Oceanic VEO 200 User manual

Veo 200/250
dive computers
operating manual
OCEANIC®

2
LIMITED TWO-YEAR WARRANTY
For details, refer to the Product Warranty Registration Card provided.
COPYRIGHT NOTICE
This operating manual is copyrighted, all rights are reserved. It may not, in whole or in part, be
copied, photocopied, reproduced, translated, or reduced to any electronic medium or machine
readable form without prior consent in writing from Oceanic / 2002 Design.
Veo 200/250 Operating Manual, Doc. No. 12-2377
© 2002 Design 2001
San Leandro, Ca. USA 94577
TRADEMARK NOTICE
Oceanic, the Oceanic logo, Veo 200/250, the Veo 200/250 logos, Smart Glo, and Oceanglo are all
registered and unregistered trademarks of Oceanic. All rights are reserved.
PATENT NOTICE
U.S. Patents have been issued, or applied for, to protect the following design features:
Dive Time Remaining (U.S. Patent no. 4,586,136), Data Sensing and Processing Device (U.S. Patent
no. 4,882,678), and Variable Ascent Rate Indicator (U.S. Patent no. 5,156,055). User Setable
Display (U.S. Patent no. 5,845,235) is owned by Suunto Oy (Finland).
DECOMPRESSION MODEL
The programs within the Veo 200/250 simulate the absorption of nitrogen into the body by using a
mathematical model. This model is merely a way to apply a limited set of data to a large range of
experiences. The Veo 200/250 dive computer model is based upon the latest research and experi-
ments in decompression theory. Still, using the Veo 200/250, just as using the U.S. Navy
(or other) No Decompression Tables, is no guarantee of avoiding decompression
sickness, i.e. “the bends.” Every diver’s physiology is different, and can even vary from day to
day. No machine can predict how your body will react to a particular dive profile.

3
CONTENTS
LIMITED TWO-YEAR WARRANTY ............................................................................................................................. 2
NOTICES ..................................................................................................................................................................... 2
DECOMPRESSION MODEL ....................................................................................................................................... 2
FEATURES AND DISPLAYS ............................................................................................. 7
INTERACTIVE CONTROL CONSOLE ........................................................................................................................ 9
BAR GRAPHS ........................................................................................................................................................... 10
Tissue Loading Bar Graph (TLBG) ....................................................................................................................... 10
Oxygen Bar Graph (O2BG) ................................................................................................................................... 11
Variable Ascen Ra e Indica or (VARI) ................................................................................................................. 11
ALPHA / NUMERIC DISPLAYS ................................................................................................................................ 12
Dep h Displays ..................................................................................................................................................... 12
Time and Da e Displays ....................................................................................................................................... 13
Tempera ure Display ............................................................................................................................................. 14
AUDIBLE ALARM ...................................................................................................................................................... 14
LED Warning Ligh ............................................................................................................................................... 14
BACKLIGHT .............................................................................................................................................................. 16
POWER SUPPLY ...................................................................................................................................................... 16
Ba ery Indica or ................................................................................................................................................... 16
Low Ba ery Condi ion .......................................................................................................................................... 17
O2 MODE ................................................................................................................................................................. 18
FO2 50% Defaul .................................................................................................................................................. 19
ACTIVATION AND SETUP ............................................................................................... 21
ACTIVATION .............................................................................................................................................................. 22
Backup Ac iva ion ................................................................................................................................................. 23
SUR ACE MODE ...................................................................................................................................................... 23
SET MODES .............................................................................................................................................................. 24
ENTERING SETTINGS -SET MODE #1 ............................................................................................................... 25
ENTERING SETTINGS -SET MODE #2 ............................................................................................................... 29

4
CONTENTS (continue )
PLAN AND DIVE MODES ................................................................................................ 43
PRE DIVE PLANNING SEQUENCETM ...................................................................................................................... 44
TISSUE LOADING BAR GRAPH .............................................................................................................................. 46
OXYGEN ACCUMULATION BAR GRAPH ............................................................................................................... 47
VARIABLE ASCENT RATE INDICATOR .................................................................................................................. 47
CONTROL O DISPLAYS ......................................................................................................................................... 48
NO DECOMPRESSION DIVE MODE ....................................................................................................................... 48
DECOMPRESSION DIVE MODE ............................................................................................................................. 51
VIOLATION MODES .................................................................................................................................................. 54
Condi ional Viola ion Mode .................................................................................................................................. 54
Delayed Viola ion Modes ..................................................................................................................................... 56
Immedia e Viola ion Mode and Gauge Mode ...................................................................................................... 57
HIGH PO2 DIVE MODE ............................................................................................................................................. 59
HIGH OXYGEN ACCUMULATION ............................................................................................................................ 60
USER SET DIGITAL GAUGE MODE ........................................................................................................................ 61
UNEXPECTED LOSS O DISPLAYED IN ORMATION .......................................................................................... 61
RESET EATURE ..................................................................................................................................................... 62
POST DIVE MODES ........................................................................................................ 63
POST DIVE SUR ACE MODE .................................................................................................................................. 64
TRANSITION PERIOD .............................................................................................................................................. 64
A TER THE TRANSITION PERIOD (THE IRST 2 HOURS) .................................................................................. 66
To ac iva e he Backligh - .................................................................................................................................... 66
To access he Pre Dive Planning Sequence - ...................................................................................................... 66
To access he Time o Fly Coun down ................................................................................................................. 67
To access he Time o Desa ura e Coun down .................................................................................................... 67
Log Mode .............................................................................................................................................................. 68
A TER THE IRST 2 HOURS ................................................................................................................................... 70
WET CONTACTS ....................................................................................................................................................... 71
DOWNLOADING DATA TO A PC .............................................................................................................................. 72

5
CONTENTS (continue )
WARNING: Prior to iving with the Veo 200/250, you must also rea
an un erstan the Oceanic Dive Computer Safety an Reference
Manual.
SIMULATOR (DEMO) MODE .......................................................................................... 73
GENERAL ........................................................................................................................ 79
CARE AND CLEANING ............................................................................................................................................. 80
INSPECTIONS AND SERVICE ................................................................................................................................. 80
MODULE REMOVAL ROM A BOOT ....................................................................................................................... 82
BATTERY REPLACEMENT ...................................................................................................................................... 83
RETURNING A MODULE TO A BOOT ..................................................................................................................... 87
ALTITUDE COMPENSATION .................................................................................................................................... 88
SPECI ICATIONS ..................................................................................................................................................... 89
OCEANIC WORLD WIDE .......................................................................................................................................... 94
SERVICE RECORD ................................................................................................................................................... 95
Pay special attention to items marked
with this Warning symbol.

6
LCD DISPLAY
Componen s:
a. Icon - Opera ing Mode
b. Ba ery Indica or
c. O2 (oxygen) Bar Graph
d. Icon - Time
e. Variable Ascen Ra e Indica or
f. Graphic - Ascen Too Fas
g. Graphic - Dep h
h. Graphic - Demo Mode
i. Icon - (Dive No. - Log only)
j. Icon - Log Mode
j. Graphic - Maximum Dep h
k. Icon - Tempera ure
l. Tissue Loading Bar Graph
m. Icon - Alarm
n. Graphic - Maximum Dep h
o. Icon - Ascend Arrow
Icon - Ceiling S op Bar
Icon - Descend Arrow
ab
c
d
e
f
g
h
i
j
k
l
m
n
op

7
FEATURES and DISPLAYS
WARNING: Prior to iving with the Veo 200/250,
you must also rea an un erstan the Oceanic
Dive Computer Safety an Reference Manual which
provi es Important Warnings an Safety Recom-
men ations as well as general pro uct information.

8
Warning
LED SmartGlo
Sensor
Advance
Button
(Left)
Veo 200 FULL DISPLAY Veo 250 FULL DISPLAY
Select
Button
(Right)
Advance
Button
( ront)
Select
Button
(Side)
SmartGlo
Sensor
Warning
LED

9
INTRODUCTION
Welcome to Oceanic and thank you for choosing the Veo 200 or Veo 250 !
It is extremely important that you read this Operating Manual in sequence and understand it
completely before attempting to use the Veo 200/250. It is equally important that you read
the Oceanic Dive Computer Safety and Reference Manual (Doc. No. 12-2262) provided
with your Veo 200/250. It contains information that you must become familiar with prior
to diving with your Veo 200/250.
Remember that technology is no substitute for common sense, and a dive computer only
provides the person using it with data, not the knowledge to use it.
The Veo 200 and 250 are configured with the same features and functions. The difference
between them is the location of the 2 Control Buttons. The Veo 200 is designed for mount-
ing in a Console Boot and has both Buttons located on the front. The Veo 250 is designed
to wear on the wrist and has 1 button on the front and 1 on the right side. Refer to page 8.
INTERACTIVE CONTROL CONSOLE
The Control Buttons, referred to as the Interactive Control Console allow you to select
display options and access specific information when you want to see it. They are also
used to enter settings, activate the Backlight, and acknowledge the Audible Alarm.
The Left button of the Veo 200 and Front button of the Veo 250 are referred to as the
Advance button. The Right button of the Veo 200 and Side button of the Veo 250 are
referred to as the Select button. The terms used in this manual are Left/Front (Advance) and
Right/Side (Select) referring to the Veo 200/250.

10
BAR GRAPHS
Tissue Loa ing Bar Graph (TLBG)
The Tissue Loading Bar Graph (Fig. 1a) represents tissue loading
of nitrogen, showing your relative no decompression or decom-
pression status. As your depth and elapsed dive time increase,
segments will add to the Graph, and as you ascend to shallower
depths, the Bar Graph will begin to recede, indicating that
additional no decompression time is allowed for multilevel diving.
The Tissue Loading Bar Graph monitors 12 different nitrogen
compartments simultaneously and displays the one that is in
control of your dive. It is divided into a green No Decompres-
sion (normal) zone, a yellow Caution zone (also No Decompres-
sion), and a red Decompression (danger) zone.
While you cannot provide a guarantee against the occurrence of
decompression sickness, you may choose your own personal
zone of caution based upon age, physique, excessive weight,
etc., to reduce the statistical risk.
NOTE: Displays associate with oxygen an the O2
Bar Graph will only appear if FO2 has been set at a
value other than 'Air' (e.g., a numerical value).
Fig. 1 - TLBG
a

11
Oxygen Accumulation Bar Graph (O2BG)
The O2 Bar Graph (Fig. 2a) represents oxygen loading, showing
the maximum of either per dive accumulated oxygen, or 24 hour
period accumulated oxygen.
As your oxygen exposure (accumulation) increases during the
dive, segments will add to the Bar Graph, and as loading de-
creases, it will begin to recede, indicating that additional expo-
sure is allowed for that dive and 24 hour period.
Variable Ascent Rate In icator (VARI)
The Variable Ascent Rate Indicator (Fig. 2b) provides a visual
representation of ascent speed (i.e., an ascent speedometer).
Green is a 'normal' rate, yellow a 'caution' rate, and red is 'Too
Fast'.
The segments of the Variable Ascent Rate Indicator represent two
sets of speeds which change at a reference depth of 60 feet (18
meters). Refer to the chart for segment values.
WARNING: At epths greater than 60 feet (18 meters),
ascent rates shoul not excee 60 feet per minute (18
meters per minute). At epths of 60 feet (18 meters)
an shallower, ascent rates shoul not excee 30 feet
per minute (9 meters per minute).
Fig. 2 - O2BG and VARI
Variable Ascen Ra e Indica or
Deeper than 60 feet (18 m)
Segments Ascent Rate =
Displayed FPM MPM
0 0-20 0 - 6
1 21-50 6.5-15
2 51-60 15.5-18
3 60 18
60 feet (18 m) & Shallower
Segments Ascent Rate =
Displayed FPM MPM
0 0-10 0 - 3
1 11-25 3.5-7.5
2 26-30 8-9
3 309
a
b

12
ALPHA / NUMERIC DISPLAYS
Each numeric and graphic display represents a
unique piece of information. It is imperative that you
understand the formats, ranges, and values of the
information represented to avoid any possible misun-
derstanding that could result in error.
Depth Displays
During a dive, the Current Depth display (Fig. 3a), indicates
depths from 0 to 330 feet (99.9 meters) in 1 foot (.1 meter)
increments.
By pressing the Left/Front (Advance) button, the Maximum
Depth reached during that dive will be displayed in the center/
left portion of the display (Fig. 4a).
• When the unit is set to operate as a digital depth gauge/
timer (referred to as User Set Gauge Mode), the Depth
Display range is 'extended' to 399 feet (120 meters). At
depths greater than 99.9 meters it will indicate metric values
in increments of 1 meter.
During a Decompression Dive, the required Ceiling Stop
Depth is displayed in the center of the screen. Maximum Depth
can be viewed by pressing the Left/Front (Advance) button.
Fig. 4 - Maximum Dep h
a
b
Fig. 3 - Curren Dep h

13
Time an Date Displays
Time displays are shown in hour:minute format (i.e., 1:16
represents 1 hour and 16 minutes, not 116 minutes!). The colon
that separates hours and minutes blinks once per second when
the display is indicating real time (e.g., Elapsed Dive Time), and
is solid (non-blinking) when times are calculated projections (e.g.,
Time to Fly).
The Main Time display is located in the lower portion of the
display (Fig. 5a) and a second time display (Fig. 5b) is
located in the center/right. Both displays are identified by a
clock icon.
• Time of Day can be set for 12 hour format (Am/Pm) or 24
hour format.
Date (Month and Day) is displayed in the center/left portion of
the screen (Fig. 6a) only to identify dive data while it is viewed
in the Log Mode. Year is only displayed when setting the Date.
• When Units of Measure are set for 'Imperial', the Month
appears to the left of Day. When set for Metric, the Month
appears to the right of Day.
Fig. 5 - Time Displays
Fig. 6 - Da e Display
a
b
a

14
Temperature Display
Ambient Temperature is displayed in the center/left portion
of the screen (Fig. 7a) while in the Surface Mode and Log Mode,
and can be viewed as part of an Alternate Display when the Left/
Front (Advance) button is pressed while in a dive mode.
NOTE: The Informational Displays are escribe in
etail as the various operating mo es they appear in
are presente throughout this manual.
AUDIBLE ALARM
LED Warning Light
A red LED Warning Light is synchronized with the Audible Alarm
and will flash when the Alarm emits a tone. They will turn OFF
when the Alarm is acknowledged, or Set OFF (a user setting).
When warning situations activate the Alarm, the unit will emit a
beeping tone for several seconds until it times out, or until the
situation is corrected, or it is acknowledged by pressing the Left/
Front (Advance) button for 2 seconds. The Alarm will sound
again upon reentry into the warning situation, or entry into
another type of warning situation.
Fig. 7 - Tempera ure Display
a

15
Situations that will soun the Alarm, if it is turne ON (a user setting), inclu e -
• Entry into Decompression Mode
• PO2 => than the Max PO2 Alarm (a user setting), or => 1.60 ATA.
• Descent deeper than the Max Depth Alarm (a user setting).
• Nitrogen Bar Graph Alarm (a user setting).
• Dive Time Remaining Alarm (a use setting).
• Elapsed Dive Time Alarm (a use setting).
• O2 Accumulation => allowable per dive limit, or limit for a 24 hour period.
• Ascending above a required Decompression stop depth for less than 5 minutes (Condi-
tional Violation).
• Ascent rate exceeds 60 feet/minute (18 meters/minute) if greater than 60 feet (18
meters), or 30 feet/minute (9 meters/minute) at 60 feet (18 meters) and shallower.
During the following situations, the beeping tone will be followe by a secon beep-
ing tone that will not turn off when acknowle ge , even if it was user Set OFF -
• Ascending above a required Decompression stop depth for more than 5 minutes (De-
layed Violation).
• Decompression requires a ceiling stop depth of 70 feet/21 meters or deeper.
• Being on the surface for 5 minutes after a Conditional Violation (Permanent Violation).
A single short beep (which cannot be isable ) is emitte for the following -
• After the Diagnostic countdown, if everything is okay.
• If the unit automatically returns to Surface Mode from Simulator Mode.

16
BACKLIGHT
To activate the Backlight - press the Right/Side (Select) button.
• While on the surface or during a dive, the Smart Glo®
feature senses the intensity of natural light present. If a low
level of light is present, the Backlight will activate and illumi-
nate the display for 5 seconds, or the Duration time (a user
setting).
• The Backlight does not operate during a Low Battery condi-
tion.
• Press the button again to activate as desired.
POWER SUPPLY
The Veo 200/250 utilizes one (1) type CR 2450 Lithium 3 volt
cell that should provide 300 hours of continuous, or 50 activation
periods, of operation. If you conduct 1 dive each time the unit is
activated, you should obtain approximately 50 dives. If you
conduct 3 dives each time the unit is activated, you should obtain
approximately 150 dives.
Battery In icator
A Battery Indicator provides an indication of battery condition.
When power is sufficient for normal unit operation, the Indicator
will be displayed during Surface Mode (Fig. 8a). The Indicator
will not be displayed during Dive Mode(s).
Fig. 8 - Ba ery Indica or
a

17
Low Battery Con ition
Voltage level is checked upon activation and every 10 minutes
during operation.
• When 75 % of the Rated Power has been consumed, the
lower bar of the Battery Indicator (only segment) will be
displayed, and the outline of the Indicator will flash once per
second as a warning that the Battery is to be replaced prior
to conducting any further dives.
• Upon decreasing to a voltage level that will no longer sustain
proper operation, the Indicator will flash 5 times followed by
shutdown of the unit.
• If a Low Battery Condition exists when the unit is activated
(by pressing the button), the graphic bAT and the Battery
Indicator will appear flashing for 5 seconds (Fig. 9) followed
by shutdown of the unit.
• If the button is not pressed to activate the unit prior to a dive,
and a Low Battery Condition exists, the Battery Indicator will
appear flashing as a warning upon descent past 4 feet (1.2
meters). No other information will be displayed.
• If the unit did not display a Low Battery Condition 'prior to'
entering the Dive Mode, and a Low Battery Condition occurs
during the dive, there will be sufficient battery power to
maintain unit operation for the remainder of 'that dive'. The
Battery Indicator will appear after the dive in Surface Mode.
Fig. 9 -Low Ba ery Condi ion

18
FO2 MODE
After Activation, the Veo 200/250 will operate as an Air com-
puter without displaying information associated with oxygen
calculations, unless it is set for a percentage of oxygen (FO2)
other than Air (a numerical value between 21 and 50 %).
When set with an FO2 value of 'Air' (Fig. 10), the Veo 200/
250 will perform calculations the same as if FO2 were set for
21% oxygen, internally accounting for oxygen loading for any
subsequent Nitrox dives. However, oxygen related displays,
warnings, and the O2 Bar Graph will not appear on the display
for that dive, or subsequent dives, unless FO2 is set for a numeri-
cal value (21 - 50).
Once a dive is made with the unit set as a nitrox computer (FO2
set for a numerical value), it cannot be programmed to operate
as an 'Air' computer until 24 hours after the last dive. 'Air' will
not be displayed as an option in the FO2 Mode. However, you
can set FO2 for 21% for use with Air.
When FO2 is set at a value of 21% (Fig. 11), the unit will
remain set at 21% for subsequent nitrox dives until FO2 is set to
a higher value, or until it automatically turns off and is reacti-
vated. Setting FO2 is escribe on Page 25.
Fig. 10 - FO2 se for Air
Fig. 11 - FO2 se for 21%

19
Fig. 12 - FO2 Defaul ON
Fig. 13 - FO2 Defaul OFF
FO2 50% Default
If the Default is set to ON (Fig. 12) and FO2 is set to a
value 'greater than 21%', the FO2 set point value will auto-
matically revert to 50% 10 minutes after that dive. The Maxi-
mum Depth that can be achieved with a PO2 of 1.60 ATA will
also be displayed.
• FO2 must therefore be reset for each repetitive nitrox dive,
or the value will automatically 'default' to 50(%) and the
dives will be calculated based on 50% O2 (50% nitrogen)
for oxygen calculations and 21% O2 (79% nitrogen) for
nitrogen calculations.
If the Default is set to OFF (Fig. 13), the FO2 value for
repetitive dives remains the same as previously set until the set
point is manually changed.

20
KEY TO SETTING INSTRUCTIONS
PAGE:
25 SET MODE 1
25 SET FO2
26 SET MAX DEPTH ALARM
27 SET ELAPSED DIVE TIME ALARM
28 PC DOWNLOAD
29 SET MODE 2
29 SET UNITS OF MEASURE
30 SET HOUR FORMAT
31 SET TIME OF DAY
32 SET DATE
33 SET AUDIBLE ALARM
34 SET TLBG ALARM
35 SET DIVE TIME REMAINING ALARM
36 SET PO2 ALARM
37 SET FO2 50% DEFAULT
38 SET BACKLIGHT DURATION
39 SET PC SAMPLING RATE
40 SET DIGITAL GAUGE MODE
41 SET WATER ACTIVATION
