Observint BLK-CPD227VH User manual

1BLK-CPD227VH_CQ
9/26/12
Base
Camera
module
L-wrench
Dome
Base
cable
access
Mounting
screws (2)
Camera
module
screws (2)
Dome
screws (3)
Side cable
access, cap
Dome
retention
cable
Drop
cable
4. Select the best fasteners to secure the base to the mounting surface. Screws provided with the
camera are adequate many surface types.
5. Drill holes in the mounting surface as required for the mounting screws (wall inserts, etc.), and the
cables, if needed.
6. Route the video / power extension cables from your monitoring equipment into the camera base.
Note that the extension cable connectors are usually dierent at each end.
7. Connect the video / power extension cables to the drop cable inside the base cavity.
8. Reattach the camera module to the based using the two screws removed earlier.
9. Connect the video / power extension cable to your camera, then connect the other end to a video
monitor and 12 Vdc or 24 Vac power source. NOTE: 1) The camera power cable provides a 2-pin
connector; an adapter with screw-down terminals is included in the box. 2) If powering the camera
with 12 Vdc, observe the polarity marked on the power drop cable.
12 Vdc polarity guide
Video drop cable
Terminal adapter
Power drop cable
Drop cable connectors
10. Verify that you can see video from your camera at the monitoring equipment.
BLK-CPD227VH 650 Line Outdoor
Vandalproof IR Camera
Quick Installation Guide
This document guides you through the basic steps to install and use your BLK-CPD227VH camera. The
camera includes 2.8-12 mm lens, 12 Vdc or 24 Vac powering.
Camera features include:
• Can be installed indoors or outdoor.
• 650 TV-line resolution in color, 720 TVL B / W
• Advanced Gen V DSP
• IP67 rated (waterproof)
• Durable enclosure: body is aluminum, dome is polycarbonate
• Smart DNR technology eciently reduces noise in low light conditions
• 75 foot range with Smart IR 24-LED IR LED array
• 3-axis camera gimbal - mountable on ceiling, wall or sloped surface
• Day & Night function (ICR)
• Support up to 8 privacy zones
• Digital Wide Dynamic Range (DWDR)
• Multi function : High-Light Mask, Lens Shading Compensation, Smart Motion Detection
• Smart IR technology greatly improves camera image in B / W mode when the IR LED array is on
• Multi-language full OSD support
Precautions
• Do not install the camera in locations subject to moisture or vibration.
• Do not scratch the camera, especially lens or dome cover.
• Operate the camera within the specied temperature range 14 °F ~ 122 °F (-10 °C ~ 50 °C).
• Handle with care. Dropping it can cause serious damage to the camera.
• Do not install the camera in locations where direct sunlight shines onto or be reected onto the lens.
• Use a 12 Vdc, 1A regulated power adapter, or 24 Vac power adaptor.
Installation
1. Remove the camera dome by loosening the three dome cover screws with the L-wrench provided,
then lifting o the cover. See the graphic to the right.
2. Remove the camera module assembly from the base by removing the two camera module screws.
3. Using the base as a template, mark the locations on the mounting surface for the mounting screws
(2) and the hole for the network video and power cables routed into the base. Note that the network
cable can be routed or through the mounting surface at the center of the base, or in through a cap
on the side of the base. The camera can be mounted on a ceiling or wall.

2© 2012 Observint Technologies, Inc. All rights reserved.
NOTE: An external video connector is provided on the camera module. See “Maintenance board”
on page 2.
11. While observing the video image from your camera, adjust the pan, tilt, and roll as follows to point
the camera at your surveillance target: Be careful not to displace the rubber ring around the lens.
a. Pan adjustment: Grasp the gimbal assembly, then rotate it (0° ~ 360°) left (L) or right (R).
b. Tilt adjustment: Grasp the protractor, then tilt it up (U) or down (D) (19° ~ 90°).
c. Roll adjustment: Grasp the camera module (within the gimbal), then rotate it (0° ~ 360°)
to set the horizon line of the image.
Gimbal
(Pan adjust)
Camera module
(roll adjust)
grasp here
Rubber ring (seal)
Protractor
(Tilt adjust)
12. While observing the video image from your camera, adjust the zoom and focus settings as follow
(see graphic below):
a. Zoom: Rotate the Tele (T) - Wide (W) ring (1) to produce the best view of your surveillance
target.
b. Focus: Rotate the Near (N) - Far (F) ring (2) to produce the best image clarity.
13. Reinstall the dome.
Maintenance board
The maintenance board is part of the camera module assembly. It includes an external video port, a debug
port, and a joystick for using the OSD menus.
Joystick
External video connector
Debug port
Video adapter cable
Maintenance board and video adapter cable
• External video connector: Use this connector with the adapter cable provided (2-pin to RCA) to
connect to a local monitor for observing video from the camera. This feature is useful during camera
setup and troubleshooting.
• Debug port: Maintenance port for engineering use only.
• Joystick: Used for accessing and conguring the camera through the on-screen display (OSD) menus:
The OSD menu structure is shown in the table below.
—Push the joystick down (toward the board) to open the OSD menu system, conrm a selection, or
open a submenu.
—Rock the joystick toward the UP or DOWN to move vertically through the OSD menus.
—Rock the joystick toward the LEFT or RIGHT to change the option displayed for an OSD parameter.
To select the parameter, press the joystick down.
—Example: Using the joystick to setup the camera for high ACG (automatic gain control).
»While observing video from the camera, press the joystick down to open the OSD main menu.
»Rock the joystick toward the UP or DOWN repeatedly until AGC is highlighted.
»Rock the joystick toward the LEFT or RIGHT repeatedly until HIGH appears.
»Press the joystick down to conrm the selection.
»Rock the joystick toward the UP or DOWN repeatedly to highlight RETURN.
»Press the joystick down to conrm the selection (RETURN: close the menu).
OSD Menu Structure
Function
setting menu Select menu Sub-menu Contents
1. EXPOSURE
Lens DC
Brightness 0 ~ 99 : Adjust brightness with a DC iris lens
E. Shutter AUTO, 1/60, 1/100FLK, 1/120, 1/250, 1/500, 1/1000, 1/2000,
1/4000, 1/10000, 1/100000 : Adjust shutter speed
AGC OFF, LOW, MIDDLE, HIGH Sets the AGC level. Note: You can not use Auto D&N change mode
when AGC is o.
SENSE-UP AUTO, OFF, X2, X4, X8, X16, X32, X64,
X128, X256, X512, X1024 Use sense-up in low luminance (x2 ~ x1024)
BACKLIGHT
BLC
BLC LEVEL OFF, LOW, MID, HIGH : BLC function, level selectable
TOP 0 ~ 15: Adjust top position of BLC zone
BOTTOM 1 ~ 16 : Adjust bottom position of BLC zone
LEFT 0 ~ 15: Adjust left position of BLC zone
RIGHT 1 ~ 16 : Adjust right position of BLC zone
HLC
HBLC
OFF : Deactivates HBLC function
MANUAL
HBLC LEVEL : OFF, LOW, MID, HIGH
Make a zone for HBLC:
TOP : 0 ~ 15
BOTTOM : 1 ~ 16
LEFT : 0 ~ 15
RIGHT : 1 ~ 16
MODE ALL DAY : Activates HBLC function all day
NIGHT : Use the function at night only
HLC LEVEL 1 ~ 100 : Level adjust
MASK 1 ~ 4
ON
Make a zone for HLC mask:
TOP : 0 ~ 33
BOTTOM : 1 ~ 34
LEFT : 0 ~ 44
RIGHT : 1 ~ 45
OFF : HLC MASK OFF
D-WDR SET LEVEL 0 ~ 20 : DWDR level adjust

3© 2012 Observint Technologies, Inc. All rights reserved.
Function
setting menu Select menu Sub-menu Contents
3D-DNR OFF, LOW, MID, HIGH, AUTO Reduces noise in low illumination (level selectable)
RETURN Move back to previous menu
2. WHITE BALANCE
AWB MODE
ATW Color temperature 2500 ~ 9500 K
MANUAL
M-WR 0 ~ 128 : Adjust the Red value to shift the color of the object
M-WB 0 ~ 128 : Adjust the Blue value to shift the color of the object
RETURN Move back to previous menu
PUSH Find the optimal white balance for current luminance environment
R-Y GAIN 0 ~ 255 Adjust Red tone of the image
B-Y GAIN 0 ~ 255 Adjust Blue tone of the image
RETURN Move back to previous menu
3. DAY & NIGHT
D&N MODE
AUTO
DAY g NIGHT 7 ~ 30 Select brightness of illumination about changing the
day D night mode by AGC
NIGHT g DAY 6 ~ 29
DELAY TIME 0 ~ 15 : Select the duration time
RETURN Move back to previous menu
AUTO-CDS
A. DAY g NIGHT 6 ~ 36 Select brightness of illumination for
changing the day D night mode by AGC
A. NIGHT g DAY 6 ~ 36
C. DAY g NIGHT 0 ~ 255 Select brightness of illumination for changing the day
D night mode by CDS
C. NIGHT g DAY 0 ~ 255
DELAY TIME 0 ~ 15 : Select the duration time
RETURN Move back to previous menu
COLOR Fixed at color
B&W Fixed at B/W
EXT DELAY TIME 0 ~ 15 : Change the color D B/W by external signal (N/A)
RETURN Move back to previous menu
BURST ON, OFF Transmit the burst signal or not in B/W mode
C_SUP 0 ~ 100 Color suppress controllable
A_SUP 0 ~ 100 Iris suppress controllable
SMART IR ON, OFF Decreases screen saturation of objects within a short range
RETURN Move back to previous menu
4. IMAGE ADJUST
MIRROR MIRROR, OFF Set a vertical image inversion
SHARPNESS 0 ~ 30 Sharpness adjustable
GAMMA
0.45, 0.55, 0.65 Set gamma value
USER GAMMA 0.20, 0.25, 0.30, 0.35, 0.40, 0.45, 0.50, 0.55, 0.60, 0.65, 0.70, 0.75,
0.80, 0.85, 0.90, 0.95, 1.00 : Gamma adjustable
RETURN Move back to previous menu
LSC ON SET LEVEL 0 ~ 30 : Use the LSC and level adjustable RETURN Move back to previous menu
OFF LSC OFF
RETURN Move back to previous menu
5. MOTION
MOTION ON, OFF Motion detection function activate/deactivate
AREA AREA 1 ~ 4
TOP: 0 ~ 143
Make a zone for motion detection
BOTTOM 2 ~ 145
LEFT 0 ~ 190
RIGHT 2 ~ 192
RETURN Move back to previous menu
RETURN Move back to previous menu
SENSITIVITY 1 ~ 30 Motion detection sensitivity
DISPLAY OFF, MESSAGE, TRACE Select notication method of motion detection
HOLD TIME 0 ~ 15 Set the duration of alarm out
ALARM OUTPUT ON, OFF Alarm ON/OFF
RETURN Move back to previous menu
6. PRIVACY
MASK 1 ~ 8
OFF Display each privacy mask or not
ON
DOT SEL L_TOP, L_BOT, R_BOT, R_TOP : Determines which of the 4 vertices
of each MD area is to be used
DOT XY ENTER SETTING : Determines the coordinate
MOVE XY ENTER SETTING : Move the mask
COLOR BLACK, WHITE, … : Select mask color (8 colors)
RETURN Move back to previous menu
Function
setting menu Select menu Sub-menu Contents
RETURN Move back to previous menu
7. SPECIAL
LANGUAGE ENGLISH, … : Select language (9 languages)
TITLE OFF, ON
EDIT Display the camera name on the screen
RESET Camera name reset
POSITION Camera name position
RETURN Move back to previous menu
COMMUNICATION OFF Not used.
DPC
OFF Deactivates Defect Pixel Correction in low illumination
AUTO
WHITE THR 0 ~ 255 : Setup the limited value of white pixel correction
LUMA THR 0 ~ 255 : Setup the limited value of white pixel correction
RETURN Move back to previous menu
FACTORY SET YES, NO Reset your camera to factory default condition
RETURN Return to previous menu
8. EXIT
SAVE AND EXIT Save values and exit menu
EXIT Exit the menu without save
RETURN Move back to previous menu
Dimensions
3.37”
4.07”
3.29”
2.16”
4.65”
Specications
Image Sensor 1/3” SONY SUPER HAD CCD II
Eective Pixel 768 (h) x 494 (v) pixels (NTSC))
Cell Size 6.35 μm (h) x 7.4 μm (v) (NTSC))
Scanning System 2:1 interlace
Sync. Type Internal
Resolution Color : 650 TV-Line, B / W : 720 TV-Line
S / N ≥ 52 dB (AGC o)
Video Output 1.0 Vp-p (sync. negative) termination 75 Ω
Minimum Illumination 0.01 lux (f/1.2), 0.0001 lux (sense up), 0 lux (75 ft range with 24 piece LED array) - indoor
Gamma ȳ = 0.45 typical (0.2 ~ 1.0)
OSD Yes (multi language)
White Balance ATW (2500 K ~ 9500 K) / manual / AWC
Shutter Speed 1/60 (NTSC) ~ 1/100,000 s
Sense up Auto (selectable limit 2x ~ 1024x) / FIXED / OFF
Backlight OFF / BLC / HLC / DWDR
AGC LOW / MIDDLE / HIGH / OFF
DNR (3D) AUTO / LOW / MIDDLE / HIGH / OFF
Motion Detection ON / OFF (4 zones)
Privacy Zone ON / OFF (8 zones)
Mirror ON / OFF
Day & Night ICR (AUTO, COLOR, B / W)
LED Brightness 24 piece array, Smart IR
Blemish Compensation AUTO / OFF
Lens Vari-focal auto iris lens
Power Supply 12 Vdc / 24 Vac dual voltage
Current Consumption Max. 500 mA (at 12 Vdc, 24 Vac): LEDs on
Operation Temperature 14 °F ~ 122 °F (-10 °C ~ 50 °C)
Storage Temperature. -4 °F ~ 140 °F (-20 °C ~ 60 °C)
Dimension Ø4.65” x 4.07” (h)
Weight 20.11 oz (570 g) approx.
