OBSBOT Tail Guide

OBSBOT Tail Air
Design Manual
Version: V1.0

Table of Contents
1. Introduction ......................................................................................................... 3
1.1 Purpose ....................................................................................................... 3
1.2 Definition ....................................................................................................3
2. Overall Design ..................................................................................................... 4
2.1 Hardware Description ............................................................................. 4
2.2 Software Structure ................................................................................... 4
2.3 Conditions and Restrictions .................................................................. 5
3. Function Detailed Description ........................................................................ 5
3.1 Hardware Function Description ........................................................... 5
3.1.1 Button .............................................................................................. 5
3.1.2 Interface Description ................................................................... 6
3.1.3 Buzzer ...............................................................................................6
3.1.4 Lighting ............................................................................................6
3.2 Software Function Description ............................................................. 8
3.2.1 Connection ..................................................................................... 8
3.2.2 Shooting Screen ............................................................................ 9

1.Introduction
1.1 Purpose
This document is operation guide of OBSBOT Tail Air equipment and the Obsbot
Start APP. In this document, we introduce the lights, buzzers and buttons of the device
in detail. It also includes a specification of the software function modules matched with
the device, so that readers can understand all the functions of the system and specific
operation.
1.2 Definition
OBSBOT Tail Air is an AI streaming camera mainly for live streaming. It can be
placed and used by fixedly placing it on the desktop, plane and other positions. By
combining the artificial intelligence, camera and software operations, the APP can view
the real-time images of the camera.
The software contains the following functions:
1) Connect device
2) Get video signal

2.Overall Design
2.1 Hardware Description
The button of device is mainly for switching the device on and off, there are
different lights and sounds when switching the device on and off, so that users can use
the device more clearly and simply.
2.2 Software Structure
The software is for the management of camera data transmission, the control of the
equipment and the video transmission .

2.3 Conditions and Restrictions
IOS: Compatible with IOS 12 and above
Android phone: Compatible with android 8.0 and above
3.Detailed Function Description
3.1 Hardware Function Description
3.1.1 Buttons
Power on: Long press 3s to power on
Sleep: In the power-on state, long press 3s to sleep
Shutdown: In the power-on state, press and hold 10s to shut down

Power display: single press to check the power in the off state
3.1.2 Interface Description
Type-C: Mainly used for charging or connecting to a computer to transfer files.
HDMI micro: Mainly used to connect to a monitor to display the current camera screen.
AUX: aux audio interface, AUX 3.5mm audio interface can be used for headphones,
microphones, computers and other devices with audio interface.
SD card slot: microSD card insertion.
Dual microphones: used to capture external audio.
3.1.3 Buzzer
Description of function:
function
sound
priority
Low battery and auto
sleep
In the last 1s, " DDD " beeps 3 times in a row
1
Error message
"DDD · · · " continuously beeps 6 times. Reasons for error
messages: slow SD card, device connection error, high
temperature warning, upgrade failure, etc.
2
3.1.4 Lighting
Description of function:
Solid: Represent the color of the light remains unchanged and the battery lasts
Breathing: The brightness of the light continues to increase from 10 to 100, and
then continues to decrease from 100 to 10, which is one breath
Horse racing: Represent the number of the lamp beads, 1-2-3-4, one time for horse

racing
Action
Light
Color
Effect
Frequency
Stop
Show
Priority
Shutdown
none
none
-
-
1
T1
Boot process,
Shutdown
blue
horse
racing
fast
Stop after
complete
shutdown and
startup
1
T1
Device error
red
solid
-
Stop after
device error is
resolved
2
T1
The device is not
ready, such as: TF
card is not inserted,
TF card is full
red
breathing
fast
Stop after
device error is
resolved
3
T1
STA mode
blue
solid
-
Switch to the
mode that is
always on, and
the display in
other situations
takes
precedence
over this mode
9
T2
AP mode
White
solid
-
Switch to the
mode that is
always on, and
the display in
other situations
takes
precedence
over this mode
9
T2

3.2 Software Function Description
3.2.1 Connection
3.2.1.1 Function Description
OBSBOT Start only supports connecting to a single device. It can search for nearby
devices through LAN and Bluetooth. After Bluetooth discovers the device, the user can
configure the network for the device through STA/AP.
LAN: Corresponding to the APP "LAN" connection, it is divided into two parts: wired
and wireless. The wired connection cannot switch the connection. That is, if you find
that the device and APP are in the same LAN, you can enter the shooting page.
STA: Corresponding to the APP "Wi-Fi" connection, that is, connect the device and APP
to the same LAN.
AP: Corresponding to the APP "cellular data" connection, that is, connect the APP to the
hotspot of the device, and streaming through the cellular data of the mobile phone.
3.2.1.2 User Permission Description
Tail Air can be connected via mobile phone. Multiple devices can be searched at the
same time, but one device only supports one APP to connect at the same time, and
another APP cannot find the connected device.

3.3.1.3 Requirements Description
3.2.2 Shooting Screen
Search Device
1. The user needs to open the APP and turn on Bluetooth and Wi-Fi, and grant relevant
permissions to the APP.
Connect Device
1. Search the device through Bluetooth, click connect, confirm whether the Bluetooth is
paired, wait for the Bluetooth connection if it is not paired. If it has been paired, start to
choose the Wi-Fi connection directly, and enter the Wi-Fi selection page.
Search the device through Bluetooth, select the cellular data connection, confirm
whether the Bluetooth is paired, and wait for the Bluetooth connection if it is not paired.
If it has been paired, connect the mobile phone to the device network, and you can
enter the camera.
3.3.2.1 Function Description
After the device is successfully connected, you can enter the shooting screen, and you
can switch the output screen by clicking the screen.

White box: Preview position
Red box: Output location
Preset position red: Output preset position
Preset position yellow: Preset position has been added, but not output
Movement path: Display the movement path according to the connection of the center
point of the output and preview frames
PTZ movement: When the PTZ moves, the animation style of ">>>" will appear.
3.3.2.2 Requirements Description
Output Display
Display the output screen according to the output frame, and the output frame will
always be the position of the "red" box

Output Switch
When clicking a position other than the preset position, it will directly switch the output
screen to this position, and the screen is the default size of the frame
PTZ Position
When the preview frame slides to the edge of the screen, arrows guide(up, down, left,
right, oblique) will appear, and the guide position will appear on the opposite side of
the moving position (eg: slide to the right, the guide will appear on the leftmost inside
the frame). PTZ rotates in this direction and stops when you let go.
4.FCC STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference
(2) This device must accept any interference received, including interference that may
cause undesired operation.
Warning: Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class

B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures: Reorient or relocate the receiving antenna. Increase the separation between
the equipment and receiver. Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected. Consult the dealer or an experienced
radio/TV technician for help.
FCC Radiation Exposure Statement: This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 20cm between the radiator & your body.
5.IC STATEMENT
This device complies with Industry Canada licence-exempt RSS standard( s). Operation
is subject to the following two conditions:
(1) this device may not cause interference.

(2) this device must accept any interference, including interference that may cause
undesired operation of the device."
- French:"
Le présent appareil est conforme aux CNR d'Industrie Canada applicables
aux appareils radio exempts de licence. L'exploitation est autorisée
aux deux conditions suivantes :
(1) l'appareil nedoit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le
fonctionnement."
Le présent appareil est conforme Après examen de ce matériel aux conformité ou aux
limites d’intensité de champ RF, les utilisateurs peuvent sur
l’exposition aux radiofréquences et compliance d’acquérir les informations
correspondantes. La distance minimale du corps à utiliser le dispositif est de 20cm.
The device is compliance with RF exposure guidelines, users can obtain Canadian
information on RF exposure and compliance. The minimum distance from body to use
the device is 20cm.

6.CE STATEMENT
This product complies with the radio interference requirements of the European
Community.
Product name: OBSBOT Tail Air
Product model: OSB -2108-CW
Manufacturer: REMO TECH Co.,LTD.
Frequency Range:
Max. Transmit Power:
SIMPLIFIED EU DECLARATION OF CONFORMITY
The simplified EU declaration of conformity referred to in Article 10(9) shall be
provided as follows:
Hereby, REMO TECH Co.,LTD declares that radio equipment type MOCHA is in
compliance with Directive 2014/53/EU, and this product is allowed to be used in all EU
member states. The full text of the EU declaration of conformity is available at following
company website:www.remo-ai.com .This product can be used across EU member
states.
