Nuaire Group MRXBOX95B-WMI Instruction Manual

The un t must rema n sw tched on at all t mes to ma nta n
vent lat on w th n the dwell ng. Turn ng the un t off w ll
cause long term damage to the un t and bu ld ng fabr c.
Th s appl ance s not ntended for use by persons
( nclud ng ch ldren) w th reduced phys cal, sensory or
mental capab l t es, or lack of exper ence and knowledge,
unless they have been g ven superv s on or nstruct on
concern ng the use of the appl ance by a person for the r
safety. Ch ldren should be superv sed so that they do not
play w th the appl ance.
MRXBOX95B-WM1
Mec anical Ventilation Unit wit Heat Recovery,
Integral Frost Protection & Summer Bypass
Installation and Maintenance
Nua re L m ted Western Industrial Estate Caerp illy United Kingdom CF83 1NA
T: 029 2085 8400 F: 029 2085 8444 E: [email protected] W: www.nuaire.co.uk
111. 09. 14. Leaflet Number 671631
Extract air
from house
Intake air
from outside
Exhaust air
from house
to outside Supply air
to house
Extract
Fan
Supply
Fan
RunonTrickleBoostTrickleBoost
Figure 1. Airflow t roug unit.
The EMC D rect ve
2004/108/EC
The Low Voltage
Drect ve
2006/95/EC
Figure 3a. Fixing t e mounting
bracket to t e rear of unit.
Pre-fitted
support feet
Bracket
Figure 3b. Mounting t e unit
on t e wall mounted bracket.
Figure 2. Fixing t e mounting bracket to t e wall via a patress.
Figure 4. Typical example of a cupboard mounted unit on a patress
using t e bracket.
125mm dia.
ducting in
ceiling void.
First floor ceiling.
Side view of unit mounted
on the wall in a cupboard.
(Note: The unit must be
fixed to a suitable patress
in upright position as
shown to comply with
safety regulations).
MVHR-DRAIN
Condensate drain,
uninsulated drain
pipe with 10ofall
running to SVP.
Supply air valve in ceiling.
1.0 Introduct on
MRXBOX95B-WM1 wall mounted un t s des gned to prov de
mechan cal supply and extract vent lat on w th heat recovery
& ncorporates ntegral frost protect on and summer bypass.
T e unit is fitted wit two independent fans. Eac fan as full
speed control for background and boost ventilation rates.
To recover eat from t e extract air t e eat exc anger block
is utilised. T e eat exc anger can recover up to 95% of t e
normally wasted eat.
T e bypass damper opens w en a 230V signal is applied to
t e unit (via a manual switc , supplied). T is opens t e damper
via an actuator. W en t e switc signal is de-activated
t e unit returns to its original state (air t roug t e eat
exc anger).
Outside air supplied t roug t e bypass is still filtered, so t e
air quality is optimal, irrespective of t e bypass setting (Open
or closed).
2.0 Installat on
Installation must be carried out by competent personnel in
accordance wit t e appropriate aut ority and conforming
to all statutory governing regulations. All mains wiring must
be in accordance wit t e current I.E.E. Regulations, or t e
appropriate standards. Ensure t at t e mains supply
(Voltage, Frequency and P ase) complies wit t e rating label.
Please note a clear working space is required around t e
installed unit to allow t e cover to be removed and provide
sufficient access for maintenance suc as filter c ange.
Please allow a minimum of 350mm in front of t e unit.
T e fan must be installed indoors, on a suitable wall away
from direct sources of frost, eat, water spray or moisture
generation. For a vibration-free result t e unit must be
mounted to a solid wall.
The un t s des gned for wall mount ng only v a a patress.
1. One part of t e mounting bracket s ould be offered up to
t e wall, ensuring it’s located orizontally. Mark t e fixing
points t roug t e pre drilled oles in t e bracket and
install wit screws (by ot ers), ensuring t e interlock side
is at t e top, fig. 2.
2. Fix t e remaining part of t e bracket to t e unit using t e
M5 screws ensuring t e interlock side is at t e bottom, fig.3a.
3. Install t e unit on t e wall by ensuring t e bracket on t e
unit interlocks over t e wall mounted bracket (fig. 3b).
Note: Care must be taken to ensure the un t s nstalled true
n all 3 d mens ons. Fa lure to do so may result n overflow
from the nternal condensat on dr p tray.

2.1 Condensate Dra n
1. T e condensate must be disc arged under a water
level in a U-trap drainpipe or an alternative drain met od
w ic acts as an airlock.
2. T is condensate disc arge connection is suitable for 21.5mm
dia. overflow pipe.
Solvent cement s ould be used to make t e joint.
3. If using a U-trap please ensure t e U-trap as been filled to
a suitable level of water to avoid any air locks.
4. If t e condensation pipe is fitted in an un eated space t e
pipe s ould be in insulated to prevent freezing.
Nua re recommend MVHR-DRAIN be used as the pr mary
condensate take-off. (see f gure 5b/7a/7b).
2.2 Extract/ nput areas
T e unit is designed to extract air from all wet rooms
e.g. bat room, kitc en, en-suite, utility room (wit sink).
WC’s do not need to be ventilated if openable windows
are fitted.
Supply air s ould be to all abitable rooms e.g. bedrooms and
lounge. Extract / input grilles s ould be adjustable valve types
(not supplied).
External grilles to ave a minimum free area of 12,250 sq mm.
2.3 Duct ng
Before commencing ducting installation reference s ould be
made to building regulations document “Domestic ventilation
compliance guide”. T is document supports ADF2010 and
details installation, testing and commissioning of all ventilation
systems.
It is recommended t at rigid ducting be used it all times.
Flexible ducting as a very ig resistance and it is impossible
to calculate ow muc resistance will be on a system if used.
If used t e flexible ducting must be kept to a minimum and
s ould always be pulled taut. A maximum of 500mm s ould
be used on eac leg.
To prevent condensation on t e outside of t e outside air inlet
duct and t e air outlet duct from t e MRXBOX95B-WM1, t ese
ducts s ould be insulated.
Ducting must be installed in suc a way t at resistance to
airflow is minimised. Bends s ould be kept to a minimum.
A minimum distance of 200mm between t e appliance and
any bends in ductwork is recommended.
Ideally 125mm diameter or 204 x 60mm rectangular ducting
s ould be used. (Refer to dwelling design drawing, figure 7a
and 7b on page 4 for furt er information).
Ducting joints must be sealed wit silicone type sealant and
s all be adequately and reliably fixed to t e appliance.
2.4 Vent lat on flow rates
Table 1.
ADF2006 / 2010 – Extract vent lat on rates
Room M n h gh rate M n low rate
Kitc en 13 l/s
Utility room 8 l/s
Bat room 8 l/s
Sanitary
accommodation 6 l/s
Table 2.
Whole dwell ng vent lat on rates
Number of bedrooms n dwell ng
12345
W ole 13 17 21 25 29
dwelling
ventilation
rate l/s
1, 2
Notes:
1, In add t on, the m n mum vent lat on rate be should be not
less than 0.3 l/s per m2of nternal floor area.
(Th s ncludes all floors, e.g. for a two-story bu ld ng add the
ground and f rst floor areas).
2, Th s s based on two occupants n the ma n bedroom and
a s ngle occupant n all other bedrooms. Th s should be used
as the default value. If a greater level of occupancy s
expected add 4 l/s per occupant.
Any a r ntake term nal MUST be nstalled n accordance
w th the appropr ate regulat on.
As a gu de, the BS5440 ser es of Br t sh Standards
deals w th th s ssue and currently states that an a r
ntake must be at a m n mum d stance of 300mm from a
gas bo ler balanced flue.
Installers are adv sed to be aware of the requ rements of
th s standard when nstall ng ‘through the wall’ supply
a r duct ng. S m larly, supply and extract a r gr lles
should be at least 300mm apart.
211. 09. 14. Leaflet Number 671631
Installat on and Ma ntenance MRXBOX95B-WM1 Mec anical Ventilation wit Heat Recovery and Summer Bypass
Figure 5a. Wet option.
Condensate pipe
connection to unit and
a typical example of
a “U” trap drainpipe.
Fit compression elbow
to aid maintenance.
Figure 5b. MVHR-DRAIN option.
Condensate drain, uninsulated drain
pipe wit 10ofall running to SVP.
Collar
Fit compression
joint to aid
maintenance
5o Drop
Total extract rate s ould
be at least t e w ole
dwelling ventilation rate
given in table 2.
To SVP
“T” piece
MVHR Drain
To unit
To CONTRAP
Figure 5c. IMPORTANT: When us ng a “T” P ece to connect the
CONTRAP dra nage and the MVHR dra n p pework the MVHR
dra n must always be f tted before the “T” P ece to prevent
condensate from feed ng back nto the MVHR system.

2.5 A r permeab l ty and nf ltrat on
Is t e uncontrolled exc ange of air between inside and outside
t roug cracks, porosity and ot er unintentional openings in
t e building. ADF2006 gives an allowance for t is in bot multi
and single storey buildings, owever ADF2010 as an
allowance for multi storey only. Additionally ADF2010 only
applies t is allowance for dwellings leaker t an 5 m3/( .m2) at
50Pa. (See below).
2.6 ADF 2006 Vent lat on calculat ons
Cont nuous supply and extract
Step 1: Determine t e w ole building ventilation rate from Table
2. Allow for infiltration by subtracting from t is value:
nfor multi-storey dwellings: 0.04 x gross internal volume of
t e dwelling eated space (m3);
nfor single-storey dwellings: 0.06 x gross internal volume of
t e dwelling eated space (m3).
Step 2: Calculate t e w ole dwelling air extract rate at
maximum operation by summing t e individual room rates for
‘minimum ig rate’ from Table 1.
(For sanitary accommmodation only, as an alternative, t e
purge ventilation provisions given in ADF 2006 can be used
w ere security is not an issue. In t is case ‘minimum ig
extract rate’ for t e sanitary accommodation s ould be omitted
from t e step 2 calculation).
Step 3: T e required airflow rates are as follows:
nt e maximum extract rate (e.g. boost) s ould be at least
t e greater of step 1 and step 2. Note t at t e maximum
individual room extract rate s ould be at least t ose given
n table 1. for minimum ig rate.
nt e minimum air supply rate s ould be at least t e w ole
building ventilation rate found in step 1.
2.7 ADF 2010 Vent lat on calculat ons
Des gn of MVHR systems
T e MVHR system as been sized for t e winter period.
Additional ventilation may be required during t e warmer
mont s and it as been assumed t at t e provisions for purge
ventilation (e.g. openable windows) could be used.
Step 1: For any design air permeability, determine t e w ole
dwelling ventilation supply rate from Table 2.
As an alternative w ere t e design air permeability is intended
to be leakier t an (>) 5m3/( .m2) 50 Pa, allow for infiltration
for all dwelling types by subtracting from t e w ole dwelling
ventilation supply rate from Table 2; 0.04 x gross internal
volume of t e dwelling eated space (m3).
Step 2: Calculate t e w ole dwelling extract ventilation rate by
summing t e individual room rates for ‘minimum ig rate’ from
Table 1.
(For sanitary accommmodation only, as an alternative, t e
purge ventilation provisions given in ADF 2010 can be used
w ere security is not an issue. In t is case ‘minimum ig
extract rate’ for t e sanitary accommodation s ould be omitted
from t e step 2 calculation).
Step 3: T e required airflow rates are as follows:
nt e maximum w ole dwelling extract ventilation rate (e.g.
boost) s ould be at least t e greater of step 1 and step 2.
Note t at t e maximum individual room extract rate s ould
be at least t ose given n table 1. for minimum ig rate.
nt e minimum air supply rate s ould be at least t e w ole
building ventilation rate found in step 1.
For Scotland refer to BRE D gest 398.
311. 09. 14. Leaflet Number 671631
Installat on and Ma ntenance MRXBOX95B-WM1 Mec anical Ventilation wit Heat Recovery and Summer Bypass
A
60 1
32
500
60 1
288
288
157
76
13079
100
400123 78
125
78 400 123
79
288
115 371 115
46
171
249
Power Cable entry
Condensate take off
Filter access
Control Pots and LED’s
190
190
Side viewFront view
View from bottom View from top
Filter access
468
3.0 D mens ons
Figure 6.

411. 09. 14. Leaflet Number 671631
Installat on and Ma ntenance MRXBOX95B-WM1 Mec anical Ventilation wit Heat Recovery and Summer Bypass
4.0 Duct ng arrangements
Air supply to lounge
via Air Valve
(Part no. VS125)
in ceilings.
Extract air from
kitchen/bathroom
via Air Valve
(Part no. VS125)
in ceilings.
Minimum
300mm
Exhaust air from
kitchen/bathroom to
outside via louvre grille
(Part no. PVC504).
Intake air
from outside
via louvre grille
(Part no. PVC504).
All duct between MVHR
unit and atmosphere to
be insulated*.
Exhaust air from
kitchen/bathroom to
outside via air brick
(Part no. PVC501).
Intake air
from outside
via air brick
(Part no. PVC501).
All duct between MVHR
unit and atmosphere to
be insulated*.
*Insulated
supply duct.
*Insulated
supply duct.
Minimum
300mm
Air supply to lounge
via Air Valve
(Part no. VS125)
in ceilings.
Extract air from
kitchen/bathroom
via Air Valve
(Part no. VS125)
in ceilings.
Air supply to
bedrooms
via Air Valve
(Part no. VS125)
in ceilings.
Top of ceiling void.
Top of ceiling void.
Nuaire
MRXBOX95B-WM1
wall mounted
unit on a patress.
Air supply to
bedrooms
via Air Valve
(Part no. VS125)
in ceilings.
Nuaire
MRXBOX95B-WM1
wall mounted
unit on a patress.
MVHR-DRAIN
Condensate drain, uninsulated
drain pipe with 10 fall running to SVP.
MVHR-DRAIN
Condensate drain, uninsulated
drain pipe with 10 fall running to SVP.
o
o
*Insulated
extract duct.
*Insulated
extract duct.
Figure 7a. Typical ducted arrangement for a wall mounted unit using 125mm dia. ducting.
Figure 7b. Typical ducted arrangement for a wall mounted unit using rectangular 204 x 60mm ducting.
ALSO FROM NUAIRE -
New range of thermal ducting,
an all-in-one insulated ducting system.
(see installation document 671620).

511. 09. 14. Leaflet Number 671631
Installat on and Ma ntenance MRXBOX95B-WM1 Mec anical Ventilation wit Heat Recovery and Summer Bypass
For good EMC eng neer ng pract ce, any sensor cables
or sw tched l ve cables should not be
placed w th n 50mm of other cables or on the same
metal cable tray as other cables.
5.0 Electr cal Connect on
The four core cable from the ma ns power supply should be
connected to a f xed w r ng nstallat on, v a a fused solator, n
accordance w th current IEE w r ng regulat ons.
Please note: t e electrical connection of t e unit must be be carried
out by a qualified electrician.
T e unit is supplied wit a flexible cord for connection to t e mains
supply.
Electr cal deta ls:-
Voltage: 240V 1ph 50Hz
Consumpt on: 75W 0.6 Amp
Fuse rat ng: 3 Amp
NOTE Th s un t must be earthed.
Figure 8
Note: W r ng s for reference
purposes only as the
connect ons above are factory
ftted. The un t s pre-w red
wth a 2 metre fly lead.
Fuse 2A
MAINS
230V
50Hz
Room
light
Light
switch
(Double
Pole)
N
L
3 Pole
isolator
Kitchen switch
Green/yellow
Blue
Brown
Black
Summer
bypass
switch
Grey (only used
on bypass unit)
Supply cord
from unit
Un t serv ng k tchen and bathroom
Un t serv ng k tchen and two bathrooms
Fuse 2A
MAINS
230V
50Hz
Room
lights
Light
switches
(Double
Pole)
N
L
3 Pole
isolator
Kitchen switch
Green/yellow
Blue
Brown
Black
Summer
bypass
switch
Grey (only used
on bypass unit)
Supply cord
from unit
Figure 9.
Figure 10.
TEMP
Connection to
Remote Fail
Indicator Ref:
MRXBOX95LH-RFI
24V 0V SW
FAN 1
FAN 2
Internal wiring
Run-on Trickle Boost Trickle Boost
Connection to
Ecosmart
sensors
ECOSMART NET
6.0 Opt onal controls
Customise MRXBOX95B-WM1 for en anced performance.
All supplied wit pre-plugged 10m data cable and incorporates
status LED.
MRXBOX95-PIR Passive infra-red detector
MRXBOX95-HUM Humidistat
MRXBOX95-RFI Remote fail indictor

611. 09. 14. Leaflet Number 671631
Installat on and Ma ntenance MRXBOX95B-WM1 Mec anical Ventilation wit Heat Recovery and Summer Bypass
The f lters f tted ns de the un t are protected w th a
plast c f lm. Pr or to comm ss on ng remove the covers
(f g 13), take off the f lm and replace.
Isolat on - Before commenc ng work make sure that the
un t, sw tched l ve and Nua re control are electr cally
solated from the ma ns supply and sw tched l ve supply.
Figure 11. Detail of unit control
on front panel.
Filter covers
Figure 12. Removing
t e two filter covers
on t e front panel of
t e unit.
Filter being
removed
Filter cover
Figure 13.T e filters
can be removed by
pulling on t e black
tab on t e visible end
of t e filters.
Normal Mode
Supply Fan Fault
Extract Fan Fault
Boost
Frost Protection
Filter Change
Extract
Fan
Supply
Fan
RunonTrickleBoostTrickleBoost
Extract
Fan
Supply
Fan
Run on Trickle Boost Trickle Boost
7.0 Comm ss on ng
1. For t e required air flow rates please refer to t e design
specification for t e property, follow 2.4, or refer to building
regulations ADF 2006/2010.
2. T e unit is supplied wit independent control for bot normal
and boost airflows. (see fig. 11).
3. Correct commissioning is essential to ensure t e ventilation
air flowrates are met. It also ensures t e unit is not over
ventilating and causing excessive power consumption.
4. Commissioning s ould be carried out in accordance wit
building regulations document “Domestic ventilation
compliance guide”. A calibrated moving vane anemometer
and ood will be required to carry out commissioning.
5. Adjustment valves s ould be locked in place to prevent
furt er adjustment.
6. Once commissioned t e ome owner / tenant s ould be
informed t at t e unit s ould not be adjusted as it will ave
a detrimental effect on t e indoor air quality and could result
in condensation and mould growt . T e label covering t e
control as an ad esive panel w ic s ould be removed post
commissioning to prevent tampering.
7.1 Opt onal summer bypass
T e bypass damper opens w en a 230V signal is applied to t e
unit (via a manual switc , supplied). T is opens t e damper via
an actuator. W en t e switc signal is de-activated t e unit
returns to its original state (air t roug t e eat exc anger).
Outside air supplied t roug t e bypass is still filtered, so t e
air quality is optimal, irrespective of t e bypass setting (Open or
closed).
8.0 Status Ind cat on
T e status of t e unit is indicated by a series of LED’s on t e
front cover. T e varients are listed below.
9.0 Ma ntenance/Clean ng
We recommend t at t e two G3 fiters are inspected after
6 mont s, and replaced every 12 to 18 mont s.
T e filters can be removed from t e unit by removing t e two
filter covers on t e front panel of t e unit. Take old of t e two
circular tabs eit er end of t e filter covers and pull out.
T e filter can now be extracted by pulling t e removal loop on
t e front edge of t e filter. Once t e filters ave been inspected
return or replace t em as necessary.
Inspect t e eat exc anger every 5 years. Generally c eck
for damage and security of components. Refit cover.
10.0 Replacement of Parts
S ould any component need replacing Nuaire keep extensive
stocks for quick delivery. Ensure t at t e unit is electrically
isolated, before carrying out any work.
Note: T e supply cable must be replaced by an electrically
competent person.
W en ordering spare parts, please quote t e serial number
of t e unit and t e ARC number of t e purc ase if possible.
(Th s nformat on w ll be ava lable on the fan label).
11.0 Warranty
T e 5 year warranty starts from t e day of delivery and
includes parts and labour for t e first year and parts only for
t e remaining 4 years. T is warranty is conditional on planned
maintenance being undertaken.
12.0 Serv ce Enqu r es
Nuaire can assist you in all aspects of service. Our service
department will be appy to provide any assistance required,
initially by telep one and If necessary arrange for an
engineer to call.
Techn cal Support
on 029 2085 8400

We declare that the mach ne named below conforms to the requ rements of
EC Counc l D rect ves relat ng to Electromagnet c Compat b l ty and Safety
of Electr cal Equ pment.
Des gnat on of mach nery: MRXBOX95B-WM1
I & M Ser al No.: 671631
Mach nery Types: Mec anical Ventilation wit
Heat Recovery and Integral Frost
Protection
Relevant EC Counc l D rect ves: 2004/108/EC (EMC), 2006/95/EC
(Low Voltage Directive)
Appl ed Harmon sed Standards: EN55014-1, EN55014-2, EN61000-3-2,
EN61000-3-3, EN60335-2-80
Bas s of Self Attestat on: Quality Assurance to BS EN ISO 9001
BSI Registered Firm Certificate No. FM 149
Sgnature of manufacture representat ves:
Name: Position: Date:
1) C. Biggs Tec nical Director 05 09. 13
2) A. Jones Manufacturing Director 05 09. 13
Nuaire Ltd,
Western Industrial Estate,
Caerp illy CF83 1NA.
Note: All standards used were current and valid at t e date of signature.
711. 09. 14. Leaflet Number 671631
To comply w th EC Counc l D rect ves 2006/42/EC Mach nery D rect ve and
2004/108/EC (EMC).
To be read n conjunct on w th the relevant Product Documentat on (see 2.1)
1.0 GENERAL
1.1 T e equipment referred to in t is Declarat on of Incorporat on is supplied by
Nuaire to be assembled into a ventilation system w ic may or may not include
additional components.
T e entire system must be considered for safety purposes and it is t e
responsibility of t e installer to ensure t at all of t e equipment is installed in
compliance wit t e manufacturers recommendations and wit due regard to
current legislation and codes of practice.
2.0 INFORMATION SUPPLIED WITH THE EQUIPMENT
2.1 Eac item of equipment is supplied wit a set of documentation w ic provides
t e information required for t e safe installation and maintenance of t e
equipment. T is may be in t e form of a Data s eet and/or Installation and
Maintenance instruction.
2.2 Eac unit as a rating plate attac ed to its outer casing. T e rating plate
provides essential data relating to t e equipment suc as serial number, unit
code and electrical data. Any furt er data t at may be required will be found
in t e documentation. If any item is unclear or more information is required,
contact Nuaire.
2.3 W ere warning labels or notices are attac ed to t e unit t e instructions given
must be ad ered to.
3.0 TRANSPORTATION, HANDLING AND STORAGE
3.1 Care must be taken at all times to prevent damage to t e equipment. Note t at
s ock to t e unit may result in t e balance of t e impeller being affected.
3.2 W en andling t e equipment, care s ould be taken wit corners and edges and
t at t e weig t distribution wit in t e unit is considered. Lifting gear suc as
slings or ropes must be arranged so as not to bear on t e casing.
3.3 Equipment stored on site prior to installation s ould be protected from t e
weat er and steps taken to prevent ingress of contaminants.
4.0 OPERATIONAL LIMITS
4.1 It is important t at t e specified operational limits for t e equipment are
ad ered to e.g. operational air temperature, air borne contaminants and unit
orientation.
4.2 W ere installation accessories are supplied wit t e specified equipment eg.
wall mounting brackets. T ey are to be used to support t e equipment only.
Ot er system components must ave separate provision for support.
4.3 Flanges and connection spigots are provided for t e purpose of joining to
duct work systems. T ey must not be used to support t e ductwork.
4.4 In t e event of RF interference t e fan may c ange speed. T is is normal and will
ave no adverse effect on t e fan. T e speed will return to normal once t e
interference as subsided.
5.0 INSTALLATION REQUIREMENTS
In addition to t e particular requirements given for t e individual product, t e
following general requirements s ould be noted.
5.1 W ere access to any part of equipment w ic moves, or can become electr cally
l ve are not prevented by t e equipment panels or by fixed installation detail
(eg ducting), t en guarding to t e appropriate standard must be fitted.
5.2 T e electrical installation of t e equipment must comply wit t e requirements
of t e relevant local electrical safety regulations.
5.3 For EMC all control and sensor cables s ould not be placed wit in 50mm or on
t e same metal cable tray as 230V switc ed live, lig ting or power cables and
any cables not intended for use wit t is product.
6.0 COMMISSIONING REQUIREMENTS
6.1 General pre-commissioning c ecks relevant to safe operation consist of t e
following:
Ensure t at no foreign bodies are present wit in t e fan or casing.
C eck electrical safety. e.g. Insulation and eart ing.
C eck guarding of system.
C eck operation of Isolators/Controls.
C eck fastenings for security.
6.2 Ot er commissioning requirements are given in t e relevant product documentation.
7.0 OPERATIONAL REQUIREMENTS
7.1 Equipment access panels must be in place at all times during operation of t e
unit, and must be secured wit t e original fastenings.
7.2 If failure of t e equipment occurs or is suspected t en it s ould be taken out of
service until a competent person can effect repair or examination. (Note t at
certain ranges of equipment are designed to detect and compensate for fan failure).
8.0 MAINTENANCE REQUIREMENTS
8.1 Specific maintenance requirements are given in t e relevant product documentation.
8.2 It is important t at t e correct tools are used for t e various tasks required.
8.3 If t e access panels are to be removed for any reason t e electrical supply to t e
unit must be isolated.
8.4 A minimum period of two minutes s ould be allowed after electrical disconnection
before access panels are removed. T is will allow t e impeller to come to rest.
NB: Care should st ll be taken however s nce a rflow generated at some
other po nt n the system can cause the mpeller to “w ndm ll” even when
power s not present.
8.5 Care s ould be taken w en removing and storing access panels in windy
conditions.
INFORMATION FOR SAFE INSTALLATION, OPERATION AND MAINTENANCE
OF NUAIRE VENTILATION EQUIPMENT
We declare that the mach nery named below s ntended to be assembled
wth other components to const tute a system of mach nery. All parts
except for mov ng parts requ r ng the correct nstallat on of safety guards
comply w th the essent al requ rements of the Mach nery D rect ve. The
mach nery shall not be put nto serv ce unt l the system has been
declared to be n conform ty w th the prov s ons of the EC Mach nery
Drect ve
Des gnat on of mach nery: MRXBOX95B-WM1
Mach nery Types: Mec anical Ventilation wit
Heat Recovery and Integral Frost
Protection
Relevant EC Counc l D rect ves: 2006/42/EC (Mac inery Directive)
Appl ed Harmon sed Standards: BS EN ISO 12100-1, BS EN ISO 12100-2,
EN60204-1, BS EN ISO 9001,
BS EN ISO 13857
Appl ed Nat onal Standards: BS848 Parts 1, 2.2 and 5
Sgnature of manufacture representat ves:
Name: Position: Date:
1) C. Biggs Tec nical Director 05 09. 13
2) A. Jones Manufacturing Director 05 09. 13
Note: All standards used were current and valid at t e date of signature.
DECLARATION OF INCORPORATION AND INFORMATION
FOR SAFE INSTALLATION, OPERATION AND MAINTENANCE
DECLARATION OF CONFORMITY

811. 09. 14. Leaflet Number 671631
Western Industrial Estate
Caerp illy United Kingdom
CF83 1NA
T: 029 2085 8400
F: 029 2085 8444
E: [email protected]
W: www.nuaire.co.uk
Tec nical or commercial considerations may, from time to time, make it necessary to alter t e design, performance and
dimensions of equipment and t e rig t is reserved to make suc c anges wit out prior notice.

Standard Assessment Procedure 2005 – Appendix Q MVHR Installation Guide
Installation Guide and Checklist
Mechanical Ventilation with Heat Recovery
(Version – 11 February 2011)
The Electric Heating and Ventilation Association have developed this guidance and
checklist document in partnership with the Residential Ventilation Association
(a HEVAC association), BRE and EST.
NOTE: This guide and checklist has been superseded for dwellings assessed under
‘The Building Regulations 2010’, specifically SAP 2009 and Approved Documents L and
F. Completion of this document is therefore only required for dwellings assessed by
SAP 2005.
Customer Details
Customer Name:
Address:
Telephone Number:
Date of Installation:
Name of Lead Contractor:
Design Project Number:
It should be noted that this guidance is not intended to replace product
manufacturer installation instructions; it is a generic addition which defines good
practice. Installers are advised to complete this form for each installation and
keep a copy to provide to Building Control Officers in case requested.

Standard Assessment Procedure 2005 – Appendix Q MVHR Installation Guide
Page 2 of 6
Introduction
This document is to be used in support of the SAP Appendix Q scheme which provides
tested performance values for MVHR products.
Note that all checklist items must be answered YES in order for the SAP Appendix Q
test figures to be used in ‘As built’ SAP calculations. If any checklist items are answered
NO then SAP default figures must be used. Systems must be designed by a
manufacturer designer and sized correctly to qualify for SAP Appendix Q figures.
SECTION 1: INSTALLATION GUIDANCE
1. Ductwork Installation
Decision
Yes, No or
N/A
Have the ducts been installed with as little air resistance and
leakages as possible (flexible ducts should be avoided)?
Note: Refer to HVCA DW/143 document ‘A Practical Guide to Ductwork Leakage
Testing’ for detailed guidance on air tightness. Rigid plastic ducting is
recommended and flexible duct should only be used in very short lengths and
mainly just to connect the ductwork to the units/diffusers or to overcome particular
obstructions.
If flexible ducting has been used, has it been pulled taut to minimise
system resistance?
Has the number of duct bends been minimised to ensure adequate
air flow and least resistance? Bends should have a minimum radius
at least the same as the diameter of the ducting used?
Refer to Figure 1 if using flexible ducting
Have the fans and ducting placed in unheated voids been insulated
to reduce the possibility of condensation forming (see notes below)?
Note: Ducts should be insulated with the equivalent of at least 25mm of insulating
material with a thermal conductivity of 0.04W/mK. Where a duct rises vertically it
may be necessary to fit a condensation trap in order to prevent backflow of any
moisture in the product. Insulation should be applied to both warm and cold air
ducts. Cold air ducts should be wrapped additionally with a vapour barrier outside
the insulation. Ducts with cold air running in warm environments will condense on
the outside of the duct.
Have recommended duct jointing collars and components been
used to ensure appropriate duct performance (duct runs should be
as air tight as possible)?
Note: All the joints should be sealed correctly either using duct tape or silicon.

Standard Assessment Procedure 2005 – Appendix Q MVHR Installation Guide
Page 3 of 6
Figure 1 Ductwork Visual Guide
Source: Approved Document F (England & Wales) 2006
2. Unit Fixing
Decision
Yes, No or
N/A
Has the heat recovery unit been effectively insulated?
Note: If the unit is not pre-insulated then ensure additional insulation is installed
around the unit to minimise heat loss
Has the heat recovery unit been fixed to a stable element of the
building fabric (e.g. wall or floor) using manufacturer
recommended/supplied fixing brackets?
Has the condensation drain been fitted and the pipe insulated?
Have approved acoustic/anti-vibration mountings been used?
Note: Special attention is needed to avoid transmission and stress to duct joints
Has the unit been installed in a position that will permit access for
maintenance purposes?
Have all grilles or ductwork that penetrate the building’s air barrier,
as identified in the construction drawings, been sealed to ensure
continuity of the air barrier?

Standard Assessment Procedure 2005 – Appendix Q MVHR Installation Guide
Page 4 of 6
Figure 2 Sample Mounting Positions
3. Electrical Connection
Decision
Yes, No or
N/A
Has the rating label been verified to establish suitability for the
installation strategy and whether an earth is required (e.g. voltage,
class I or II product status)?
Has a local isolator been provided to enable the unit to be isolated
for maintenance purposes?
Has the unit been fused in accordance with its power rating?
SECTION 2: COMMISSIONING GUIDANCE

Standard Assessment Procedure 2005 – Appendix Q MVHR Installation Guide
Page 5 of 6
1. System Balancing & Calibration
Decision
Yes, No or
N/A
Has the air flow been checked using a proprietary device such as
an anemometer (recommended)?
Have the controls been set following a defined process?
Refer to figure 3 flow diagram
Have all distribution grilles been locked where possible to minimise
unapproved occupant adjustment?
Figure 3
Ensure all external and internal
windows and doors are closed
Set fan speed using manufacturer data
table
Set normal daytime air flow on extract
points starting at location furthest from
unit
Set normal daytime air flow on input
points starting at location furthest from
unit
Step 1
Step 2
Step 3
Step 4
Step 5
Set fan speed to boost and measure
extract rates at each location, adjust
fan speed setting as required to
achieve required flow

Standard Assessment Procedure 2005 – Appendix Q MVHR Installation Guide
Page 6 of 6
2. Handover and Control/Maintenance Advice
Decision
Yes, No or
N/A
Has the customer been supplied with suitable documentation
detailing maintenance and operational requirements?
Has the customer been advised that opening windows is not
recommended during normal use in order to ensure the energy
efficient operation and performance of the balanced system?
Has the customer been advised not to seal natural air flows from
room to room (e.g. avoid door seals and thick pile carpets)
Has the customer been advised not to alter settings post-
commissioning?
Has the customer been advised to clean the filters as explained in
the manufacturer’s instructions?
