Policies
An ID Policy container is a repository for ID policies and is used in conjunction with the ID
Provider driver. An ID policy allows the ID Provider driver to generate unique IDs. When the ID
Provider driver receives an ID request from a client, it generates an ID based on the ID policy
specified in the request and passes it to the client.
By default, there are three ID policies that are created when the driver is imported. The three policies
are sample policies. You can use these policies or create your own. The default policies are:
pid: The pid policy generates unique ids between the range of 100000 to 2000000000. It also
adds the prefix of PID to each unique ID.
wfid: The wfid policy generates unique ids between the range of 10000000 to 99999999. It
also adds the prefix of WFID to each unique ID for the workforce ID.
woid: The woid policy generates unique ids between the range of 100000 to 2000000000. It
also adds the prefix of WOID to each unique ID.
To create an ID policy:
1In Designer, right-click the ID Policy container in the Outline tab, then click New > ID Policy.
The ID Policy container is created when the ID Provider driver is created. The ID Policy
container can only reside under the ID Provider driver.
2Specify the name for the ID policy, then click OK.
3Double-click the ID policy to access the properties page.
4Use the information in Table 3-4 to create your ID policy, then click OK to save the
information.
Table 3-4 The ID Policy’s General Settings
Trace level ALL This is not the driver trace level, but the ID Provider trace
level. The levels are:
OFF: Tracing is turned off.
FATAL: Displays only fatal messages.
ERROR: Displays only error messages.
WARN: Displays only warning messages.
INFO: Displays only informational messages.
DEBUG: Displays only debug messages.
ALL: Displays all messages.
Field Description
Policy Name The name of the ID policy.
Parameter Default Value Description
