Novus NVC-VS10BD User manual

USER`S MANUAL VER. 1.0
Contents
Preface
Safety instructions
Function description
Installation
Specifications
VANDAL DOME
B/W & COLOR CAMERA
NOVUS SECURITY Sp. z o.o.
359 Pulawska Str., 02-801 Warsaw, Poland
tel: [phone]; fax: [phone]
[email protected]; www.novuscctv.com
© Copyright 2003, NOVUS SECURITY Sp. z o.o.

Vandal Dome B/W & Color Camera Manual, ver. 1.0
© Copyright 2003, NOVUS SECURITY Sp. z o.o., All rights reserved
CONGRATULATIONS ON YOUR PURCHASE OF OUR
CAMERA
This product has been carefully inspected through rigid quality control
before shipment. With reasonable installation and operation, it will
provide years of reliable performance. Considering your investment, we
understand you would like to know the full performance capability about
the new product. Therefore, we need to recommend that you read the
installation and operation manual thoroughly before attempting to install
and operate the product.
IMPORTANT INFORMATION BEFORE INSTALLATION
Please read and observe all instructions and warnings contained in this
manual. Retain the original manual for the future reference. When
unpacking your new product, first please compare the received items with
your order list, second check for damaged items. If there is anything
missing or damage in evidence, please do not install or operate the
product. Contact your dealer for assistance immediately. Never try to
service this product by yourself. Opening the covers may expose you to
dangerous power voltage or other hazards. For your protection, take a
moment to complete the following product purchase information. The
serial number of this product may be found on the cover of the unit. The
serial number may be required by the factory when need service or
technical support.
Model NO.
Serial NO.
Purchase date

Vandal Dome B/W & Color Camera Manual, ver. 1.0
© Copyright 2003, NOVUS SECURITY Sp. z o.o., All rights reserved
PREFACE
Design for this series CCD camera is based on professional video system
processing capability. Interior key components adopt Japanese advanced
charge coupled device (CCD) sensor and related peripheral IC. So the
CCD camera has better performance such as high sensitivity, sharpness,
premium fidelity and low noise. It also has auto electronic shutter,
backlight compensation and white balance function (for Color Cameras
only). Because power design uses switching regulator, its operating
current is only 200~250mA for DC12V model. Installation becomes more
simple and easier.
SAFETY INSTRUCTIONS
1. Never expose the unit to rain or moisture and avoid electric shock
hazard.
2. Any service or maintenance should be made by qualified service
personnel.
3. Storage temperature –30ºC~+80ºC.
4. All installation and service should be confirmed to local agents.
5. Do not open the cover; it may expose you to electric and other hazard.
6. Do not place anything on the unit which may spill or fall into the unit.
7. The equipment has been tested and passed the CE standard, which is
designed to provide reasonable protection against harmful interference
and be insusceptible to other radiating interference when operated in
commercial environment. Therefore the equipment can not also
generate and cause any interference to radio communication.

Vandal Dome B/W & Color Camera Manual, ver. 1.0
© Copyright 2003, NOVUS SECURITY Sp. z o.o., All rights reserved
FUNCTION DESCRIPTION
Window for lens
1/3”
1/4"
or
Video out Power in
INSTALLATION
CCD Camera
Screw hole
1/3”
1/4"

Vandal Dome B/W & Color Camera Manual, ver. 1.0
© Copyright 2003, NOVUS SECURITY Sp. z o.o., All rights reserved
or
Ceiling mounting type fixed
by screw (option)
1/4"
1/3”
Adjust lens focal length
Remove cover:
Press down spring hook turn right and remove cover.
After adjustment, replace it counterclockwise.

Vandal Dome B/W & Color Camera Manual, ver. 1.0
© Copyright 2003, NOVUS SECURITY Sp. z o.o., All rights reserved
SPECIFICATIONS
A. Color Cameras
Model: NVC-
VS50CD
NVC-
VS55CD
NVC-
VH60CD
NVC-
VS45CD/IR
Pick-up Element 1/3” color CCD imager
Number of Pixels
(H) x (V) 537 x 597 795 x 596 537 x 597
Resolution > 380 TVL > 480 TVL > 380 TVL
Synchronizing
System internal
Video Output 1,0 Vpp, 75 Ohm, BNC
IR Projector N/A Yes
Min. Illumination 0,8 lx/F=1.2 1,2 lx/F=1.2 1,0 lx/F=1.2
0 lx/IR on
Electronic Shutter auto 1:50 to 1:100 000 s
S/N Ratio 48 dB (AGC off)
Gamma 0,45
White Balance auto / 2000°K ~ 8000°K
Back Light
Compensation auto
Standard Board
Lens
fixed focal:
f=3.6 mm varifocal auto iris: 4-9 mm fixed focal: f=3.6 mm
Operating
Temperature –10°C ~ +50°C
Water Resistance IP66
Power Supply 12VDC / max. 250 mA
Dimensions 108 (D) x 75 (H) mm
Weight 640 g

Vandal Dome B/W & Color Camera Manual, ver. 1.0
© Copyright 2003, NOVUS SECURITY Sp. z o.o., All rights reserved
B. B/W Cameras
Model: NVC-
VS10BD
NVC-
VS25BD NVC-VH35BD NVC- VS15BD/IR
Pick-up Element 1/3” B/W CCD imager
Number of Pixels
(H) x (V) 537 x 597 795 x 596 537 x 597
Resolution > 420 TVL > 580 TVL > 420 TVL
Synchronizing
System internal
Video Output 1,0 Vpp, 75 Ohm, BNC
IR Projector N/A Yes
Min. Illumination 0,05 lx/F=1.2 0,08 lx/F=1.2 0,05 lx/F=1.2
0 lx/IR on
Electronic Shutter auto 1:50 to 1:100 000 s
S/N Ratio 48 dB (AGC off)
Gamma 0,45
Back Light
Compensation auto
Standard Board
Lens
fixed focal:
f=3.6 mm varifocal auto iris: 4-9 mm fixed focal: f=3.6 mm
Operating
Temperature –10°C ~ +50°C
Water Resistance IP66
Power Supply 12VDC / max. 250 mA
Dimensions 108 (D) x 75 (H) mm
Weight 640 g
