NuVision 42LCM3 User manual

42LCM3

Table of Contents
Important Information..........................................................................................................................................................1
Important Safety Precautions .............................................................................................................................................2
Preparations .......................................................................................................................................................................5
Using the Remote Control........................................................................................................................................5
Batteries for the Remote Control .............................................................................................................................5
Power Connection....................................................................................................................................................5
Identification of Controls.....................................................................................................................................................6
Main Unit..................................................................................................................................................................6
Remote Control........................................................................................................................................................8
Connections........................................................................................................................................................................9
Cautions Before Connecting ....................................................................................................................................9
Connect a VCR ........................................................................................................................................................9
Connect a Camcorder ............................................................................................................................................10
Connect a DVD player............................................................................................................................................11
Connect a product to HDMI....................................................................................................................................12
Connect a PC.........................................................................................................................................................13
Connect a VCR for Recording................................................................................................................................14
Turning the Unit On and Off..............................................................................................................................................15
Viewing the Menus and Displays ...........................................................................................................................15
Displaying Status Information.................................................................................................................................15
Adjusting the Volume..............................................................................................................................................15
Using the Mute .......................................................................................................................................................15
Basic Operations ..............................................................................................................................................................16
Selecting Input Source Signal ................................................................................................................................16
Editing Input Label..................................................................................................................................................16
Selecting a Menu Language...................................................................................................................................16
Setting Picture ..................................................................................................................................................................17
Customizing the Picture .........................................................................................................................................17
Using the Preset Picture Mode...............................................................................................................................17
Setting Auto Color Function On or Off ....................................................................................................................18
Selecting the Preset Color Warmth Mode ..............................................................................................................18
Changing Screen Aspect Ratio ..............................................................................................................................18
Setting Sound ...................................................................................................................................................................19
Customizing the Sound ..........................................................................................................................................19
Setting the Line Output...........................................................................................................................................19
Using the Preset Sound Mode ...............................................................................................................................19
Adjusting On-Screen Display............................................................................................................................................20
Adjusting OSD Position ..........................................................................................................................................20
Setting OSD Timeout..............................................................................................................................................20
Adjusting OSD Transparency .................................................................................................................................20

Table of Contents (continued)
Setting System .................................................................................................................................................................21
Setting Clock Timer ................................................................................................................................................21
Setting Wake Up Timer ..........................................................................................................................................21
Displaying Signal Source Information ....................................................................................................................21
Loading Default Values ..........................................................................................................................................21
PIP Operations .................................................................................................................................................................22
Viewing and adjusting the Size of PIP Frame ........................................................................................................22
Turning Off the PIP Frame .....................................................................................................................................22
Adjusting the Volume for the PIP Frame ................................................................................................................22
Swapping the Contents of the PIP Frame and Main Frame...................................................................................22
Changing the Position of the PIP Frame.................................................................................................................22
Selecting Speaker Output Source..........................................................................................................................23
Viewing Picture-by-Picture .....................................................................................................................................23
Viewing Picture-out-Picture....................................................................................................................................23
Adjustment in VGA/HDMI/Component Mode....................................................................................................................24
Selecting the Preset Color Warmth Mode ..............................................................................................................24
Adjusting the Picture Automatically ........................................................................................................................24
Adjusting the Clock ...............................................................................................................................................24
Adjusting the Phase ...............................................................................................................................................25
Changing the Position of Image.............................................................................................................................25
Setting Over Scan Function...................................................................................................................................25
Using Hotkeys..................................................................................................................................................................26
Viewing Closed Captions..................................................................................................................................................27
Setting Closed Caption...........................................................................................................................................27
Setting CC When Mute...........................................................................................................................................27
Adjusting Parental Control Settings..................................................................................................................................28
Parental Control .....................................................................................................................................................28
Password Setup .....................................................................................................................................................30
Turning Parental Control On or Off.........................................................................................................................30
Adjusting the Movie Rating.....................................................................................................................................30
Adjusting the TV PG Rating ...................................................................................................................................30
Adjusting Canadian English Rating........................................................................................................................31
Adjusting Canadian French Rating.........................................................................................................................31
Troubleshooting................................................................................................................................................................32
.....................................................................................................................................................3
Specification .....................................................................................................................................................................34
Care and Maintenance 3

Important Information
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR
MOISTURE.
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
dangerous voltage wi thin the product's
enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
p r e s e n c e o f i m p o r t a n t op e r a t i n g a n d
maintenance (servicing) instructions in the
literature accompanying the appliance.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
CAUTION-To reduce the risk of electric shock, do not perform any
servicing other than that contained in the operating
instructions unless you are qualified to do so.
This product utilizes tin-lead solder, and fluorescent lamps containing a small amount of mercury. Disposal of these materials may be regulated
due to environmental considerations. For disposal or recycling information, please contact your local authorities or the Electronic Industries
Alliance: www.eia.org
FCC STATEMENT
FCC Notice
LCD Monitor: A CLASS B digital device
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the interference at his own expense.
FCC CAUTION:
Pursuant to 47CFR, Part 15.21 of the FCC rules, any changes or modifications to this monitor not expressly approved by the
manufacturer could cause harmful interference and would void the user's authority to operate this device.
WARNING: This is a CLASS B product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures to counter interference.
1

Important Safety Precautions
Electrical energy can perform many useful functions, but it can also cause personal injuries and property damage if improperly handled.
This product has been engineered and manufactured with the highest priority on safety. But IMPROPER USE CAN RESULT IN
POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD. In order to prevent potential danger, please observe the following instructions
when installing, operating and cleaning the product. To ensure your safety and prolong the service life of your LCD Monitor product, please
read the following precautions carefully before using the product.
1. Read these instructions---All operating instructions must be read and understood before the product is operated.
2. Keep these instructions---These safety and operating instructions must be kept in a safe place for future reference.
3. Heed all warnings---All warnings on the product and in the instructions must be observed closely.
4. Follow all instructions---All operating instructions must be followed.
5. Do not use this apparatus near water---for example, near a bathtub, washbowl,
kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.
Do not use immediately after moving from a low temperature to high temperature
environment, as this causes condensation, which may result in fire, electric shock, or
other hazards.
Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids,
such as vases, shall be placed on the apparatus.
6. Clean only with dry cloth---Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
7. Ventilation---Do not block any ventilation openings. Install in accordance with the
manufacturer instructions. The vents and other openings in the cabinet are designed for
ventilation. Do not cover or block these vents and openings since insufficient ventilation
can cause overheating and/or shorten the life of the product. Do not place the product on
a bed, sofa, rug or other similar surface, since they can block ventilation openings. This
product is not designed for built-in installation; do not place the product in an enclosed
place such as a bookcase or rack, unless proper ventilation is provided or the
manufacturer’s instructions are followed.
8.Heat sources---Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9.Grounding or Polarization---Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10.Power cord protection---Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and
the point where they exit from the apparatus.
Never attempt to move the monitor unless the AC plug has been disconnected.
11.Attachments---Only use attachments/accessories specified by the manufacturer. Do not use attachments not recommended by the
manufacturer. Use of improper attachments can result in accidents.
2

Important Safety Precautions (continued)
12. Stand---Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or
sold with the apparatus. Do not place the product on an unstable trolley, stand, tripod or table.
Placing the product on an unstable base can cause the product to fall, resulting in serious personal
injuries as well as damage to the product. When mounting the product on a wall, be sure to follow
the manufacturer’s instructions. Use only the mounting hardware recommended by the
manufacturer.
13. Move Carefully---When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over. Sudden stops, excessive force and uneven floor surfaces
can cause the product to fall from the trolley.
14. Lightning---Unplug this apparatus during lightning storms or when unused for long periods of
time.
For added protection for this apparatus during a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall outlet. This will prevent damage to the
equipment due to lightning and power-line surges.
15. Servicing---Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.
16. Replacement parts---In case the product needs replacement parts, make sure that the service person uses
replacement parts specified by the manufacturer, or those with the same characteristics and performance as the
original parts. Use of unauthorized parts can result in fire, electric shock and/or other danger.
17.Overloading---Do not overload wall outlets, extension cords, or convenience receptacles on other
equipment as this can result in a risk of fire or electric shock.
18.Entering of objects and liquids---Never insert an object into the product through vents or openings. High voltage flows in the product,
and inserting an object can cause electric shock and/or short internal parts. For the same reason, do not spill water or liquid on the product.
19.Damage requiring service---If any of the following conditions occurs, unplug the power cord from the AC outlet, and request a qualified
service person to perform repairs.
a. When the power cord or plug is damaged.
b. When a liquid is spilled on the product or when objects have fallen into the product.
c. When the product has been exposed to rain or water.
d. When the product does not operate properly as described in the operating instructions.
Do not touch the controls other than those described in the operating instructions. Improper adjustment of controls not described in the
instructions can cause damage, which often requires extensive adjustment work by a qualified technician.
e. If the product has been dropped or the cabinet has been damaged in any way.
f. When the product displays an abnormal condition or exhibits a distinct change in performance. Any noticeable abnormality in the product
indicates that the product needs servicing.
20.Safety checks---Upon completion of service or repair work, request the service technician to perform safety
checks to ensure that the product is in proper operating condition.
21.Wall or ceiling mounting---When mounting the product on a wall or ceiling, be sure to install the product according to the method
recommended by the manufacturer. This is a safety feature.
3

23.Panel protection---The LCD panel used in this product is made of glass. Therefore, it can break
when the product is dropped or impacted upon by other objects. Be careful not to be injured by
broken glass pieces in case the LCD panel breaks.
24.Pixel defect---The LCD panel is a very high technology product, giving you finely detailed pictures. Occasionally, a few non-active
pixels may appear on the screen as a fixed point of blue, green or red. Please note that this does not affect the performance of your product.
Important Safety Precautions (continued)
22. Power source---This product is intended to be supplied by a listed power supply indicated on the marking label. If you are not sure of the
type of power supply to your home, consult your product dealer or local power company. For added protection for this product during a
lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the cable
system. This will prevent damage to the product due to lightning and power line surges. When the unit has to be used with another power
supply voltage, the power cable must be changed. Consult your product dealer. The socket outlet should be installed near the equipment
and easily accessible. Use only the power cord designated by our dealer to ensure safety and EMC. When connecting other products such
as VCRs and personal computers, you should turn off the power of the unit for protection against electric shock.
4

Preparations
Precaution on battery use
Improper use of batteries can result in a leakage of chemicals and/or explosion. Be sure to follow the instructions below.
<Place batteries with their terminals corresponding to the (+) and (–) indications.
<Different types of batteries have different characteristics. Do not mix batteries of different types.
<Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries and/or cause old batteries to leak
chemicals.
<Remove batteries as soon as they are non-operable. Chemicals that leak from batteries can cause a rash. If chemical leakage is found,
wipe with a cloth.
<The batteries supplied with the product may have a shorter life expectancy due to storage conditions.
<If the remote control is not used for an extended period of time, remove the batteries from the remote control.
Using the Remote Control
<Use the remote control by pointing it towards the remote sensor window of the set. Objects between
the remote control and sensor window may prevent proper operation.
Cautions regarding use of remote control
<Do not expose the remote control to shock. In addition, do not expose the remote control to liquids,
and do not place in an area with high humidity.
<Do not install or place the remote control under direct sunlight. The heat may cause deformation of the unit.
<The remote control may not work properly if the remote sensor window of the main unit is under direct sunlight or strong lighting. In such a
case, change the angle of the lighting or the LCD Monitor, or operate the remote control closer to the remote sensor window.
Batteries for the Remote Control
If the remote control fails to operate the LCD Monitor functions, replace the batteries in the remote control.
<(Place the batteries with
t h e i r t e r m i n a l s
corresponding to the (+)
and (–) indications in the
battery compartment.)
Open the battery cover.
1Insert two size-AAA batteries. 2Replace the cover. 3
Note: This illustration is for reference only. The remote sensor may be in different locations on
different models.
5
Power Connection
30
30
5m
Plug into AC outlet.
AC cord
Household
power outlet
bottom view
Note:
<This illustration is for reference only. The AC plug may be different on different models.
<This product should be operated only from the type of power source indicated on the marking label.
<Always unplug the AC cord from power outlet when not using for a long period of time.
1. Connecting the female plug to the AC socket on the unit.
2. Connecting the male plug to the outlet as illustrated.

Main unit
6
Note:
Functions of 5/6, VOL3/4, MENU, INPUT and POWER are also provided to the remote control. This operation manual provides
a description based on operating functions with the remote control.
1.
2.
Press the VOL or VOL button to directly increase or decrease the sound volume level;
In OSD Menu, press these buttons to adjust the value or setting of each item
3. MENU
Press this button to access the Menu main page
4. INPUT
To access signal source select menu
5. POWER
Headphone Jack
6/5
In OSD menu, press these buttons to select OSD items
VOL3/4
4 3
Press this button to turn the unit ON from STANDBY mode. Press it again to turn the set back to STANDBY.
6.
Power Indicator
Remote Sensor
Identification of Controls
5
VOL4
6
VOL3
MENU
INPUT
1
2
3
4
5
6

1. Speaker output jacks
Connect the speaker audio cable to the speaker output jacks on the unit matching the “+” and
“-” ends of the cable by color.
2. HDMI1 interface
3. HDMI2 interface
4. VGA input
Connect to the VGA/audio output jacks from your computer.
5. Component inputs (Y, Cb/Pb, Cr/Pr, Audio R, L)
Connect to the component and audio output sockets of a DVD player or Set-Top Box.
6. S-VIDEO input
Receive an S-Video signal from external source such as VCR or DVD player.
7. AV inputs (Video, Audio L, R)
Receive video/audio signals from external sources such as VCR or DVD player.
8. AV Outputs (Video, Audio L, R)
9. Nucontrol interface
For service only. The user cannot operate the unit through the NuControl interface.
10.AC power input
Identification of Controls (continued)
Main Unit
7
5 6 78 9
YLRVIDE O
S-VIDEO
AV O UT PUT
AUDIO
L
L
R
R
AUDIO
VIDE O
VIDE O
AV I NP UT
AUDIO
CO MPONE NT I NPUT
C /P
r r
C /P
r r
C /P
b b
C /P
b b
NuCont rol
1
VG A
HD MI 1
VIDE O
HD MI 2
234
10
