ACS CryptoMate EVO User manual

CryptoMate EVO
User Manual • Uživatelský manuál •
Užívateľský manuál • Használati utasítás •
Benutzerhandbuch

2
English
3 –10
Čeština
11 –19
Slovenčina
20 –28
Magyar
29 –37
Deutsch
38 –45

3
Dear customer,
Thank you for purchasing our product. Please read the following instructions carefully
before first use and keep this user manual for future reference. Pay particular attention
to the safety instructions. If you have any questions or comments about the device,
please contact the customer line.
✉www.alza.co.uk/kontakt
✆[phone]
Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Prague 7, www.alza.cz

4
Introduction
The CryptoMate EVO contains an ACOS5-EVO cryptographic smart card module. The
ACOS5-EVO cryptographic smart card module offers advanced asymmetric and
symmetric cryptographic algorithms such as ECC and RSA and is compliant with
international standards for PKI smart cards such as FIPS 14-2 (US Federal Information
Processing Standards) Level 3 and CC EAL 5+ (chip level).
The CryptoMate EVO is similar in appearance to the CryptoMate Nano, but it can be
easily distinguished when plugged in the PC with its Green LED. PC applications will
recognize it through its PCSC and Driver Name: ACS CryptoMate EVO. It also offers
higher memory and more advanced cryptographic functionalities compared to the
CryptoMate Nano.
Features
Cryptographic Smart Card Features
The CryptoMate EVO contains the ACOS5-EVO cryptographic smart card module, which
has the following features:
Communication Protocols
•T=0, T=1 with baud up to 446,400 bps
Memory
•Capacity: 192Kb
•EEPROM Endurance: 500,000 erase/write cycles
•Data Retention: 30 years
Reader MCU
ACOS5-EVO PKI Smart Card
CryptoMate EVO

5
Cryptographic Capabilities
The ACOS5-EVO supports a number of cryptographic algorithms, including:
•ECC: Curves P-224/P-256/P-384/P-521
•RSA: 512 –4096 bits in 256 bits increments
•AES: 128/192/256-bits (ECB, CBC)
•DES/3DES: 56/112/168-bits (ECB, CBC)
•Hash: SHA1, SHA224, SHA256, SHA384, SHA512
•MAC: CBC-MAC (DES/3DES, AES), CMAC (3DES, AES)
Random Number Generation
•Deterministic RNG according to FIPS 140-2
•Non-deterministic RNG compliant to AIS-31
File Security
•Private and secret key file read access can be set to “Never”
•File access condition capability with ISO 7816-compliant Secure Attribute-
Compact. File access is only allowed if the proper security conditions are met
(e.g., PIN submissions)
•Command execution condition capability per Dedicated File (DF) with ISO 7816-
compliant Secure Attribute-Extended. Commands are allowed only if the proper
security conditions are met (e.g., PIN submission)
•Secure Messaging function for confidential and authenticated data transfer
•Mutual authentication (terminal-co-card and card-to-terminal) with session key
generation for encryption and MAC
•Anti-tearing Function Support
Compliance to Standards
•Compliance with ISO 7816 Parts 1,2.3,4, 8, and 9
•Compliance with FIPS 140-2 Level 3
•Certified with Common Criteria ELA 5+ (Chip Level)

6
Token Features
Physical Characteristics
•Green Status LED
•Lightweight: 4.61 g
•Extremely small: 29.25 mm x 14.80 mm x 10.28 mm
•Keychain hole
•Tamper-evident casing
•Smart card power supply through USB port
Compliance to Standards
•USB Full Speed Interface
•CCID-compliant (Plug and Play)
•CE and FCC-certified
•RoHS-compliant
•REACH-certified
•Microsoft WHQL-certified
•Supports Android 3.1 and later
Typical Applications
•e-Government
•e-Healthcare
•Banking and Payment
•Network Security
•Access Control
•Public Key Infrastructure
•Digital Signature

7
Middleware
To use CryptoMate EVO for PKI applications with digital certificates, an applicable
middleware id needed.
ACS offers software solutions such as the ACOS5 Minidriver and ACOS5-EVO PKI Kit so
that the ACOS5-EVO and the CryptoMate EVO can be used with other third-party
applications as shown in the figure below:
Please contact us at [email protected].hk for inquiries about the middleware supports for
the CryptoMate EVO token.
ACS Applications
Microsoft
Applications
Smart Card
Logon
Non-Microsoft
Applications
Microsoft
CryptoAPI:
Next Gen
Microsoft
CryptoAPI
Minidriver
PKCS #11
ACS CNG
(CryptoAPI Next
Generation
ACS CSP
(Cryptographic
Service Provider
ACS Minidriver
ACS PKCS #11
Windows Resource Manager
Applications
Middleware
Operating System Layer
ACS Smart Card Reader/Token Driver

8
Technical Specifications
Physical Characteristics
Dimensions
29.18 mm (L) x 14.50 mm (W) x 10.54 mm
(H)
Weight
4.61 g
Color
Black
ACOS5-EVO Cryptographic Smart Card Module
Memory Size
192 KB
Endurance
500,000 write/erase cycles
Data Retention
30 years
Cryptographic Capability
ECC: Curves P-224/P-256/P-384/P-521
RSA: 512 –4096 bits in 256 bits
increments
AES: 128/192/256-bits (ECB, CBC)
DES/3DES: 56/112/168-bits (ECB, CBC)
MAC: CBC-MAC (DES/3DES, AES) CMAC
(3DES, AES)
Hashing Capabality
SHA1, SHA 224, SHA256, SHA384, SHA512

9
USB Host Interface
Protocol
USB CCID
Connector Type
Standard Type A
Power Source
From USB port
Speed
USB Full Speed (12 Mbps)
Built-in Peripherals
LED
Green
Casing
Tamper-evident
Others
Keychan hole for portability
Operating Conditions
Temperature
0°C - 50°C
Humidity
Max. 90% (non-condensing)
MTBF
500,000 hrs
Certifications/Compliance
ISO 7816, USB Full Speed, Common Criteria ELA5+ (Chip Level), PC/SC, CCID, CE, FCC,
RoHS, REACH, FIPS, 140-2 Level 3 (USA), Microsoft WHQL
Middleware Support
ACS PKCS #11, ACS CSP (based on Microsoft’s CryptoAPI), ACS CNG (based on Microsoft’s
CNG)
ACS Minidriver
X.509 v3 Certificate Storage (can store more than 10 Key Pairs)
Device Driver Operating System Support
Windows 7, Windows 8, Windows 8.1, Windows 10
Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server
2012 R2, Windows Server 2016
Linux, Mac OSM Android 3.1 and later

10
Warranty Conditions
A new product purchased in the Alza.cz sales network is guaranteed for 2 years. If you
need repair or other services during the warranty period, contact the product seller
directly, you must provide the original proof of purchase with the date of purchase.
The following are considered to be a conflict with the warranty conditions, for
which the claimed claim may not be recognized:
•Using the product for any purpose other than that for which the product is intended
or failing to follow the instructions for maintenance, operation, and service of the
product.
•Damage to the product by a natural disaster, the intervention of an unauthorized
person or mechanically through the fault of the buyer (e.g., during transport,
cleaning by inappropriate means, etc.).
•Natural wear and aging of consumables or components during use (such as
batteries, etc.).
•Exposure to adverse external influences, such as sunlight and other radiation or
electromagnetic fields, fluid intrusion, object intrusion, mains overvoltage,
electrostatic discharge voltage (including lightning), faulty supply or input voltage and
inappropriate polarity of this voltage, chemical processes such as used power
supplies, etc.
•If anyone has made modifications, modifications, alterations to the design or
adaptation to change or extend the functions of the product compared to the
purchased design or use of non-original components.
