READ AND SAVE THESE
INSTALLATION INSTRUCTIONS!
Wall Cap
MODEL: 846
TERMINATES
8" ROUND DUCT
FOR WOOD WALL
INSTALLATION
Refer to Figure 1.
Attach Wall Cap to outside wall with
screws through four slots on side
of flanges.
FOR BRICK WALL
INSTALLATION
Refer to Figure 2.
Wall Cap can be set back into wall 2"
from outside face of brick and grouted
into place or can be placed flush with
surface of brick and anchored into
place with four lead anchors.
ATTACH DUCT WORK
Refer to Figure 3.
Insert 8" round duct into lip on rear
wall cap.
NOTE: Remove tape and be certain
louvers operate freely.
FIGURE 1
FIGURE 2
FIGURE 3
8" DIA.
DUCT
INSERT
DUCT INTO
LIP ON
WALL CAP
133⁄4"
51⁄4"
133⁄4"
READ AND SAVE THESE
INSTALLATION INSTRUCTIONS!
Wall Cap
MODEL: 846
TERMINATES
8" ROUND DUCT
FOR WOOD WALL
INSTALLATION
Refer to Figure 1.
Attach Wall Cap to outside wall with
screws through four slots on side
of flanges.
FOR BRICK WALL
INSTALLATION
Refer to Figure 2.
Wall Cap can be set back into wall 2"
from outside face of brick and grouted
into place or can be placed flush with
surface of brick and anchored into
place with four lead anchors.
ATTACH DUCT WORK
Refer to Figure 3.
Insert 8" round duct into lip on rear
wall cap.
NOTE: Remove tape and be certain
louvers operate freely.
FIGURE 1
FIGURE 2
FIGURE 3
8" DIA.
DUCT
INSERT
DUCT INTO
LIP ON
WALL CAP
133⁄4"
51⁄4"
133⁄4"
Product specifications subject to change without notice.
4820 Red Bank Road, Cincinnati, Ohio 45227
Printed in U.S.A., Rev. 4/01, Part No. 13714
One Year Limited Warranty
WARRANTY OWNER: NuTone warrants to the original consumer purchaser of its products that
such products will be free from defects in materials or workmanship for a period of one (1) year from
the date of original purchase. THERE ARE NO OTHER WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE.
During this one year period, NuTone will, at its option, repair or replace, without charge, any
product or part which is found to be defective under normal use and service. THIS WARRANTY
DOES NOT EXTEND TO FLUORESCENT LAMP STARTERS OR TUBES, FILTERS, DUCT,
ROOF CAPS, WALL CAPS AND OTHER ACCESSORIES FOR DUCTING. This warranty does not
cover (a) normal maintenance and service or (b) any products or parts which have been subject to
misuse, negligence, accident, improper maintenance or repair (other than by NuTone), faulty
installation or installation contrary to recommended installation instructions.
The duration of any implied warranty is limited to the one year period as specified for the express
warranty. Some states do not allow limitation on how long an implied warranty lasts, so the above
limitation may not apply to you.
NUTONE’S OBLIGATION TO REPAIR OR REPLACE, AT NUTONE’S OPTION, SHALL BE THE
PURCHASER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS WARRANTY. NUTONE SHALL
NOT BE LIABLE FOR INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES ARISING OUT
OF OR IN CONNECTION WITH PRODUCT USE OR PERFORMANCE. Some states do not allow
the exclusion or limitation of incidental or consequential damages, so the above limitation or
exclusion may not apply to you. This warranty gives you specific legal rights, and you may also have
other rights, which vary from state to state. This warranty supersedes all prior warranties.
WARRANTY SERVICE: To qualify for warranty service, you must (a) notify NuTone at the
address stated below or telephone 1/800-543-8687, (b) give the model number and part
identification and (c) describe the nature of any defect in the product or part. At the time of
requesting warranty service, you must present evidence of the original purchase date.
Date of Installation Builder or Installer
Model No. and Product Description
IF YOU NEED ASSISTANCE OR SERVICE:
For the location of your nearest NuTone Independent Authorized Service Center:
Residents of the contiguous United States Dial Free 1-800-543-8687
Please be prepared to provide:
Product model number • Date and Proof of purchase • The nature of the difficulty
Residents of Alaska or Hawaii should write to: NuTone Inc. Attn: Department of National Field
Service, 4820 Red Bank Road, Cincinnati Ohio 45227-1599.
Residents of Canada should write to: Broan-NuTone Canada, 1140 Tristar Drive,
Mississauga, Ontario, Canada L5T 1H9.
Rev. 03/2001
