NUK 10.749.057 User manual

NUK Humidifier
NUK Humidificador
Art. No. 10.749.057
Operating Instructions
Manual de instrucciones
Luftbefeuchter 1108 Seite 1 Mittwoch, 25. Februar 2009 10:21 10

English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Please see inside cover fold-out page
Español . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Observar la portada plegable
Português . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
É favor observar a folha desdobrável
Italiano . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Leggere attentamente la pagina pieghevole
Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Veuillez tenir compte des informations fournies sur les rabats
Ελληνικά . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Παρακαλούμε προσέξτε την αναδιπλούμενη σελίδα
Türkçe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Lütfen açılan resimli sayfayı dikkate alınız
 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
.   
Polski . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Przy czytaniu proszę otworzyć rozkładaną stronę okładki
Deutsch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Bitte Ausklappseite beachten
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Luftbefeuchter 1108 Seite 1 Mittwoch, 25. Februar 2009 10:21 10

5.
2.
1.
3.
4.
6.
Luftbefeuchter 1108 Seite 1 Mittwoch, 25. Februar 2009 10:21 10

8.
7.
9.
10.
Luftbefeuchter 1108 Seite 2 Mittwoch, 25. Februar 2009 10:21 10

12
3
4
798
6
5
11.
Luftbefeuchter 1108 Seite 3 Mittwoch, 25. Februar 2009 10:21 10

Luftbefeuchter 1108 Seite 2 Mittwoch, 25. Februar 2009 10:21 10

3
Contents
1. Important Information Before First Use . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2. Components of the Humidifier (see Figure 11). . . . . . . . . . . . . . . . . . . . . . . 4
3. Description of Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.1 Intended Purpose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.2 Scope of Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.3 Description of Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
3.4 Symbols on the Appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4. Warnings and Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4.1 Explanation of Terms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4.2 General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4.3 Protection From Electric Shock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4.4 ForYour Child’s Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.5 Handling Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5. Unpack and Set Up Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5.1 Humidifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5.2 Hygro-thermometer (Moisture andTemperature Measuring Instrument) . . . . . . . . . . . . 7
6. Operate the Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
6.1 Using for the First Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
6.2 Switching the Appliance Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
7. Clean and Maintain Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
7.1 Empty and Dismantle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
7.2 Clean . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
7.3 Disinfect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
7.4 Descale . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
7.5 Assemble. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
8. Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
9. Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
10. Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
10.1 Humidifier and Hygro-thermometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
10.2 Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
10.3 Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
11. Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Luftbefeuchter 1108 Seite 3 Mittwoch, 25. Februar 2009 10:21 10

4
Dear Parents
Congratulations on deciding to purchase our
NUK Humidifier – a decision in favour of quality
and safety.
This humidifier helps improve the air in a child’s
room by ensuring that it is at a pleasant
humidity. This prevents excessively dry air
leading to your baby suffering from irritated
mucous membranes, dry, cracked skin, a dry,
sore throat and cracked lips.At the same time,
it also reduces the risk of flu, colds and some
fungal and bacterial infections, as humidification
stops your baby’s resistance being weakened by
excessively dry air.
We wish your baby a healthy development.
1. Important Information Before First Use
These operating instructions will help you use
your humidifier safely and economically.
Anyone setting up, operating, cleaning or
disposing of this appliance must have noted and
understood the complete contents of these
operating instructions.
For this reason, you should keep these
instructions somewhere safe so that they are
available whenever required.
If you ever sell or give away your appliance,
please pass on these operating instructions as
well, so that the next user can also use the
appliance safely.
2. Components of the Humidifier
(see Figure 11)
1 Rotating mist outlet
2 Mist duct
3 Water tank
4 Control knob for "On/Off" and infinite
adjustment of mist intensity
5 Indicator lamp
6 Mains plug
7 Water level sensor
8 Atomizer
9 Base of appliance
3. Description of Appliance
3.1 Intended Purpose
This NUK Humidifier increases humidity indoors
and thus prevents the air becoming too dry.
This appliance may only be used in dry indoor
areas. Use outdoors or in damp areas is
prohibited.This appliance is intended for use in
private households and is not suitable for
commercial use.
Humidity is a measure of how much water
vapour there is in the air.
The quantity of water vapour the air can absorb
is highly dependent on temperature.The higher
the air temperature, the more water vapour
can be absorbed.
When the air is fully saturated (e.g. when it is
foggy or raining), in other words when it cannot
absorb any more water, we talk about a relative
humidity of 100%.
We feel best at a relative humidity of 40-55%.
A relative humidity of less than 30% is perceived as
too dry. The hygro-thermometer (moisture and
temperature measuring instrument) supplied enab-
les you to measure relative humidity at any time.
Luftbefeuchter 1108 Seite 4 Mittwoch, 25. Februar 2009 10:21 10

5
3.2 Scope of Supply
• 1 NUK Humidifier, complete
• 1 digital hygro-thermometer (moisture and
temperature measuring instrument)
• 1 set of operating instructions
3.3 Description of Function
This humidifier is electronically operated. High
frequency ultrasound at the atomizer breaks the
water inside the humidifier down into
minuscule droplets.The ventilation system gives
off these droplets into the ambient air in the
form of a microfine mist. Here the mist
evaporates and thus increases humidity. The
benefit of ultrasound atomization is that it is
very quiet in operation and will not disturb your
child's sleep.
In contrast to water evaporators, this appliance
also has a very low power consumption. The
water level sensor integrated in the appliance
ensures that the mist stops being sprayed
automatically when the water level is too low.
This automatic cut-out protects the atomizer
from overheating. However, the appliance stays
switched on and the fan continues to run.
3.4 Symbols on the Appliance
4. Warnings and Precautions
This device is designed and built to state-of-the-
art technology. All relevant European safety
directives have been observed and the device
has been tested in accordance with the relevant
standard. However, there are potential hazards
from using this type of equipment.
Please read these instructions to ensure your
own safety! It will take no longer than 5
minutes.
4.1 Explanation ofTerms
The following signs are used in these operating
instructions:
Warning!
High risk: Non-observance of the
warning may result in minor or
serious injury.
Caution!
Medium risk: Non-observance of the warning
may result in damage.
Important:
Low risk: Information on how to handle the
device should be observed.
4.2 General Information
• These operating instructions should be read
carefully before use. They are part of this
equipment and must be kept readily availa-
ble at all times.
• The device should be used solely for the
intended purpose as described (see
“3.1 Intended Purpose” on page 4).
• Check whether the required voltage agrees
with your local voltage (see nameplate on
device).
• This equipment is not intended for use by
persons (including children) with limited
physical, sensory or mental abilities or with
insufficient experience and/or insufficient
knowledge, unless the person concerned is
either supervised by a person responsible
for his/her safety, or receives instructions
from this person as to how to use the
equipment. Children should be supervised
in order to ensure that they do not play
with the device.
Symbol Location Meaning
Base of
appliance 9
Only empty water
in this direction
TOP Float ring of
water level
sensor 7
This marking must
point upwards
Luftbefeuchter 1108 Seite 5 Mittwoch, 25. Februar 2009 10:21 10

6
• Please observe the fact that any claim under
warranty and liability will be declared void if
accessories are used that are not
recommended in these operating
instructions or, in the case of repairs, if
original parts are not used exclusively. This
also applies to repairs undertaken by non-
qualified persons. The contact address can
be found at the end of these operating
instructions.
• In the event of a breakdown, maintenance
work on the device may only be undertaken
by a qualified person. If this is not adhered
to, any claims under warranty will be
declared null and void.
• Ensure that the mains cable is never a
tripping hazard and that no-one can get
tangled in it or tread on it.
• The appliance may only be set up on a firm,
level, dry and non-flammable surface.
• Do not set up the appliance close to hot
surfaces, hot ovens or close to gas or
electrical appliances, as this might damage
the appliance.
• Never use the appliance without water and
do not add any substances for inhalation or
essential oils, as these might damage it.
• Do not point the mist coming out of the
appliance directly at furniture or other
objects, as the mist might condense there
before it evaporates.
• Never cover the appliance with a towel or
other objects while it is running.
• Disconnect the appliance from the mains
after use so that it cannot be switched on
inadvertently.
4.3 Protection From Electric Shock
Warning! The following safety
information is intended to protect you
against electric shock.
• Use the appliance only if the appliance and
mains cable are undamaged.
• If the mains cable is damaged, it should be
replaced by the manufacturer, its Customer
Service department or a similarly qualified
person in order to prevent hazards.
• Never open the base of the appliance
yourself or try to repair it. Only qualified
professionals may do this.
• Always disconnect the mains plug before
filling, emptying, cleaning, disinfecting or
descaling the appliance.
• No water or other liquids should get into
the appliance under any circumstances,
except in the containers intended for this
(water tank and water collector in the base
of the appliance above the atomizer).
Consequently:
– never use the appliance outdoors
– never immerse the base of the appliance
in water
– never use the appliance in a very damp
environment where the humidity is
already above 55%
– do not operate right next to a
washbasin.
If liquid ever does get into the appliance,
disconnect it from the mains power supply
immediately and have the appliance repaired
by a qualified professional. The contact
address can be found at the end of these
operating instructions.
• Never touch the device, the mains lead or
the plug with wet hands.
• Always remove the plug from the socket by
pulling on the plug. Never pull on the lead
itself.
• Ensure that the lead never becomes bent or
squashed.
• Keep the mains cable away from hot
surfaces (e.g. cooker hotplates).
• Avoid the use of extension leads. These
should only be used in specific cases:
– The extension lead must be suitable for
the current specified for the device.
Luftbefeuchter 1108 Seite 6 Mittwoch, 25. Februar 2009 10:21 10

7
– The extension lead must not be laid
"freely”: it must be secured so as to pre-
vent accidents and must be kept out of
the reach of children.
– The extension lead must on no account
be damaged.
– No other equipment should be plugged
into the socket at the same time, as this
will overload the mains supply (i.e. no
multi-pin sockets to be used!).
4.4 ForYour Child’s Safety
Warning! Children often do not
recognise danger
and can therefore
sustain injury. For this reason please
observe the following:
• This product may only be used under super-
vision from adults, in order to ensure that
children do not play with the device.
• Always ensure that the device is kept out of
the reach of children.
• Always ensure that children are never able
to pull on the cable.
• Always ensure that the plastic packaging
does not pose a fatal risk to children.
Packaging is not meant as a toy.
4.5 Handling Batteries
• The battery must be removed when flat or
if the hygro-thermometer is not going to be
used for a prolonged period. A leaking
battery might otherwise damage the
instrument.
• Do not dispose of flat batteries with
household waste. Take them to a battery
collection point.
• Take care to insert the battery with the
correct polarity (+/–).
• Batteries should never be charged or
thrown on a fire - risk of explosion.
• Use only the quoted battery type (AG13,
1.5V).
5. Unpack and Set Up Appliance
5.1 Humidifier
1. Take the individual parts out of the
packaging.
2. Check that the individual parts are complete
(see section 3.2 on page 5) and undamaged.
3. Clean the appliance thoroughly before using
it for the first time (see section 7. on
page 9).
Important: A new appliance may smell a
little if it is not cleaned beforehand.
4. Before switching the humidifier on, put it in
the room where it is to be operated for half
an hour.
This is intended to ensure that the
humidifier is at the same temperature as the
room, which will make it function more
accurately.
5. Place the appliance on a level, dry, non-slip
surface.
5.2 Hygro-thermometer (Moisture
andTemperature Measuring
Instrument)
Measuring range for humidity: 20% to 99%
Measuring range for temperature: –10°C to
+50°C or 14°F to 122°F.
Important: The hygro-thermometer must be
calibrated before being used for the first time.
Prolonged use in an overheated room with dry
air may likewise impair the sensitive parts of the
instrument, requiring it to be recalibrated.To do
this, wrap the appliance in a damp cloth for an
hour. This increases moisture to a maximum.
The instrument is recalibrated and operational
(again).
Luftbefeuchter 1108 Seite 7 Mittwoch, 25. Februar 2009 10:21 10

8
1. To start the instrument, open the battery
compartment and remove the safety strip
from the battery.
The instrument is now operational and
displays humidity and temperature.
2. To switch the temperature display from
"°C" to "°F", press the button in the rear of
the instrument using a thin and spiky object
(such as a toothpick).
3. Now check the humidity in your baby’s
room. To do this, place the instrument
about 1m away from the humidifier and as
far away as possible from any direct source
of heat like a radiator or the sun.
Important: As soon as the display becomes
unclear, replace the battery with a new one,
type AG13 1.5V.
Important: Recommended room temperature
is about 16-20°C, recommended relative
humidity is about 40-55%.
6. Operate the Appliance
6.1 Using for the FirstTime
Warning!
To protect you against electric shock
always disconnect the mains plug
before filling the water tank.
1. Take water tank 3 off base of the appliance
9 (Figure 1).
2. Turn over water tank 3 and unscrew the
sealing cap (Figure 2).
Warning!
To prevent limescale deposits and
growth of bacteria hazardous to
health:
• it is essential to use fresh and clean,
ideally boiled or distilled water every
time you use the appliance.
• the water temperature should not
exceed 20°C.
• never use additives such as substances
for inhalation or essential oils.
3. Fill water tank 3 with up to 2l of water as
required (Figure 3).
4. Screw sealing cap tightlyonto water tank
3
(Figure 4).
5. Put water tank 3 back on base of the
appliance 9 (Figure 5).
6. Plug the mains plug into a mains electricity
supply socket (220–240V~/50Hz) (Figure 6).
7. Turn control knob 4 clockwise beyond the
noticeable resistance (Figure 6).
The appliance is now switched on and
indicator lamp 5 comes on. Steam becomes
visible within a few seconds.
8. Regulate the intensity of humidification at
control knob 4 (Figure 7).
9. Turn mist outlet 1 in the desired direction.
10. Check humidity regularly using the hygro-
thermometer (moisture and temperature
measuring instrument) supplied. Humidity
should be between 40 and 55%.
6.2 Switching the Appliance Off
1. Switch off the humidifier by turning control
knob 4 anticlockwise beyond the noticeable
resistance (Figure 8).
The appliance is now switched off and
indicator lamp 5 goes out.
2. Empty water tank 3and base of the appliance
9in the direction of the arrow (Figure 9) after
every use, especially if the appliance is not to
Luftbefeuchter 1108 Seite 8 Mittwoch, 25. Februar 2009 10:21 10

9
be used for a prolonged period, e.g. overnight
(see section 7.1 on page 9).
3. Clean the parts of the appliance (see
section 7.2 on page 9).
7. Clean and Maintain Appliance
Warning!
Always disconnect the mains plug
before filling, emptying, cleaning,
disinfecting or descaling the appliance.
7.1 Empty and Dismantle
1. Take water tank 3off base of the appliance
9(Figure 1).
2. Empty water tank 3.
3. Tip out the rest of the water still in base of
the appliance 9.
Caution!There is a marking (arrow) on the
base of the appliance to indicate in which
direction the water should be tipped out
(Figure 9).
4. Take off both parts of water level sensor 7
(locking washer and float ring) in an upward
direction.
Both parts are only pushed on.
7.2 Clean
The appliance should be cleaned after every
use, but at least once a week.
Caution! Use neither corrosive detergents/
scouring agents nor objects made of metal or
other hard materials, as these may attack the
surfaces.
Caution! Do not immerse base of the
appliance 9in water or allow water to
penetrate it, as it contains electrical
components which could be damaged by this.
Important: Regular thorough cleaning of the
appliance after each use, but at least once a
week, will prevent limescale deposits building
up.
1. Rinse mist outlet 1and both parts of water
level sensor 7(locking washer and float
ring) under running water.
2. To clean base of the appliance 9, wipe the
outside of it with a soft clean cloth after
every use (Figure 10). Clean the inside
carefully with a clean, damp cloth and use a
clean paintbrush for tight places if at all
possible.
3. To clean water tank 3, place the tank upside
down on a level, dry and non-slip surface
and fill with 0.5l of boiling water.
Caution! Only put the screw cap on loosely
and do not screw it up tightly:an overpressure
could arise in the tank which might cause
material damage!
Allow the tank to cool down for at least 30
minutes and then empty it.
4. Allow all the cleaned parts of the appliance
to dry in the open.
7.3 Disinfect
The appliance needs disinfecting at least once a
week.
1. Place mist outlet 1, both parts of water
level sensor 7(locking washer and float
ring) and the screw cap together with its
rubber seal (removed) in boiling water for 3
minutes.
2. Fill base of the appliance 9with about
200ml of boiling water, allow to cool for 30
minutes and empty in the direction of the
arrow (Figure 9).
Luftbefeuchter 1108 Seite 9 Mittwoch, 25. Februar 2009 10:21 10

10
3. Allow all the disinfected parts to dry in the
open.
Important:Water tank 3 does not have to be
separately disinfected. The cleaning procedure
with boiling water described above (see section
7.2 on page 9) is sufficient.
7.4 Descale
Regular thorough cleaning of the appliance after
each use in accordance with "7.2 Clean", but at
least once a week, will reduce the build-up of
limescale. However, limescale will start to build
up in the base of the appliance after some time.
Limescale can cause humidification performance
to deteriorate considerably.
Important on preventing limescale:
• It is essential to use fresh and clean, ideally
boiled or distilled water every time you use
the appliance.
• The water temperature should not exceed
20°C.
Important:The process outlined below is best
for mild limescale. If limescale is severe, you
should use a proprietary limescale remover.
Follow the manufacturer's instructions for the
limescale remover.
1. For descaling, mix 50ml of hot water with
50ml of household vinegar and pour into
base of the appliance 9.
2. Allow the solution to take effect for 30
minutes and pour away in the direction of
the arrow (Figure 9).
3. Then wipe out the appliance with a clean,
damp cloth.
4. Place the water tank upside down on a
level, dry and non-slip surface and screw it
on.
5. Mix a fresh solution of about 100ml hot
water and 100ml household vinegar (e.g.
table vinegar) and pour into the water tank.
6. Allow the solution to take effect for at least
4 hours, ideally overnight.
7. Empty the water tank.
8. Rinse out the water tank 2–3 times with
clean water.
7.5 Assemble
1. Put both parts of water level sensor 7, first
the float ring and then the locking washer,
into base of the appliance 9.
Important: The "TOP" marking on the
float ring must point upwards.
2. Screw up water tank 3tightly and put on
base of the appliance 9(Figure 1).
Luftbefeuchter 1108 Seite 10 Mittwoch, 25. Februar 2009 10:21 10

11
8. Troubleshooting
9. Technical Data
Voltage: (220–240V~/50Hz)
Power consumption: 40W
Protection class: II
Atomizer output: approx. 250ml/h
Capacity: max. 2l
Hygro-thermometer: 1 AG13, 1.5V-type battery
Fault Cause Remedy
Indicator lamp does not
come on, appliance does
not work.
Humidifier not (properly)
connected to the power supply.
Plug the mains supply plug (properly)
into the socket and switch on the
humidifier.
The indicator lamp is on,
the fan is running, but no
mist is produced.
The water tank is empty or the
water level is too low.
Fill the water tank with fresh, ideally
boiled or distilled water.
The float ring of the water level
sensor is not fitted or is not
fitted correctly.
Check the float ring.The "TOP"
marking must be pointing upwards.
The humidifier is making
an unpleasant smell.
The appliance is still new. Clean the humidifier in accordance
with 7.2 on page 9.
The humidifier contains stale,
dirty water.
Clean the water tank in accordance
with 7.2 on page 9 and fill it with
fresh, ideally boiled or distilled water.
The humidifier is not
generating sufficient mist.
There is limescale on the
atomizer.
Descale the atomizer.
The water tank does not
contain enough water.
Fill the water tank with fresh, ideally
boiled or distilled water.
Luftbefeuchter 1108 Seite 11 Mittwoch, 25. Februar 2009 10:21 10

12
10. Disposal
10.1 Humidifier and
Hygro-thermometer
The symbol of the crossed-
through wheelie bin means, within
the European Union, that the
product is subject to a separate
waste collection. This applies to
the product and all accessories
marked with this symbol. Products
labelled as such must not be disposed of with
the normal household waste collections; they
must be taken to a recycling bank for electrical
and electronic equipment. Recycling helps to
reduce the use of raw materials and is eco-
friendly.
10.2 Packaging
If you wish to dispose of the packaging, follow
the environmental regulations applicable in your
country.
10.3 Batteries
Every consumer is legally obliged to take all
batteries and rechargeable batteries, regardless
of whether they contain harmful substances or
not, to a collection point or to a retailer so that
they can be routed to environmentally-friendly
disposal.
The battery of the hygro-thermometer (type
AG13, 1.5V) should only be handed in when
flat!
11. Warranty
When used with care and observing the operat-
ing instructions the manufacturer will guarantee
the product for 2 years from the date of pur-
chase.
We agree to repair the device free of charge,
providing it is either a material or design fault.
All other claims are excluded.
Any damage resulting from improper use of the
device will not be rectified. Leads and plugs are
excluded from the warranty if caused by wear.
Within the first 2 years from the date of pur-
chase we will rectify without additional charge
any faults recognised as being justified. All costs
are to be clarified in advance.
When returning the device the warranty certifi-
cate or proof of purchase must be enclosed at
all times.
Without proof of purchase you will be charged.
The goods will be returned via COD.
Please complete the warranty certificate imme-
diately after purchase and keep in a safe place.
Warranty certificates that are mislaid will not
be replaced.
The Warranty Certificate is to be found at the
end of this booklet.
Luftbefeuchter 1108 Seite 12 Mittwoch, 25. Februar 2009 10:21 10

13
Índice
1. Notas importantes antes del primer uso. . . . . . . . . . . . . . . . . . . . . . . . . . 14
2. Componentes del humidificador (ver figura 11) . . . . . . . . . . . . . . . . . . . . . 14
3. Descripción del aparato . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.1 Uso previsto . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.2 Piezas suministradas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.3 Descripción del funcionamiento. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.4 Señalización en el aparato. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4. Indicaciones de seguridad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.1 Explicación de conceptos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.2 Indicaciones generales . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.3 Protección frente a descarga eléctrica. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.4 Para la seguridad de su bebé . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.5 Manipulación de las pilas. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5. Desembalar y colocar el aparato . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.1 Humidificador . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.2 Higrómetro-termómetro (medidor de humedad y temperatura). . . . . . . . . . . . . . . . . . 18
6. Manejo del aparato . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.1 Poner en funcionamiento . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6.2 Poner fuera de servicio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7. Limpiar y cuidar el aparato. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
7.1 Vaciar y desmontar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
7.2 Limpieza . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
7.3 Desinfección . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
7.4 Desincrustar la cal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7.5 Ensamblar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
8. Solución de fallos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
9. Datos técnicos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
10. Eliminación . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
10.1 Humidificador e higrómetro-termómetro. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
10.2 Embalaje . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
10.3 Pilas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
11. Garantía . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Luftbefeuchter 1108 Seite 13 Mittwoch, 25. Februar 2009 10:21 10

14
Estimados padres
Les agradecemos su elección por nuestro
humidificador NUK y, con ello, por la calidad y
la seguridad.
Este humidificador colabora a mejorar el aire en
la habitación de los niños, logrando con ello un
ambiente de humedad agradable del aire. De
esta manera impide que el aire demasiado seco
reseque excesivamente las mucosas de su bebé
provocando irritaciones, sequedad y grietas, la
garganta seca e irritada, así como los labios
agrietados. Al mismo tiempo con ello se
previene el riesgo de contraer una gripe o
resfriado, así como algunas infecciones por
hongos y bacterias, impidiendo con ello que las
defensas de su bebé se debiliten debido a un
aire demasiado seco.
Le deseamos un sano desarrollo de su bebé.
1. Notas importantes antes del primer uso
Estas instrucciones de uso le ayudarán a utilizar
su humidificador de forma segura y económica.
Toda persona que instale, maneje, limpie o
elimine este aparato, debe haber tomado
conocimiento y entendido todo el contenido de
estas instrucciones de uso.
Por ello, guarde bien estas instrucciones de uso,
para poder disponer de ellas en todo momento.
Si vende o regala su aparato, entregue con él
estas instrucciones de uso, para que el siguiente
propietario pueda utilizarlo también de forma
segura.
2. Componentes del humidificador (ver figura 11)
1Salida giratoria de la nebulización
2Canal de nebulización
3Depósito de agua
4Botón de mando para "on/off" y ajuste
continuo de la intensidad de la nebulización
5Lámpara de control
6Enchufe de la red
7Sensor del nivel del agua
8Nebulizador
9Base del aparato
3. Descripción del aparato
3.1 Uso previsto
Con este humidificador NUK se incrementa la
humedad relativa del aire en los recintos
interiores y con ello se impide que el aire sea
demasiado seco.
Este aparato sólo debe utilizarse en recintos
interiores secos. No es permisible su uso a la
intemperie o en recintos húmedos.
Este aparato sólo es apropiado para el uso
doméstico privado y no para fines industriales.
La humedad del aire indica la cantidad de vapor
de agua presente en el aire.
La cantidad de vapor de agua que puede
absorber el aire, depende mucho de la
temperatura. Cuanto más elevada sea la
temperatura del aire, más vapor de agua podrá
absorber.
Cuando el aire está totalmente saturado (p.ej.
cuando hay niebla o llueve), y por lo tanto ya no
puede absorber más agua, se dice que tiene una
humedad relativa del 100 %.
Luftbefeuchter 1108 Seite 14 Mittwoch, 25. Februar 2009 10:21 10

15
Con una humedad relativa del aire del 40 - 55 %
es cuando nos encontramos más a gusto. Una
humedad relativa del aire inferior al 30 % se
percibe como demasiado seca. Con el
higrómetro-termómetro (medidor de humedad
y de temperatura) puede medir en todo
momento la humedad relativa del aire.
3.2 Piezas suministradas
• 1 humidificador NUK, completo
• 1 higrómetro-termómetro
(medidor de humedad y temperatura)
• 1 instrucciones de uso
3.3 Descripción del funcionamiento
Este humidificador funciona eléctricamente. El
agua que se encuentra en el aparato es dividida
en pequeñísimas gotitas en el nebulizador,
mediante un proceso de alta frecuencia de
ultrasonidos. Estas gotitas se lanzan en forma de
nebulización microfina a través del sistema de
ventilación al aire ambiental. Allí se evapora la
nebulización y, de esta manera, se incrementa la
humedad del aire. La ventaja de la nebulización
ultrasónica es su funcionamiento silencioso, de
manera que el sueño del niño no se ve
perturbado.
Al contrario que los evaporadores de agua, este
aparato tiene además un consumo muy bajo de
corriente. Cuando el nivel de agua es
demasiado bajo, el sensor del nivel del agua
integrado en el aparato se encarga de que se
desconecte automáticamente la nebulización.
Este sistema automático de desconexión
protege al nebulizador del sobrecalentamiento.
No obstante, el aparato continúa conectado y
el ventilador sigue funcionando.
3.4 Señalización en el aparato
4. Indicaciones de seguridad
Este aparato está construido y fabricado según el
actual estado de la técnica. Se han aplicado todas
las correspondientes Directivas europeas de
seguridad y el aparato se ha verificado de
acuerdo con la norma. No obstante, este tipo de
aparatos también pueden suponer una fuente de
riesgos.
¡Vale la pena que dedique 5 minutos a su
seguridad! No precisará más tiempo para leer
nuestras indicaciones de seguridad.
4.1 Explicación de conceptos
En estas instrucciones de uso encontrará los
siguientes conceptos señalizados:
¡Advertencia!
Riesgo elevado: La no observancia de
las advertencias puede causar lesiones
corporales o incluso la muerte.
¡Precaución!
Riesgo medio: La no observancia de las
advertencias puede causar daños materiales.
Nota:
Riesgo reducido: Comportamientos técnicos
que se deben observar al manipular el aparato.
4.2 Indicaciones generales
• Antes del uso, lea atentamente estas
instrucciones de uso. Éstas forman parte del
aparato y tienen que estar a mano en todo
momento.
Símbolo Lugar Significado
Base del
aparato 9
Vaciar el agua sólo
en esta dirección
TOP Anillo
flotador del
sensor del
nivel del agua
7
Esta marca debe
señalar hacia arriba
Luftbefeuchter 1108 Seite 15 Mittwoch, 25. Februar 2009 10:21 10

16
• Utilice el aparato solamente para el uso
descrito (ver la sección 3.1 en la página 14).
• Compruebe si la tensión de red necesaria
(ver placa de características en el aparato)
coincide con su tensión de red.
• Este aparato no está destinado a ser
utilizado por personas (incluidos niños) con
capacidades físicas, sensoriales o
intelectuales limitadas o con insuficiente
experiencia y/o con insuficientes
conocimientos, a no ser que sean
supervisadas por una persona encargada de
su seguridad o hayan recibido instrucciones
sobre cómo se debe utilizar el aparato. Se
debe vigilar a los niños, para asegurar que
no jueguen con el aparato.
• Debe tenerse en cuenta que se extingue
cualquier derecho de garantía y
responsabilidad en caso de utilizar
accesorios que no sean recomendados en
estas instrucciones de uso o de no emplear
únicamente repuestos originales en caso de
reparaciones. Lo mismo es aplicable en caso
de ejecución de las reparaciones por
personas no cualificadas. Al final de estas
instrucciones de uso encontrará la dirección
de contacto.
• En caso de eventuales fallos de
funcionamiento, la reparación del aparato
debe ser ejecutada únicamente por una
persona cualificada. De lo contrario, se
extingue todo derecho de garantía.
• Preste atención a que el cable de la red no
pueda ser causa de tropiezos, ni que nadie
se pueda enredar con él o pisarlo.
• El aparato sólo debe colocarse sobre una
base firme, plana, seca y no inflamable.
• No colocar el aparato cerca de superficies
muy calientes, en hornos calientes o cerca
de aparatos eléctricos o de gas, ya que el
aparato podría resultar dañado.
• No ponga nunca el aparato en
funcionamiento sin agua, ni le agregue
productos para inhalación o aceites
esenciales, ya que podría resultar dañado.
• No dirija la nebulización que sale
directamente contra muebles u otros
objetos, ya que podría provocar
condensación antes de evaporarse.
• No cubra nunca el aparato durante el
funcionamiento con una toalla, ni con otros
objetos.
• Desconecte el aparato de la red después de
su utilización, para que no pueda ser
conectado accidentalmente.
4.3 Protección frente a descarga
eléctrica
¡Advertencia! Las siguientes
indicaciones de seguridad están
indicadas frente a posible una descarga
eléctrica.
• Utilice el aparato solamente cuando estén
intactos el aparato y el cable de la red.
• Si el cable de red está dañado, deberá ser
sustituido por el fabricante, el servicio
técnico o una persona cualificada, a fin de
prevenir riesgos.
• No abra nunca la base del aparato, ni realice
intentos de reparación. Esto sólo debe
realizarlo personal experto cualificado.
• Desconecte siempre el enchufe de la red,
antes de llenar, vaciar, limpiar, desinfectar o
desincrustar de cal el aparato.
• En el aparato no debe entrar en ningún caso
agua u otros líquidos, excepto en los
recipientes previstos para ello (depósito de
agua y cubeta de agua en la base del aparato
sobre el nebulizador). Por ello:
– no emplearlo nunca a la intemperie
– no sumergir nunca la base del aparato en
el agua
– no emplearlo nunca en ambientes muy
húmedos, cuando la humedad del aire ya
supera el 55 %
– no hacerlo funcionar cerca de un
fregadero.
Luftbefeuchter 1108 Seite 16 Mittwoch, 25. Februar 2009 10:21 10
