NTTworks Syscall SLL-400 User manual

User Manual
Please read the user manual carefully
before start using the device.
User Manual
Light Indicator SLL-400

Syscall User Manual
2Table of Contents
Getting Started
1. Components & Specification
2. Device Layout & Installation
3. Set Button
Function Setting
4. Bell Registration
5. Clear Bell Registration
6. LED Light Type Setting
7. Buzzer Volume Setting
8. Alert Time Setting
9. Initialization
3
3
4
5
5
6
7
8
8

Syscall User Manual
3
Components
1. Components & Specification
Specification
Frequency
Input Voltage
Current Consumption
FSK/433.42MHz
12V
Standby: 45mA/ Operate: 600mA
Features
1. Receive the signal of transmitter and output an alarm
2. Register up to 200 call bells
3. Register up to 10 clear bells
Dimension
Color
W82 x L156 x H79.5(mm)/365g
Red, White
Light Indicator Bracket Power Adapter
(DC 12V 1A)
User Manual
2. Device Layout & Installation
Front Back Underside
1
2
34
1
2
3
4
LED
LED: LED will blink when receiving the signal from the transmitter.
Adapter connector jack: Plug-in the adapter and insert the connector in to the jack.
Set Button: Setting or Initialization
Buzzer: Buzzer will sound when receiving the signal from the transmitter.

Syscall User Manual
4
3. Set Button
How to enter and shift the menus
Installation
Button Controls
Click once
Double-click
Press and hold the button for 2 sec
Press and hold the button for 3 sec
Press and hold the button for 5 sec
Press and hold the button for 10 sec twice
Beep sound
Beep
Beep, Beep, Beep
Beep, Beep
Beep, Beep, Beep~~
Beep, Beep, Beep~~, Beep~~, Beep~~
Beep, Beep, Beep~~, Beep~~Beep~~, Beep~~~~~
Beep, Beep, Beep~~, Beep~~Beep~~, Beep~~~~~
Function
Clear the alarm
Exit the menu / Save
Shift the menu
Enter the menu
Alert time setting
Initialization
Plug-in the adapter and
insert the connector
in to the jack.
Tighten a screw in the
bottom.
Fix the bracket on the wall.
12 3
Bell
Registration
LED Light Type
Setting
Siren Alert
Setting
Clear Bell
Registration Exit
Turn on the SLL-400 by connecting the adapter before setting.
Please use the device only with the power adapter (12V/1A) provided by manufacturer.
Caution
Press and hold
the button for 3 sec
Press and hold
the button for 2 sec
Press and hold
the button for 2 sec
Press and hold
the button for 2 sec
Double-click
Beep, Beep,
Beep~~ Beep, Beep Beep, Beep Beep, Beep Beep, Beep,
Beep
Set button

Syscall User Manual
5
4. Bell Registration
Register up to 200 call bells
Beep, Beep, Beep
Beep, Beep, Beep
Beep, Beep, Beep~
Beep, Beep, Beep~ Beep, Beep
Beep!
Beep!
Press and hold the set button
for 3 sec
Press the bell to register
- Registered: Beep once
- Already registered: Double beep
Press and hold the set button
for 3 sec
Press and hold the set button
again for 2 sec
Press the bell to register
- Registered: Beep once
- Already registered: Double beep
Double-click the set button
to exit
1. Enter the menu 3. Exit the menu2. Press the bell
* Default: Delay time 10 sec to avoid duplication
Double-click
Double-click
3 sec
3 sec 2 sec
1. Enter the menu 2. Shift the menu 3. Press the bell
Double-click the set button
to exit
4. Exit the Menu
5. Clear Bell Registration
Register up to 10 clear bells

Syscall User Manual
66. LED Light Type Setting (Default: LED Type 2)
Beep, Beep, Beep~~ Beep, Beep
Beep, Beep Beep, Beep Beep, Beep
Beep, Beep
Press and hold the set button
for 3 sec
Press and hold the set button
again for 2 sec
Press and hold the set button
again for 2 sec
Beep, Beep, Beep
Double-click
3 sec 2 sec 2 sec
1. Enter the menu 2. Shift the menu 3. Shift the menu
Change the type when clicking
[Type 2 ‒ LED OFF ‒ Type 1]
4. Setting
Click
Double-click the set button
to save and exit
5. Save & Exit
* LED Type
Type 1: Blinking slowly
Type 2: Blinking fast
[Type 2]
Blinking fast
[Type 1]
Blinking slowly
LED OFF
Click once Click once Click once

Syscall User Manual
7
7. Buzzer Volume Setting (Default: HIGH)
Beep, Beep, Beep~~ Beep, Beep
Beep, Beep
Beep, Beep
Press and hold the set button
for 3 sec
Press and hold the set button
again for 2 sec
Press and hold the set button
again for 2 sec
Press and hold the set button
again for 2 sec
Beep, Beep, Beep
Double-click
3 sec
2 sec
2 sec 2 sec
Beep, Beep Beep, Beep Beep, Beep
Click once Click once Click once
Beep, Beep
Click once
1. Enter the menu 2. Shift the menu 3. Shift the menu
Change the volume when clicking
[HIGH ‒ OFF ‒ LOW ‒ MID]
5. Setting4. Shift the menu
HIGH LOWBUZZER OFF MID
Double-click the set button
to save and exit
6. Save & Exit
Click

Syscall User Manual
8
Beep, Beep, Beep~~,
Beep~~, Beep~~
Beep, Beep, Beep
* Press the button for 3sec to set alert time unlimited
Press and hold the set button
for 1sec to change the alert
time (Refer to the table below)
Press and hold the set button
for 5 sec
1. Enter the menu 2. Setting
Double-click the set button
to save and exit
3. Save & Exit
8. Alert Time Setting (Default: 10sec)
Alert Time
1 sec
3 sec
5 sec
10 sec (Default)
30 sec
1 min
Alert Time
3 min
5 min
10 min
30 min
60 min
Unlimited
Beep Sound
Beep, Beep
Beep, Beep
Beep, Beep
Beep~
Beep, Beep
Beep~
Beep Sound
Beep, Beep
Beep, Beep
Beep~
Beep, Beep
Beep~ Beep~
Beep~
No.
1
2
3
4
5
6
No.
7
8
9
10
11
12
Alert Time Setting Table
Press and hold the button
for 10 sec
1. Enter the menu 3. Completed2. Setting
Press and hold the button
again for 10 sec
A short beep will sound,
once it is initialized.
It will take about 30 sec.
9. Initialization
5 sec
Beep, Beep, Beep~~,
Beep~~Beep~~, Beep~~~~~
Beep, Beep, Beep~~,
Beep~~Beep~~, Beep~~~~~
10 sec
Beep!
10 sec
1 sec Double-click

■SYSCALL France - www.syscall.fr
0033 (0)1 84 17 61 81 - [email protected]
242 boulevard de Stalingrad 94500 Champigny sur Marne
France
■NTTWORKS CO., LTD
413-9 NTTWORKS Bldg, Galhyun-Dong, Eunpyong-Gu
Seoul, Korea
Manufacturer
