NuTone RMIP33 User manual

SPECIFICATION SHEET
REFERENCE QTY. REMARKS Project
Location
Architect
Engineer
Contractor
Submitted by Date
70D 99043303E
Mount insert so bottom of custom hood is 24’’ to 30’’
above cooking surface.
RMIP SERIES
INSERT
16
36", 42", 48", 60"
”
4
”
14
1
4
”
18
”
10
”
HA0011
4 1/2''
6 3/8''
HC0010
HK0076A
Custom Hood Liner
RML33 or RML45 Series
Backsplash
RMP Series
RMIPWC Remote Control
HB0032
Broan-NuTone LLC, 926 West State Street, Hartford, WI 53027 (1-800-637-1453)
NuTone, Inc., 4820 Red Bank Road, Cincinnati, OH 45227 (1-800-543-8687)
Broan-NuTone Canada, Inc., 1140 Tristar Drive, Mississauga, Ontario, L5T 1H9 (1-888-882-7626)
Bafe Filters
RBFIP Series
HA0026
4”
Adjustable depth
(See liner spec
sheet for details)
Fits custom hood nominal
width 36”, 42”, 48”, 54” or 60
”
Especially designed to be installed in custom hood
for use over residential commercial-style
cooking surfaces.
A complete installation requires several optional
components. Refer to page 2 when planning your
installation.
FEATURES
•Cabinet mount _ custom application
•Widths: 33’’, 45’’
•Halogen lighting (33’’_2 x 50 watt; 45’’_3 x 50 watt
PAR20)
Lamps not included
•Controls: rocker switches for lighting and on-off,
knob for innite speed
•Heat Sentry™ turns blower ON to HIGH speed when
excess heat is detected
OPTIONS
•Custom hood liners (RML33 or RML45 Series):
Widths - 36’’, 42’’, 48’’, 54” and 60’’
Adjustable depth - see liner spec. sheet for details
Stainless Steel construction - protects custom hood
base
and wipes clean easily
• Dishwasher-safe stainless steel bafe lters RBFIP
Series
•Backsplash (RMP Series):
Widths - 36’’, 42” 48”, 60”
Stainless Steel construction - protects back wall
and wipes clean easily
•RMIPWC Remote control: With Stainless Steel
faceplate,
to t any décor.
INSERT SPECIFICATIONS
120 Vac, 60 Hz
Amps (without blower): 0.8 (RMIP33) 1.3 (RMIP45)

RMIP MOUNTING
Size of the cut-out
NOTE: The 3 1/2’’ notch must be cut only if the RMIPWC
optional wall control will be installed.
HH0040A
1 1/2”
HD0093A
17 1/16''
16 3/8''
32 1/2'' or 44 1/2''
3 1/2''
2 1/4'' min.
Suggested Custom Hood Internal Framework
NOTE: If optional RML series liner is used, refer to installation
instructions for size and location of the cut-out.
RMIP SERIES INSERTS
BLOWER DUCTING
POSITIONS
MODEL RMIP33 WITH P8 BLOWER (Vertical Outlet)
HB0032


3/4’’
3 1/4’’
16 1/8’’
7 5/8’’
7/8’’
14’’
9 1/8’’
7/8’’ dia.
8’’ round
transition
HK0031A
MODEL RMIP33 WITH P5 BLOWER (Vertical Outlet)


3/4’’
3 1/4’’
16 1/8’’
7 5/8’’
7/8’’
10’’
11 1/8’’
7/8’’ dia.
7’’ or 8’’
round transition
HK0030A
MODEL RMIP33 WITH 331H, 332H, 335, 336, HLB3,
HLB6, HLB9 OR HLB11 BLOWER (Vertical Outlet)


5 1/4’’
16 1/8’’
9 5/8’’ dia.
7/8’’ dia.
1 11/16’’
6 11/16’’
HK0029
MODEL RMIP45 WITH P8 BLOWER (Vertical Outlet)
MODEL RMIP45 WITH P5 BLOWER (Vertical Outlet)
MODEL RMIP45 WITH 331H, 332H, 335, 336, HLB3,
HLB6, HLB9 OR HLB11 BLOWER (Vertical Outlet)


3 1/4’’
22 1/8’’
13 5/8’’
7/8’’
3/4’’ 15 1/8’’
14’’
7/8’’ dia.
8’’ round
transition
HK0034A


3 1/4’’
22 1/8’’
13 5/8’’
7/8’’
3/4’’ 17 1/8’’
10’’
7/8’’ dia.
7’’ or 8’’
round transition
HK0033A


5 1/4’’
22 1/8’’ 12 11/16’’
1 11/16’’
9 5/8’’ dia.
7/8’’ dia.
HK0032
Top view Top view
Top view Top view
Top view Top view

HL0067
RMP Series Backsplash
(Stainless Steel wall
covering with warming
shelves. Optional)
RML3336S, RML3342S,
RML4548S, RML4554S or
RML4560S
Custom Hood Liner (optional)
Model 415
7” Rd adjustable
elbow (optional)
8” Rd
adjustable
elbow (optional)
Model 412
transition
(31/4” x 10” to 7”)
Adapter and damper 31/4’’ x 10’’
(supplied with P5 and P8 blowers)
Adapter and damper 31/4’’ x 14’’
(supplied with P8 blower)
Model P5
single-blower
(500 cfm)
RMIP33 OR RMIP45
INSERT
- RMIP33 AND RMIP45 INSERT SYSTEM -
INTERIOR BLOWERS
Flow deviator
(supplied with P5 and P8 blowers)
Model 647
(7” Rd wall cap)
Model 634 or 644
(roof cap)
Model 643
(8” Rd wall cap)
8” Rd
standard
duct
Model 407
(7” Rd x 24’’
section)
7” Rd metal
flexible duct
(optional)
8” Rd metal
flexible duct
(optional)
Model 413
transition
(31/4” x 10” to 8”)
Model 459
transition
(31/4” x 14” to 8”)
Model P8
dual-blower (900 cfm)
NOTE: The dual blower P8 can be
installed either with 7’’ round
or 8’’ round ductwork.
For optimal air and quiet sound
performance, use 8’’round ductwork.
Rough-in kit
(supplied with P5 and P8 blowers)
RMIPWC
Wall control
(Optional)
RBFIP Series
Baffle Filters
(Optional)

HL0068
RMP Series Backsplash
(Stainless Steel wall
covering with warming
shelves. Optional)
RML3336S, RML3342S,
RML4548S, RML4554S or
RML4560S
Custom Hood Liner (optional)
Model 418
10” Rd
adjustable elbow
(optional)
Model HLB3 (280 cfm)
in-line blower
(includes one 8” to 10”
round transition)
RMIP33 OR RMIP45
INSERT
- RMIP33 AND RMIP45 INSERT SYSTEM -
IN-LINE AND EXTERIOR BLOWERS
Model 331H (600 cfm)
or 332H (900 cfm)
exterior blower
Model 335 (1200 cfm)
or 336 (1500 cfm)
exterior blower
Model 441
(10” Rd wall cap)
Model 437
(High capacity roof cap)
Model 441
(10” Rd wall cap)
Model 421
(10” Rd. vert.
in-line damper)
Recommended
for use with
exterior blowers
Model 410
(10” Rd duct
- 2ft. sections)
10” Rd metal
flexible duct
(optional)
332KR in-line and exterior blower
rough-in kit - Purchase separately.
RMIPWC
Wall control
(Optional)
RBFIP Series
Baffle filters
(Optional)
Model HLB6 (600 cfm)
in-line blower
(includes two 4½” x 18½”
to 10’’ round transitions)
Model HLB9 (800 cfm)
or HLB11 (1100 cfm)
in-line blower
(includes two 8” x 12” to
10’’ round transitions)
