Novus NVIP-3DN3552H/IR-1P User manual

U ser’s manual
( short form)
NVIP-3DN3552H/IR-1P

NVIP-3DN3552H/IR-1P - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A.
2
IMPORTANT SAFEGUARDS AND WARNINGS
EMC (2004/108/EC) and LVD (2006/95/EC ) Directives
CE Marking
Our products are manufactured to comply with requirements of the following directives and national regulations
implementing the directives:
 Electromagnetic compatibility EMC 2004/108/EC.
 Low voltage LVD 2006/95/EC with further amendment. The Directive applies to electrical
equipment designed for use with a voltage rating of between 50VAC and 1000VAC as well as
75VDC and 1500VDC.
WEEE Directive 2012/19/EU
Information on Disposal for Users of Waste Electrical and Electronic Equipment
This appliance is marked according to the European 1000VAC Directive on Waste Electrical and Electronic
Equipment (2012/19/EU) and further amendments. By ensuring this product is disposed of correctly, you will
help to prevent potential negative consequences for the environment and human health, which could otherwise
be caused by inappropriate waste handling of this product.
The symbol on the product, or the documents accompanying the product, indicates that this appliance may not be
treated as household waste. It shall be handed over to the applicable collection point for used up electrical and
electronic equipment for recycling purpose. For more information about recycling of this product, please contact
your local authorities, your household waste disposal service or the shop where you purchased the product.
RoHS Directive 2011/65/UE
Out of concern for human health protection and friendly environment, we assure that our products
falling under RoHS Directive regulations, regarding the restriction of the use of hazardous
substances in electrical and electronic equipment, have been designed and manufactured in
compliance with the above mentioned regulations. Simultaneously, we claim that our products have
been tested and do not contain hazardous substances whose exceeding limits could have negative
impact on human health or natural environment
Information
The device, as a part of professional CCTV system used for surveillance and control, is not designed for self
installation in households by individuals without technical knowledge.
Excluding of responsibility in case of damaging data on a disk or other devices:
The manufacturer does not bear any responsibility in case of damaging or losing data on a disk or other devices
during device operation.
WARNING!
PRIOR TO UNDERTAKING ANY ACTION THAT IS NOT DESCRIBED FOR THE GIVEN PRODUCT IN
USER’S MANUAL AND OTHER DOCUMENTS DELIVERED WITH THE PRODUCT, OR IF IT DOES
NOT ARISE FROM THE USUAL APPLICATION OF THE PRODUCT, MANUFACTURER MUST BE
CONTACTED UNDER THE RIGOR OF EXCLUDING THE MANUFACTURER’S RESPONSIBILITY FOR
THE RESULTS OF SUCH AN ACTION.

NVIP-3DN3552H/IR-1P - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A
3
IMPORTANT SAFEGUARDS AND WARNINGS
WARNING!
THE KNOWLEDGE OF THIS MANUAL IS AN INDESPENSIBLE CONDITION OF A PROPER
DEVICE OPERATION. YOU ARE KINDLY REQUSTED TO FAMILIRIZE YOURSELF WITH
THE MANUAL PRIOR TO INSTALLATION AND FURTHER DEVICE OPERATION.
WARNING!
USER IS NOT ALLOWED TO DISASSEMBLE THE CASING AS THERE ARE NO
USER-SERVICEABLE PARTS INSIDE THIS UNIT. ONLY AUTHORIZED SERVICE
PERSONNEL MAY OPEN THE UNIT
INSTALLATION AND SERVICING SHOULD ONLY BE DONE BY QUALIFIED SERVICE
PERSONNEL AND SHOULD CONFORM TO ALL LOCAL REGULATIONS
1. Prior to undertaking any action please consult the following manual and read all the safety and operating
instructions before starting the device.
2. Please keep this manual for the lifespan of the device in case referring to the contents of this manual is
necessary;
3. All the safety precautions referred to in this manual should be strictly followed, as they have a direct
influence on user’s safety and durability and reliability of the device;
4. All actions conducted by the servicemen and users must be accomplished in accordance with the user’s
manual;
5. The device should be disconnected from power sources during maintenance procedures;
6. Usage of additional devices and components neither provided nor recommended by the producer is
forbidden;
7. You are not allowed to use the camera in high humidity environment (i.e. close to swimming pools, bath tubs,
damp basements);
8. Mounting the device in places where proper ventilation cannot be provided (e. g. closed lockers etc.) is not
recommended since it may lead to heat build-up and damaging the device itself as a consequence;
9. Mounting the camera on unstable surface or using not recommended mounts is forbidden. Improperly
mounted camera may cause a fatal accident or may be seriously damaged itself. The camera must be mounted
by qualified personnel with proper authorization, in accordance with this user’s manual.
10. Device should be supplied only from a power sources whose parameters are in accordance with those
specified by the producer in the camera technical datasheet. Therefore, it is forbidden to supply the camera
from a power sources with unknown parameters, unstable or not meeting producer’s requirements;
Due to the product being constantly enhanced and optimized, certain parameters and functions
described in the manual in question may change without further notice.
We strongly suggest visiting the www.novuscctv.com website in order to access the newest manual.

NVIP-3DN3552H/IR-1P - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A.
4
TABLE OF CONTENTS.................................................................................................4
1. FOREWORD INFORMATION..................................................................................5
1.1. General characteristics .....................................................................................5
1.2. Technical specification ....................................................................................6
1.3. Camera dimension ...........................................................................................7
1.4. Package contents..............................................................................................7
2. START-UP AND INITIAL IP CAMERA CONFIGURATION ................................8
2.1. Description of connectors and control tools ......................................................8
2.2. Cameras mounting ...........................................................................................9
2.3. Desiccant mounting guide ..............................................................................10
2.4. Starting the IP camera ....................................................................................12
3. NETWORK CONNECTION UTILIZING WEB BROSWER ...............................14
3.1. Recommended PC specification for web browser............................................14
3.2. Connection with IP camera via web browser...................................................14
4. USING AND CONFIGURING..................................................................................16
4.1. Remote Preview Interface. ..............................................................................16
5. ELECTRIC CONNECTORS AND ACCESORIES ...............................................17
5.1. Connecting power supply to the camera. ........................................................17
5.2. Camera control RS..........................................................................................17
5.3. Connecting alarm inputs/outputs.....................................................................17
5.4. SD card installation.........................................................................................18
6. RESTORING FACTORY DEFAULTS ..................................................................19
6.1. Restoring software factory defaults .................................................................19
6.2. Restoring factory defaults by hardware means ................................................19
TABLE OF CONTENTS

NVIP-3DN3552H/IR-1P - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A
5
1. FOREWORD INFORMATION
1.1. General Characteristics
 Imager resolution: 3 megapixels
 Mechanical IR cut filter ,IR operation capability
 Min. Illumination from 0 lx with IR LED on
 Wide Dynamic Range (WDR) for enhanced image quality in diverse light conditions
 Digital Noise Reduction (DNR)
 Lens type: Varfocal, f=7- 22 mm/F=1.4
Built-in LED illuminator: 25 pcs LED (NVIP-3DN3052H/IR-1P)
 Compression: H.264/H.265
 Max video processing resolution: 2048 x 1536
 Multi streaming: compression, resolution, speed and quality defined individually for each video
stream
 RTP/RTSP protocol support for video transmission
 Post-alarm functions
 Hardware motion detection
 ROI Zones
 Built-in webserver: camera configuration through the website
 Wide range of responses to alarm events: e-mail with attachment, saving file on FTP server
(all cameras) and triggering alarm output, saving file on SD/SDHC card
 Software: NMS (NOVUS MANAGEMENT SYSTEM) for video recording, live monitoring,
playback and remote IP devices administration
 Power supply: 12VDC, PoE (Power over Ethernet)
FOREWORD INFORMATION

NVIP-3DN3552H/IR-1P - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A.
6
1.2. Technical specification
FOREWORD INFORMATION
Image Sensor 3 MPX CMOS sensor 1/2.8” SONY
Number of Effective Pixels 2048 (H) x 1536 (V)
Min. Illumination 0.01 lx/F1.4 - color mode
0 lx (IR on) - B/W mode
Electronic Shutter auto/manual: 1/25 s ~ 1/100000 s
Wide Dynamic Range (WDR) yes
Digital Noise Reduction (DNR) 2D, 3D
LENS
Lens Type varifocal, f=7 ~ 22 mm/F1.4
DAY/NIGHT
Switching Type mechanical IR cut filter
Switching Mode auto, manual, time
Switching Schedule yes
Visible Light Sensor yes
NETWORK
Stream Resolution 2048 x 1536 (QXGA), 1920 x 1080 (Full HD), 1280 x 720 (HD), 704 x 576, 640 x 480
(VGA), 480 x 270, 352 x 288 (CIF)
Frame Rate 30 fps for each resolution
Multistreaming Mode 3 streams
Video/Audio Compression H.264, H.265, MJPEG/G.711
Number of Simultaneous Connections max. 10
Bandwidth 40 Mb/s in total
Network Protocols Support HTTP, TCP/IP, IPv4, FTP, DHCP, DDNS, NTP, RTSP, PPPoE, SMTP
ONVIF Protocol Support Profile S (ONVIF 2.3
Camera Configuration from Internet Explorer, Firefox, Chrome, Opera browser
languages: Polish, English, Russian, and others
Compatible Software NMS
OTHER FUNCTIONS
Privacy Zones 4
Motion Detection yes
Region of interest (ROI) 8
Image Processing 90˚ image rotation, 180˚ image rotation, sharpening, mirror effect
Prealarm/Postalarm -/up to 120 s
System Reaction to Alarm Events e-mail with attachment, saving file on FTP server, saving file on SD card, alarm output
activation
IR LED
LED Number 25
Range 70 m
Angle 60°
INTERFACES
Video Output BNC, 1.0 Vp-p, 75 Ohm - maintenance only
Audio Input/Output 1 x Jack (3.5 mm)/1 x Jack (3.5 mm)
Alarm Input/Output 1 (NO/NC)/1
Network Interface 1 x Ethernet - RJ-45 interface, 10/100 Mbit/s
Memory Card Slot SD
INSTALLATION PARAMETERS
Dimensions (mm) with bracket: 109 (Ф) x 360 (L)
Weight 1.7 kg
Degree of Protection IP 66
Enclosure aluminium, white, fully cable manged wall mount bracket in-set included
Power Supply PoE, 12 VDC
Power Consumption 2.5 W
6 W (IR on)
Operating Temperature -20°C ~ 50°C

NVIP-3DN3552H/IR-1P - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A
7
FOREWORD INFORMATION
1.3. Camera dimensions
1.4. Package contents
After you open the package make sure that the following elements are inside:
 IP camera
 Accessories bag
 Short version of user’s manual
If any of this elements has been damaged during transport, pack all the elements back into the original
box and contact your supplier for further assistance.
CAUTION!
If the device was brought from a location with lower temperature, please wait until it reaches
the temperature of location it is currently in. Turning the device on immediately after bringing it
from a location with lower ambient temperature is forbidden, as the condensing water vapour
may cause short-circuits and damage the device as a result.
Before starting the device familiarize yourself with the description and the role of particular
inputs, outputs and adjusting elements that the device is equipped with.

NVIP-3DN3552H/IR-1P - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A.
8
1.4. Package contents
After you open the package make sure that the following elements are inside:
 IP camera
 230 VAC / 12 VDC power supply
 Accessories bag
 Short version of user’s manual
 CD containing manual and software
If any of this elements has been damaged during transport, pack all the elements back into the original
box and contact your supplier for further assistance.
CAUTION!
If the device was brought from a location with lower temperature, please wait until it reaches the
temperature of location it is currently in. Turning the device on immediately after bringing it
from a location with lower ambient temperature is forbidden, as the condensing water vapour
may cause short-circuits and damage the device as a result.
Before starting the device familiarize yourself with the description and the role of particular
inputs, outputs and adjusting elements that the device is equipped with.
2. START-UP AND INITIAL CAMERA CONFIGURATION
2.1 Description of connectors and control tools
1. BNC video output
2. Audio output
3. Audio input
4. Power supply 12VDC
5. 100 Mb/s Ethernet port (RJ-45 connector)
6. Alarm COM - Alarm output
7. Alarm NO - Alarm output
8. Alarm IN - Alarm input
9. Alarm GND - Alarm input
10. RS485 T+
11. RS485 T-
START-UP AND INITIAL CAMERA CONFIGURATION
1
2
4
3
5 6
7
10
9
8
11

NVIP-3DN3552H/IR-1P - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A
9
WARNING! To get access to above ports it is required to open service compartment.
1. 3 pin connector. Video output and power supply - maintenance only
2. Reset button
3. Network indicator
4. SD card slot
2.2 Zoom and focus adjustment
User can adjust camera zoom and focus. It is recommended to check focus settings in infrared
illumination and make correction in color mode to have proper focus in both modes.
START-UP AND INITIAL CAMERA CONFIGURATION
1 2
3
4
Zoom adjustment Focus adjustment

NVIP-3DN3552H/IR-1P - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A.
10
2.3 Camera mountain
WARNING! In order to obtain declared degree of protection please seal the camera bracket to prevent
water getting inside. Furthermore, when installing the bracket on rough/uneven surfaces, please
additionally seal the junction with appropriate sealing mass. Please pay special attention to any
mounting holes and if they are a loop-through ones, seal them too.
To mount a camera please follow the instructions below:
1. Drill the screw holes and the cable hole on the wall according to the drill template.
2. Route the cables to the cable hole and connect the cables.
3. Using included screws mounting base on smooth surface providing declared degree of IP protection.
4. Optionally open service compartment to insert SD card and connect monitor through DCIN/CVBS
cables.
5. Using allen key loosen screws 1, 2 and 3. Then adjust camera position and tight lock screws.
6. Adjust zoom and focus screw until you get the optimum image (after starting IP Camera, details in
chapter 2.4).
START-UP AND INITIAL CAMERA CONFIGURATION
1 2 3
Service compartment

NVIP-3DN3552H/IR-1P - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A
11
2.4. Starting the IP camera
To run NOVUS IP camera you have to connect ethernet cable between camera and network switch.
To power it up you can connect it directly via power supply adapter with parameters compatible with
camera power supply specification, or camera can be powered with PoE (IEEE 802.3af ) compatible
switch.
After connecting power supply it takes about 30 seconds to start camera. Then You can proceed to
connect to the camera via web browser.
The recommended way to start an IP camera and perform its configuration is a connection directly
to the network switch which is not connected to other devices. To obtain further information about
network configuration parameters (IP address, gateway, network mask, etc.) please contact your
network administrator.
 Connection utilising network switch with PoE support
 Connection utilising external power supply and network switch
START-UP AND INITIAL CAMERA CONFIGURATION
Power supply and
network transmission
Computer
IP Camera
Network Switch
PoE
Network transmission
IP Camera
Network transmission
Network Switch Computer
Network transmission

NVIP-3DN3552H/IR-1P - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A.
12
 Connection utilising external power supply directly to the computer
Information:
Power supply adapter is not included. Please use power adapter with parameters specified in user ‘s
manual.
Caution:
In order to provide protection against voltage surges/lightning strikes, usage of appropriate surge
protectors is advised. Any damages resulting from surges are not eligible for service repairs.
2.5. Initial configuration via the web browser
The default network settings for NVIP-… IP camera series are :
1. IP address= 192.168.1.200
2. Network mask - 255.255.255.0
3. Gateway - 192.168.1.1
4. User name - root
5. Password - pass
Knowing the camera’s IP address you need to appropriately set PC IP address, so the two devices can
operate in one network subnet ( e.g. for IP 192.168.1.1, appropriate address for the camera ranges from
192.168.1.2 to 192.168.1.254, for example 192.168.1.60). It is not allowed to set the same addresses for
camera and PC computer
You can either set a network configuration (IP address, gateway, net mask, etc.) of NOVUS IP camera
yourself or select DHCP mode (DHCP server is required in this method in target network) by using
web browser or by NMS software. When you use DHCP server check IP address lease and its linking
with camera MAC address to avoid changing or losing IP address during device operation or network/
DHCP server breakdown. You have to remember to use a new camera IP address after changing
network parameters.
After network setting configuration has been done, the camera can be connected to a target
network
START-UP AND INITIAL CAMERA CONFIGURATION
IP Camera
Network transmission - cross over cable
Computer

NVIP-3DN3552H/IR-1P - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A
13
.3. NETWORK CONNECTION UTILIZING WEB BROSWER
3.1. Recommended PC specification for web browser connections
Requirements below apply to connection with an IP camera, assuming smooth image display
in 1920x1080 resolution and 25 fps speed.
1. CPU Intel Core i3 3 GHz or newer
2. RAM Memory min. 4 GB
3. VGA card (any displaying Direct 3D with min. 512 MB RAM memory)
4. OS Windows 7/8/8.1/10
6. Network card 100/1000 Mb/s
3.2. Connection with IP camera via web browser
You have to enter camera IP address in the address bar. When you connect to the camera, web browser
will download the applet for displaying images from the camera. In Internet Explorer it may be
necessary to accept an ActiveX control. To do this, click the right mouse button on the message, select
"Install Active X control" and then click Install. After successfully SuperClientEX plug in downloading
run and install it on a computer.
NETWORK CONNECTION UTILIZING WEB BROWSER

NVIP-3DN3552H/IR-1P - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A.
14
If the installation fails, changing security settings for the IE browser is required. In order to do that,
please choose: Tools > Internet options > Security tab > Custom level and:
 Under Download unsigned ActiveX controls - select either Enable or Prompt
 Under Initialize and script ActiveX controls not marked as safe - select Enable or Prompt
You can also add the camera’s IP address to “trusted zone” and set lowest security level for it.
In addition, when working in Windows Vista/7 the ActiveX applet may be blocked by Windows
Defender or User account control. In such case you should allow to run this applet, or simply disable
these functions.
After successful installation login window will be displayed. Default user is root and default password
is pass. For safety reasons, it is recommended to change default user name and password.
NETWORK CONNECTION UTILIZING WEB BROWSER

NVIP-3DN3552H/IR-1P - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A
15
4. USING AND CONFIGURING
4.1 Remote Preview Interface
1. Motion detection
Motion detection icon changes color from white to red when motion is detected.
Alarm icon changes color from white to red when alarm situation has occured.
2. Display fluency settings
It is possible to increase video display fluency by setting video buffor (0 ~ 4 seconds).
3. Video size settings
Fix size Zoom in Full screen
Zoom in Zoom out
4. Local record
Start record Snap
Playback Enable / disable audio
REMOTE PREVIEW
1 2 3 4

NVIP-3DN3552H/IR-1P - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A.
16
5. ELECTRIC CONNECTORS AND ACCESORIES
5.1. Connecting power supply to the camera.
Camera can be supplied using external power supply unit corresponding with the camera parameters
or by using RJ45 network socket and PoE (802.3at Type 1 ) power supply unit.
Information:
Power supply adapter is not included. Please use power adapter with parameters specified in user’s
manual.
Caution:
In order to provide protection against voltage surges/lightning strikes, usage of appropriate
surge protectors is advised. Any damages resulting from surges are not eligible for service
repairs.
 5.2. Camera control - RS-485
Function unavailable.
5.3. Connecting alarm inputs/outputs.
Alarm input
 Alarm input connection
ELECTRIC CONNECTORS AND ACCESORIES
Alarm
input (-)
Alarm GND
IP Camera
Alarm
input (+)
Alarm IN
Switch/sensor

NVIP-3DN3552H/IR-1P - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A
17
ELECTRIC CONNECTORS AND ACCESORIES
Alarm output
Camera alarm output is an relay output type.
 Alarm output electric connections
5.4 SD card installation
Camera supports SD/SDHC cards up to a maximum size of 64GB. In order to install the card properly,
please follow the instructions below:
 Turn the camera off
 Unscrew the service compartment screw and open the service compartment
 Mount SD card, according to the picture:
 Close service compartment and firmly screw the service compartment screw
 Turn the camera on
 Check the SD card by checking its capacity in the “System Config” -> “SD Card” tab.
Alarm
Output (-)
Alarm COM
Alarm
Output (+)
Alarm NO
Indicator
power
supply
Indicator
IP Camera
Service compartment
SD card slot

NVIP-3DN3552H/IR-1P - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A.
18
REMOTE PREVIEW
6. RESTORING FACTORY DEFAULTS
NOVUS IP cameras allow to restore defaults via:
 software (web browser level)
 hardware (using reset button)
6.1. Restoring factory defaults by software means
User can restore default settings of the IP camera except network settings. To restore to default settings
go to: “Advanced Config -> Config Backup & Restore” tab. Process of restoring takes about two
minutes.
6.2. Restoring factory defaults by hardware means
In order to restore factory defaults for the camera please follow the instructions:
 Unscrew the service compartment screw and open the service compartment
 Press the RESET button and hold on for 10 seconds
 Release button
 Close service compartment and firmly screw the service compartment screw
 Log on after approx. 30 seconds using default IP address (http://192.168.1.200) and default user
name (root) and password (pass)
Service compartment
RESET button

NVIP-3DN3552H/IR-1P - User’s manual (short form) ver 1.0.
All rights reserved © AAT Holding S.A
19
NOTES

2014-11-05 TŁ
AAT Holding sp. z o.o., ul. Puławska 431, 02-801 Warszawa, Polska
tel.: [phone], faks: 22 546 07 59
www.novuscctv.com
