Numark MATRIX2 User manual

Matrix 2 Operating Instructions

PAGE 1 SAFETY PRECAUTIONS
Thank you for buying this Numark product.
Please read these operating instructions so you will know how to operate this equipment properly.
After you have finished reading these instructions, keep them for future reference.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
CAUTION:
This product satisfies FCC regulations when shielded cables and connectors are used to connect the unit to other
equipment. To prevent electromagnetic interference with electric appliances such as radios and televisions, use
shielded cables and connectors for connections.
IMPORTANT NOTICE:
RECORD THE MODEL NUMBER AND SERIAL NUMBER OF THIS EQUIPMENT BELOW.
MODEL NO: Matrix-2
SERIAL NO:
SAFETY PRECAUTIONS
READ INSTRUCTIONS
All the safety and operating instructions should be read before the product is
operated.
RETAIN INSTRUCTIONS
The safety and operating instructions should be retained for future
reference.
HEED WARNINGS
All warnings on the product and in the operating instructions should be
adhered to.
FOLLOW INSTRUCTIONS
All operating and use instructions should be followed.
CLEANING
Unplug this product from the wall outlet before cleaning. The product should
be cleaned only with a polishing cloth or a soft dry cloth. Never clean with
furniture wax, benzene, insecticides or other volatile liquids since they may
corrode the cabinet.
ATTACHMENTS
Do not use attachments not recommended by the product manufacturer as
they may cause hazards.
WATER AND MOISTURE
Do not use this product near water - for example, near a bathtub, washbowl,
kitchen sink, or laundry tub; in a wet basement; or near a swimming pool;
and the like.
ACCESSORIES
Do not place this product on an unstable cart, stand, tripod, bracket, or
table. The product may fall, causing serious injury to a child or adult and
serious damage to the product. Use only with a cart, stand, tripod, bracket,
or table recommended by the manufacturer, or sold with the product. Any
mounting of the product should follow the manufacturer's instructions, and
should use a mounting accessory recommended by the manufacturer.
CART
A product and cart combination should be moved with care. Quick stops,
excessive force, and uneven surfaces may cause the product and cart
combination to overturn.
POWER SOURCES
This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power
supply to your home, consult your product dealer or local power company.
LOCATION
The appliance should be installed in a stable location.
NONUSE PERIODS
The power cord of the appliance should be unplugged from the outlet when
left unused for a long period.
GROUNDING OR POLARIZATION
If this product is equipped with a polarized alternating current line plug (a
plug having one blade wider than the other), it will fit into the outlet only
one way. This is a safety feature. If you are unable to insert the plug fully
into the outlet, try reversing the plug. If the plug should still fail to fit,
contact your electrician to replace your obsolete outlet. Do not defeat the
safety purpose of the polarized plug. If this product is equipped with a three-
wire grounding type plug, a plug having a third (grounding) pin, it will only
fit into a grounding type power outlet. This is a safety feature. If you are
unable to insert the plug into the outlet, contact your electrician to replace
your obsolete outlet. Do not defeat the safety purpose of the grounding type
plug.
POWER-CORD PROTECTION
Power-supply cords should be routed so that they are not likely to be walked
on or pinched by items placed upon or against them, paying particular
attention to cords at plugs, convenience receptacles, and the point where
they exit from the product.
OUTDOORS ANTENNA GROUNDING
If an outside antenna or cable system is connected to the product, be sure
the antenna or cable system is grounded to provide some protection against
voltage surges and built-up static charges. Article 810 of the National
Electrical Code, ANSI/NFPA 70, provides information with regard to proper
grounding of the mast and supporting structure, grounding of the lead-in
wire to an antenna discharge unit, size of grounding conductors, location of
antenna-discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.
LIGHTNING
For added protection for this product during a lightning storm, or when it is
left unattended and unused for long periods, unplug it from the wall outlet
and disconnect the antenna or cable system. This will prevent damage to the
product due to lightning and power-line surges.
POWER LINES
An outside antenna system should not be located in the vicinity of overhead
power lines or other electric light or power circuits, or where it can fall into
such power lines or circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching such power lines or
circuits, as contact with them might be fatal.
OVERLOADING
Do not overload wall outlets, extension cords, or integral convenience
receptacles as this can result in a risk of fire or electric shock.
OBJECT AND LIQUID ENTRY - Never push objects of any kind into this
product through openings as they may touch dangerous voltage points or
short-out parts that could result in a fire or electric shock. Never spill liquid
of any kind on the product.
SERVICING
Do not attempt to service this product yourself as opening or removing
covers may expose you to dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
DAMAGE REQUIRING SERVICE
Unplug this product from the wall outlet and refer servicing to qualified
service personnel under the following conditions:
When the power-supply cord or plug is damaged.
If liquid has been spilled, or objects have fallen into the product.
If the product has been exposed to rain or water.
If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions as an improper adjustment of other controls may result in
damage and will often require extensive work by a qualified technician to
restore the product to its normal operation.
If the product has been dropped or damaged in any way.
When the product exhibits a distinct change in performance - this indicates a
need for service.
REPLACEMENT PARTS
When replacement parts are required, be sure the service technician has
used replacement parts specified by the manufacturer or have the same
characteristics as the original part. Unauthorized substitutions may result in
fire, electric shock, or other hazards.
SAFETY CHECK
Upon completion of any service or repairs to this product, ask the service
technician to perform safety checks to determine that the product is in
proper operating condition.
HEAT
The product should be situated away from heat sources such as radiators,
heat registers, stoves, or other products (including amplifiers) that produce
heat.

HANDLING AND CARE
Location
Install the mixer in a well-ventilated location where it will not be exposed to high temperatures or
humidity. Do not install the mixer in a location that is exposed to direct rays of the sun, or near stoves or
radiators. Excessive heat can adversely affect the cabinet and internal components. Installation of the unit
in a damp or dusty environment may also result in a malfunction or accident. (Avoid installation near
cookers etc., where the unit may be exposed to oily smoke, steam or heat.)
Cleaning the Unit
Use a polishing cloth to wipe off dust and dirt.
Do not spray any cleaners or lubricants into the mixer faders. This may damage the mixer and will void
the product warranty.
When the surfaces are very dirty, wipe with a soft cloth dipped in some neutral cleanser diluted five or six
times with water and wrung out well, then wipe again with a dry clothe.
Do not use furniture wax or cleaners.
Never use thinners, benzene, insecticide sprays or other chemicals on or near this unit, since these may
damage the surface and finishes.
Condensation
When this unit is brought into a warm room from previously cold surroundings or when the room
temperature rises sharply, condensation may form inside, and the unit may not be able to attain its full
performance. In cases like this, allow the unit to stand for about an hour or raise the room temperature
gradually.
PAGE 3 HANDLING AND CARE

PAGE 4SETUP DIAGRAM
SETUP DIAGRAM
Power the mixer before powering the amplifier.
Turn off the amplifier before turning off the mixer.
TO REC
TO AMP
TO CH2
TO CH2
TO CH1
TO CH1

PAGE 2TABLE OF CONTENTS
IMPORTANT
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of un-insulated "dangerous voltage"
within the product's enclosure that may be of sufficient magnitude to constitute
a risk of electric shock to persons.
NOTICE
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
CAUTION!
TO PREVENT THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
TABLE OF CONTENTS
Safety Precautions 1
Handling and Care 3
Setup Diagram 4
Controls
1. Microphone Controls 5
2. Mixing Controls for CH 1 and CH 2 7
3. Meters and Lighting 9
4. Cueing Controls 9
5. Master Output Controls 11
6. Crossfader Controls 11
7. Special Crossfader Related Controls 13
8. Inputs and Outputs 15
9. Customizing and Servicing Your Mixer 17
Specifications 19
Limited Product Warranty 20
Return Information 21

PAGE 5 MICROPHONE CONTROLS
CONTROLS
1. Microphone Controls
"Mic" (Microphone Trim)
This knob adjusts the volume of the main microphone. When turned all the way to the left, the volume is
off. When turned to the right, the volume is at a maximum. The Microphone Trim should be turned
completely to the left when connecting and disconnecting a microphone from the Quarter-Inch
"Microphone" Input on the front panel of the mixer.
"Middle" (Microphone Midrange EQ)
This knob adjusts the low-tone input sound of the microphone. The center position for this control is flat.
Turning this knob to the right increases the low-tone input sound of the microphone. Turning this knob to
the left decreases the low-tone input sound of the microphone.
"Treble" (Microphone High EQ)
This knob adjusts the high-tone input sound of the microphone. The center position for this control is flat.
Turning this knob to the right increases the high-tone input sound of the microphone. Turning this knob to
the left decreases the high-tone input sound of the microphone.
"Bass" (Microphone Low EQ)
This knob adjusts the low-tone input sound of the microphone. The center position for this control is flat.
Turning this knob to the right increases the low-tone input sound of the microphone. Turning this knob to
the left decreases the low-tone input sound of the microphone.
"Microphone" (Quarter Inch Microphone Input)
One microphone can be connected to this Quarter Inch output terminal. The Microphone Trim should
always be at its lowest setting while connecting and disconnecting a microphone to prevent damage to
the mixer and/or your audience.
"PFL" (Microphone Pre Fade Level Cueing)
See Section 4 "Cueing Controls."

PAGE 6MICROPHONE CONTROLS
SECTION 1

PAGE 7 PRIMARY MIXING INPUT CONTROLS
CONTROLS
2. Primary Mixing Input Controls for CH-1 and CH-2
"Gain" (Input Level Trim)
This rotary control adjusts the input signal levels of the inputs. Turning the knob completely to the right
(clockwise) increases the level. Turning the knob completely to the left (counter clockwise) decreases the
level.
"Treble" (Input Level High EQ)
This rotary control adjusts the high-tone sound of the inputs. Turning the knob completely to the right
increases the level (to +10dB at 15kHz.) Turning the knob completely to the left decreases the level (to -
28dB at 15kHz.)
"Middle" (Input Level Midrange EQ)
This rotary control adjusts the mid-tone sound of the inputs. Turning the knob completely to the right
increases the level (to +12dB at 1kHz.) Turning the knob completely to the left decreases the level (to -
32dB at 1kHz.)
"Bass" (Input Level Low EQ)
This rotary control adjusts the low-tone sound of the inputs. Turning the knob completely to the right
increases the level (to +12dB at 40Hz.) Turning the knob completely to the left decreases the level (to -
32dB at 40Hz.)
"PFL" (Input Level Meter and Cue Button)
These meters display the peak levels of the inputs. You can use the "Gain" and EQ controls to match the
levels of input signals while Cueing.
For additional information on Cueing, see Section 4 "Cueing Controls."
"Phono/Line Switch" (Input Selector Switch)
These two-position toggles select what input source is engaged among the connected units (see Section 9
"Inputs and Outputs" for details on connecting sources.)
The CH-1 and CH-2 Input Selectors switch between a line level input (typically a CD player) and a Phono
Level Input (Turntable.)
These toggles can be rotated to suit your mixing preferences by removing the top Mixer Panel. See
Section 10 "Customizing and Servicing your mixer" for details.
Input Level Faders
These slide faders adjust the level for CH-1 and CH-2 respectively.

PAGE 8PRIMARY MIXING INPUT CONTROLS
SECTION 2

PAGE 9 METERS+ LIGHTING, CUEING CONTROLS
CONTROLS
3. Meters and Lighting
"Master Level" (Master Level Meter)
This meter displays the stereo output levels of the master signal. The display ranges from -40dB to
+10dB.
Dual BNC Style Light Connectors
Two BNC style lights can be connected simultaneously to these 12V receptacles.
4. Cueing Controls
"Volume" (Headphone Level)
This rotary control adjusts the levels of the headphones connected to the front panel input. Turning the
knob completely to the right increases the level to and turning the knob completely to the left decreases
the level.
"Split/Blend" (Master/Split Style Headphone Cueing Switch)
The split cueing mode is engaged by depressing the button into the low position. The split mode means
that any selected source (CH-1 to CH-3 and Mic) will be sent to the left channel of the headphones and
the program output is sent to the right. If the blend cueing mode is engaged (the button will be in the up
position) then the cued or master source (dependent on "Mix") will be heard in both the left and right
channels of the headphones.
"Mix" (Master/Cue Blend Control)
This control blends between the cued source(s) and the program output (the program output is the
master signal before it reaches the master level control.) At the center position an even mix of both the
program output and the cued source are monitored. Turning the knob completely to the right selects only
the program output and turning the knob completely to the left monitors only the cued source(s.)
"Headphones" (Quarter Inch and Eighth Inch Headphone Output Terminals)
Two headphones can be connected simultaneously to these Quarter Inch and Eighth Inch output
terminals. The Volume should always be set at its lowest setting while connecting and disconnecting
headphones to prevent damage to headphones and/or your hearing.
"PFL" (CH-1, CH-2, CH-3 and Mic PFL Buttons)
CH-1, CH-2, CH-3 and the Microphone can be sent to the headphones one at a time or simultaneously for
cueing. When depressed, the PFL (cue) button illuminates yellow indicating that the source is being cued.
Use the "Mix" control to get a balance of the cued PFL source(s) and the master output in the
headphones.

METERS+ LIGHTING, CUEING CONTROLS PAGE 10
SECTION 3
SECTION 4

PAGE 11 MASTER OUTPUT, CROSSFADER CONTROLS
CONTROLS
5. Master Output Controls
"Master" (Main Output Level Control)
This rotary control adjusts the main output levels for any equipment connected to the Master Output on
the rear panel (Section 9 "Inputs and Outputs".) Turning the knob completely to the right increases the
level to +10dB and turning the knob completely to the left mutes the signal.
"Booth" (Master/Split Style Headphone Cueing Switch)
This rotary control adjusts the auxiliary (AKA booth) output levels for any equipment connected to the
Booth Output on the rear panel (Section 9 "Inputs and Outputs".) Turning the knob completely to the
right increases the level and turning the knob completely to the left mutes the signal.
Blue Power LED
The blue power LED will illuminate when the mixer has been connected to a power source and switched to
the "on" position (See Section 9 "Inputs and Outputs.")
6. Crossfader Controls
Crossfader with Tracking Light System
This slide fader blends between CH-1 and CH-2. Its action can be fine-tuned using the "Slope" control
switch or it can be reversed or deactivated by the "Direction" switch. A red light glows on either the right,
left or both sides for the Crossfader indicating only the position of the Crossfader, not the amount of
signal being sent to the master output.
"Slope" (Crossfader Curve Style Control)
The position of this switch determines where the startup level of CH-1 and CH-2 lie on the crossfader
(with respect to "Direction.") When switched to the left, the Crossfader will gradually fade the channel in
to the master output signal as it is engaged. When switched to the right, a very sharp fade of the
channel will occur immediately when the fader is engaged.
"Direction" (Crossfader Assignment Reverse and Deactivation Control)
The position of this switch can reverse the assignment of CH-1 and CH-2 or deactivate the Crossfader. In
the left switch setting ("Normal",) CH-1 is assigned to the left side of the Crossfader and CH-2 is assigned
to the right side of the crossfader. In the right switch setting, the assignment of CH-1 and CH-2 are
reversed on the Crossfader. In the center position, the Crossfader is deactivated.

MASTER OUTPUT, CROSSFADER CONTROLS PAGE 12
SECTION 5
SECTION 6

PAGE 13 SPECIAL CROSSFADER RELATED FEATURES
CONTROLS
7. Special Crossfader Related Features
"Fader Start" (Fader Start On/Off switches)
When engaged the fader start can be used to instantly start a fader-start compatible device (See "Inputs
and Outputs" Section 9) by moving the Crossfader away from the endpoints. The behavior of this control
is largely dependent on the settings of your fader start compatible device.
NOTE: The performance of the fader-start function is also dependent on the settings of the crossfader as
described in "Crossfader Controls" Section 6.

PAGE 14
SECTION 7
SPECIAL CROSSFADER RELATED FEATURES

PAGE 15 INPUTS AND OUTPUTS
CONTROLS
9. Inputs and Outputs
CH-1 and CH-2 Phono/Line Stereo Inputs
Each channel has a selectable phono level input (phonograph level/line level) and a line level input. The
line level input is used to connect CD players and other line level devices. When connecting a turntable to
the phono input, the switch must be set to "PHONO" instead of "AUX." When this switch is set to "AUX",
you can connect a line level device to the mixer (CD player, etc.) Please note that many turntables need
to be grounded to the mixer with a ground wire to prevent hum and excessive noise (see "GND.") It is
also recommended that the mixer be turned off before connecting and disconnecting any sources to the
inputs of the mixer.
WARNING: The Input Level Switch on the rear panel of the mixer must be set to "AUX" when connecting
line level devices. Failure to do so will result to damage in the mixer.
"Master" (Main Stereo Output)
This RCA output is for connecting an external device such as a PA system, powered monitors or a home
stereo. The level of the master stereo output signal increases as the "master" volume control is increased.
"Zone" (Auxiliary Stereo Output)
This RCA output is for connecting a secondary external device such as a booth monitor or second stereo
output. The level of the booth output signal will increase as the "Booth" volume control is increased.
"Rec" (Recording Level Stereo Output)
This RCA output is for connecting an external recording device such as a CD Recorder, MD Recorder or a
Tape Deck. The level of this signal is not affected by "master" volume or "booth" adjustments but is
affected by all other controls.
"GND" (Grounding Lug)
This screw connector should be used to secure any devices connected to the mixer that need to be
grounded. Most turntables that are connected to the mixer will need to have a ground wire that is
designed to connect to the mixer to eliminate hum and noise.
"Player A/B" (Fader Start Eighth Inch Terminals)
These two eighth inch terminals allow Fader/Remote Start Compatible devices (Numark CD Players) to be
connected to the unit using eighth inch fader start cables (not included.) Any connected device can then
be remotely started using the Crossfader (Section 7 "Special Crossfader Related Features.) "Fader Start"
must be switched to the on position for this feature to work properly.
NOTE: These terminals are only compatible with Digital Pulse Style Reception Devices

PAGE 16
AC In and Power Switch
This mixer uses an IEC type power cable. Make sure that the Internal Voltage Selector Switch is properly
set before inserting the power cable into the mixer. The mixer should be switched on after all devices are
already connected to prevent damage to your equipment. A Blue Power LED indicates that the unit has
been switched on (See Section 3 "Meters and Lighting.")
Internal Voltage Selector Switch
This switch allows the voltage for the mixer to be set at 110 VAC or 240 VAC (dependent on region and
plugtype.) To switch the voltage setting, remove the top screw on the plastic shield, and rotate the shield
counterclockwise.
INPUTS AND OUTPUTS
IEC type power cable

PAGE 17 CUSTOMIZING + SERVICING YOUR MIXER
CONTROLS
10. Customizing and Servicing Your Mixer
Replacing the Crossfader
This mixer features a replaceable Crossfader. The Crossfader can be
removed from the mixer by loosening the two screws at the endpoints of the fader (See illustrations at
right.) Follow the steps below for removing the top panel to have access to the Crossfader.
Customizing the Direction of the Input Selector Switches
This mixer features multi directional Input Switches that can be removed and rotated to one of eight
positions (See illustrations at right.) Each Input Selector Switch is secured to the mixer by two adjacent
screws. Be sure to make note of the current switch position and the new switch positions before rotating
the switches to prevent any uncertainty before re-securing the top panel. Follow the steps below for
removing the top panel to have access to the Input Selector Switches.
Removing the Top Panel
1. Unplug the mixer and set it on a flat surface. 2. Remove the Three Fader Knobs.
3. Remove the four screws that secure the
top panel using a #2 Philips Screwdriver.
4. Carefully remove the top panel.
CAUTION!
BEFORE REPLACING ANY PARTS, IT IS EXTREMELY
IMPORTANT TO UNPLUG THE MIXER FROM ITS
POWER SOURCE.

PAGE 18CUSTOMIZING + SERVICING YOUR MIXER
Replacing the Crossfader
Customizing the Direction of the Input Selector Switches
1. After removing the top panel, remove the
two screws that secure the selector switch
you want to rotate using a #2 Philips
Screwdriver.
1. After removing the top panel, remove the
two screws that secure the crossfader
using a #2 Philips Screwdriver.
2. Carefully slide the crossfader out of the
mixer chassis, and unplug the harness
from the bottom of the part. Replace the
crossfader, refasten the two screws that
hold the crossfader in place.
3. Resecure the top panel, test the function,
and refasten the four screws that secure
the top panel.
2. Carefully slide the switch out of the
mixer chassis, and unplug the harness
from the bottom of the part. Rotate and
replace the switch, refasten the two screws
that hold the switches in place.
3. Resecure the top panel, test the function,
and refasten the four screws that secure
the top panel.

PAGE 19 SPECIFICATIONS
SPECIFICATIONS
Inputs:
Line: 10K ohm input impedance
63mV rms sensitivity for 1.22V output
Mic: 600 ohm input impedance unbalanced
1.5mV rms sensitivity for 1.22V output
180mV rms max input
Phono: 47Kohm input impedance
1mV rms sensitivity @ 1KHz for 1.22V output
Outputs:
Line: 9V rms max
Headphone: 0.5W into 47ohm
Distortion: less than 0.01%
Signal to Noise Ratio: (maximum output) JIS-A weighted
Line: Better than 92dB
Mic: Better than 82dB
Phono: Better than 85dB
Frequency response:
Line: 20Hz-20KHz +/-0.5dB
Mic: 20Hz-15KHz +/-0.5dB
Phono: +/-1dB except for controlled attenuation of -3dB
@ 20Hz to reduce rumble and feedback
Channel equalizer:
Bass: +12/-32dB @40Hz
Middle: +12/-32dB @1KHz
Treble: +10/-28dB @15KHz
Power consumption:
11.5 Watt typical
14.2 Watt with full headphone output
Dimensions:
220mm(W) by 370mm(D) by 90mm(H)
Weight: 4.2 kgs
