NT-ware uniFLOW Release Station Instruction sheet

uniFLOW Release Station
Installation & Configuration Manual

Versioning
Document
Versioning
Version
Date
Author(s)
Reviewer(s)
1.0
03-Sep-2014
Sebastian
Husnik
Oliver Shikaloski, Holger Bauszus, Thomas Lemmer
1.1
05-Sep-2014
Sebastian
Husnik
Thomas Lemmer
1.2
08-Sep-2014
Sebastian
Husnik
Thomas Lemmer
1.3
17-Sep-2014
Sebastian
Husnik
Thomas Lemmer

1.4
06-Oct-2014
Sebastian
Husnik
Thomas Lemmer
1.5
08-Oct-2014
Sebastian
Husnik
Thomas Lemmer
1.6
20-Jan-2015
Sebastian
Husnik
Thomas Lemmer
1.7
29-Apr-2015
Sebastian
Husnik
Thomas Lemmer
1.8
08-Jun-2015
Sebastian
Husnik
Thomas Lemmer
1.9
15-Oct-2015
Sebastian
Husnik
Thomas Lemmer
1.10
22-Mar-2016
Sebastian
Husnik
Thomas Lemmer
1.11
26-Apr-2016
Sebastian
Husnik
Thomas Lemmer
1.12
03-Aug-2016
Sebastian
Husnik
Thomas Lemmer, Holger Bauszus
1.13
03-Nov-2016
Sebastian
Husnik
Thomas Lemmer
2.0
10-Feb-2017
Sebastian
Husnik
Thomas Lemmer
2.1
16-Aug-2017
Sebastian
Husnik
Thomas Lemmer
2.2
16-Aug-2017
Thomas
Lemmer
Thomas Lemmer
2.3
08-Dec-2017
Thomas
Lemmer
Thomas Lemmer
Document Name
uniFLOW Release Station - Installation & Configuration
Knowledgebase
MOMKB-770 (https://web.nt-ware.net/its/browse/MOMKB-770)
File Name
uniFLOW Release Station - Installation & Configuration - V2.2.pdf
Technologies
Concerned
uniFLOW Release Station HID
uniFLOW Release Station Hitag
uniFLOW Release Station Multi
uniFLOW Release Station PLUS
uniFLOW Release Station PLUS-2 V2
uniFLOW Release Station Touch
uniFLOW
uniFLOW Online
Short Summary
This document describes the installation and configuration of the uniFLOW Release Station.
Document
Version
Topic(s)
Changes

Changes
1.1
Configuration (on page 6), Network
Configuration (see "Network" on page 19),
Firmware Update (on page 24), Factory
Reset (on page 24), Job Release via
uniFLOW Release Station (see "Job
Release" on page 25)
Added note that IPv6 is not
supported.
Added note about USB drive file
system (FAT, FAT32).
Updated cost center search
description.
1.2
Card Reader (on page 16)
Added PLUS card reader configuration
instructions.
1.3
Mounting Options (on page 35)
Corrected a link.
1.4
Card Reader (on page 16)
Added MiCard PLUS config tool
download instructions.
1.5
FCC and IC Compliance Notes (see
"Compliance and Disposal Notes" on
page 35)
Updated IC Notes.
1.6
Configuration (on page 6)
Added note about network cable
connection.
1.7
Info Screen (on page 27)
Added description of info screen.
1.8
Firmware Update (on page 24)
Added information on where to
download the newest firmware.
1.9
Specific Settings (on page 10)
Added Printed Queue Parameter
(uniFLOW V5.4, firmware 1.0 SR4
only).
1.10
Release Station (see "uniFLOW Release
Station" on page 14)
Added new parameter Server Ping
Interval for Emergency Access
(seconds).
1.11
uniFLOW Release Station Website (on page
12)
Settings (on page 23)
Logout (on page 23)
Factory Reset (on page 24)
Described new login screen.
Described new settings page.
Described new logout page.
Updated Factory Reset infos.
1.12
uniFLOW Release Station Website (on page
12)
Updated URL.
1.13
Specifications (on page 28)
Reformatted chapter, moved to end of
book, added disposal note.
2.0
uniFLOW Online (on page 20), Network (on
page 19), uniFLOW Release Station
Website (on page 12)
Added firmware V1.1 features:
uniFLOW Online connectivity, proxy
configuration, HTTPS support,
changed screenshots.
2.1
uniFLOW Online (on page 20)
Firmware V1.2: Added wizard based
adding to uniFLOW Online.
2.2
Firmware Update (on page 24)
Added a more detailed description.
2.3
Various topics
Added uniFLOW Release Station
MiCard PLUS-2 V2

Disclaimer
NT-ware Systemprogrammierungs-GmbH, all its affiliates, partners and licensors disclaim all warranties,
including, but not limited to, warranties about the accuracy or completeness of statements of this
site's/document's content or the content of any site or external sites for a particular purpose. This
site/document and the materials, information, services, and products at this site/document, including,
without limitation, text, graphics, and links, are provided 'as is' and without warranties of any kind, whether
expressed or implied.
All rights reserved. No parts of this work may be reproduced in any form or by any means - graphic,
electronic, or mechanical, including photocopying, recording, taping, or information storage and retrieval
systems - without the prior written permission of NT-ware Systemprogrammierungs-GmbH (hereinafter
also referred to as NT-ware).
Company and product names mentioned herein are registered or unregistered trademarks of their
respective companies. Mention of third-party products is for information purposes only and constitutes
neither an endorsement nor a recommendation. NT-ware assumes no responsibility with regard to the
performance or use of these products. Also, NT-ware makes no claim to these trademarks. Any use of
trademarks, logo, service marks, trade names, and product names is prohibited without the written
permission of the respective owners.
Adlib, Express and Express Server are either registered trademarks or trademarks of Adlib Publishing
Systems Inc.; Adobe®, Adobe® Reader®, Acrobat®, Distiller®, PostScript® and products of the CREATIVE
SUITE(S) are either registered trademarks or trademarks of Adobe Systems Incorporated in the United
States and/or other countries; Android is a trademark of Google Inc.; Apple®, the Apple® logo, Mac®, Mac
OS®, Macintosh®, iPhone®, iPad® and AirPrint® are trademarks of Apple Inc. registered in the U.S. and other
countries; Box of Box Inc.; Blackboard Transact™ of Blackboard Inc.; CANON, imageRUNNER, imageRUNNER
ADVANCE, MEAP, CPCA, AMS, iW AMS, iW Desktop, iSend, iW SAM are trademarks or registered
trademarks of Canon Inc.; CardSmith® is a trademark of CardSmith LLC; CBORD CS Gold® of the CBORD
Group Inc.; Crystal Reports and other Business Objects products and services mentioned herein as well as
their respective logos are trademarks or registered trademarks of Business Objects Software Ltd. Business
Objects is an SAP company; Dropbox of Dropbox Inc.; eCopy™, eCopy ShareScan® and eCopy ScanStation™
are marks or trademarks of Nuance Communications, Inc.; Evernote® of Evernote Corporation; FileNet® of
IBM Corporation; Foxit®SDK and Foxit® Reader of Foxit Corporation; Google Docs of Google Inc.; Google
Cloud Print™ web printing service is a trademark of Google Inc.; Helix™ Production Workflow is a trademark
of NT-ware Systemprogrammierungs-GmbH; HP, HEWLETT-PACKARD, PCL and LASERJET are registered
trademarks that belong to Hewlett-Packard Development Company; KONICA MINOLTA is a registered
trademark of KONICA MINOLTA Inc.; iOS® of Cisco Technology Inc.; iDRS™ SDK and IRISConnect™ are
unregistered trademarks of I.R.I.S. Group S.A.; JAWS pdf courier™ are trademarks of Global Graphics SA.;
Microsoft®, Windows®, Windows Server®, Internet Explorer®, Internet Information Services, Microsoft®
Word, Microsoft® Excel, Microsoft SharePoint®, Microsoft SharePoint® Online, OneDrive®, One Drive® for
Business, SQL Server®, Active Directory®, Hyper-V® are either registered trademarks or trademarks of
Microsoft Corporation in the United States and/or other countries of Microsoft Corporation; Neevia
Document Converter Pro™ of Neevia Technology; NetWare®, Novell®, Novell eDirectory™ of Novell Inc. are
registered/unregistered trademarks of Novell Inc. in the United States and other countries; MobileIron® of
Mobile Iron Inc., Océ, Océ PlotWave®, Océ ColorWave® and PRISMA are trademarks or registered
trademarks of Océ-Technologies B.V. Océ is a Canon company, OpenOffice.org™ of Oracle Corporation;
PAS™ is a trademark of Equitrac Corp.; PosterJet is copyrighted and an internationally registered trademark
of Eisfeld Datentechnik GmbH & Co. KG; RedTitan EscapeE of RedTitan Limited; NETAPHOR®, SiteAudit™ are

trademarks of NETAPHOR SOFTWARE Inc.; SAMSUNG is a trademark of SAMSUNG in the United States or
other countries; Therefore™, Therefore™ Online of Therefore; UNIX® is a registered trademark of The Open
Group; uniFLOW®, uniFLOW Serverless Secure Printing®, Helix Production Workflow®, MIND®,
microMIND®, MiCard® and uniFLOW Service for AirPrint® are registered trademarks of NT-ware
Systemprogrammierungs-GmbH; pcProx®, AIR ID® are registered trademarks of RFIdeas Inc.Readers;
CASI-RUSCO® is a registered trademark of ID Card Group; Radio Key® is a registered trademark of Secura
Key; GProx™ II is an unregistered trademark of Guardall; HID® ProxHID is a registered trademark of HID
Global Corporation; Indala® is a registered trademark of Motorola; ioProx™ is an unregistered trademark of
Kantech; VMware vSphere® and VMware vSphere® Motion® are registered trademarks of VMware; Xerox,
Xerox and Design, as well as Fuji Xerox and Design are registered trademarks or trademarks of Xerox
Corporation in Japan and/or other countries.
All other trademarks, trade names, product names, service marks are property of their respective owners
and are hereby acknowledged.
While every precaution has been taken in the preparation of this document, NT-ware assumes no
responsibility for errors or omissions, or for damages resulting from the use of information contained in this
document or from the use of programs and source code that may accompany it. NT-ware does not assume
any responsibility or liability for any malfunctions or loss of data caused by the combination of at least one
NT-ware product and the used operation system and/or third-party products. In no event shall NT-ware be
liable for any loss of profit or any other commercial damage caused or alleged to have been caused directly
or indirectly by this document.
In addition, this manual provides links to the sites of affiliated or independent companies and certain other
businesses. NT-ware is not responsible for examining or evaluating, and NT-ware does not warrant the
offerings of, any of these businesses or individuals or the content of their websites. NT-ware does not
assume any responsibility or liability for the actions, product, and content of all these and any other third
parties. You should carefully review their privacy statements and other conditions of use.
Friday, December 08, 2017, Bad Iburg (Germany)
Important Note
Serious problems might occur if you modify the registry of your Windows operating system incorrectly.
These problems might require that you reinstall the operating system. We strongly recommend to always
back up the registry of your Windows operating system before applying changes to it, just in case you do
something wrong. NT-ware does not assume any responsibility or liability for any impact on the
operating system after changing the registry. You understand and accept that you use this information
and modify the registry of your Windows operating system at your own risk.
uniFLOW and corresponding components like Web Submission and Internet Gateway rely heavily on
their SQL databases. We strongly suggest that you refrain from modifying these SQL databases manually
without prior consultation from the NT-ware support team. NT-ware does not assume responsibility or
liability for possible impact on your uniFLOW environment after modifying any of the SQL databases.
Copyright and Contact
NT-ware Systemprogrammierungs-GmbH
Niedersachsenstraße 6
49186 Bad Iburg
Germany

www.nt-ware.com
Tel: +49 - 54 03 - 7243 - 0
Fax: +49 - 54 03 - 78 01 03
Email: [email protected]om
Register of Companies: Amtsgericht Osnabrück
No. of entry in Register of Companies: HRB 110944
Chief Executive Officer: Karsten Huster
Responsible according to § 6 MDStV: Karsten Huster
VAT registration no. according to §27 a Umsatzsteuergesetz: DE 230932141
©1998-2017 NT-ware Systemprogrammierungs-GmbH.
Feedback
Should you come across any relevant errors or have any suggestions please contact
[e-mail] or use the Send feedback here button of the uniFLOW Online Help.
Technical Support
First technical support services will be provided by your dealer. Before you contact the dealer for technical
support, ensure you have read this document.

How to use this Document
Text Styles
This style is used for text that is displayed on screen.
This style is used for text the user has to type in.
This style is used for hyperlinks to web pages, internal links to other pages in this manual.
This style is used for code examples: XML code, variables or regular expressions.
Pictograms
Important Note:
Information that is crucial for the correct functioning of the uniFLOW software.
Further Information:
Pointer to additional manuals, installation manuals, white papers or the NT-ware
Knowledgebase.
Region Specific Feature:
Indicator for uniFLOW features that are not available worldwide.
External Link:
Link to an external web page.
Settings:
Detailed explanation of configuration settings or operational procedures.
Compass:
Path to the menu or configuration page in the software.
Screenshots and Diagrams
This manual contains screenshots of the software, diagrams explaining relations and pictures of products.
Even though all visuals are up-to-date at the time of writing, they are subject to change.
Language and Translations
This document has originally been written in English language. Translations of this document are based on
the English original. Some screenshots, diagrams and pictures in this document may not be translated and
appear in English language only.
Send Feedback
Should you come across any relevant errors or have any suggestions please contact
[e-mail] or use the Send feedback here button of the uniFLOW Online Help.

About this Document
This document is delivered as part of the device / the software from NT-ware. Please read this document
before using the device / the software and keep this document or the link to an online version of this
document for future reference. Please make sure that all persons operating the device / the software are
familiar with this document. Please observe all instructions given in this document. Installation,
configuration and maintenance must only be performed by sufficiently qualified personnel. Failure to
comply with this document may void the warranty.
Every effort has been made to ensure that the contents of this manual are accurate. However, NT-ware
reserves the right to make changes without notice.

uniFLOW Release Station Contents
I
Contents
1Introduction ............................................................................................... 1
2Available Models........................................................................................ 2
3Scope of Supply .......................................................................................... 2
4Ports........................................................................................................... 3
5LED / Beep Status ....................................................................................... 4
6Copy Control Cables.................................................................................... 5
7Installation ................................................................................................. 6
8Configuration ............................................................................................. 6
8.1 Advanced Configuration................................................................................................8
8.1.1 Specific Settings ...........................................................................................................................10
8.2 uniFLOW Release Station Website............................................................................... 12
8.2.1 uniFLOW Release Station.............................................................................................................14
8.2.2 Card Reader .................................................................................................................................16
8.2.3 Port Configuration .......................................................................................................................16
8.2.3.1 Signal Interpreter ................................................................................................................................. 17
8.2.4 Network .......................................................................................................................................19
8.2.5 Support ........................................................................................................................................20
8.2.6 Upgrade .......................................................................................................................................20
8.2.7 uniFLOW Online ...........................................................................................................................20
8.2.8 About ...........................................................................................................................................22
8.2.9 Settings ........................................................................................................................................23
8.2.10 Logout ..........................................................................................................................................23
8.3 MiCard Configuration.................................................................................................. 23
8.4 Factory Reset .............................................................................................................. 24
8.5 Firmware Update ........................................................................................................ 24
9Job Release............................................................................................... 25
10 Info Screen ............................................................................................... 27
11 Specifications ........................................................................................... 28
11.1 Supported Card Standards........................................................................................... 30
11.2 Mounting Options....................................................................................................... 35
11.3 Compliance and Disposal Notes................................................................................... 35

uniFLOW Release Station Contents
II
12 Index ........................................................................................................ 41

uniFLOW Release Station
1
1Introduction
The uniFLOW Release Station is an easy to use external terminal with touch screen and
embedded card reader that can be used for releasing personal secure print jobs from
any device as well as for print & copy accounting.
Copy accounting can only be used on devices for which a copy control cable has been
developed and produced.
For a list of available copy control cables, please refer to chapter Copy Control Cables
(on page 5).
Specifications
5.7 inch capacitive multi-touch screen.
Integrated MiCard contactless card readers or model without card reader for PIN
code or credentials authentication.
Integrated two port network switch.
For a use in projects, the uniFLOW Release Station is furthermore equipped with:
A USB port for connecting external MiCard card readers via USB.
MiCard Magnetic Card Reader is not supported at the moment.
An I/O connector for controlling and monitoring copying devices via copy control
cable.

uniFLOW Release Station
2
2Available Models
The uniFLOW Release Station is available in versions with integrated MiCard card
readers and in a version without integrated card reader.
Available Models
uniFLOW Release Station Hitag (with MiCard Hitag reader)
uniFLOW Release Station HID (with MiCard HID reader)
uniFLOW Release Station Multi (with MiCard Multi reader)
uniFLOW Release Station PLUS (with MiCard PLUS reader)
uniFLOW Release Station PLUS-2 V2 (with MiCard PLUS-2 V2 reader)
uniFLOW Release Station Touch (PIN code or credentials only; without
integrated card reader)
3Scope of Supply
The uniFLOW Release Station package includes:
The uniFLOW Release Station device.
A patch cable to connect the device to a printer.
Power supply.
The uniFLOW Release Station Installation Guide.

uniFLOW Release Station
3
4Ports
1. Network port 1:
To connect the uniFLOW Release Station to the printer or to the network.
2. Network port 2:
To connect the uniFLOW Release Station to the printer or to the network.
3. USB port:
Used to connect an additional MiCard USB card reader to the uniFLOW Release
Station.
4. Copy Control port 1:
To connect a copy control cable.
5. Copy Control port 2:
To connect a copy control cable.
6. RJ45 port:
Only for internal use.
7. Power input jack:
To connect the external power supply.

uniFLOW Release Station
4
5LED / Beep Status
The uniFLOW Release Station is equipped with either three, one or no LEDs, depending
on what model is used.
uniFLOW Release Station Hitag/HID/Multi
The uniFLOW Release Station Hitag/HID/Multi is equipped with 3 status LEDs: green
(left), yellow (middle) and red (right). The table below shows the status information
given by the respective LED.
Status
Green LED
Yellow LED
Red LED
Booting up
flashing
flashing
Not synchronized
flashing
Synchronized (operating)
flashing
Authentication OK
on
flashing
Authentication failed
flashing
on
The uniFLOW Release Station Hitag/HID/Multi is equipped with a little beeper which
emits different beep tones for different statuses. The table below shows the status
information given by the beeper.
Status
Beep Signal
The card reader is booting up.
2 x fast
The card reader is not parameterized which means, there
was no saved config found.
2 x slow
The card reader is parameterized. A configuration was found
on the device.
1 x short
If parameters are sent to the card reader.
2 x slow
A card has been detected.
1 x long
If a Facility Code has been detected as invalid.
3 x fast
uniFLOW Release Station PLUS / PLUS-2 V2
The uniFLOW Release Station PLUS / PLUS-2 V2 is equipped with 1 status LED that can
show three colors: Green, Yellow and Red. The table below shows the status
information given by the LED.

uniFLOW Release Station
5
Status
LED color/Beep
Booting up
yellow, then green with beep
Not synchronized
flashing yellow
Synchronized (idle)
steady red
Reading/Hold
green with beep
uniFLOW Release Station Touch
The uniFLOW Release Station Touch does not have any LEDs. Neither does it have a
beeper.
Network Port LED (all models)
Status
LED color
A link to a network is established.
green
A link to a network is established
and data is transmitting.
green flashing
The network speed is 100 Mbit/s.
yellow ON
The network speed is 10 Mbit/s.
yellow OFF
6Copy Control Cables
A copy control cable is needed to make use of uniFLOW copy accounting and device
lock options. The cables are developed by NT-ware to make them fit to the uniFLOW
Release Station.
Copy control cables are sold separately and are not included by default with the
uniFLOW Release Station.
Copy control cables have to be configured via the PORTS.ini file. For more
information, refer to chapter Port Configuration (on page 16).
This is not necessary, if the uniFLOW Release Station is connected to uniFLOW
Online.
For a detailed list of all available copy control cables, please refer to the NT-ware DIF
Portal (http://difportal.nt-ware.net) or to the NT-ware Accessory Guide which can be
found on the NT-ware Partner Site (https://web.nt-ware.net/partner/).

uniFLOW Release Station
6
7Installation
Required Components
uniFLOW Release Station.
Power supply for the uniFLOW Release Station.
Printer.
Network cable (delivered with the uniFLOW Release Station).
Optional Components
Copy control cable for the manufacturer and model of your device.
Please refer to the NT-ware DIF Portal (http://difportal.nt-ware.net) or to the
Accessory Guide on the NT-ware Partner Site (https://web.nt-ware.net/partner/) for
more information about which copy control cable is required for your specific
machine(s).
Installation
1. Switch off the desired printer.
2. Disconnect the printer from the network.
3. Attach network cable of the printer to one of the two network ports.
4. Optional: In case copy accounting is required on an MFP: Attach the uniFLOW
Release Station with the respective copy control cable to the MFP.
Connecting the copy control cable to your MFP might require
additional installation steps.
5. Attach the uniFLOW Release Station to the network.
6. Attach the power supply to the uniFLOW Release Station.
7. The uniFLOW Release Station boots up.
8. Switch on the printer.
The uniFLOW Release Station is now ready for more advanced configurations. For the
uniFLOW Release Station configuration, see chapter Configuration (on page 6).
8Configuration
The uniFLOW Release Station works without any additional configuration if your
network has a DHCP server configured to provide an IP address.
