Oceanic PROPLUS X Manual

PROPLUS X BATTERY SERVICE PROCEDURE
DOC. 12-7959-r02 (8/19/20)

Doc. 12-7959-r01 (8/19/20)
2
© Pelagic (2020)
USA Ofce
1540 North 2200 West
Salt Lake City, Utah 84116
Tel: [phone]
Web: www.OceanicWorldwide.com
CONTENTS
INTRODUCTION
GENERAL PROCEDURES
SERVICE TOOLS
ASSEMBLY DRAWING
DISASSEMBLY
REASSEMBLY
3
3
4
4
6
7

Doc. 12-7959-r01 (8/19/20)
3
© Pelagic (2020)
This manual is intended as a guide to replace the battery in the
Oceanic ProPlus X dive computer module.
This service must be performed in a dry (maximum 40% relative
humidity) and clean environment at room temperature (56-78°F
/ 18-25°C).
Safety Precautions
This manual provides step by step instructions for replacing
the battery of the Oceanic ProPlus X dive computer. It is
recommended that all steps are followed in the order given.
Read each section completely PRIOR to beginning the work
described in that section.
Pay close attention to all WARNINGS, CAUTIONS and NOTES
that are intended to draw your attention to items of importance.
Denitions of terms:
!WARNING
WARNING is used before a procedure that could
potentially result in serious injury or death if
performed incorrectly.
!
CAUTION
CAUTION is used in connection with a procedure
that may cause damage to the equipment.
NOTE
NOTE is used in connection with a procedure
that requires special attention.
INTRODUCTION
NOTE
Do not open any seals if not necessary. After opening a
seal, always replace the O-ring.
Battery replacement is necessary when the battery replacement
message is displayed on the computer screen and/or the user
is experiencing shortened battery life per charge.
Handling & Storage of Parts
Spare parts must be stored in a clean and dry environment.
Ensure parts are not exposed to dust or other contaminants.
Take special care of sealing gaskets, O-rings, and electronic
components.
NOTE
The battery kit must be stored in original packaging until
being used in repair.
GENERAL PROCEDURES SERVICE TOOLS
General Tools
• 3/32” Allen key
• Grounding strap
• Work station (grounded)
• Orange stick or spudger
• Silicone grease
• Lint-free microber cloth

Doc. 12-7959-r01 (8/19/20)
4
© Pelagic (2020)
ASSEMBLY DRAWING
ITEM OCEANIC PART
#
DESCRIPTION QTY.
1 - BATTERY, PPX 1
2 - O-RING, BATTERY COVER, PPX 1
3 - O-RING 1
4 - PLUG, OVER PRESSURE 1
N/S 04.6175.97 Battery Kit, PPX (includes items 1-4) 1
N/S = Not Shown
1
2
3
4

Doc. 12-7959-r01 (8/19/20)
5
© Pelagic (2020)
!CAUTION
To prevent damage resulting from static discharge, the
individual and work station must be grounded when
handling any electronic components.
!
CAUTION
DO NOT attempt to open the ProPlus X before reading
these instructions completely.
NOTE
Protect the lens and nish of the ProPlus X by working on
a clean padded surface.
1. Unscrew the battery retaining screws by turning
counterclockwise (using an allen driver), as shown (Fig. 1).
2. Remove the battery cover (Fig. 2). Inspect for any signs of
damage, discard if found.
3. Carefully, press the over-pressure plug and O-ring out of the
cavity in the battery cover using a non-marking tool (Fig. 3,
4). DO NOT use metal tools.
DISASSEMBLY
Fig. 1
Fig. 2
Fig. 3
Fig. 4

Doc. 12-7959-r01 (8/19/20)
6
© Pelagic (2020)
Fig. 5
Fig. 6
Fig. 7
4. Remove and discard the battery cover O-ring with a non-
marking tool (Fig. 5). Do not use metal tools.
5. Carefully separate the battery contacts with a plastic tool
(Fig. 6). Do not bend or damage the battery terminals.
6. Carefully lift the battery out of the housing (Fig. 7).
!
CAUTION
Properly recycle or dispose of the original battery in
accordance with local regulations.

Doc. 12-7959-r01 (8/19/20)
7
© Pelagic (2020)
!CAUTION
To prevent damage resulting from static discharge, the
individual and work station must be grounded when
handling any electronic components.
NOTE
Protect the lens and nish of the ProPlus X by working on
a clean padded surface.
!CAUTION
Do not use chemicals or alcohol to clean the plastic parts.
1. Install the battery, as shown, by pressing and fully seating
the connector (Fig. 1, 2).
NOTE
The writing on the battery should be facing outwards.
2. Lightly lubricate the battery O-ring with silicone and install it
along the O-ring groove (Fig. 3).
!
CAUTION
Ensure the O-ring is free of any debris and evenly seated.
3. Ensure that the battery cover still has insulating pads in place
and in good condition (Fig. 4).
REASSEMBLY
Fig. 1
Fig. 2
Fig. 3
Fig. 4

Doc. 12-7959-r01 (8/19/20)
8
© Pelagic (2020)
4. Evenly seat the battery cover onto the case assembly (Fig. 5).
5. Install the battery cover screws (Fig. 6). DO NOT overtighten.
6. Carefully press the over-pressure plug and O-ring into the
cavity of the battery cover, as shown (Fig. 7, 8).
!
CAUTION
The O-ring installs under the over-pressure plug. The
plug and O-ring need to be fully seated to maintain water
integrity of the ProPlus X assembly. Fig. 5
Fig. 6
Fig. 7
Fig. 8

Doc. 12-7959-r01 (8/19/20)
9
© Pelagic (2020)
7. Visually inspect the ProPlus X unit to ensure correct assembly
and that there are no gaps between the battery cover and
case. Power the unit up and ensure proper operation (Fig. 9).
!
CAUTION
Fully charge the battery after assembly and before use.
Expect 3-4 hours to charge fully.
Fig. 9
