NX NXP2-RL-SP User manual

3483B 031321
72-00669
™
1
NX Lighting Control Panel Relays
INSTALLATION INSTRUCTIONS
PRECAUTIONS
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
• CAUTION - RISK OF ELECTRICAL SHOCK. To prevent electrical shock, turn o power at the circuit breaker before installing
or servicing unit. Never wire energized electrical components.
• NOTICE: For installation by a licensed electrician in accordance with national and/or local Electrical Codes and the
following instructions.
• CAUTION: USE COPPER CONDUCTOR ONLY.
• CAUTION: This equipment provides more than one power supply output source. To reduce the risk of electric shock
disconnect both normal and emergency sources within this unit before servicing any equipment connected to this unit.
• Be sure to read and understand all instructions before installing or servicing unit
• For Indoor use only. Do not use outdoors.
• Do not install near gas or electric heaters.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
• Conrm that device ratings are suitable for application prior to installation.
• Equipment should be mounted in locations and at heights where it will not readily be subjected to tampering by unauthorized
personnel.
• Use only approved materials and components (i.e. twist on connectors, electrical box, etc.) as appropriate for installation.
• NOTICE: Do not install if product appears to be damaged.
• If the equipment is used in a manner not specied by the manufacturer, the protection provided by the equipment may
be impaired.
• Do not use this equipment for other than intended use.
SAVE THESE INSTRUCTIONS!
INSTALLATION OVERVIEW
The installation instructions contained in this document are provided as a guide for proper and reliable installation and connection of
NX Lighting Control Panel V2 Single Pole (p/n NXP2-RL-SP) and Double Pole Relays (p/n NXP2-RL-DP).
These instructions include information as follows:
Precautions
Description
Installing Individual Relays
Relay Specications
701 Millennium Blvd. | Greenville, SC 29607 | [phone] | hubbellcontrolsolutions.com
Copyright © 2021 Hubbell Control Solutions, a division of Hubbell Lighting, Inc. All rights reserved. All product and company names, logos and product
identiers are trademarks ™ or registered trademarks ® of Hubbell Lighting, Inc. or their respective owners. Use of them does not necessarily imply any
aliation with or endorsement by such respective owners.

3483B 031321
72-00669
™
2
NX Lighting Control Panel Relays
INSTALLATION INSTRUCTIONS
DESCRIPTION
The NX Panel is a congurable lighting control panel consisting of single and/or double pole relays, 0-10V dimming channels, low
voltage inputs, dry contact outputs, NX SmartPORTs™for NX Occupancy Sensors, Daylight Sensors and Smart Wall Stations, and an
optional UL924 Emergency Interface. Panels can be congured with all relays of the same type installed or with space available for
relays to be installed in the eld. The relays are mounted with lighting circuit terminals in the high voltage area. The low voltage
control inputs/outputs are in the low voltage area of the panel. See Figure 1.
Figure 1: Fully populated 16 relay interior with UL924 board mounted in the exterior enclosure
Power Supply Input*
Power Supply Output to Panel
NX Network
RJ45 Ports
Relay With Override Switch
Relay Line Voltage Terminals
Metal Barrier
Line Voltage Area
*Connect to normal power
source if panel is controlling
emergency circuits.
A: Controller Board B: Relay/Dimmer Board
Status LED
Low Voltage
Auxiliary Inputs
Battery
NX SmartPORTs
Low Voltage
Auxiliary Outputs
0-10V
Dimming Channels
C: UL924 Board (Optional)
Test Button
Low Voltage Wiring Area
701 Millennium Blvd. | Greenville, SC 29607 | [phone] | hubbellcontrolsolutions.com
Copyright © 2021 Hubbell Control Solutions, a division of Hubbell Lighting, Inc. All rights reserved. All product and company names, logos and product
identiers are trademarks ™ or registered trademarks ® of Hubbell Lighting, Inc. or their respective owners. Use of them does not necessarily imply any
aliation with or endorsement by such respective owners.

3483B 031321
72-00669
™
3
NX Lighting Control Panel Relays
INSTALLATION INSTRUCTIONS
INSTALLING INDIVIDUAL RELAYS
The NX Panel can be congured with single and/or double pole mechanically latching relays pre-installed. If the project requires
additional relays (and space is available in the panel), additional relays can be eld installed as shown in Figure 2.
CAUTION! ALWAYS REMOVE POWER FROM THE NX PANEL’S TRANSFORMER PRIOR TO MAKING ANY ELECTRICAL CONNECTIONS
INSIDE THE PANEL. FAILURE TO DO SO MAY RESULT IN PERSONAL INJURY, DAMAGE TO THE PANEL, AND VOID ITS WARRANTY.
1. Verify that power is turned o at breaker panel before installing relay in panel.
2. Remove panel door assembly from panel enclosure.
3. Locate an open relay position (two adjacent positions for a double pole relay) in the panel and remove the relay guard cover(s).
4. Insert relay into mounting bracket noting proper orientation of input/output sides. Verify that relay is securely held in
mounting bracket.
5. Connect relay input and output as shown in the wiring diagram below. Connect input to panel I/O control card using relay
connector cable. Attach red lead to red screw and blue wire to blue screw. Slide connector on to header pins of I/O control card.
Connect line and load leads to relay output.
Figure 2: Relay Wiring Diagrams
SIMLXRL1 - Simplicity LX Single Pole Relay
SIMLXRL2 - Simplicity LX Double Pole Relay
Installation Instructions
Hubbell Building Automation, Inc.
9601 Dessau Road • Building One • Suite 100
Austin, Texas 78754
512-450-1100 • 512-450-1215 Fax
www.hubbell-automation.com
Overview
This document provides instructions for installing and connecting Single and/or Double Pole Relays in the Simplicity LX Series Lighting
Control Panel.
Contents
These instructions include information as follows:
Description
General Precautions
Installation
Precautions
• Read and understand all instructions before beginning installation.
• For installation by a qualified electrician in accordance with National and/or local Electrical Codes and the following instructions.
•RISK OF ELECTRICAL SHOCK. Turn power off at breaker panel before servicing unit. Never wire energized electrical components.
Never operate unit with door panel or relay guards removed.
•USE COPPER CONDUCTOR ONLY.
• Confirm that device ratings are suitable for application prior to installation.
• Use only approved materials and components (i.e. wire nuts, electrical box, etc.) as appropriate for installation.
•NOTICE: Do not install if any damage to product is noticed.
Installation
1. Verify that power is turned off at breaker panel before installing relay in panel.
2. Remove panel door assembly from panel enclosure.
3. Locate an open relay position (two adjacent positions for a double pole relay) in the panel and remove the relay guard cover(s).
4. Insert relay into mounting bracket noting proper orientation of input/output sides. Verify that relay is securely held in mounting bracket.
5. Connect relay input and output as shown in the wiring diagram below. Connect input to panel I/O control card using relay connector
cable. Attach red lead to red screw and blue wire to blue screw. Slide connector on to header pins of I/O control card. Connect line and
load leads to relay output.
Figure 1: Relay wiring diagrams
Load
(to lighting system)
Load , Ph ase 2
(to lighting system)
Load , Ph ase 2
(
from Circuit Breaker)
Load , Ph ase 1
(to lighting system)
Load , Ph ase 1
(to lighting system)
Blue Input Screw
Blue Lead
Red Input Screw Red Lead
Relay Connector
I/ O co nt ro l
Card Head
er
(Polarized)
Blue Input Screw Blue Lead
Red Input Screw
Red Lead
Relay Connector
I/ O co nt ro l
Card Head
er
(Polarized)
Line
(
from Circuit Breaker)
Single Pole Relay
Double Pole Relay
6. If necessary, reinstall relay guard covers over open relay positions.
7. Re-install panel door assembly to panel enclosure.
8. Reapply power to panel.
9. Verify relay operation by manually switching relay on and o using the manual control switch located on the relay.
SPECIFICATIONS
CONSTRUCTION
Relay Dimensions
• Single Pole - L:106.5mm x W:24.5mm x
H:60mm
• Double Pole – L:96mm x W:49.5mm x
H:60mm*
MOUNTING
• Mounts directly to NX Lighting Control
Panel V2 relay mounting strap
ELECTRICAL
Relay Operating Voltages
• Single Pole (p/n NXP2-RL-SP):
• General Use: 20A @ 300VAC
• Tungsten: 2400W @ 120VAC
• (Standard) Ballast: 20A @ 300VAC
• Electronic Ballast: 16A @ 277VAC
• Motor Starting: ½ HP @ 110-125VAC;
1.5HP @ 220-277VAC
ELECTRICAL CONTINUED
Relay Operating Voltages (Continued)
• Double Pole (p/n NXP2-RL-DP)*:
• General Use: 20A @ 480VAC
• Tungsten: 2400W @ 120VAC
• (Standard) Ballast: 20A @ 480VAC
• Motor Starting: ½ HP @ 110-125VAC;
1½ HP @ 220-277VAC
Relay Electrical Ratings
• Rated for minimum 60,000+ operations
(30,000+ cycles) at full 20A load
• Short Circuit Current Rating (SCCR) of
14,000A @ 277VAC
• Rated full-life with HID load
Relay Mechanical Ratings
• Rated for minimum 120,000+ operations
(60,000+ cycles)
OPERATION
• Mechanically latching
• Provides at-a-glance indication of ON or
OFF relay status
• Includes manual override switch
(integral to the relay)
OPERATING ENVIRONMENT
• Indoor use only
• 32° to 112°F (0° to 50°C)
• Relative humidity (non-condensing):
10% to 90%
CERTIFICATIONS
• UL Listed
• CSA Approved
WARRANTY
• 5 year limited warranty
• See HCS Standard Warranty for
additional information
*Double pole relays occupy (2) relay spaces
