O3 Pure G3 User manual

ureure®
O
3
Eco Laundry Systems
G3 Eco Laundry System User Manual
Please retain this manual and your sales receipt for all warranty issues.
O3 PURE® is a division of Pure Energy LLC®
Table of Contents
Product Diagram Pg. 1
Installaon Requirements Pg. 2-3
Product Purpose Pg. 4
Use & Safety Pg. 5
Indicator Lights Pg. 5
Warranty & Contact Pg. 7

G3 Eco Laundry System User Manual
Please Visit www.o3pure.com
Page 1

G3 Eco Laundry System User Manual
Please Visit www.o3pure.com
Page 2
Installaon Requirements
Electrical Requirements
O3PURE Eco-laundry G3 requires 120Volts 60Hz power on a 15amp
fuse or circuit breaker. Never use an extension cord or a power adapter
other than the one provided with Eco-laundry G3.
Water requirements
Water pressure of 40 to 100 psi is required to properly operate your
O3PURE Eco-laundry G3. Water quality may aect the performance
of your unit. If you have any water quality concerns, such as high iron,
consult a water ltraon expert.
Installaon
The O3PURE Eco-laundry G3 should be fastened to the wall directly be-
hind and above your washing machine. First, mount the included metal
plate on the wall. The mounng bracket has three mounng holes and
three anchor screws (included).
Secure the mounng bracket to the wall with the anchor screws and
make sure that the plate is level (a level is recommended to ensure that
the mounng bracket is horizontal. Tilted installaon may aect opera-
on).
There are three sockets located on the backside of the Eco-laundry G3.
Carefully slide the unit down aligning the three sockets onto the metal
plate. The Eco-laundry G3 should be securely hung now.

G3 Eco Laundry System User Manual
Please Visit www.o3pure.com
Page 3
Installation Continued
Turn OFF your homes cold water faucet located near your washing ma-
chine. Turn your washing machine’s seng to “COLD” water only and
run the machine for a moment to help remove excess water from the
cold water hose. Note: Some washing machines mix hot water with cold
water to ensure a minimum water temperature so you may not see the
water ow stop. Running the washing machine for a few seconds should
be adequate.
Remove your exisng hose from the cold water faucet but keep the
hose aached to your washing machine. Connect your exisng hose to
the area marked water “Outlet” on the Eco-laundry G3. Do NOT over
ghten. Make sure that there is a secure t. Note: Make sure the hose
is in a good and funconal condion. Replace the hose if it appears to
be worn out.
Aach the hose included with the Eco-laundry G3 to the area marked
water “Inlet” on the unit. Aach the other end to the cold water faucet.
Tighten both ends of the hose but do not over ghten them.
Slowly turn your cold water faucet back on. Make sure that there isn’t
any leaking from any of the hoses.
Plug in the DC adapter to the Eco-laundry G3 unit and then plug it
into the outlet. It is now installed for operaon. The Eco-laundry G3 is
automac and will turn on when the water ows through it. A blue light
will appear only when water is owing through the unit. Finally, run the
wash cycle on your washing machine two to three mes before adding
any laundry. This helps remove all detergent buildup accumulated in the
machine.

G3 Eco Laundry System User Manual
Please Visit www.o3pure.com
Page 4
Product Purpose
O3PURE Eco-laundry G3 is an environmentally friendly appliance
intended for use with residenal washing machines. By adopng a
magnezing principle to soen tap water and then mixing the acvated
oxygen into the water. The processed water can wash clothes and kill
bacteria without leaving any residual detergent.
The operaon of Eco-laundry G3 is easy and convenient as long as you
install it properly. You simply need to operate your washing machine
following the manufacturer’s operaon instrucons. Eco-laundry G3 will
start working automacally when the washing machine starts to work
and it will turn o automacally with the washing machine.
The Eco-laundry G3 has three levels of ozone based on various clothing.
You can choose between the high level, low level, and none through the
touch key on the le side of the unit.

G3 Eco Laundry System User Manual
Please Visit www.o3pure.com
Page 5
Use & Safety Consideraon
Before installing and operang your Eco-laundry G3 unit read the User’s
Manual carefully.
Eco-laundry G3 can only operate properly with cold water.
Maximum water inlet pressure is 100 psi.
Use the supplied hose when connecng the Eco-laundry G3 unit to your
washing machine. You should replace any exisng washing machine
hose that is more than two years old with a new one.
Use a so cloth dampened with water to clean the unit. Do not use
harsh chemicals, abrasives, or cleansers.
Disconnect ALL power before servicing.
Do not operate the unit with the cover removed.
To avoid the possibility of water damage (i.e. a hose leak) it is
recommended that you always turn o the water supply valves/faucets
when the washing machine is not in use.
Do not mount the Eco-laundry G3 unit vercally or at an angle.
Eco-laundry G3 is designed for residenal use only and is not intend-ed
for use in a commercial or industrial seng

G3 Eco Laundry System User Manual
Please Visit www.o3pure.com
Page 6
LED Bar Diagram
When the unit is plugged in and on stand-by mode,
It is suggested to choose “H” if you need to clean strong stains and white
clothes for beer result.
It is suggested to choose “L” to clean lightly soiled or delicate clothing (i.e.
silk and linen)
When there isn’t an O3 signal on the LED bar it is indicang that there isn’t
any ozone in the water.
Note: You need to initially touch the key on the left side of the unit to
choose different ozone levels while the washer is running.
The water drop will be in red if water leaks. Your Eco-laundry G3 is equipped
with an internal leak detector. If a leak happens to develop on the inside
of the unit, the water will accumulate on the boom panel. The sensor will
set o an audible alarm and will automacally turn the unit o. This alarm
will connue to buzz unl the leak is stopped and/or the unit is unplugged.
If this alarm should occur you should unplug the unit immediately and then
turn o the cold water valve. Contact Customer Service.
Indicators & Alarm System
Light Indicators
The vercal LED bar, viewed on the cover of the unit, has two states of operaon:
Blue light indicates normal operaon
Flashing red light indicates that the ozone generator is not operang properly. Please
contact your dealer for service or visit , www.o3pure.com

Warranty Informaon
Your O3 Pure LS is warranted to be free from all defects in material and workmanship in normal household
use for a period of (2) years limited from date of purchase. The warranty is granted only to the original
purchaser and members of his or her immediate household. Please retain your sales receipt. The warranty
is subject to the following provisions. Any damages or malfuncons caused by negligence, abuse, or use not
in accordance with the Owner’s Use Handbook are not covered by this warranty. Likewise, any defects or
damages caused by unauthorized service or the use of other than O3 Pure LS parts are not covered. O3 Pure
will, as its opon, repair or replace a defecve O3 Pure LS or part(s) for the O3 Pure LS that is covered by
this warranty. As a maer of warranty policy, O3 Pure will not refund the customer’s purchase price.
What is not covered by the Limited Warranty?
THIS WARRANTY DOES NOT COVER CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY
DAMAGE AND DOES NOT COVER INCIDENTAL COSTS AND EXPENSES RESULTING FROM ANY BREACH OF
THIS WARRANTY, EVEN IF FORESEEABLE. Some States or Provinces do not allow the exclusion or limitaons
of incidental or consequenal damages, so the above limitaon or exclusion may not apply to you depend-
ing on the State or Province of purchase.
Nor does this warranty cover damages caused by the services performed by anyone other than O3 Pure or
it authorized service providers, use of parts other than genuine O3 Pure LS parts or external causes such as
abuse, misuse, inappropriate power supplies or acts of God.
Other Limitaons ( Please retain your sales receipt for all warranty issues. )
THIS WARRANTY IS EXCLUSIVE AND IS IN LIEU OF ANY EXPRESS WARRANTY, WHETHER WRITTEN OR
ORAL. IN ADDITION O3 PURE HEREBY SPECIFICALLY DISCLAIMS ALL OTHER WARRANTIES WITH RESPECT
TO YOUR O3 PURE LS, INCLUDING MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE.
Some States or Provinces do not allow disclaimers of such implied warranes or limitaons on how long an
implied warranty lasts, so the above limitaon may not apply to you depending on the State or Province of
purchase.
How do you obtain warranty service?
O3 Pure products are high quality appliances and, with proper care, are intended to provide years of sas-
fying performance. However, should the need arise for warranty servicing; simply visit our website or email
us or call O3 Pure Customer Service (see last page for links and phone numbers). Please do not return your
O3 Pure LS unit for servicing without rst speaking to an O3 Pure Customer Service representave to obtain
an Authorized to Return number (ATR). O3 Pure LS unit returned without an ATR number will be returned
to the sender without servicing. Please have your proof of purchase handy when you make your call or O3
Pure will be unable to assist you.
G3 Eco Laundry System
Name:
Street Address:
City, State/Province, Country, Zip:
E-Mail Address:
Phone Number:
Purchased From:
Serial Number:
Date Purchased:
North American Contact
Pure Energy LLC
O3 Pure Division
8100A Main Street
Garrettsville, OH
44231
Please contact us without hesitaon if you need help:
Website: www.o3pure.com
Sales Website: www.pureenergystore.com
Sales / Service line : 1-330-527-9057
