Novus NVC-DN6227SD-II User manual

U s e r ’s m a n u a l
NVC-DN6227SD-II
NVC-DN6237SD-II

NVC-DN6227SD-II and NVC-DN6237SD-II User’s manual, ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
2
INFORMATION
EMC (2004/108/EC) and LVD (2006/95/EC ) Directives
CE Marking
Our products are manufactured to comply with requirements of following directives
and national regulations implementing the directives:
Electromagnetic compatibility EMC 2004/108/EC.
Low voltage LVD 2006/95/EC with further amendment. The Directive applies to electrical
equipment designed for use with a voltage rating of between 50VAC and 1000VAC as
well as 75VDC and 1500VDC.
WEEE Directive 2002/96/EC
Information for users who want to get rid of electrical and electronic appliances
This product is marked according to the European Directive on Waste Electrical and
Electronic Equipment (2002/96/EC) and further amendments. By ensuring this product is
disposed of correctly, you will help to prevent potential negative consequences for the
environment and human health, which could otherwise be caused by inappropriate waste
handling of this product. The symbol on the product, or the documents accompanying the
product, indicates that this appliance may not be treated as household waste. It shall be handed
over to the applicable collection point for the waste electrical and electronic equipment for
recycling purpose. For more information about recycling of this product, please contact your
local authorities, your household waste disposal service or the shop where you purchased the
product.
RoHS Directive 2002/95/EC
Information concerning limitation of the use of dangerous substances in the
electrical and electronic appliances.
Out of concern for human health protection and friendly environment, we assure that our
products falling under RoHS Directive regulations, regarding the restriction of the use of
hazardous substances in electrical and electronic equipment, have been designed and
manufactured in compliance with the above mentioned regulation. Simultaneously, we
claim that our products have been tested and do not contain hazardous substances whose
exceeding limits could have negative impact on human health or natural environment.
Information
The device, as a part of professional CCTV system used for surveillance and control, is not designed
for self installation in households by individuals without technical knowledge.
The manufacturer is not responsible for defects and damages resulted from improper or inconsistent
with user’s manual installation of the device in the system.

NVC-DN6227SD-II and NVC-DN6237SD-II User’s manual, ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
3
OSTRZEŻENIA
IMPORTANT SAFEGUARDS AND WARNINGS
ATTENTION!
PRIOR TO UNDERTAKING ANY ACTION THAT IS NOT PROVISIONED FOR THE
GIVEN PRODUCT IN ITS USER’S MANUAL AND OTHER DOCUMENTS DELIVERED
WITH THE PRODUCT, OR THAT ARISES FROM THE NORMAL APPLICATION OF THE
PRODUCT, ITS MANUFACTURER MUST BE CONTACTED OR THE RESPONSIBILITY
OF THE MANUFACTURER FOR THE RESULTS OF SUCH AN ACTION SHELL BE
EXCLUDED.
IMPORTANT SAFEGUARDS AND WARNINGS
1. Prior to undertaking any action with the device, please consult following manual, and read all the
safety and operating instructions before operating the device.
2. Please keep the following manual for the time of device’s lifespan in case when referring to the
contents of the manual would become necessary.
3. Follow all the safety precautions described in this manual. Improper installation and camera
operation may have impact on operator safety as well as camera operational reliability and lifespan.
4. Camera mounting and operations should be conducted according to this manual, both for users and
service personnel.
5. Please unplug the unit from the power before starting maintenance procedures.
6. Please use only attachments / accessories specified by the manufacturer.
7. Do not install the camera near any steam sources or near water (any wet area like pools, bath tubs
etc.).
8. Mounting the device in places where proper ventilation cannot be provided (e. g. closed lockers etc.)
is not recommended since it may lead to heat build-up and damaging the device itself in
consequence.
9. Mounting the camera on unstable surface or using not recommended mounts is forbidden.
Improperly mounted camera may be the cause of fatal accident or be seriously damaged itself.
Camera must be mounted by qualified personnel with proper authorization, in accordance to user’s
manual.
10.Device should be supplied only from power sources which parameters are in accordance to one’s
pointed out by the producer in camera technical datasheet. Therefore it is forbidden to supply the
camera from power sources with their parameters unknown, unstable or not meeting the producer’s
requirements.
11.Signal cables (conducting TV or/and telemetric signal) should be placed in a way excluding the
possibility of damaging them by accident. Special attention must be paid to cables going out of the
camera and connecting power supply;

NVC-DN6227SD-II and NVC-DN6237SD-II User’s manual, ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
4
OSTRZEŻENIA
IMPORTANT SAFEGUARDS AND WARNINGS
12.To avoid equipment damage, whole TV circuit should be equipped with properly made
(in accordance with Polish Regulations) discharge-, overload- and lightning protection devices.
Usage of separating transformers is advised.
13.Electric installation supplying the device should be designed to meet the specifications given by the
producer in such a way, that overloading it is impossible.
14. Camera should be protected from water and objects that may get inside it.
15. User cannot repair or upgrade equipment himself. All maintenance actions and repairs should
be done only by the qualified service personnel.
16. Unplug the camera from the power source immediately and contact the proper maintenance
department when the following occurs:
Damages to the power cord or to the plug itself;
Liquids getting inside the device or exposure to strong mechanical shock;
Device behaves in a way not described in the manual and all adjustments approved by the
manufacturer, and possible to apply by user himself, seem not to have any effect;
Camera is damaged;
Atypical behaviour of the camera components may be seen (heard).
17. In case of repairs please pay attention to using only original replacement parts (with their
parameters in accordance to those specified by the producer) should be paid. Non-licensed service
and non-genuine replacement parts may cause fire or electrocution;
18. After maintenance procedures please conduct device tests and make sure that all the camera
components are operating correctly.
19. Device should be supplied only from a power sources whose parameters are in accordance with
those specified by the producer in the camera technical datasheet. Therefore, it is forbidden to
supply the camera from a power sources with unknown parameters, unstable or not meeting
producer’s requirements;
INFORMATION
Due to the product being constantly enhanced and optimized, certain parameters and functions
described in the manual in question may change without further notice. We strongly suggest visiting
the www.novuscctv.com website in order to access the newest manual
Data included in the following user’s manual is up to date at the time of printing. AAT Holding
Sp z o.o. holds exclusive rights to modify this manual. The producer reserves the rights for device
specification modification and change in the design without prior notice.

NVC-DN6227SD-II and NVC-DN6237SD-II User’s manual, ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
5
TABLE OF CONTENT.......................................................................................................5
1. FOREWORD INFORMATION................................................................................... ..6
1.1. General characteristic .......................................................................................... 6
1.2. NVC-DN62x7SD-II tech specification ........................................................... ...7
1.3. Camera dimensions .......................................................................................... ...9
1.4. Package contents ...............................................................................................10
2. START-UP AND INITIAL NVC-DN62X7SD CONFIGURATION ........................11
2.1. Description of crucial electrical connectors ...................................................... 11
2.2. Connecting MAIN cable.................................................................................... 11
2.3. Camera DIP switch settings............................................................................... 13
2.4. Description of alarm connector inputs/outputs ................................................15
3. MOUNTING THE CAMERA ..................................................................................... 16
4. CONTROLLING THE CAMERA...............................................................................18
4.1. Controlling the camera via N-Control ............................................................... 18
4.2. Controlling the camera via PELCO-D / PELCO-P protocols ............................ 21
5. CAMERA OSD MENU ................................................................................................. 23
5.1. System information. ........................................................................................... 24
5.2. Display setup...................................................................................................... 24
5.3 Clock ...................................................................................................................25
5.4. Dome camera setup ............................................................................................ 26
5.4.1. Camera setup.............................................................................................. 26
5.4.2. Motion setup ..............................................................................................29
5.4.3. Preset setup ................................................................................................30
5.4.4. Scan setup ..................................................................................................30
5.4.5. Pattern setup............................................................................................... 31
5.4.6. Tour setup ..................................................................................................32
` 5.4.7. Schedule.....................................................................................................33
5.5. Password setup ...................................................................................................34
5.6. System initialize .................................................................................................34
TABLE OF CONTENT

NVC-DN6227SD-II and NVC-DN6237SD-II User’s manual, ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
6
1. FOREWORD INFORMATION
1.1. General characteristic
Day/Night PTZ cameras
Mechanical IR cut filter
IR operation capability
Horizontal resolution: up to 680 TVL
Min. illumination: from 0.02 lx/F=1.6
Motor-zoom lens, AI and AF function
Digital Slow Shutter (DSS)
DIS - digital image stabilization
8 tours (40 actions per tour)
10 auto-scans
8 patterns
255 presets
Independent exposure settings for each preset
8 privacy zones
27x (NVC-DN6227SD-II ) or 37x (NVC-DN6237SD-II ) optical zoom
3 alarm inputs and 1 relay output (NO/NC)
Home function
Schedule function
Auto-flip - automatic 180° camera rotation after reaching tilt limit.
Global function
Password protected menu
OSD camera menu, controllable via:
- NV-KBD70, NV-KBD50 keyboards,
- directly via front panels of certain NOVUS® DVRs
Features pan, tilt and zoom control via NV-KBD70, NV-KBD50 keyboards and directly via
front panels of certain NOVUS® DVRs
RS-485 control
N-Control, Pelco-P, Pelco-D remote control protocols
IP 67
FOREWORD INFORMATION

NVC-DN6227SD-II and NVC-DN6237SD-II User’s manual, ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
7
Installation options:
- wall mount via bracket (included)
- ceiling mount via additional adapter NVB-SD6CB-II
- corner mount via additional adapter NVB-SD6CA
- pole mount via additional adapter NVB-SD6PA
Bubble and wall bracket included
12 VDC / 24 VAC power supply
1.2. NVC-DN62X7SD-II tech specification
FOREWORD INFORMATION
Model NVC-DN6237SD -II NVC-DN6227SD -II
Pick-up Element 1/4” Sony Super HAD CCD
Horizontal Resolution 560 TLV - color mode, 680 TLV - B/W mode
Sensitivity 0.2 lx/F=1.6 - Color,
0.02 lx/F=1.6 - B/W
S/N ratio > 52 dB (AGC off)
Electronic shutter Automatic: 1/50 s ~ 1/120 000 s, Manual
Digital Slow Shutter (DSS) Up to x512
Auto Gain Control (AGC) Low, Medium, High, Manual, Off
White balance Auto / Manual (RGB adjustment)
Back Light Compensation (BLC) Low, High, Off
High Light Compensation (HLC) Low, High
Digital Noise reduction (DNR) Low, Medium, High, Off
Synchronization Internal
Day/night switching Automatic / Manual
Lens type Motor-Zoom AF/ AI lens,
f=3.5 ~ 129.5mm (F1.6 ~ F3.9),
Motor-zoom AF/ AI lens,
f=3.5 ~ 95 mm (F1.6 ~ 2.8)
Angle of view (H) 55.5° ~ 1.59° 55.5° ~ 2.24°
Zoom 37 x Optical, 16x Digital 27 x Optical, 16x Digital
Video output BNC, 1.0 Vp-p, 75 Ohm
Alarm input 3 (NO/NC) galvanically separated
Alarm output 1 relay, DC24V 1A / AC125V 0,5AC

NVC-DN6227SD-II and NVC-DN6237SD-II User’s manual, ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
8
Model NVC-DN6237SD-II / NVC-DN6227SD-II
Remote control RS-485
Protocol N-Control, Pelco-P, Pelco-D
Camera OSD On Screen Display (OSD)
User Authorization Password protected camera menu access
Presets 255
Tours 8 (40 actions per tour)
Auto-scans 10
Patterns 8 (760 commands, approx. 5 min. per pattern)
Privacy zones 8
Tilt 0° ~ 90°
Pan 360° (continuous rotation)
Tilt/pan speed Up to 500°/sek
Additional functions
Auto-flip - automatic 180° rotation,
Home function,
DIS - Digital Image Stabilization,
Image flip,
Preset freeze,
Global preset function
Multi-lingual OSD
Enclosure Aluminium, Polycarbonate, ABS
Degree of protection IP 67
Fan/heater Yes/Yes
Power supply 12 VDC, 24 VAC
Power consumption 18 W (12 VDC heater on)
38 W (24 VAC heater on)
Operating temperature -30°C ~ 50°C
Dimensions (mm) Camera ∅200mm 208 (H)
Camera with wall bracket 300 (W) ×310 (H) mm
Weight 4.3 Kg camera with wall bracket
FOREWORD INFORMATION

NVC-DN6227SD-II and NVC-DN6237SD-II User’s manual, ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
9
1.3. Camera dimensions
FOREWORD INFORMATION

NVC-DN6227SD-II and NVC-DN6237SD-II User’s manual, ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
10
1.4. Package contents
Please make sure that the package contains the following items:
If the equipment has been damaged during transport or is incomplete, the contents of package should
be packed back to the original box. Contact the local NOVUS distributor for further assistance.
CAUTION!
If the device was brought from a location with lower temperature, please wait until it reaches
the temperature of location it is currently in. Turning the device on immediately after bringing
it from a location with lower ambient temperature is forbidden, as the condensing water vapour
may cause short-circuits and damage the device as a result.
Before starting the device please familiarize yourself with the description and the role
of particular inputs, outputs and adjusting elements that the device is equipped with.
Speed dome camera: 1 pc.
Dome with O-ring: 1 pc.
Wall bracket: 1 pc.
Mounting screws: 4 pcs
Allen key: 1 pc.
Wall bracket rubber
seal
Main
connector
User’s manual
FOREWORD INFORMATION
Alarm
connector

NVC-DN6227SD-II and NVC-DN6237SD-II User’s manual, ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
11
2. START-UP AND INITIAL NVC-DN62x7SD-II CONFIGURATION
2.1. Description of crucial electrical connectors
NVC-DN62x7SD-II Camera
2.2. Connecting MAIN cable
Power supply should be connected to MAIN cable, as depicted below :
Cable allows to create basic electrical connections for power supply and remote controlling of the
camera.
ATTENTION!
The camera is 12 VDC/24VAC supplied. Minimal required power output for the power supply
unit should be at least 38W. In case of using 12 VDC power supply please pay attention to wire
polarisation!
As while it is not important when using AC power supply, it is recommended to connect the same
phase to respective power supply terminals in devices.
START-UP AND INITIAL CAMERA CONFIGURATION
1. I/O - Alarm input/output terminal block
2. MAIN - Main connector ( 12 VDC/24VAC power supply, RS485, BNC monitor output)
POWER + (+12VDC/24VAC, orange wire)
POWER - (-12VDC/24VAC, white wire)

NVC-DN6227SD-II and NVC-DN6237SD-II User’s manual, ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
12
Table below describes wiring for the MAIN cable:
For camera and controller communication, RS-485 (selected by micro switches
setting) link is used. CAT5 unshielded twisted pair cable is recommended for telemetry data
transmission. Only one wire pair of CAT5 0.35 mm² cable is used for controlling the camera and
maximum allowed distance for RS-485 communication between camera and keyboard
is 1.200 m.
For RS-485 connections, RS485+ and RS485–wires should be used. They should be connected
to respective TX+ and TX–connectors of the controller, e.g. NV-KBD70 keyboard. Next camera in the
cascade is connected also using same RS485+ and RS485–connectors.
When conecting telemetry cables into a star a serial data distributor should be used, e.g. NOVUS
NVRS-016DD.
START-UP AND INITIAL CAMERA CONFIGURATION
MAIN RJ45
connector pin Wire color Description
1,2 BNC connector Video out -(BNC, 1.0 Vp-p, 75 Ohm)
3 Yellow RS485 -
5 Red RS485 +
7 Orange POWER + (12VDC, 24VAC)
8 White POWER - (12VDC, 24VAC)
RS485
CONTROLLER

NVC-DN6227SD-II and NVC-DN6237SD-II User’s manual, ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
13
2.3. Camera DIP switch settings
Camera features DIP-switch blocks for configuring addresses and transmission parameters for RS-485
protocol. Switch positioning is presented on the picture below:
Camera address Protocol and termination settings
Addressing the camera
In order to avoid control conflicts, each camera should be assigned with unique address in the system.
Switches numbered 1 to 8 are responsible for assigning an address.
When building a system containing a single DVR, assign addresses in accordance with their respective
video inputs numbering.
Number visible on the DIP switch and their values are described in table below. Sum of the values
determines the physical ID address of the camera.
ATTENTION!
Each camera has its address set to 1 by default!
START-UP AND INITIAL CAMERA CONFIGURATION
Switch no: 1 2 3 4 5 6 7 8
Value: 1 2 4 8 16 32 64 128
1 ON OFF OFF OFF OFF OFF OFF OFF
2 OFF ON OFF OFF OFF OFF OFF OFF
3 ON ON OFF OFF OFF OFF OFF OFF
5 ON OFF ON OFF OFF OFF OFF OFF
11 ON ON OFF ON OFF OFF OFF OFF

NVC-DN6227SD-II and NVC-DN6237SD-II User’s manual, ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
14
Selecting protocol parameters
Switches from 1 to 3 select protocol and transmission speed. Please pay attention to setting identical
transmission parameters for controllers (keyboard, DVR, PC). Table below depicts available switch
configurations:
ATTENTION!
Camera has Pelco-D with 2400 bps speed set by default!
Bus termination settings
The device which is connected at the end of the line, whether a camera or a keyboard
controller, must have its DIP switch set as explained below. Without proper termination, control signal
errors may occur. Total length of the cable for communication should not exceed 1.200 m. (CAT5
twisted pair cable).
START-UP AND INITIAL CAMERA CONFIGURATION
Switch no
Protocol and transmission
speed 1 2 3
PELCO-D, 2400 bps OFF OFF OFF
PELCO-D, 9600 bps ON OFF OFF
PELCO-P, 4800 bps OFF ON OFF
PELCO-P, 9600 bps ON ON OFF
N-CONTROL, 9600 bps OFF OFF ON
Termination Switch no. 4
DISABLED OFF
ENABLED ON

NVC-DN6227SD-II and NVC-DN6237SD-II User’s manual, ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
15
2.4. Description of alarm connector inputs/outputs
Table below contains description of alarm inputs/outputs
Typical alarm input connection
ATTENTION!
Please pay special attention for maintaining polarity and voltage. IN COMM + is a common
connector for all inputs and should be therefore connected to the + of power supply. Improper
connection may result in camera damage.
Typical relay output connection.
START-UP AND INITIAL CAMERA CONFIGURATION
I/O RJ45 pin Wire color Description
1 Blue IN COM + common alarm input (+)
2 Yellow IN 1 - alarm input 1
3 Green IN 2 - alarm input 2
4 Red IN 3 - alarm input 3
5 Black RELAY - relay output
6 White RELAY - relay output
RELAY
common
RELAY
output
indicator
Indicator’s
power supply
Switch or
detector
IN -
alarm input
Alarm input
(IN COMM +)
5-12V DC
power supply
CAMERA
CAMERA

NVC-DN6227SD-II and NVC-DN6237SD-II User’s manual, ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
16
3. MOUNTING THE CAMERA
In order to obtain declared watertightness camera should be mounted on flat, smooth surfaces.
When mounting the camera on uneven/rough surfaces please seal the mounting place additionally
with appropriate sealing mass, paying special attention to mounting holes.
Caution!
Due to safety reasons, maximum load capacity of surface shouldn’t be less than 25kg.
In order to successfully mount a camera, please follow the procedure below:
Put the bracket to the wall in a desired mounting place (with cable hole). Taking the bracket’s
base screw holes as a pattern, mark future drilling holes for screws using a punch.
Drill 4 holes in accordance with previously done markings and base hole placement (when
mounting the camera to concrete surfaces please purchase appropriate mounting accessories)
Put required cables through the seal and bracket’s arm.
Mount the bracket with seal, paying special attention to all mounting holes and additionally
sealing them with appropriate sealing mass if necessary.
Using safety cable, attach the dome to the bracket.
MOUNTING THE CAMERA

NVC-DN6227SD-II and NVC-DN6237SD-II User’s manual, ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
17
Connect required signal and power supply cables.
Put the excess cable back into the bracket.
Put the dome onto the bracket so the vertical markings on the dome and bracket’s surface are
aligned and turn right until resistance is felt.
Screw the camera to the bracket using three Torx screws (key included). Please make sure that
the casing fits the bracket after screwing, otherwise the rubber gasket won’t fill its purpose
and water may get inside the camera.
Remove the lens plug from the camera module.
Attach camera bubble to the casing paying special attention to rubber gasket. Please make
sure that the gasket fits the gap between bubble and casing, otherwise water may get inside
the camera.
CAUTION!
The supply voltage should be turned on when camera unit is completely installed. Otherwise,
enter camera’s menu and reboot it after finishing installation.
MOUNTING THE CAMERA

NVC-DN6227SD-II and NVC-DN6237SD-II User’s manual, ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
18
4. CONTROLLING THE CAMERA
N-Control is the recommended control protocol for the Novus NVC-DN62x7SD-II series cameras and
allows to fully exploit their abilities. Cameras may be also PELCO-D/PELCO-P controlled, however
methods of programming and control differ.
To establish proper connection between camera and keyboard following conditions must be met:
an unique camera address for the whole system
the same baud rate (speed setting) in the camera and in the keyboard (2400/4800/9600)
Details regarding camera control settings are described in proper manual of the keyboard.
4.1. Controlling the camera via the N-Control
In order to start camera control please enter its number via numpad and confirm with (for NV-
KBD50 keyboard) or (for NV-KBD70) key.
When controlling the camera via NV-KBD70 keyboard, function and numerical keys as well
as joystick are used.
Controlling camera via the NV-KBD50 utilizes function, numpad buttons as well as joystick.
To open camera menu please press and hold for 3 sec. button (for NV-KBD50) or press button
(for NV-KBD70).
Navigation through camera’s OSD menu:
CONTROLLING THE CAMERA
Action Function
Joystick up or down
Navigation through menu
Changing parameter values
Editing field value
Joystick left or right Navigation through text fields
Navigation through settings fields
IRIS CLOSE
FOCUS NEAR
Execution of a command
Value edition
IRIS OPEN
FOCUS FAR
Cancelling a command
Return to a higher-level menu
CAM

NVC-DN6227SD-II and NVC-DN6237SD-II User’s manual, ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
19
CONTROLLING THE CAMERA
Functions of particular buttons for NV-KBD50 and NVKBD70 are presented below:
In order to call a surveillance function, please select its number from the numpad and confirm it by
pressing appropriate function button (e.g. [TOUR])
Manual
description NV-KDB70 NV-KBD50 Function
IRIS OPEN
iris control - opening, password entering,
start of programming
IRIS CLOSE iris control - closing, end of programming
FOCUS FAR
focus control - far
FOCUS NEAR focus control - near
PRESET MOVE preset calling
GLOBAL
PRESET MOVE preset calling for all connected cameras
PRESET SET (3s) preset saving
SCAN auto-scan
SCAN SET (3s) auto-scan programming
TOUR tour function
TOUR SET (3s) tour programming
PATTERN pattern function
PATTERN SET (3s) pattern programming
MENU (3s) opens OSD menu, confirms selection
ESC exits menu
ON enables additional functions
OFF disables additional functions
HOME returns camera to home position
ENTER

NVC-DN6227SD-II and NVC-DN6237SD-II User’s manual, ver. 1.0
All rights reserved © AAT Holding sp. z o.o.
20
CONTROLLING THE CAMERA
Additional functions are enabled/disabled via ON / OFF buttons
Additional functions are presented in the table below:
Function number Function
1 Enables/disables relay 1
7 Selects Auto / Manual focus mode
8 Selects Auto / Manual AE mode
9 Changes night shot to auto
10 Turns on / turn off infrared filter
11 Turns on / turn off back light compensation
12 Turns digital zoom on / off
13 Turn camera status information on / off
104 Turn wide dynamic range on / off
105 Turn picture stabilization on / off
NV-KBD70
Keyboard
NV-KBD40
Keyboard Function
Turning on additional functions. List of additional functions
is described below. To turn on a demanded function, select
its number using numerical keys and press or
Turning off additional functions. List of additional functions
is described below. To turn off an additional function, select
its number using numerical keys and press or
