NRC V1200 User manual
Model(s):V1200
November 13, 2023
Document number:8923304—Revision0
Original Instructions
TOUCHSCREEN INTERFACE
USER GUIDE
NRC-INDUSTRIES.COM
Serial number:
User Guide
INTELLECTUAL PROPERTY NOTICE
Copyright © 2023 NRC Industries Inc. All rights reserved. This manual may not be copied,
photocopied, reproduced, translated or converted to any electronic or machine-readable format
in whole or in part without the prior written approval of NRC Industries Inc. NRC Industries Inc.
reserves the right to modify the information provided herein at any time without notice.
Please send your comments and questions to:
NRC Industries Inc.
2430 Principale St.
Saint-Paul-d'Abbotsford, QC J0E 1A0
CANADA
Tel: (450) 379-5796
Fax: (450) 379-5995
3
Touchscreen Interface – User Guide
Models: V1200
REV. 0
NOVEMBER 13, 2023
User Guide 4
Touchscreen Interface – User Guide
Models: V1200
REV. 0
NOVEMBER 13, 2023
User Guide
REVISION HISTORY
Revision Date Description
0 2023-11-13 Initial release
5
Touchscreen Interface – User Guide
Models: V1200
REV. 0
NOVEMBER 13, 2023
User Guide 6
Touchscreen Interface – User Guide
Models: V1200
REV. 0
NOVEMBER 13, 2023
User Guide
CONTENTS
LIMITED WARRANTY 9
ABOUT THIS MANUAL 11
1 LOGIN SCREEN 13
1.1 New user 14
2 HOME SCREEN AND NAVIGATION 15
2.1 Notifications 17
3 OPERATION SCREEN 19
4 TOW SCREEN (OPTIONAL) 23
5 TRUCK SCREEN 25
6 SETTINGS SCREEN 27
6.1 General settings 27
6.2 Profile settings 37
6.3 Brightness settings 39
6.4 Tow truck information 40
6.5 Notifications and sound settings 43
7 CAMERA SCREEN (OPTIONAL) 45
8 MAINTENANCE SCREEN 47
8.1 To Do list 48
8.2 Upcoming list 51
8.3 Done list 52
8.4 General list 53
9 MANUALS SCREEN 55
7
Touchscreen Interface – User Guide
Models: V1200
REV. 0
NOVEMBER 13, 2023
User Guide 8
Touchscreen Interface – User Guide
Models: V1200
REV. 0
NOVEMBER 13, 2023
User Guide
LIMITED WARRANTY
A. GENERAL PROVISIONS - THE WARRANTY DESCRIBED BELOW IS PROVIDED BY INDUSTRIES NRC INC, 2430 PRINCIPALE EST C.P. 160, ST-PAUL D’ABBOTSFORD,
QUÉBEC, CANADA, J0E 1A0 (“INDUSTRIES NRC”) TO THE ORIGINAL PURCHASER OF NEW TOWING AND RECOVERY EQUIPMENT (“EQUIPMENT”) PURCHASED FROM
INDUSTRIES NRC OR AUTHORIZED INDUSTRIES NRC DEALERS. UNDER THIS WARRANTY, INDUSTRIES NRC WILL REPAIR OR REPLACE, AT ITS OPTION, ANY PART
COVERED UNDER THIS WARRANTY WHICH IS FOUND TO BE DEFECTIVE IN MATERIAL OR WORKMANSHIP DURING THE APPLICABLE WARRANTY TERM. WARRANTY
SERVICE MUST BE PERFORMED BY A DEALER OR SALES SERVICE CENTRE AUTHORIZED BY INDUSTRIES NRC TO SELL AND/OR SERVICE THE EQUIPMENT (THE
“AUTHORIZED DEALER”). THE AUTHORIZED DEALER WILL USE ONLY NEW OR REMANUFACTURED PARTS OR COMPONENTS FURNISHED OR APPROVED BY
INDUSTRIES NRC. WARRANTY SERVICE WILL BE PERFORMED WITHOUT CHARGE TO THE PURCHASER FOR PARTS. HOWEVER, THIS WARRANTY DOES NOT
OBLIGATE INDUSTRIES NRC TO BEAR THE COST OF LABOR OR TRANSPORTATION CHARGES IN CONNECTION WITH THE REPAIR OR REPLACEMENT OF ANY PARTS
FOUND TO BE DEFECTIVE, NOR SHALL IT APPLY TO A PRODUCT UPON WHICH REPAIRS OR ALTERATIONS HAVE BEEN MADE UNLESS AUTHORIZED BY INDUSTRIES
NRC. THE PURCHASER WILL BE RESPONSIBLE FOR SERVICE CALLS AND/OR TRANSPORTATION OF EQUIPMENT TO AND FROM THE AUTHORIZED DEALER’S PLACE
OF BUSINESS (EXCEPT WHERE PROHIBITED BY LAW), FOR ANY PREMIUM CHARGED FOR OVERTIME LABOUR REQUESTED BY THE PURCHASER AND FOR ANY
SERVICE AND/OR MAINTENANCE NOT DIRECTLY RELATED TO ANY DEFECT COVERED UNDER THIS WARRANTY. THIS WARRANTY IS TRANSFERABLE, PROVIDED AN
AUTHORIZED INDUSTRIES NRC DEALER IS NOTIFIED OF THE OWNERSHIP CHANGE, AND INDUSTRIES NRC APPROVES THE TRANSFER.
B. WHAT IS WARRANTED - SUBJECT TO PARAGRAPH C, ALL PARTS, MANUFACTURED BY INDUSTRIES NRC, OF ANY NEW INDUSTRIES NRC EQUIPMENT, ARE
WARRANTED FOR THE NUMBER OF MONTHS SPECIFIED BELOW. WARRANTY STATEMENTS COVERING COMPONENTS NOT MANUFACTURED BY NRC ARE FOUND
WITH THE OPERATOR’S MANUALS DELIVERED WITH THE EQUIPMENT.
C. WHAT IS NOT WARRANTED - PURSUANT TO THE TERMS OF THIS WARRANTY, INDUSTRIES NRC IS NOT RESPONSIBLE FOR THE FOLLOWING: (1) USED
EQUIPMENT (UNLESS IT IS SPECIFICALLY COVERED BY SEPARATE WARRANTY DOCUMENTS); (2) ANY EQUIPMENT THAT HAS BEEN ALTERED OR MODIFIED IN WAYS
NOT APPROVED BY INDUSTRIES NRC, INCLUDING, BUT NOT LIMITED TO, HYDRAULIC PRESSURE SETTINGS ABOVE INDUSTRIES NRC SPECIFICATIONS; (3)
DEPRECIATION OR DAMAGE CAUSED BY NORMAL WEAR, LACK OF REASONABLE AND PROPER MAINTENANCE, FAILURE TO FOLLOW OPERATING INSTRUCTIONS,
MISUSE, LACK OF PROPER PROTECTION DURING STORAGE, VANDALISM, THE ELEMENTS OR COLLISION OR ACCIDENT; (4) THE EQUIPMENT IF USED FOR
OVERHEAD LIFTING, CRANE WORK OR ANY OTHER UNAPPROVED ACTIVITY; (5) NORMAL MAINTENANCE PARTS AND/OR SERVICE.
D. SECURING WARRANTY SERVICE - TO SECURE WARRANTY SERVICE THE PURCHASER MUST, (1) REPORT THE EQUIPMENT DEFECT TO AN AUTHORIZED DEALER
AND REQUEST WARRANTY SERVICE WITHIN THE APPLICABLE WARRANTY TERM; (2) PRESENT EVIDENCE OF THE WARRANTY START DATE TOGETHER WITH THE
VALID PROOF OF PURCHASE; AND, (3) MAKE THE EQUIPMENT AVAILABLE TO AN AUTHORIZED DEALER OR SERVICE CENTRE WITHIN A REASONABLE PERIOD OF
TIME.
E. NO IMPLIED WARRANTY, REPRESENTATION OR CONDITION - TO THE EXTENT PERMITTED BY LAW, NEITHER INDUSTRIES NRC NOR ANY COMPANY AFFILIATED
WITH IT MAKES ANY WARRANTY, REPRESENTATION, CONDITION OR PROMISE, EXPRESS OR IMPLIED, VERBAL OR OTHERWISE, AS TO THE QUALITY,
PERFORMANCE OR FREEDOM FROM DEFECT OF THE EQUIPMENT. NO IMPLIED OR STATUTORY CONDITIONS OR WARRANTIES OF MERCHANTABILITY OR FITNESS
(WHETHER PURSUANT TO THE SALE OF GOODS ACT OR ANY OTHER STATUTE OF ANY PROVINCE/STATE OR OTHERWISE) ARE MADE.
9
Touchscreen Interface – User Guide
Models: V1200
REV. 0
NOVEMBER 13, 2023
User Guide 10
Touchscreen Interface – User Guide
Models: V1200
REV. 0
NOVEMBER 13, 2023
F. EXCLUSIVE REMEDY - TO THE EXTENT PERMITTED BY LAW, THE PURCHASER’S EXCLUSIVE REMEDY IN CONNECTION WITH THE BREACH OR PERFORMANCE OF
ANY WARRANTY ON THE EQUIPMENT ARE THOSE SET FORTH IN THIS WARRANTY. IN NO EVENT WILL AN AUTHORIZED DEALER, INDUSTRIES NRC OR ANY
COMPANY AFFILIATED WITH INDUSTRIES NRC, BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES OR INJURIES, INCLUDING BUT NOT LIMITED TO,
LOSS OF PROFITS, RENTAL OF SUBSTITUTE EQUIPMENT, OTHER COMMERCIAL OR PERSONAL LOSS OR DAMAGES ARISING AS A RESULT OF A FUNDAMENTAL
BREACH OR BREACH OF A FUNDAMENTAL TERM.
G. NO DEALER WARRANTY - EXCEPT FOR CONDITIONS OR WARRANTIES WHICH MAY NOT BE EXCLUDED BY LAW, THE SELLING DEALER MAKES NO WARRANTY OF
ITS OWN ON ANY ITEM WARRANTED BY INDUSTRIES NRC, AND MAKES NO WARRANTY ON OTHER ITEMS UNLESS IT DELIVERS TO THE PURCHASER A SEPARATE
WRITTEN WARRANTY DOCUMENT SPECIFICALLY WARRANTING THE ITEM. THE SELLING DEALER HAS NO AUTHORITY TO MAKE ANY REPRESENTATION OR
PROMISE ON BEHALF OF INDUSTRIES NRC OR TO MODIFY THE TERMS OR LIMITATIONS OF THIS WARRANTY IN ANY WAY.
H. WARRANTY TERMS
EQUIPMENT TERMS
TRUCK MOUNTED RECOVERY EQUIPMENT 12 MONTHS FROM “IN SERVICE” DATE. NO MORE THAN 24 MONTHS.
SLIDING SYSTEM COMPONENTS 10 YEARS FROM DATE OF MANUFACTURING.
TOWING ACCESSORIES MANUFACTURED BY INDUSTRIES NRC 12 MONTHS FROM DATE OF MANUFACTURING.
ACCESSORIES MANUFACTURED BY A THIRD PARTY THIRD PARTY WARRANTY APPLIES.
User Guide
ABOUT THIS MANUAL
This manual will teach you how to use the touchscreen interface.
It contains the following sections, which you should read and follow in the order they are
presented:
lChapter 1 Login screen
lChapter 2 Home screen and navigation
lChapter 3 Operation screen
lChapter 4 Tow screen (optional)
lChapter 5 Truck screen
lChapter 6 Settings screen
lChapter 7 Camera screen (optional)
lChapter 8 Maintenance screen
lChapter 9 Manuals screen
Document conventions
The following conventions are used throughout this document:
NOTE: We highly recommend that you read this manual in full before using your NRC
equipment.
Disclaimer
This manual, including the equipment specifications, is subject to change without notice. Ensure
that you have the latest version of this manual before using your equipment.
11
Touchscreen Interface – User Guide
Models: V1200
REV. 0
NOVEMBER 13, 2023
User Guide 12
Touchscreen Interface – User Guide
Models: V1200
REV. 0
NOVEMBER 13, 2023
Applicable models and serial numbers
This manual is intended for use with the following models with serial numbers within the
following ranges only:
lCSR85-022 and CSR85-024+
User Guide
1LOGIN SCREEN
To access the V1200 touchscreen interface, log in to your profile.
To log in, select your profile from the list of users. If requested, enter your PIN.
FIGURE 1 — LOGIN SCREEN
13
Touchscreen Interface – User Guide
Models: V1200
REV. 0
NOVEMBER 13, 2023
User Guide 14
Touchscreen Interface – User Guide
Models: V1200
REV. 0
NOVEMBER 13, 2023
1.1 New user
To create a new user:
1. Tap in the upper right corner.
2. Complete the fields as follows:
a. Name: Enter your name.
b. Phone number: Enter your phone number.
c. Email: Enter your email address.
d. 4 digits password: This is the same as the PIN. Enter four digits.
3. Tap Save.
User Guide
2HOME SCREEN AND NAVIGATION
The touchscreen interface is used to view information and troubleshoot the wrecker.
The Home screen of the touchscreen interface (Figure 2) allows you to view the tow truck and
related settings. The buttons at the bottom of the screen are used to access different menus and
screens.
NOTE: Only admin users can perform admin management functions. A PIN is required.
FIGURE 2 — HOME SCREEN OF THE V1200
15
Touchscreen Interface – User Guide
Models: V1200
REV. 0
NOVEMBER 13, 2023
User Guide 16
Touchscreen Interface – User Guide
Models: V1200
REV. 0
NOVEMBER 13, 2023
TABLE 1 —HOME SCREEN COMPONENT DESCRIPTIONS
Component Description
1 Displays the following:
l: Tap to show notifications. See Section 2.1.
l: Tap to choose View profile or Log out.
2 Displays the following:
lOperation: See Section 3.
lTow: See Section 4.
3 Displays the following:
lHome: The home screen.
lOperation: See Section 3.
lTow: See Section 4.
lTruck: See Section 5.
lSettings: See Section 6.
lCamera: See Section 7.
lMaintenance: See Section 8.
lManuals: See Section 9.
User Guide
2.1 Notifications
To view notifications, tap in the upper right corner. Examples of notifications include:
lLifting an object that is heavier than the current limit.
lRotating the boom to the front of the truck.
FIGURE 3 — NOTIFICATIONS
In the Notifications window, you can do the following:
lTap a notification to go to the relevant screen.
lSwipe left on a notification to delete it.
17
Touchscreen Interface – User Guide
Models: V1200
REV. 0
NOVEMBER 13, 2023
User Guide 18
Touchscreen Interface – User Guide
Models: V1200
REV. 0
NOVEMBER 13, 2023
Notifications will disappear on their own once the issue has been resolved. To mute notifications,
see Section 2.
TABLE 2 — NOTIFICATION COMPONENT DESCRIPTIONS
Component Description
1 The screen the notification is from.
2 The notification details.
3 Date and time of the notification.
User Guide 20
Touchscreen Interface – User Guide
Models: V1200
REV. 0
NOVEMBER 13, 2023
TABLE 3 — HYDRAULIC SYSTEM DESCRIPTIONS (TOP BAR)
Element Description
Oil Flow Rate of the oil flow in the system.
Pump Actu. Percentage of hydraulic pump activation.
Swing Press. Rotation pressure.
Engine RPM Engine rotation per minute of the tow truck.
Oil Temp. Oil temperature.
Pressure Upper value:Pump pressure.
Lower value: X port pump pressure.
TABLE 4 — LOAD CHART DESCRIPTIONS
The values displayed on the screen are valid when all outriggers are fully extended on solid
ground.
Item Description
Rear lift Lift capacity when lifting the load from the rear.
Side lift Lift capacity when lifting the load from the side.
