Ocean Matrix OMX-ADA1x3 User manual

OMX-ADA1x3

Contents
i
Contents
1 Introduction 1
2 Getting Started 1
3 Overview 1
4 Your OMX-ADA1x3 Audio Distributor 2
5 Connecting the OMX-ADA1x3 3
6 Technical Specifications 4
Figures
Figure 1: OMX-ADA1x3 Audio Distributor 2
Figure 2: Connecting the OMX-ADA1x3 Audio Distributor 3
Tables
Table 1: OMX-ADA1x3 Features and Functions 2
Table 2: Technical Specifications of the OMX-ADA1x3 4

Introduction
1
1 Introduction
Congratulations on purchasing your OCEAN MATRIX® OMX-ADA1x3
Audio Distributor,which comes with a power adapter and this instruction
manual. The OMX-ADA1x3 is ideal for the following typical applications:
Audio duplication studios
Audio broadcast and production studios for signal distribution
Presentation and multimedia audio distribution
Field audio distribution
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and
packaging materials for possible future shipment
Review the contents of this instruction manual
3 Overview
The OMX-ADA1x3 is a high quality 1:3 balanced stereo audio distribution
amplifier. It accepts one balanced stereo input and distributes the signal to
three identical stereo outputs with no discernible signal degradation. The
OMX-ADA1x3:
Achieves a signal output level reaching +20dBm
Has front panel left and right signal level trimmer controls
Can function as a 1:3 unbalanced stereo audio DA
To achieve the best performance:
Connect only good quality connection cables, thus avoiding
interference, deterioration in signal quality due to poor matching,
and elevated noise- levels (often associated with low quality cables)
Avoid interference from neighboring electrical appliances and position
your OMX-ADA1x3 away from moisture, excessive sunlight and dust
Caution – No operator-serviceable parts inside unit.
Warning – Use only the input power wall adapter that is
provided with this unit.
Warning – Disconnect power and unplug unit from wall
before installing or removing device or servicing unit.

Your OMX-ADA1x3 Audio Distributor
2
4 Your OMX-ADA1x3 Audio Distributor
Figure 1 and Table 1 define the OMX-ADA1x3 Audio Distributor:
12 VDC
+
-
-
+
+
-
-
+
+
-
-
+
+
-
-
+
OUT 1
OUT 2
OUT 3
INPUT
R G L R G L R G L R G L
Figure 1: OMX-ADA1x3 Audio Distributor
Table 1: OMX-ADA1x3 Features and Functions
# Feature Function
1 LEFT LEVEL Trimmer Adjusts
1
the left output signal level
2 RIGHT LEVEL Trimmer Adjusts
1
the right output signal level
3 ON LED Illuminates when receiving power
4 INPUT Detachable Terminal Block
Connector
Connects to the audio source
5 OUT Detachable Terminal Block
Connector
Connects to the audio acceptor (from 1 to 3)
6 12 VDC +12V DC connector for powering the unit
1 Insert a screwdriver into the small hole and carefully rotate it, trimming the appropriate OUT level

Connecting the OMX-ADA1x3
3
5 Connecting the OMX-ADA1x3
To connect the OMX-ADA1x3, as the example in Figure 2 illustrates, do the
following:
1. Connect the balanced stereo audio source and up to 3 balanced stereo audio
acceptors
1
to the rear panel of the OMX-ADA1x3.
2. Connect the 12V DC power adapter to the power socket and connect the
adapter to the mains electricity.
The balanced stereo audio input is buffered to the balanced stereo audio
outputs and the ON LED lights.
Balanced
Stereo Source
Balanced
Stereo Audio Acceptor 1
Balanced
Stereo Audio Acceptor 3
Figure 2: Connecting the OMX-ADA1x3 Audio Distributor
1 Switch OFF the power on each device before connecting it to your OMX-ADA1x3. After connecting your OMX-ADA1x3,
switch on its power and then switch on the power on each device

Technical Specifications
4
6 Technical Specifications
Table 2 describes the technical specifications:
Table 2: Technical Specifications of the OMX-ADA1x3
INPUT: 1 balanced audio stereo +4dBm/100k on detachable terminal blocks
OUTPUTS: 3 balanced audio stereo +4dBm/50on detachable terminal blocks
MAX. OUTPUT LEVEL:
20dBm
BANDWIDTH (-3dB): >100 kHz
S/N RATIO: 87dB
CONTROL: Output level control: - 0.5dB to +8.6dB
COUPLING: DC
AUDIO THD + NOISE: 0.024%
POWER SOURCE: 12 VDC 48mA
DIMENSIONS: 11.7cm x 6cm x 3.2cm (4.6” x 2.4” x 1.3”) W, D, H
WEIGHT: 0.28 kg (0.62 lbs.) approx.
ACCESSORIES: Power supply
