nuVita Materno Go 1282M User manual
Tiralatte Elettrico
Sacaleche Eléctrico
Electric Breast Pump
Tire-Lait Électrique
Elektrische Milchpumpe
Bomba Elétrica de Mama
Ηλεκτρικό Θήλαστρο
IT
ES
EN
FR
DE
PT
GR
Materno Go
Manuale di Istruzioni
Manual de Instrucciones
Instruction Manual
Manuel d’Instructions
Bedienungsanleitung
Manual de instruções
Εγχειρίδιο οδηγιών
IT
ES
EN
FR
DE
PT
GR
1282M
Dear Customer, you bought one of the most reliable breast pumps actually available in the market. We
studied this device to be as much user friendly as possible but, we are afraid, you still have to spend a small
amount of time in reading these instructions in order to get 100% of the benets this product can bring you.
Keep this manual for future reference.
Package Content
Precautions
1. Dust-proof cover
2. Silicone Massage cup
3. Breast Pump Body
4. Anti-spill silicone
5. Anti-spill cover
6. Suction Valve
7. Mimic Baby Bottle (150ml)
8. Mimic Bottle Silicone Valve
9. Breast Pump Control Unit
10. Connection Tube
11. Dust proof feeding bottle cover
12. Bottle Teat
13. Feeding bottle ring
14. Power Adapter
15. Velvet Bag (not shown in the diagram)
16. Adapter
Before assembly and use the electric
breast pump to make sure that inside
the packaging there are the following
accessories, refer to your shop in case of
any missing parts:
• Please read the instruction manual carefully before using the product.
• This product must be used by adult only with complete attention during the entire process.
• Do not use the power adapter other than the provided.
• Do not warp or knot the connecting tube (Package Content No. 10) during the using process.
• Please put the product or dismounted parts out of baby’s reach.
• Do not dismount Breast Pump Control Unit (Package Content No. 9) in any condition; it shall be
repaired or replaced by the manufacturer or professional.
Electric Breast Pump
Materno Go
EN
1282M
1
6
7
11
2 3 4 5 10
91681213
14
Instruction for cleaning
1. This Breast pump uses a 2 Phases Technology:
• 1st Phase with 9 Automatic stimulation levels
for 2 minutes operation.
• 2nd Phase with 9 Selectable levels for your
best Expression action
2. This device is provided with an anti-reux
protection system which prevents the breast
1. Insert the silicone massage cup (Package Content No. 2) in the breast pump as shown.
2. Fit the anti-spill silicon (Package Content No. 4) with the anti-spill cover (Package Content No. 5) as shown
below. Aim at the sliding slot and screw the anti-spill cover as shown in the gure.
3. Fix the suction valve (Package Content No. 6) at the lower end of the breast pump see the gure below.
4. To connect the upper part of the breast pump with the wide neck bottle rotate until it ts close.
5. Insert the connection tube (Package Content No.10) into the interface of the anti-spill upper cover. Insert
the other end of the connection tube into the suction slot of the pump.
milk to return to the control unit and damaging
it during the milk extraction process.
3. Your 1282M is provided with memory function
4. Your 1282M is portable (AC/DC and Battery
operated) so suitable for travelling and perfect
for breast pumping activity at work.
• Before cleaning and sterilization, dismount the parts in contact with the breast or breast milk (apart
from Breast Pump Control Unit (Package Content No. 9)).
• Do not clean the Breast Pump Control Unit (Package Content No. 9) in the water.
• Do not sterilize the Breast Pump Control Unit (Package Content No. 9) in the steam sterilizer.
• Do not hot sterilize the connection pipe. Cold sterilization only. Otherwise cleaning with warm soapy
water and then rinse with sterile water. (Package Content No. 10).
• Clean the parts immediately after each use to avoid the residual milk and bacteria growth.
• Put the cleaned parts on the dry clean towel at the shady and cool place.
Product Features
Assembly of the breast pump
A rechargeable electric single breast pump model for maximizing milk extraction process.
It’s designed to simulate the suction rhythm of baby.
Description of Pump Control Unit
Frequency levels of absorption of
Nuvita 1282M:
1to 9
1to 9This is the Expression mode. This simulates the
suction of a baby. The rhythm of this phase is slower,
deeper and longer.
A1. On and O Switch button
A2. Mode Switch button
A3. Increase Suction Level button
A4. Decrease Suction Level button
B1. Level indicator
B2. Stimulation mode indicator
B3. Expression mode indicator
This is the Stimulation mode with fast and short
suction rhythm.
B2
A1 A2A3 A4
B3B1
Using the breast pump
1 2 3
3 4
54
1. Please clean hands before using the product, ensure the parts of the breast pump are cleaned and
assembled accurately as per instruction in this guide.
2. Relax and be at ease while having a normal sitting posture. Use a thermal gel breast pad or a hot towel
before starting the pumping process.
3. Use your hand to aim the center of the breast pump at the nipple and ensure it is tight and lock without
air getting in and out.
4. Power on, long press the power button. The screen of the machine will self-test and icker. The machine
will then enter stimulation mode. The factory default level is level 5. After 2 mins of stimulation, the
machine will automatically switch to expression mode. The machine will automatically shut o after
30mins working.
5.
Under the Expression mode, press the + button or – button to select any levels from L1 to L9. This device is
provided with Memory function. In the next breast feeding it will recall the previous level you selected.
6. Disassemble, clean and sterilize the non electronic parts for next use.
Installation of AC adaptor
1 3
IMPORTANT: Please turn o the machine before connecting with the adaptor.
1. Insert DC round pin of AC power adapter into the DC socket at the Control Unit, and insert the AC power
adapter into the power socket as shown in the diagram.
2. When battery is low capacity, the digit on the screen (level indicator) will icker, indicating that battery
needs to be charged.
3. When charging, the line of the digit on the screen will move clockwise and icker, indicating that the
machine is in charging mode as shown in the diagram. When machine full charged, it will auto shut o.
SERVICE: Every care has been taken in the realisation of products, accessories provided in the box and
documentation provided, so in case of problems it is advisable to repeat the operations by faithfully following the
instructions in the manual. For further information on the help service visit the website: www.nuvitababy.com
WARRANTY - TERMS AND CONDITIONS: This product benets of a warranty of 24 months on material and
manufacturing defects, starting from the date of purchase (see sales slip). The warranty of 24 months does not
include damages caused by the usual use of parties identied as “consumable” (e.g., batteries, brush heads or
parts subject to usury). The legal guarantee of 24 months is void if: 1) The product has undergone aesthetic
damage due to improper use not in accordance with instructions in the manual. 2)This product has been modied
and/or tampered with. 3) The cause of the failure was due to poor maintenance of the individual components
and/or accessories and/or supplies (e.g. oxidation and/or scaling due to the retention of water or other liquids,
sediment blocking the sensor, leak of corrosive liquid from batteries). The following is excluded from the legal
guarantee of 24 months: 1) Costs related to replacements and/or repair of parts subject to wear or costs for
ordinary maintenance of the product. 2) The costs and risks involved in transporting the product to and from the
store where you purchased or otherwise authorized collection centre to receive the products under warranty. 3)
Damage caused by or resulting from improper installation or improper use not in accordance with the directions
in the instruction manual. 4) Damage due to natural disasters, accidental events or adverse conditions not
compatible with the product. 5) Defects that have a negligible eect on product performance. The manufacturer,
distributor and all the parties involved in the sale do not assume any liability for losses and economic damage from
any malfunction of the product. In accordance with current regulations the manufacturer, distributor and all the
parties involved in the sale are not responding in any case for damages, including direct, indirect ones, loss of net
income, loss of savings and additional damage and other details consequences going beyond the damage caused
by the breach of warranty, contract, strict liability, wrongdoing or due to other causes, resulting from the use or
inability to use the product and/or paper and electronic documents, including the lack of service.
Imported/Distributed by
Anteprima Brands International Ltd
1, Ferris Bldg. St.Luke Street PTA1020 Gwardamangia
Malta - Europe
www.nuvitababy.com
