Novomatic NOVOLINE INTERACTIVE VGT ILLINOIS Manual

1 | P a g e
Novomatic Americas Sales LLC
- 1050 E. Business Center Drive, Mount Prospect, IL 60056 - Illinois - USA
Phone: [phone] - Fax: + 1(224) 500-3305 - www.novomaticamericas.com
Support: [phone] - Support: [e-mail]
NO V OLIN E
IN TE RACTIV E
V
GT ILLINOI S
RAM C L EAR
AND
SET
UP

2 | P a g e
Novomatic Americas Sales LLC
- 1050 E. Business Center Drive, Mount Prospect, IL 60056 - Illinois - USA
Phone: [phone] - Fax: + 1(224) 500-3305 - www.novomaticamericas.com
Support: [phone] - Support: [e-mail]
RAM-Clea r Proce dure
W it h US B R AM - Cl e a r De v ic e
To clear critical errors, a RAM-Clear has to be performed. This means a total reset of all accounting and events data will
be erased. Follow below instructions to execute a RAM-Clear:
Power off the terminal
• Open CPU Door and then close it again. ( By Opening the CPU and then closing it will cause for CPU to drain
any power from itself.
• Connect RAM Clear Device on top of the CPU
.
• Power on the Terminal.
• Close the Main Door. After restart of the terminal the following message will be displayed:

3 | P a g e
Novomatic Americas Sales LLC
- 1050 E. Business Center Drive, Mount Prospect, IL 60056 - Illinois - USA
Phone: [phone] - Fax: + 1(224) 500-3305 - www.novomaticamericas.com
Support: [phone] - Support: [e-mail]
Turn the audit key (leave in the horizontal position) to enter the audit menu where the following screen will be displayed:
• Press the Factory Default Ram Clear button to perform the RAM-Clear.
After the RAM-Clear is successfully completed the following message will be displayed.
Note: If you do a PARTIAL RAM CLEAR that will allow you to change any parameters, but if is pressed all soft
meter will be erased.
After this message you can pull out the ram clear USB (while machine is still on) and turn the attendant key off and remove.
The machine will reboot after the machine reboots insert the attendant key, turn to the on (horizontal) position and leave in.
Press BACK to go to the Main setup screen. Select Machine Setup
Note: When a selection is made the word or value will change to yellow
1. Limit Settings

3I Page
Novomatic Americas Sales LLC-
1050 E. Business Center Drive, Mount Prospect,IL 60056- Illinois-
USA
Phone: [phone]- Fax:+ 1(224) 500-3305- www.novomaticamericas.com
Support: +1(833)
668-6628- Support: [e-mail]
NOVOMATIC
Touch a value to highlight and choose edit, after each entry touch OK
• Max Win to Credit: That will need to be as a default to 1199.99
Midwest Settings are as follows
• Max credit =10,000
Max Credit In = 1000
Max Bill In = 0
Ticket payout limit = 10,000
• After you’re done setting all up hit back on the left bottom corner.

4 | P a g e
Novomatic Americas Sales LLC
- 1050 E. Business Center Drive, Mount Prospect, IL 60056 - Illinois - USA
Phone: [phone] - Fax: + 1(224) 500-3305 - www.novomaticamericas.com
Support: [phone] - Support: [e-mail]
2. Initial Settings: When selecting Initial settings press Enter,
in that selection you can enter the IGB Tag of the machine.
• After you’re done setting all up, hit back on the left bottom corner
• Below picture shows you we enter your example (MACHINE NUMBER = IGB tag number 123456)
• Other settings in this page are leave it has a default
• After you’re done setting all up hit back on the left bottom corner

5I Page
Novomatic Americas Sales LLC-
1050 E. Business Center Drive, Mount Prospect,IL 60056- Illinois-
USA
Phone: [phone]- Fax:+ 1(224) 500-3305- www.novomaticamericas.com
Support: +1(833)
668-6628- Support: [e-mail]
NOVOMATIC
---AMERICAS---
3. Protocol Settings: Press Protocol settings; leave everything on channel 1 as a default.
• Protocol: G2S
• Port: None
• Channel Address: 1
• Features: Control and Tito
• Network Security: Enable
When finished Press back to return to the main menu

5I Page
Novomatic Americas Sales LLC-
1050 E. Business Center Drive, Mount Prospect,IL 60056- Illinois-
USA
Phone: [phone]- Fax:+ 1(224) 500-3305- www.novomaticamericas.com
Support: +1(833)
668-6628- Support: [e-mail]
4. Ticket Settings
• Press Ticket Settings
• Press and select you printer that is in the machine
• TransAct = ithaca
• Gen5= Future Logic
• Validation type: Needs to be Secure Enhanced
• Ticket Redemption: Disable
• Promotional Ticket Redemption: Disable
• Ticket Expires Days: 365
• Press back after you’re done with the settings.

6 | P a g e
Novomatic Americas Sales LLC
- 1050 E. Business Center Drive, Mount Prospect, IL 60056 - Illinois - USA
Phone: [phone] - Fax: + 1(224) 500-3305 - www.novomaticamericas.com
Support: [phone] - Support: [e-mail]
5. System Settings
• Enable Print HP Receipt
Press back after you’re done with the settings

NOVOMATIC
---AMERICAS---
14
I
Page
Novomatic Americas Sales LLC-
1050 E. Business Center Drive, Mount Prospect,IL 60056- Illinois-
USA
Phone: [phone]- Fax:+ 1(224) 500-3305- www.novomaticamericas.com
Support: +1(833)
668-6628- Support: [e-mail]
6. Advanced Settings Press Advanced Settings
• Press Show Malfunction : set it to Enable
• Press Max Banknote Rejects: set it to 0
Press back after you’re done with the settings

NOVOMATIC
---AMERICAS---
15
I
Page
Novomatic Americas Sales LLC-
1050 E. Business Center Drive, Mount Prospect,IL 60056- Illinois-
USA
Phone: [phone]- Fax:+ 1(224) 500-3305- www.novomaticamericas.com
Support: +1(833)
668-6628- Support: [e-mail]
7. G2S Settings Press G2S Settings
• Control Host ID: Make sure that is says 1
• Audit Host as Control Host: Enable
• Press NEXT PAGE to EGM Serial number: machine serial number (use the (1 ! +) key for number pad)

NOVOMATIC
---AMERICAS---
16
I
Page
Novomatic Americas Sales LLC-
1050 E. Business Center Drive, Mount Prospect,IL 60056- Illinois-
USA
Phone: [phone]- Fax:+ 1(224) 500-3305- www.novomaticamericas.com
Support: +1(833)
668-6628- Support: [e-mail]
8. OCSP Settings: Select OCSP Settings
• OCSP Responder URL will be as a default to http://ocsp.il-prod.com/ocsp/ will need to be changed if is
not properly
• OCSP all should be set at 30,000
Press back after you’re done with the settings

NOVOMATIC
---AMERICAS---
17
I
Page
Novomatic Americas Sales LLC-
1050 E. Business Center Drive, Mount Prospect,IL 60056- Illinois-
USA
Phone: [phone]- Fax:+ 1(224) 500-3305- www.novomaticamericas.com
Support: +1(833)
668-6628- Support: [e-mail]
9. Calibration to Enter Date and Time
• Press Calibration
.Adjust volume to minimum (10)
• Select Time and Date and press Enter.
Note: Don’t forget to set your Time Zone to Central Time US &Canada
• Fix Time and Date according to your region
.
.

NOVOMATIC
---AMERICAS---
18
I
Page
Novomatic Americas Sales LLC-
1050 E. Business Center Drive, Mount Prospect,IL 60056- Illinois-
USA
Phone: [phone]- Fax:+ 1(224) 500-3305- www.novomaticamericas.com
Support: +1(833)
668-6628- Support: [e-mail]
After the machine reboots put in the attendant key and turn horizontal, press “back” to return to the main screen
10. Configuring IP Setting
• Select IP Settings
• Press Configure IP, you will get a Loading word on the center of the window .

NOVOMATIC
---AMERICAS---
19
I
Page
Novomatic Americas Sales LLC-
1050 E. Business Center Drive, Mount Prospect,IL 60056- Illinois-
USA
Phone: [phone]- Fax:+ 1(224) 500-3305- www.novomaticamericas.com
Support: +1(833)
668-6628- Support: [e-mail]
11. Internet Protocol Configuration
• Select Ethernet connection I217-LM which is the CPU port, check “Enable DHCP”
And fill IP address, subnet Mask and Default Gateway with all Zero 0.0.0.0
Select Ethernet connection I210 Gigabit Network adapter 1 is the back plane board
Uncheck “Enable DHCP”
Please use Keypad on the screen to change anything in the fields
• Type where it says IP Address = 10.167.250.?? then the number of the machine.
• Type where it says Subnet Mask = 255.255.255.240
• Type where is says Default Gateway = 10.167.250.1
• Type where is says Primary DNS = 10.167.250.1
• After all fields are filled Check REBOOT after apply, touch apply, then you will get a windows message
asking to confirm reboot. Choose yes and machine will be rebooted, Turn the Key Vertical and remove

NOVOMATIC
---AMERICAS---
20
I
Page
Novomatic Americas Sales LLC-
1050 E. Business Center Drive, Mount Prospect,IL 60056- Illinois-
USA
Phone: [phone]- Fax:+ 1(224) 500-3305- www.novomaticamericas.com
Support: +1(833)
668-6628- Support: [e-mail]
13. Getting a Machine Cert from Sci Games
Machine will reboot after all settings are done; you will get the SCEP Configuration Require.
Please follow the following steps.
• When you get this message, promptly turn the key horizontal and it will take you to get your CERT:
• Press Get Root showing below in order to get your Cert from Sci Games
• Then press Accept Certificate then Generate Certificate and you will see a FINGERPRINT after all is
done turn the key Vertical and machine will reboot itself.

NOVOMATIC
---AMERICAS---
21
I
Page
Novomatic Americas Sales LLC-
1050 E. Business Center Drive, Mount Prospect,IL 60056- Illinois-
USA
Phone: [phone]- Fax:+ 1(224) 500-3305- www.novomaticamericas.com
Support: +1(833)
668-6628- Support: [e-mail]
Example how your CERTS (Get Root) would look like:
Remove the attendant key , close all doors and call SCI-Games
