NPD Albie KD Diamond Stitching PU Bar User manual

ASSEMBLY INSTRUCTIONS
3900054-55
Albie KD Diamond Stitching PU Bar/
Counter Stool
Flip the seat
②upside down so that the bottom faces you. Remove the bottom
fabric attached by velcro to get ready for assembly。
Flip front legs ③and insert it into the seat ②. Fit a spring washer B to a bolt A
followed by a flat washer C. Insert the bolt into a hole and tighten it with your
hand until it is finger-tight. This will allow an opportunity to level the chair and
prevent any unnecessary “rocking”. Repeat this for the other hole and then

Align the left and right rails 4 with the slots of front legs. Please identify each end
of the foot rest carefully before aligning. Please pay attention on the sticker label
on the foot rest to make sure foot rest in right position and they are attached in
compliance with points below :1. The Straight Head of each foot rest goes into
the slot of the front leg (as shown in Bird’s Eye View). 2. The Angled Head of each
foot rest shall incline outward (as shown in Bird’s Eye View). 3. The screw holes
on the foot rest face you (in the direction that would be toward the ground when
standing upright). Please pay attention on the sticker label on the foot rest to
Place the backrest
①
on a level surface. Align the structure formed in Step 5
with the backrest. Fit the angled heads into the slots of the rear legs,Fit a
spring washer C to a bolt B followed by a flat washer D. Insert the bolt into a
hole on the seat frame and tighten it with your hand until it is finger-tight.

Insert a screw D into a hole on the
rail. Secure the screw in place
using a screwdriver but do not
tighten it yet. This will allow an
opportunity to level the stool and
prevent any unnecessary “rocking”
.
Repeat this for the remaining
screw holes.
Place the loosely assembled stool in its desired location. Apply gentle
downward pressure on the seat to eliminate rocking and ensure the
stool is level.And then tighten all the screws and bolts
