Oasis BA-5429 User manual

1
These guidelines are recommended for
the proper installation of Oasis products. A
careful review of these procedures (and any
referenced publications) before starting is
important in avoiding an improper assembly
and/or installation.
NOTE: All illustrations in this publication are
typical, and may appear different than the
actual product. Optional items may also be
shown that were not ordered on the product
being installed.
ON WHIRLPOOL EQUIPPED MODELS,
A SEPARATE SET OF INSTRUCTIONS
IS PACKED WITH THE UNIT FOR THE
WHIRLPOOL SYSTEM. READ THEM
BEFORE INSTALLING UNIT!
Special Notes to Installer
uLIFT UNIT ONLY BY THE OUTSIDE
SHELL. DO NOT HANDLE BY SYSTEM
PIPING OR COMPONENTS!
uIt is the sole responsibility of the installer
to determine the requirements necessary for
compliance with all installation code require-
ments!
uAll paperwork packaged with the product
should be saved and presented to the home
owner upon completion of the installation!
uAll published product dimensions are
for reference only. Any critical dimensions
required for installation should be taken
directly from the product being installed!
u Anyindependentmodicationsmadeto
the product (or any options / accessories
supplied) beyond those required for normal
installation can void all warranties! (Refer to
warranties for further information)
INSPECTION GUIDELINES
Carefully check the unit upon receipt. Notify
your supplier immediately if any questions
or problems are encountered during this
process.
DO NOT INSTALL PRODUCT
WITHOUT FIRST ADDRESSING
QUESTIONS WHICH ARISE DURING
THE INSPECTION!
Basic Module Check
lCheck unit drain position for match to
bathroom drain location.
lCheck unit for surface damage.
lCheck unit color for coordination to other
bathroomxtures.
Whirlpool System Check
Assembly and operational instructions are
included in a separate publication for all
whirlpool and air equipped models.
lCheck for proper trim color and system
options.
INSTALLATION SITE FRAMING
Duetoindividualsitevariations,exact
guidelines for every situation cannot be
supplied. The recommended framing and
dimensional requirements shown are for a
typical application and may vary depending
on site requirements.
The dimensions shown are from the sur-
faces where the unit will be attached. This
surface can be bare studding, drywall, or
other suitable underlayment material. It is
importantthattheoorandallframingbe
square and level. Framing should be done
using accepted materials and construction
techniques in accordance with all applicable
codes.
®
Alcove Style Installation
BA-5429
BA-R-41
BA-R-51
Paradise Isle / TR(G)-S-900
Paradise Isle / TR(G)-IF-900
Geneva / TR(G)-S-200
Geneva / TR(G)-IF-200
Geneva / TR-S-240
Geneva / TR-IF-240
Prestige / TR-S-220
Prestige / TR-IF-220
Geneva / TR-S-270
Geneva / TR-IF-270
Futura / OV(G)-S-310
Futura / OV(G)-IF-310
Futura / OV-S-320
Futura / OV-IF-320
Styllis / BA-6036
Styllis / BA-IF-6036
Styllis / BA-6042
Styllis / BA-IF-6042
Styllis / BA-7236
Styllis / BA-IF-7236
Styllis / BA-6036 / BA-IF-6036
Styllis / BA-6042 (shown) / BA-IF-6042
BA-R-41 R/L
BA-R-51 R/L
Geneva 3260 / TR(G)-S-200 R (shown)
Geneva 3260 / TR(G)-IF-200 R/L
Futura 4272 / OV-S-320 (shown)
Futura 4272 / OV-IF-320
Futura 4260 / OV(G)-S-310 R (shown)
Futura 4260 / OV(G)-IF-310 R/L
Prestige 3466 / TR-S-220 R (shown)
Prestige 3466 / TR-IF-220 R/L
Geneva 3672 / TR-S-270 R (shown)
Geneva 3672 / TR-IF-270 R/L
Geneva 3660 / TR-S-240 R (shown)
Geneva 3660 / TR-IF-240 R/L
Styllis / BA-7236 (shown) / BA-IF-7236
Paradise Isle / TR(G)-S-900 (shown)
Paradise Isle / TR(G)-IF-900
BA--5429

2
NOTE: A pump access MUST BE
PROVIDED for all whirlpool equipped units
that do not include a removalbe apron
access panel. Additional access may be
required to comply with local codes (illust.
1c & 1e).
NOTE: Preconstructed walls may require
modicationsoradditionalframingmembers
toallowforpipesorttingswhichprotrude
from the unit on whirlpool equipped models.
Installation Procedure
NOTES:
1. ‘Wet-set’ is not required to support the
oorunderanOasisproductduetothe
encapsulated Balsa wood construction.
2. Block base feet on skirted (“S” & “BA”)
models are NOT pre-leveled and will NOT
beincontactwiththeroomoorwhen
placed within the framing and leveled.
With the unit positioned in the alcove, sever-
al details must be checked prior to securing
the unit in place (illust. 2 & 3).
l Conrmtheapronand/orthepre-leveled
unitbaseblocksarerestingushonthe
oor
l Conrmdrainposition.
l Conrmtheunitislevelalongeachside
and across each end.
l Conrmtheunitissquareintheframe-
work.
Oasis units are pre-leveled at the factory,
however, site variations may require shim-
ming to maintain level. If required, place
shimsorllermaterialundertheblock
bases.
NOTE: Any material place under the base
to keep the unit level must be structurally
sound and applied to ensure the unit’s
weight will be equally distributed over the
entire base.
Theuseofshimsorllermaterialmayalso
berequiredbehindthenailingangeat
each framing member to maintain the unit in
the proper position.
With the unit square and level in the alcove,
drilla1/8”holethroughtthenailingange
at each framing member. Secure the unit
inplaceacrossthebackwallrst,followed
BA-R-41 L (illustrated) BA-R-51 L (illustrated)
2” Dia. Drain
2-1/2” Dia. Overflow
C Drain
Clearance
Drain CenterOverflow Center
1-1/4”
1-1/4”
60”
8-1/2” 22-3/4”
51-1/2”
14-1/4”
15”
29-1/4”
30-1/2”
2-1/2”
13-1/4”
D
A
B
5-3/4”
Std Unit ABF Unit
A 18-1/2” 20-1/2”
B 17-1/4” 19-1/4”
C 1-1/2” 3-1/2”
D 14-1/2” 16-1/2”
2” Dia. Drain
2-1/2” Dia. Overflow
C Drain
Clearance
Drain CenterOverflow Center
1-1/4”
1-1/4”
60”
8-1/2” 22-3/4”
51-1/2”
15-7/8”
32”
33-1/4”
2-3/4”
13”
D
A
B
5-7/8”
16-1/8”
Illustration 1a - Unit Dimension & Alcove Framing Guidelines (dimensional tolerance +0 / -3/8”)
Geneva 3260 / TR(G)-S-200 L
Geneva 3260 / TR(G)-IF-200 L (illustrated)
(S model apron
extendsdown
toroomoor)
50-1/4”
9-3/4”
60”
16”
16”
2” Dia. Drain
32”
16-3/4“
4-1/4”
2-1/2” Dia. Overflow
1“ Drain Clearance
Drain CenterOverflow Center
6-1/2”
1-1/4”
21”
Arm Rest
Arm Rest
15-3/4“
Beveled Edge
22-1/4”
33-1/4”
1-1/4”
2”
Geneva 3660 / TR-S-240 L
Geneva 3660 / TR-IF-240 L (illustrated)
(S model apron
extendsdown
toroomoor)
49-5/8”
10-3/8”
60”
17-3/4”
18-1/4”
2” Dia. Drain
36”
16-3/4
4-1/4”
2-1/2” Dia. Overflow
1“ Drain Clearance
Drain CenterOverflow Center
6-1/2“
1-1/4”
21”
Arm Rest
Arm Rest
15-3/4“
Beveled Edge
22-1/4
”
37-1/4”
1-1/4”
2”
Std Unit ABF Unit
A 18-1/2” 19-3/4”
B 17-1/4” 18-1/2”
C 16” 17-1/4”
D 1-3/4” 3”
E 13-3/4” 15”
54”
1-5/8”
29”
30-1/4”
1-1/4”
50-3/4”
1-5/8”
14-1/2”
14-1/2”
8”
Apron
Style Line
1-1/4”
Splash
1-1/4”
46”
Tub Deck
2” Dia. Drain
2-1/2” Dia. Overflow
Drain Clearance
D
B
A
EC
BA-5429 L
(illustrated)

3
Std Unit ABF Unit
A 25” 26-3/4”
B 23-3/4” 25-1/2”
C 18-1/4” 20”
D 1-3/4” 3-1/2”
E 16” 17-3/4”
F - -
Std Unit ABF Unit
A 25” 26-3/4”
B 23-3/4” 25-1/2”
C 18-1/4” 20”
D 1-3/4” 3-1/2”
E 16” 17-3/4”
F - -
Std Unit ABF Unit
A 25” 26-3/4”
B 23-3/4” 25-1/2”
C 18-1/4” 20”
D 1-3/4” 3-1/2”
E 16” 17-3/4”
F - -
60-5/8”
11-3/8”
72”
18-1/4”
17-3/4”
2” Dia. Drain
36”
16-3/4“
4-1/4”
2-1/2” Dia. Overflow
1-1/8“ Drain Clearance
Drain CenterOverflow Center
7-1/4“
1-1/4”
21”
Arm Rest
Arm Rest
15-5/8“
Beveled Edge
22-1/4”
37-1/4”
1-1/4”
2”
Illustration 1b - End Drain, Unit Dimension & Alcove Framing Guidelines (dimensional tolerance +0 / -3/8”)
Prestige / TR-S-220 L
Prestige / TR-IF-220 L (illustrated)
(S model apron
extendsdown
toroomoor)
57-1/4”
8-3/4”
66”
17-1/8”
2” Dia. Drain
34-1/4”
18“
3”
2-1/2” Dia. Overflow
2-1/4“ Drain
Clearance
Drain CenterOverflow Center 6“
22-1/4”
15-3/4“
Leveling Supports
17-1/8”
1-1/4”
21”
Arm Rest
Arm Rest
35-1/2”
1-1/4”
1-3/4”
Geneva 3672 / TR-S-270 L
Geneva 3672 / TR-IF-270 L (illustrated)
(S model apron
extendsdown
toroomoor)
Futura 4260 / OV(G)-S-310 L
Futura 4260 / OV(G)-IF-310 L (illustrated)
(S model apron
extendsdown
toroomoor)
2” Dia. Drain
4-1/4”
2-1/2” Dia. Overflow
1-3/8“ Drain Clearance
Drain CenterOverflow Center 6“
Leveling Supports
1-1/4“
Arm Rest
Arm Rest
Beveled Edge
15-1/8” 20-3/4”
51-1/2”
60”
9“
42”
43-1/4”
21”
21”
22”
16-1/2” 2“
Styllis / BA-6042
Styllis / BA-IF-6042 (illustrated)
(BA model apron
extendsdown
toroomoor)
Styllis / BA-6036
Styllis / BA-IF-6036 (illustrated)
(BA model apron
extendsdown
toroomoor)
Styllis / BA-7236
Styllis / BA-IF-7236 (illustrated)
(BA model apron
extendsdown
toroomoor)
1-7/8”
36”
37-1/4”
1-1/4”
1-1/4”
60”
56-1/4”
1-7/8”
9”
51”
2-1/2” Dia. Overflow
2” Dia. Drain
Head
Rest
Arm Rest
Arm Rest
Low Bow Shelf
Low Bow Shelf
Head
Rest
18”
18”
5-1/2”
4-1/2”Shelf
Drain Clearance
D
B
AE
C
2”
Pre-Leveled Block Base (IF model)
1-5/8”
42”
43-1/4”
1-1/4”
1-1/4”
60”
56-3/4”
1-5/8”
9”
51”
2-1/2”Dia.
Overflow
2” Dia. Drain
Head
Rest
Arm Rest
Arm Rest
Low Bow Shelf
Low Bow Shelf
Head Rest
21”
21”
5-1/2”
4-1/2”Shelf
Drain Clearance
D
B
AE
C
Pre-Leveled Block Base (IF model)
2”
Pre-Leveled Block Base (IF model)
2”
1-1/4”
5-1/2”
Drain Clearance
D
B
A
E
C
1-7/8”
36”
37-1/4”
1-1/4”
72”
68-1/4”
1-7/8”
9”
63”
2-1/2” Dia. Overflow
2” Dia. Drain
Head
Rest
Arm Rest
Arm Rest
Low Bow Shelf
Low Bow Shelf
Head
Rest
18”
18”
4-1/2”Shelf

4
Fixture
Blocks
Drain Cut-Out
21" W x 16" H
Pump Access
MANDATORY
on All Whirlpool
Equipped Units
Drain Cut-Out
5
“
04
02
Mi
n
i
m
u
m
Al
cove
D
ept
h
,
U
n
i
t
R
oug
h
-
In
D
ept
h
Drain
Center
05
Drain
Center
0
6
07
08
03
Fi
n
ished
Unit Dept
h
0
1
Alcove Length - Unit Width
NOTE: Left End Drain Installation Illustrated.
21
“
Wi
de
W
hirl
p
ool
P
ump
Access
Illustration 1c - End Drain, Unit Dimension & Alcove Framing Guidelines (dimensional tolerance +0 / -3/8”)
2” Dia. Drain
3”
2-1/2” Dia.
Overflow
2“ Drain Clearance Leveling Supports
1-1/4“
21”
41-3/4”
12-3/4”
29”
16”
18”
60”
30”
22-1/4”
43”
1-1/4”
30”
2”
Paradise Isle TR(G)-S-900
Paradise Isle TR(G)-IF-900 (illustrated)
(S model apron
extendsdown
toroomoor)
Futura 4260 / OV-S-320
Futura 4260 / OV-IF-320 (illustrated)
(S model apron
extendsdown
toroomoor)
2” Dia. Drain
4-1/2”
1-3/4“ Drain Clearance Leveling Supports
1-1/4“
Beveled Edge
16-1/2”
14-3/4”
20-3/4”
36”
36“
42”
8-1/4”
33-3/4”
22”
43-1/4”
1-1/4”
72“
2-1/2” Dia. Overflow
2“
Illustration 1d - Front-Center Drain, Unit Dimension & Alcove Framing Guidelines (dimensional tolerance +0 / -3/8”)
Model 01 02 03 04 05 06 07 08
BA-5429 54” 30-1/4” 29” 14-1/2” 8” 10-1/2” 12” 10-1/2
BA-R-41 60” 30-1/2” 29-1/4” 14-1/4” 8-1/2” 11” 11-3/4” 13-1/2”
BA-R-51 60” 33-1/4” 32” 15-7/8” 8-1/2” 11” 13-3/8” 13-5/8”
TR(G)-S/IF-200s60” 33-1/4” 32” 16” 9-3/4” 12-1/4” 13-1/2” 13-1/2”
TR(G)-S/IF-240s60” 37-1/4” 36” 17-3/4” 10-3/8” 12-7/8” 15-1/4” 15-3/4”
BA-6036 60” 37-1/4” 36” 18” 9” 11-1/2” 15-1/2” 15-1/2”
BA-6042 60” 43-1/4” 42” 21” 9” 11-1/2” 18-1/2” 18-1/2”
TR-S/IF-220s66” 35-1/2” 34-1/4” 17-1/8” 8-3/4” 11-1/4” 14-5/8” 14-5/8”
TR(G)-S/IF-270s72” 37-1/4” 36” 18-1/4” 11-3/8” 13-7/8” 15-3/4” 15-1/2”
BA-7236 72” 37-1/4” 36” 18” 9” 11-1/2” 15-1/2” 15-1/2”
OV(G)-S/IF-310s 60” 43-1/4” 42” 21” 9” 11-1/2” 18-1/2” 18-1/2”
sWhirlpool equipped ‘S’ model includes a removable apron access panel

5
bytheangesateachend,thendown
thefrontverticalanges.Use1-1/4”large
headed nails or screws. Continously check
toconrmtheunitremainssquarewithinthe
alcove as it is being secured (illust. 3 & 4).
NOTE: It is advisable to protect the unit sur-
face with a thin plywood or cardboard shield
whilefasteningtheangestotheframing
(illust. 5).
WARNING!
THE INSIDE UNIT SURFACE SHOULD
BE CLEAR OF ALL LOOSE DEBRIS
AND THE SURFACE PROTECTED
BEFORE STEPPING INSIDE.
Removable Apron Panel
Certain aproned models come standard with
a removable apron panel, while most mod-
els include a removable apron panel when a
whirlpool or air system is ordered. Refer to
yourspecicmodelforincludedfeatures.
Oasis models with a removable apron
system incorporate 4-6 adjustable magnet
assemblies for quick and secure panel
removal and reattachment.
The following procedure is recommended
for the careful removal of the apron panel.
1. Grasp the bottom of the apron panel
edge with both hands and pull away from
the unit. This will release the bottom
magnets while the panel top remains at
rest on the upper row of magnets (illust. 7).
2. Pull the panel completely away from the
top magnets and safely store the panel
out of the way to avoid damage.
To reattach the panel:
1. Locate the ‘up’ arrow on the inside of
the panel and rotate it to the correct
position for reassembly.
2. Holdingthepanelatthetopwiththen-
ished side facing you, locate the magnet
alignment edges of the two outside re-
ceiverplateswithyourngers.Anglethe
panel top in toward the unit apron and
attach the receiver plates to the outside
magnets, ensuring the alignment edge is
above the top of the magnet (illust. 8).
3. Once the top of the panel is aligned,
complete the attachment by pushing the
bottom of the panel against the lower
magnet assemblies until they catch.
4. In the event that the reattachment does
not line up, simply remove the panel
(steps 1 & 2 for panel removal) and
repeat the attachment.
Removable Panel Adjustments
Hand adjustments can be made to the
removable apron attachment system should
they become necessary. Simply move the
magnets in or out by turning in either direc-
tion (illust. 9). Reattach the panel to check
foracorrecttandreadjustthemagnetsif
necessary
Nailing
Flange
Wall
Framing
1. Position Tub
in Framed Area. Confirm unit apron is
flush on floor. Whirlpool Access
Confirm Drain Alignment
Nailing Flange
Illustration 2 -
Unit Installation
Procedure
Fixture
Blocks
Front Drain Cut-Out
5
“
0
4
02
Minim
u
m
A
lcove Depth,
U
nit Rough-In
D
epth
Drain
Cut-Out
Drain
Center
0
7
08
01
Alcove Length - Unit Width
03
Fini
s
h
ed
Unit De
p
t
h
06a
0
6b
0
5a
0
5b
5
“
21
“
Wid
e
Whi
r
l
poo
l
P
ump
A
ccess
Model 01 02 03 04 05a 05b 06a 06b 07 08
TR(G)-S/IF-900*s60” 43” 41-3/4” 29” 30” 30” 27-1/2” 27-1/2” 26-1/2” 10-1/4”
OV-S/IF-320*s72” 43-1/4” 42” 33-3/4” 36” 36” 33-1/2” 33-1/2” 31-1/4” 5-3/4”
*Standard ‘S’ model includes a removable apron access panel
sWhirlpool equipped ‘S’ model includes a removable apron access panel
Illustration 1e - Front-Center Drain, Unit Dimension & Alcove Framing Guidelines (dimensional tolerance +0 / -3/8”)

6
Water Supply and Drain Connections
Refer to, and follow, the assembly and
installation instructions provided with the
supply valves and drain system. Carefully
check all connections for leaks.
Finishing Guidelines
Fillerstripsorllermaterialmayberequired
over the framing to ensure the under lay-
mentmountsushoverthenailinganges.
A water resistant under layment is recom-
mended surrounding the unit. Stop the
under layment 1/16 to 1/8-inch from the unit
surface,andllthespacewithacontinuous
bead of water resistant sealant. (Illust. 6)
NOTE: Oasis recommends a high qual-
ity silicone based sealant with a mold and
mildew resistant content.
Use care when fastening the under layment
near the unit surface to avoid damage. Seal
the under layment seams and edges, as
required,andinstallthenishmaterialto
specications.
UNIT SURFACE CARE
WARNING!
NEVER USE ABRASIVE MATERIALS,
OR ABRASIVE CLEANERS
ON THE UNIT SURFACE!
EXTREME CAUTION is urged regarding
the use of any cleaner, acid or solvent
on the unit surface.
READ AND FOLLOW PACKAGE
INSTRUCTIONS FOR ALL
PURCHASED CLEANING PRODUCTS!
Through routine use, the unit surface can
collect residues from soap, bath additives
and natural body oils. Additional deposits
can also collect from minerals or particles
found in the water. After each use, wipe the
excesswaterfromtheunit.Thispractice
will reduce the buildup of deposits and help
maintain the natural unit lustre.
Following a thorough surface cleaning,
anapplicationofqualityautomotivewax
will help reduce major accumulations. The
actualscheduleforcleaningandwaxingwill
depend on unit usage and water quality.
WARNING!
NEVER APPLY WAX
TO THE UNIT FLOOR!
uRoutine Cleaning: Mild, non-abrasive
cleanerspecicallyformulatedforgelcoat
and acrylic surfaces recommended. (Rinse
surface thoroughly)
uHeavy Soap Deposits: Liquid ammonia
household cleaner, applied full strength.
(Rinse surface thoroughly)
uStubborn Stains: Liquid household
cleanerorhydrogenperoxideapplied
full strength. Place a saturated clean rag
directly on stain and let stand several hours.
(Rinse surface thoroughly)
uHard Water Scales: Liquid scale remover
or white vinegar, applied full strength.
(Rinse surface thoroughly)
uMold/Mildew: Liquid mildew remover or
baking soda and water paste. (Apply paste
andallowtozzseveralminutes.)(Rinse
surface thoroughly)
uConstruction Adhesive: Soften adhesive
with a hand held hair dryer and peel off
adhesive. (Caution is advised when using
any electrical device near water.)
For adhesive residue, apply rubbing alcohol
or nail polish remover, full strength. (Rinse
surface thoroughly)
WARNING!
BATH MATS AND OTHER ITEMS
HELD IN PLACE USING SUCTIONS
MUST BE REMOVED FROM THE UNIT
SURFACE AFTER EACH USE.
OVER AN EXTENDED PERIOD
FAILURE TO REMOVE
SUCTION ATTACHED ITEMS WILL
DAMAGE THE UNIT SURFACE.
Illustration 3 -
Unit Installation
Procedure
Nailing
Flange
Wall
Framing
2. Level Tub
in Framed Area.
Whirlpool Access
Confirm unit is square
within the framed area.
Nailing Flange
Confirm the tub is level
along the sides and
across each end.
Illustration 3 -
Unit Installation
Procedure
Nailing Flange
Wall Framing
Drill 1/8 inch hole through
flange at each framing member
Illustration 4 - Securing Unit
Wall
Framing
Secure unit to
framing with
large headed
fasteners.
CAUTION: Protect unit surface
with a shield when fastening.
Nailing Flange
Illustration 5 - Securing Unit

7
Water Resistant
Underlayment
Waterproof
Sealant
Furring Strip or
Shim Material
Nailing
Flange
Wall Framing
Illustration 6 - Securing Unit
O
U
T
I
N
Illustration 9 - Panel Adjustment
Panel
Angled
For
Reattachment
Adjustable
Magnet
Assembly
Top
Receiver
Plate
Magnet
Alignment
Edge
Attach
Top of Panel
First
Illustration 8 -
Panel Attachment
Removable
Panel
Top
Receiver
Plate
Adjustable
Magnet
Assemblies
Bottom
Receiver
Plate
Pull Panel
Bottom
Out To
Remove
Illustration 7 -
Panel Removal

8INST-0760.02 / 060315
Oasis Lifestyle, LLC - 1400 Pidco Drive - Plymouth, Indiana 46563
Oasis Lifestyle Product Assurance Program
Bathing and Shower Unit Structure & Surface Finish Limited Warranty
OasisLifestyleprovidesaperformanceassuranceprogramforunitstructuralintegrityandsurfacenishcoveringave
(5) year period from the date-of-purchase on GELCOAT, and covering a ten (10) year period from the date-of-purchase on
VACUUM FORMED ACRYLIC product, for the original purchaser and subsequent consumer. This Oasis limited warranty pro-
gramaddressesspecicdefectsintheproduct,andtheworkmanshipassociatedwiththemanufactureoftheOasisbathing
andshowerproduct.Thespecicdefectscoveredmustresultinasignicantlyalteredappearanceand/oraffecttheintended
performance standards for the product under normal residential use.
Hydro-Massage Systems (water recirculation & air), Option & Accessories Limited Warranty
Oasis Lifestyle provides a performance assurance program for their hydro-massage systems (herein called ‘system’), and
their options and accessories covering a two (2) year period from the date-of-purchase for the original purchaser and subse-
quentconsumer.ThisOasislimitedwarrantyprogramaddressesspecicdefectsinthesystemcomponents,andthework-
manship associated with the assembly of the systems, along with offered options and accessories installed by Oasis, on an
Oasisunit.Thespecicdefectscoveredmustresultinasignicantlyalteredappearanceand/oraffecttheintendedperfor-
mance standards for the system, the option and/or the accessory.
Duringthecoverageperiod,Oasiswill,atitsdiscretion(followingavericationbyanauthorizedOasisrepresentative),either
provideserviceorsupplyareplacementproductwithoutcharge,butexcludinganycostassociatedwiththetransportation,
removalofand/orreinstallationoftheunit(module).FailuretoallowrequestedinspectionbyanauthorizedOasisrepresenta-
tive,and/orfailuretoprovideadequateaccessibilityforanauthorizedinspection,and/orserviceperformedpriortodocument-
edauthorizationfromOasisLifestyle,LLC.,maydelayservice,and/orpossiblyterminateanywarrantycoverage,andremove
any liability to Oasis Lifestyle, LLC.
This ‘Product Assurance Program’ does not cover service resulting the following:
a) Impropereldinstallationoftheproduct,system,option,accessory,and/orsurroundingstructure
modications,and/orutilityserviceconnectionsbeyondtherecommendationssuppliedbyOasisandwithinthe
scope of applicable codes and ordinances; or
b) Carelessness,damage,abuse,misuse,negligence,impropercare,re,ood,oractsofGod;or
c) Non-conforming use, including any use beyond those intended for the product, system, option and/or
accessory, including failure to follow the Prescribed Care and Maintenance Instructions; or
d) Anyunauthorizedalterationsormodicationstotheproduct,system,option,accessoryand/ortheindividual
parts or components supplied by Oasis.
e) Any surface and/or component staining, discoloration, component failure and/or build-up caused as a result of
water chemistry or water quality at the site.
f) Service resulting from normal use and wear for the product, system, option and/or accessory.
Repairorthesupplyingofreplacementproductand/orcomponents,underthislimitedwarrantyprogram,shallbetheex-
clusive remedy. Oasis Lifestyle, LLC., shall not be liable for any incidental or consequential damages, including damages to
thebuilding/structure,thecontents,theoccupants,orbreachofanyexpressedorimpliedwarranties.OasisLifestyle,LLC.,
doesnotrecognize,norauthorizesanypartytoprovideimpliedorwrittenwarrantiesregardingaproduct,system,optionand/
oraccessoriestnessforaparticularpurpose,normodifythetermsofthelimitedwarrantybeyondthosestated.
Somestatesdonotallowtheexclusionorlimitationofincidentalorconsequentialdamages,orallowlimitationsonthedura-
tionofanyimpliedwarranty.Therefore,theaboveexclusionsand/orlimitationsmaynotapply.
THIS WARRANTY PROVIDES SPECIFIC LEGAL RIGHTS, WHICH CAN VARY FROM STATE-TO-STATE.
800.638.8556
HomeInnovation.com
The manufacturer represents that the product to which this
label is affixed (a) duplicates samples independently
tested by Home Innovations Research Labs and certified
to conform to the requirements of HUD UM Bulletin 73a
and the appropriate ANSI Z124 and ICC/ANSI A117.1
standards, and (b) has been manufactured under quality
controls deemed appropriate by the manufacturer and
periodically reviewed by the certifier.
Oasis Lifestyle, LLC
Plymouth, IN
6006
800.638.8556
HomeInnovation.com
The manufacturer represents that the product to which this
label is affixed (a) duplicates samples independently
tested by Home Innovations Research Labs and certified
to conform to the requirements of HUD UM Bulletin 73a
and the appropriate ANSI Z124 and ASME A112.19.7
standards, and (b) has been manufactured under quality
controls deemed appropriate by the manufacturer and
periodically reviewed by the certifier.
Oasis Lifestyle, LLC
Plymouth, IN
6006
®
