Novus 800 Series User manual

NVDN-821H/IR-2
NVDN-841H/IR-2
u s e r ’s m a n u a l

NVDN‐821H/IR‐2, NVDN‐841H/IR‐2 ver. 1.1 ‐ User’s manual
All rights reserve © AAT Hol ing sp. z o.o.
2
EMC (2004/108/EC) and LVD (2006/95/EC ) Directives
CE Marking
Our products are manufactured to comply with the requirements of the following directives and national
regulations implementing the directives:
• Electromagnetic compatibility EMC 2004 108 EC.
• Low voltage LVD 2006 95 EC with further amendment. The Directive applies to electrical
equipment designed for use with a voltage rating of between 50VAC and as well as 75VDC and
1500VDC.
WEEE Directive 2002/96/EC
nformation on Disposal for Users of Waste Electrical and Electronic Equipment
This appliance is marked according to the European 1000VAC Directive on Waste Electrical and
Electronic Equipment (2002/96/EC) and further amendments. By ensuring this product is disposed of
correctly, you will help to prevent potential negative consequences for the environment and human health,
which could otherwise be caused by inappropriate waste handling of this product.
The symbol on the product, or the documents accompanying the product, indicates that this appliance
may not be treated as household waste. t shall be handed over to the applicable collection point for used
up electrical and electronic equipment for recycling purpose. For more information about recycling of this
product, please contact your local authorities, your household waste disposal service or the shop where
you purchased the product.
RoHS Directive 2002/95/EC
Out of concern for human health protection and friendly environment, we assure that our products
falling under RoHS Directive regulations, regarding the restriction of the use of hazardous substances
in electrical and electronic equipment, have been designed and manufactured in compliance with the above
mentioned regulations. Simultaneously, we claim that our products have been tested and do not contain
hazardous substances whose exceeding limits could have negative impact on human health or natural
environment.
nformation
The device, as a part of professional CCTV system used for surveillance and control, is not designed for self
installation in households by individuals without technical knowledge.
The manufacturer is not responsible for defects and damages that result from improper or inconsistent with
user’s manual installation of the device in the system.
NFORMAT ON

NVDN‐821H/IR‐2, NVDN‐841H/IR‐2 ver. 1.1 ‐ User’s manual
All rights reserve © AAT Hol ing sp. z o.o.
3
WARN NG!
THE KNOWLEDGE OF THIS MANUAL IS AN INDESPENSIBLE CONDITION OF A
PROPER DEVICE OPERATION. YOU ARE KINDLY REQUSTED TO FAMILIRIZE
YOURSELF WITH THE MANUAL PRIOR TO INSTALLATION AND FURTHER
DEVICE OPERATION.
WARN NG!
USER IS NOT ALLOWED TO DISASSEMBLE THE CASING AS THERE ARE NO
USER-SERVICEABLE PARTS INSIDE THIS UNIT. ONLY AUTHORIZED SERVICE
PERSONNEL MAY OPEN THE UNIT
INSTALLATION AND SERVICING SHOULD ONLY BE DONE BY QUALIFIED SERVICE
PERSONNEL AND SHOULD CONFORM TO ALL LOCAL REGULATIONS
WARN NG!
PRIOR TO UNDERTAKING ANY ACTION THAT IS NOT DESCRIBED FOR THE GIVEN
PRODUCT IN USER’S MANUAL AND OTHER DOCUMENTS DELIVERED WITH THE
PRODUCT, OR IF IT DOES NOT ARISE FROM THE USUAL APPLICATION OF THE
PRODUCT, MANUFACTURER MUST BE CONTACTED UNDER THE RIGOR OF
EXCLUDING THE MANUFACTURER’S RESPONSIBILITY FOR THE RESULTS OF SUCH AN
ACTION.
MPORTANT SAFEGUARDS AND WARN NGS
1. Prior to undertaking any action please consult the following manual and read all the safety and
operating instructions before starting the device.
2. Please keep this manual for the lifespan of the device in case referring to the contents of this manual
is necessary;
3. All the safety precautions referred to in this manual should be strictly followed, as they have a
direct influence on user’s safety and durability and reliability of the device;
4. All actions conducted by the servicemen and users must be accomplished in accordance with the
user’s manual;
5. The device should be disconnected from power sources during maintenance procedures;
6. Usage of additional devices and components neither provided nor recommended by the producer
is forbidden;
7. Mounting the device in places where proper ventilation cannot be provided (e. g. closed lockers
etc.) is not recommended since it may lead to heat build-up and damaging the device itself
as a consequence;
8. Mounting the camera on unstable surface or using not recommended mounts is forbidden.
Improperly mounted camera may cause a fatal accident or may be seriously damaged itself. The
camera must be mounted by qualified personnel with proper authorization, in accordance with this
user’s manual;
SAFETY REQU REMENTS

NVDN‐821H/IR‐2, NVDN‐841H/IR‐2 ver. 1.1 ‐ User’s manual
All rights reserve © AAT Hol ing sp. z o.o.
4
SAFETY REQU REMENTS
9. Device should be supplied only from a power sources whose parameters are in accordance with
those specified by the producer in the camera technical datasheet. Therefore, it is forbidden to supply
the camera from a power sources with unknown parameters, unstable or not meeting producer’s
requirements;
10. Signal cables (conducting TV or and telemetric signal) should be placed in a way excluding the
possibility of damaging them by accident. Special attention must be paid to cables getting from the
camera and connecting the power supply;
11. To avoid equipment damage, whole TV circuit should be equipped with properly made
discharge-, overload- and lightning protection devices. Usage of separating transformers is
advised;
12. Electric installation supplying the device should be designed to meet the specifications given
by the producer in such a way that overloading is impossible;
13. User cannot repair or upgrade the equipment himself. All maintenance actions and repairs should
be conducted only by qualified service personnel;
14. Unplug the camera from the power source immediately and contact the proper maintenance
department when the following occurs:
♦ Damages to the power cord or to the plug itself;
♦ Liquids getting inside the device or exposure to strong mechanical shock;
♦ Device behaves in a way not described in the manual and all adjustments approved by the
manufacturer and possible to apply by user himself, seem not to have any effect;
♦ Camera is damaged;
♦ Atypical behaviour of the camera components may be seen (heard).
15. In necessity of repairs attention to using only original replacement parts (with their parameters
in accordance with those specified by the producer) should be paid. Non-licensed service and
non-genuine replacement parts may cause fire or electrocution;
16. After maintenance activities tests should be run to ensure proper operation of all the functional
components of the device.
Attention!
Technical changes reserved without prior notice and printing errors possible.

NVDN‐821H/IR‐2, NVDN‐841H/IR‐2 ver. 1.1 ‐ User’s manual
All rights reserve © AAT Hol ing sp. z o.o.
5
1. PACKAGE CONTENTS
• Video camera
• User’s manual
• Allen key
• Extra video output cable
• Extra power supply cable
• Screws, 3 pcs.
If any of the listed equipment has been damaged during transport or if the package is incomplete,
the contents of package should be packed back in to the original box. Please contact your local
NOVUS distributor for further assistance.
2. MA N CHARACTER ST CS
• Mechanical IR cut filter
• IR operation capability
• Horizontal resolution: up to 700 TVL
• Min. Illumination: from 0.00002 lx F=1.2 (DSS) (0 lx IR on)
• Digital Slow Shutter (DSS)
• Digital zoom: 16x
• Wide dynamic range (SSDR)
• High Light Compensation (HLC)
• Digital Image Stabilizer (DIS)
• Digital Noise Reduction (DNR)
• Lens type: auto-iris DC lens,
f=2.5~12 mm - NVDN‐821H IR-2
f=6~50mm - NVDN‐841H IR-2
• Privacy zones: 12
• 1 alarm output triggered by motion detection
• Other functions: various picture effects, motion detection (4 zones)
• Full configuration (user friendly multi-lingual OSD):
- directly from the camera
- from the NV-KBD70, NV-KBD50 & NV-KBD40 keyboards
- from NOVUS
®
video capture cards
- directly from the front panel of selected NOVUS
®
DVR models
• Remote control: RS-485
• Protocols: PELCO-D, PELCO-P
• Built-in IR illuminator: 40 LED
• IR illumination intensity adjustment
• Adjustable IR illuminator trigger
• Degree of protection: IP66
• Power supply: 12V DC 24V AC
FOREWORD NFORMAT ON

NVDN‐821H/IR‐2, NVDN‐841H/IR‐2 ver. 1.1 ‐ User’s manual
All rights reserve © AAT Hol ing sp. z o.o.
6
3. SPEC F CAT ON
FEATURES AND SPEC F CAT ON
Model NVDN‐
‐‐
‐821H/ R-2 NVDN‐
‐‐
‐841H/ R-2
Pick-up element 1 3” SONY EXview HAD II CCD imager
Horizontal resolution 650 TVL – color mode, 700 TVL – B W mode
Min. illumination
0.1 lx F=1.2 - color mode (1 50 s),
0.01 lx F=1.2 - B W mode (1 50s),
0.0002 lx F=1.2 - color mode DSS,
0.00002 lx F=1.2 - B W mode DSS,
0 lx (IR włączony) - B W mode
S N Ratio 52 dB (AGC off)
Electronic Shutter Auto (AES): 1 50 s ~ 1 120 000 s
Digital Slow Shutter (DSS) 1 25 s ~ 10.24 s
Auto Gain Control (AGC) On Off (2 levels)
White Balance 5 modes: Manual AWC Outdoor Indoor ATW
Backlight Compensation (BLC) On Off (3 modes)
High light Compensation (HLC) On Off (3 modes)
Synchronization Internal
Day Night Switching Auto Manual
Filter Delay 3 s 5 s 7 s 10 s 15 s 20 s 30 s 40 s 60 s
Flickerless Function On Off
Privacy Zones 12
Lens type auto iris DC lens f=2.5~12mm auto iris DC lens f=6 ~50mm
Angle of wiev (H) 102° ~ 28° 43.6° ~ 5.5°
Video Output 1.0Vp-p 75 Ohm (BNC)
Alarm Output 1 (voltage), triggered by motion detection
Remote Control RS-485
Protocol Pelco-D, Pelco-P
Digital Zoom 16 x
IR LED 40 pcs.
IR effective range
Set-up Multi-lingual On Screen Display (OSD)
Other Functions Digital Image Stabilizer (DIS), Digital Noise Reduction (DNR), Motion detection, Various
picture effects: Mirror (horizontal) and 180˚ image rotation, Image sharpness adjustment
Degree of protection IP 66
Power Supply 12 V DC 24V AC ± 10%
Power Consumption 4W, 7.4W (IR on)
Operating Temperature -10°C ~ 50°C
Dimensions (mm) 83 (W) x 82 (H) x 166 (L)
Weight 1300 g
40 m

NVDN‐821H/IR‐2, NVDN‐841H/IR‐2 ver. 1.1 ‐ User’s manual
All rights reserve © AAT Hol ing sp. z o.o.
7
3.1 Dimensions
3.2. View of the camera, layout of the camera items
Bottom view, after unscrewing and opening the service lid:
Description of particular DIP switches functions:
LED: Enables disable IR illuminator
LED-ON: Sets illumination threshold for the IR illuminator (Fast - 6lx illumination or lower triggers
the IR on, Slow - 3lx)
LED-BEAM: Allows to control the current flowing through IR LEDs. Low corresponds to about
200mA, with 20m illumination range, Hi corresponds to 300mA and >20m accordingly.
RS-485: Allows to enable or disable RS-485 transmission.
FEATURES AND SPEC F CAT ON
Extra video output
Up down right left SET
buttons
IR RS-485 control DIP
switches
Zoom adjustment
lever
Focus adjustment lever

NVDN‐821H/IR‐2, NVDN‐841H/IR‐2 ver. 1.1 ‐ User’s manual
All rights reserve © AAT Hol ing sp. z o.o.
8
4. NSTALLAT ON
4.1 Power supply connection
Warning:
Device should be supplied only from a power sources whose parameters are
in accordance with those specified by the producer in the camera technical
datasheet. Therefore, it is forbidden to supply the camera from power sources with
their parameters unknown, unstable or not meeting the producer’s requirements.
See the power supply terminal connections below.
• The cameras are 12V DC 24V AC ± 10% supplied.
4.2 RS-485 port
RS-485 port enables remote setup of the camera. Communication between remote controllers (such as
keyboards, DVRs, PCs) via RS-485 utilizes PELCO-D or PELCO-P protocol. Usage of UTP cat. 5
cable is advised. One pair of wires is used in transmission process.
RS-485 485 (+) Remote control RS-485 connector, connect with corresponding RS-485 (+) output
located on the keyboard or any other remote control device. Transmission speed depends on camera
settings.
RS-485 485 (-) Remote control RS-485 connector, connect with corresponding RS-485 (-) output
located on the keyboard or any other remote control device. Transmission speed depends on camera
settings.
Remote control procedures using NOVUS KBD 70, KBD50 or KDB40 keyboards and PELCO-D
protocol are described below:
95 + PRESET SET - Display main menu screen, enter submenus, select highlighted position,
JOYSTICK MOVEMENT UP DOWN - select particular menu positions,
JOYSTICK MOVEMENT LEFT RIGHT - select function or change selected values
NSTALLAT ON
1. BNC output (video signal)
2. 24V AC power supply input
3. RS-485 cable
• RS-485 (-) - orange
• RS-485 (+) - white
4. Alarm output
• output (green)
• common wire (black)
5. 12V DC supply connector
+
- (GND)
1
2
3
4
5

NVDN‐821H/IR‐2, NVDN‐841H/IR‐2 ver. 1.1 ‐ User’s manual
All rights reserve © AAT Hol ing sp. z o.o.
9
KBD-40 connections diagram.
Note:
f system fields more than two cameras depicted above, connections between them should be
made analogically.
4.3 Alarm output
Cameras contain alarm output used for triggering external devices. Triggering motion detection feeds
about 3V to the output, with maximum current being about 10mA.
A diagram depicting possible alarm output configuration is presented below:
NSTALLAT ON
NV-KBD40 keyboard
RJ11 connection cable
RS485 - RS485 -
RS485 + RS485 +
RS485(TX-) RS485 -
RS485(TX+) RS485 +
Twisted pair
Twisted pair
+ -
+ -
Relay supply
Indicator
COM
OUT
Camera

NVDN‐821H/IR‐2, NVDN‐841H/IR‐2 ver. 1.1 ‐ User’s manual
All rights reserve © AAT Hol ing sp. z o.o.
10
5. SETT NGS
Camera features the OSD menu. During camera standard operation status information may be
displayed on the screen.
As it has been mentioned before, a set of buttons located at the camera’s bottom control panel,
available after unscrewing the service lid, is dedicated for navigation and changing the settings.
Available commands associated with these are listed below:
In order to enter the menu please execute the SET. For choosing the submenus please press the UP,
DOWN. Enter particular sub-menus by pressing the SET button. To change the parameters use the
LEFT and RIGHT commands.
In order to leave the menu select EXIT and press SET. Depending on the value of the parameter
located to the right of the EXIT text, different actions are taken when exiting:
• selecting SAVE and pressing SET means that the changes that have been made are saved and
are kept even when the camera restarts.
• selecting NOT SAVE and pressing SET means that the changes that have been made are
temporary and will be cancelled once the camera restarts.
• selecting RESET and pressing SET results in restoring factory defaults.
To exit submenu please select RETURN position, and when Press SET to Return message is
displayed at the bottom part of the screen press SET to leave the menu .
After one minute of inactivity in the menu camera will automatically exit from the programming
mode.
5.1 Main menu
In order to enter the menu press the SET . The following main menu is displayed on the screen:
SETT NGS
MAIN SETUP


1.LENS DC


2.EXPOSURE


3.WHITE BAL ATW
4.SSDR OFF
5.BACKLIGHT HLC


6.DNR3 ON


7.DAY NIGHT COLOR
8.SPECIAL


9.EXIT SAVE

NVDN‐821H/IR‐2, NVDN‐841H/IR‐2 ver. 1.1 ‐ User’s manual
All rights reserve © AAT Hol ing sp. z o.o.
11
5.1.1 LENS submenu
This submenu allows for setting the lens parameters.
LENS Lens operating mode.
MANUAL Manual settings of the lens operating mode. For that setting a submenu that allows
for adjusting the BRIGHTNESS level in the range from 1 to 70 is available.
DC Automatic lens mode. For that setting a submenus that allow for adjusting the
BRIGHTNESS level in the range from 1 to 70, the iris speed IRIS SPEED and the
precise setting of image sharpness FOCUS ADJ are available.
5.1.2 EXPOSURE submenu
This submenu allows for choosing and changing the settings of the parameters connected with AE
and controlling the iris.
BRIGHTNESS Selection of brightness level in the range from 1 to 70.
SHUTTER Selection of shutter mode.
- - - Automatically sets the shutter speed according to present light conditions. This
option is available when DC or VIDEO option is selected in the LENS submenu.
A.FLK FLICKERLESS) The mode of flicker reduction in variable light conditions is equal to
the shutter speed of 1 120s. This mode is available for any setting selected in the
LENS position.
ESC This option will control the shutter speed automatically depending of the light
conditions. For that setting a submenu that allows for setting MIN and MAX speed
of the shutter is available.
MANUAL Manual setting of the shutter speed. For that setting a submenu that allows for
setting the shutter speed (SHUTTER) in the range from 1 120000s to 512x(1 50s)
is available.
SETT NGS
EXPOSURE SETUP


1.BRIGHTNESS ιιιιιxιιιιιιιιιιιι 25
2.SHUTTER MANUAL


3.AGC HIGH
4.SENS-UP - - -
5.RETURN



NVDN‐821H/IR‐2, NVDN‐841H/IR‐2 ver. 1.1 ‐ User’s manual
All rights reserve © AAT Hol ing sp. z o.o.
12
AGC Automatic Gain Control function. When OFF is selected, the function is switched
off. When NORMAL is selected, the function is working with camera sensitivity
smaller than the light intensity changes. When HIGH is selected, the function is
providing bigger camera sensitivity than the light intensity changes. Please
remember that increasing gain results in increasing brightness and noise level as
well.
SENS - UP Low shutter mode function. OFF - the function is switched off, AUTO - in low
light conditions function automatically sets low shutter speed. After pressing SET
button in this mode it is possible to set the multiplier of the basic shutter speed
(1 50s in AUTO mode) in the range from x2 to x512.
This function is switched off when AGC is off or shutter mode is A.FLK or
MANUAL.
Please remember that together with selecting higher values from the low shutter
range the image becomes brighter but simultaneously the noise level goes up and
moving objects become blurred.
5.1.3 WHITE BAL submenu
This feature allows for setting appropriate color settings in various color temperature conditions.
WHITE BAL White balance mode
ATW This mode (Auto Tracking White Balance) can be used in the 1700°K ~ 11000°
color temperature range.
MANUAL Manual mode settings. In case of inappropriate color settings for ATW, AWC
modes it is possible to set RED and BLUE color values manually . The range of
changes is from 0 to 900 and is displayed as a line. The changes are seen
immediately. The lines of changes are active only in WB manual mode.
AWC → SET This mode (Auto White balance Control) allows for adaptive setting of white
balance. In order to obtain the optimum state under the current illumination, direct
the camera at a sheet of white paper and press SET button. When lighting
parameters change ( e.g. light bulbs changed to halogen lamps, daylight to artificial
light etc. ), procedure mentioned above should be repeated.
OUTDOOR This mode (Auto Tracking White Balance) can be used in the 1700°K ~ 11000°K
color temperature range (e.g. when using sodium vapour lamps).
INDOOR This mode (Auto Tracking White Balance) can be used in the 4500°K~8500°K
color temperature range (e.g. when using the camera inside the house).
5.1.4 SSDR submenu (Wide dynamic range)
This function allows to effectively observe the scene with different illumination level. Function can
be enabled (ON) or disabled (OFF). When ON is selected, a submenu that allows for setting the
function intensity level in the range from 1 to 15 becomes available.
SETT NGS

NVDN‐821H/IR‐2, NVDN‐841H/IR‐2 ver. 1.1 ‐ User’s manual
All rights reserve © AAT Hol ing sp. z o.o.
13
5.1.5 BACKLIGHT submenu
These compensation functions allow for enhancing visibility of the objects located in the foreground,
surrounded by strongly illuminated background (BLC) or for enhancing visibility of the objects
located near the strong light source (HLC).
BACKLIGHT Backlight compensation mode.
OFF Function OFF.
BLC BLC function allows for enhancing visibility of the objects located in the
foreground, surrounded by strongly illuminated background. After pressing SET
button in this mode submenu depicted below appears:
Submenu presented above allows for setting the size and location of the area where
the BLC function will be active, furthermore it allows for setting the sensitivity of
the function.
LEVEL Select the intensity of the function from available: LOW, MIDDLE, HIGH
TOP Move upper part of the area up or down.
BOTTOM Move bottom part of the area up or down
LEFT Move left part of the area left or right side.
RIGHT Move right part of the area left or fight side.
HLC High light compensation function. It allows for enhancing visibility of the objects
located near the strong, point light source. If a strong, point light source appears on
the screen, function will mask it allowing for effective observation of the scene
itself (this function is best used to, for example, observe licence-plates of the cars).
SETT NGS
BLC SETUP


LEVEL LOW
TOP ιιιιιxιιιιιιιιιιιι 38
BOTTOM ιιιιιιιιιιιιιxιιιι 109
LEFT ιιιιιxιιιιιιιιιιιι 54
RIGHT ιιιιιιιιιιιιιιxιιι 121
Press SET to Return

NVDN‐821H/IR‐2, NVDN‐841H/IR‐2 ver. 1.1 ‐ User’s manual
All rights reserve © AAT Hol ing sp. z o.o.
14
Press the SET please, to display below submenu.
Submenu allows to set the size and location of the area in which the HLC function
analyzes the level of illumination and sets the other HLC function options described
below.
LEVEL Adjust level of the HLC function from available: LOW, MIDDLE HIGH.
LIMIT Sets the lighting threshold that, when exceeded, activates the function.
ALL DAY Threshold is set to low variations in illumination level.
NIGHT ONLY Threshold is set to high variations in illumination level.
MASK COLOR Select the colour of the masking area from available: RED, BLUE,
CYAN, MAGENTA, BLACK.
MASK TONE Adjusts opacity of masking area.
TOP Moves upper part of the area up or down.
BOTTOM Moves bottom part of the area up or down
LEFT Moves left part of the area left or right side.
RIGHT Moves right part of the area left or right side.
Note: HLC function works only in the low-light conditions. It is activated automatically when level
of the light is low enough for the function to execute properly and when a strong point light
source appears on the screen.
Because the effectiveness of HLC function relies mostly on the amount of light area in the
screen, optimize the installation angle for the best HLC performance.
SETT NGS
HLC SETUP


LEVEL MIDDLE
LIMIT ALL DAY
MASK COLOR RED
MASK TONE ιιιιιιιιιιιιιxιιιι 25
TOP ιιιιιxιιιιιιιιιιιι 5
BOTTOM ιιιιιιιιιιιιιιxιιι 120
LEFT ιxιιιιιιιιιιιιιιιι 5
RIGHT ιιιιιιιιιιιιιιxιιι 172
Press SET to Return

NVDN‐821H/IR‐2, NVDN‐841H/IR‐2 ver. 1.1 ‐ User’s manual
All rights reserve © AAT Hol ing sp. z o.o.
15
5.1.6 DNR3 (Digital Noise Reduction) submenu
This submenu allows for changing digital noise reduction settings.
DNR Digital Noise Reduction function.
ON Digital Noise Reduction function ON.
OFF Digital Noise Reduction function OFF.
After selecting ON press the SET please, to display submenu allowing for adjustment of the
digital noise reduction level, as depicted below.
Note: While working in DNR mode, image quality might slightly worsen. Digital noise reduction
function is disabled when the AGC function is off.
5.1.7 DAY / NIGHT submenu
DAY / NIGHT Selects operating mode of the IR cut filter.
AUTO Camera switches between night (b w) and day (color) mode automatically,
depending on current illumination conditions.
After pressing SET button the submenu depicted below appears.
BURST MODE Enable (ON) or disable (OFF) the BURST (color burst) signal.
SETT NGS
SDNR


 LEVEL ιιιιιιιιιιιιιxιιιι 12
RETURN


AUTO SETUP


1. BURST MODE OFF
2. COLOR→B W
DURATION FAST
DWELL TIME 5 SEK
3. B W →COLOR
DURATION FAST
DWELL TIME 5 SEK
4. RETURN



NVDN‐821H/IR‐2, NVDN‐841H/IR‐2 ver. 1.1 ‐ User’s manual
All rights reserve © AAT Hol ing sp. z o.o.
16
COLOR→B/W Allows for configuring the switching from b w to color mode.
DURATION Selects color to b w switching speed from available: FAST, SLOW
DWELL TIME Sets the delay between color and b w mode switching. Values range
from 3 to 60 sec.
B/W→COLOR Allows for configuring the switching from b w to color mode.
DURATION Selects b w to color switching speed from available: FAST, SLOW
DWELL TIME Sets the delay between b w and color modes switching. Values range
from 3 to 60 sec.
EXTERN Not available.
COLOR Camera works permanently in color mode.
B/W Camera works permanently in B W mod. For that setting a submenu that allows for
enabling or disabling the BURST MODE and SMART IR function is available
5.1.8 SPECIAL submenu
This submenu allows for setting the additional functions available in the camera.
IMAGE ADJ. Allows for enabling the additional picture effects.
MONITOR Allows for configuring camera picture parameters, depending on the type of
monitor used.
LCD Allows for configuring the camera to enhance its LCD monitor cooperation
capabilities, pressing SET displays additional submenu which allows for
adjustment the LCD monitor display settings.
USER Allows for configuring the camera to enhance its monitor (of non-standard types)
cooperation capabilities, pressing SET displays additional submenu which allows
for adjustment the display settings.
CRT Allows for configuring the camera to enhance its CRT monitor cooperation
capabilities, pressing SET displays additional submenu which allows for
adjustment the CRT monitor display settings.
SETT NGS
SPECIAL
1. IMAGE ADJ


2. CAM TITLE OFF
3. SYNC INT
4. MOTON OFF
5. PRIVACY OFF
6. DIS OFF
7. PROFILE USER
8. COMM ADJ


9. RETURN



NVDN‐821H/IR‐2, NVDN‐841H/IR‐2 ver. 1.1 ‐ User’s manual
All rights reserve © AAT Hol ing sp. z o.o.
17
REVERSE flips the picture:
OFF - Function off.
V - REV Flips the picture vertically,
H - REV Flips the picture horizontally (Mirror)
HV - REV Rotate 180 degree the picture;
PIP - (Picture in Picture) Function displays a full-size image in the thumbnail. Used in digital
zoom mode. The position of the thumbnail is adjustable.
D - ZOOM Digital zoom function. After selecting ON, pressing the SET displays additional
submenu which allows for adjusting the digital zoom level, ranging from x0.1 to x16, OFF -
function off.
FONT COLOR Selects the OSD font color
SHARPNESS Screen sharpness function. After selecting ON, pressing SET displays additional
submenu which allows for sharpness level adjustment, ranging from 1 to 20. OFF - function
off. If the SHARPNESS level is too high the picture may become distorted or noisy.
LANGUAGE Selects OSD language from available: ENGLISH, GERMAN, ITALIAN,
FRENCH, SPANISH, RUSSIAN, CZECH, ROMANIAN, SERBIAN, SWEDISH, DANISH,
TURKISH, PORTUGUESE, THAI.
CAM TITLE After selecting ON and pressing SET, a sub-menu appears, allowing for entering a
string of characters that later is displayed on the screen, e.g. as camera title. Title may consist
of up to 15 characters. Please select desired characters from the virtual keyboard, which
becomes available after pressing SET.
Screen contains mainly alphanumerical characters, which may be used in camera’s title. Select
desired character and please apply it by pressing SET key. Currently edited title is visible at
the bottom of the screen. A line just above it contains buttons for editing the title. To enable
particular functions, please highlight them as normal characters and confirm by pressing SET
key. Button functions are described below:


 Moves character highlight cursor left.


 Moves character highlight cursor right
POS Allows for adjusting the position of entered characters.
CLR Erases the whole title.
END Exits title editing menu.
SETT NGS
CAMERA TITLE SETUP
ABCDEFGHIJKLM
NOPRSTUVWXYZ
abcdefghijklm
noprstuvwxyz
_ . 0123456789


 CLR POS END
CAMERA---------

NVDN‐821H/IR‐2, NVDN‐841H/IR‐2 ver. 1.1 ‐ User’s manual
All rights reserve © AAT Hol ing sp. z o.o.
18
SYNC Selects synchronization mode.
INT Internal synchronization.
MOTION This menu allows (provided, that ON option is selected) for turning a built-in
motion detection feature on or off. Motion detection may simultaneously be
conducted in eight independent zones (with their size and location selectable by
user). Detection of motion with MOTION DET turned on results in Motion
Detected message being displayed on the screen.
After selecting ON and pressing SET the submenu below is displayed, which
allows for adjusting the motion detection function parameters.
SENSITIVITY Selects one of eight available motion detection zones (AREA1, AREA2,
AREA3, AREA4). Each zone has different sensitivity level. The higher
number, the higher sensitivity.
AREA MODE Turns motion detection in selected zone on or off.
SEL POS Selects edge of the area so its position can be changed.
L_BOTTOM Left bottom area corner.
R_BOTTOM Right bottom area corner.
L_TOP Left top area corner.
R_TOP Right top area corner.
YPOS Change the selected area corner position toward vertical axis.
XPOS Change the selected area corner position toward horizontal axis.
FILL 

 SET After pressing SET button actually selected area will appear on the first plan.
Note: Disabling privacy zones prior to setting motion detection parameters is advised.
PRIVACY Allows for enabling privacy zones (when turned ON). If this option is turned on,
desired part of the screen is masked using four rectangular zones.
Pressing SET displays submenu which allows for adjusting privacy settings.
SETT NGS
MOTION DET
1. SENSITIVITY AREA1
2. AREA MODE OFF
3. SEL POS R_BOTTOM
4. YPOS ιιιιιιιιιιιιιxιιιι 5
5. XPOS ιιιιιιιιιιιιιxιιιι 5
6. FILL

SET
8. RETURN



NVDN‐821H/IR‐2, NVDN‐841H/IR‐2 ver. 1.1 ‐ User’s manual
All rights reserve © AAT Hol ing sp. z o.o.
19
AREA SEL Selects one of twelve available privacy zones: AREA1, AREA25 AREA12.
MODE Turns selected privacy zone displaying on or off. After selecting ON and
pressing SET displays submenu allowing for selected privacy zone location and
size adjustment.
MASK COLOR Allows for setting the color of all privacy zones. Available colours: GREEN,
RED, BLUE, BLACK, WHITE, GRAY.
MASK TONE Allows for adjusting brightness of masking zones in the range from 1 to 10.
TOP Moves upper part of the area up or down.
BOTTOM Moves bottom part of the area up or down
LEFT Moves left part of the area left or right side.
RIGHT Moves right part of the area left or right side.
DIS Digital image stabilization function. It eliminates any picture movement which may
occur due to external factors, such as wind. ON - function on, OFF function off.
Note: Turning on the DIS function narrows the camera’s field of view. When using DIS function a
decrease in resolution is possible, due to fact that the function uses digital zoom
PROFILE Predefined mode according to the picture condition
BASIC - Profile optimized to the most common environment condition.
DAY/NIGHT - Profile optimized to the day or night conditions, respectively.
BACKLIGHT - Profile optimized to distinguish the object from the background in
a backlighting scene.
ITS - Profile optimized to the traffic conditions.
INDOOR - Profile optimized to a regular indoor lighting condition.
USER - Profile for custom user settings.
SETT NGS
PRIVACY AREA SETUP
1. AREA AREA1
2. MODE ON
3. MASK COLOR GRAY
4. MASK TONE ιιιιxιιιιιιιιιιιιιι 4
5. TOP ιιιιιιιxιιιιιιιιιιι 39
6. BOTTOM ιιιιιιιxιιιιιιιιιιι 79
7. LEFT ιxιιιιιιιιιιιιιιιιι 13
7. RIGHT ιιιιιιιxιιιιιιιιιιι 52
8. RETURN



NVDN‐821H/IR‐2, NVDN‐841H/IR‐2 ver. 1.1 ‐ User’s manual
All rights reserve © AAT Hol ing sp. z o.o.
20
COMM ADJ Function allows for configuring the RS-485 communication settings of the
camera.
CAM ID Allows for setting unique ID number for the camera, ranging from 1 to 255,
enabling the device to communicate through RS-485
BAUD RATE Allows for setting data transfer speed for RS-485 protocol. Values range from
2400 to 57600 bps
UART MODE Configures the parameters of the RS-485. 8-0-1 mode presented above means
that 8 data bits are sent in one packet, 0 meaning bit oddity (with possibility of
setting E meaning parity and N meaning lack of parity) and 1 meaning stop bit.
RET PKT Enables confirmation of receiving sent packets (enable disable).
DISP ID Allows for turning the camera number displaying (enable disable).
PROTOCOL Allows for selecting the RS-485 communication protocol
SETT NGS
COMM SETUP
1. CAM ID ιιιιxιιιιιιιι 4
2. BAUD RATE 9600
3. UART MODE 8-0-1
4. RET PKT ENABLE
5. DISP ID OFF
6. PROTOCOL PELCO-D
7. RETURN


