When bank lock to on, type the two-digit number (00
through 99) ot the desired patch In the current Bank.
Or, press + or -until the desired patch In the current
Bank is displayed. To change Banks, hold down Bank
Lock and t>pe the d-gtt ol the desired Bank (0 through
9).
Selecting aPatch From MIDI
How do you enter a3-dlgit patch nurrtoer if your Master instru-
ment has only 2-digit patches? This is where bank lock comes
Is-flGDQDGD
Ext
Funct Bank Lock
In especially handy.
Press the Bank Lock key to turn on bank lock. The
decimal point between the first and second display
will light. Do a patch change on your Master Instrument,
and the MatrbMOOO recalls the corresponding patch In
the current Bank. For instance, suppose patch 309 is
selected on the Matrix-1 000* Press Bank Lock, and
then select patch 22 on your Master instrument. The
Mairix-1000 selects patch 322 .
If your Master instrument has patch numbers which start
all rather than 0. then patch 01 on the Master selects
patch 00 of the selected bank on the Matrix-1000, patch
02 on the Master selects patch 01 ,etc.
•To change banks (ram MIDI, push (or pull) the Master
controls Vfcrato or Modulation wheel, lever or Joystick (MIDI
controller #1) to Its maximum poeitlon. While holding the
Master's Vforato control at Its maximum, select a patch trom
through 9on the Master The bank of the same number is
recalled on the Matrix-1000. For instance, suppose patch 322 is
selected on the Matrix-1 000. Hokf the Vibrato control and select
patch 4onthe Master The Mairix-1000 selects bank 4, so the
patch changes trom 322 to 422,
It your Master has patch numbers which start at 1rather than 0,
then patch 1selects bank 0, patch 2selects bank 1, etc.
•In short, whenever the Matrix-1000 sees aMIDI Patch Change
when the Vlbraio or Modulation (MIDI controller #1) is more than
half way on. It uses the patch number as a bank number. So be
careful —»you're playing notes with your Vibrato on, and you
make aPatch change, the Matrix-1000 understands thai as a
bank change command. To allow bank changing without using
Vibrato, MID! controller #31 performs the same function, ThEs
mode Is the same as that found In the Oberhelm DPX-1 and
some other Instruments.
•Hbank lock is turned off, the Matrix-1000 will receive patches
000 through 127 over MIDI If abank change is sent trom MIDI,
using erther the Vibrato or MIDI controller #31 ,the Matrix-1000
turns on bank lock automatically.
MIDI patch changes are transmitted and received by the Matrix-1000
on Its Basic Channel. Patch changes and bar* changes are re-
ceived by the Matrix-1 000 In all front panel modes, not Just Patch.
18 Matrix-1000 Owner's Manual Matrix- 1000 Owner's Manual 19
