Oceanic Ice Fountain User instructions

PRODUCT IMAGE
Oceanic Ltd, Pountney Street, Wolverhampton, WV2 4HX
Phone: [phone] [email protected].uk www.oceanic-saunas.co.uk
Sauna & Steam
Ice Fountain
Assembly and operating manual

Sauna & Steam
Oceanic Saunas 01902 450 550 [e-mail] 2
Ice Fountain Manual
Table of contents
1. Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. Components included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3. Components Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
4. Supply Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
5. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
5.1. Ice machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
5.2. Locating the Ice Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
5.3. Ice Level Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
6. Example installations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6.1. Vertical alignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6.2. Horizontal alignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Sauna & Steam
Oceanic Saunas 01902 450 550 [email protected] 3
Ice Fountain Manual
1. Introduction
Thank you for choosing to buy our Oceanic Ice Fountain, please take the time to
read these instructions before you begin as they contain important information about the
installation and maintenance requirements.
2. Components included
• Ice Machine (requires water, power and drain)
• 154mm stainless steel ice chute (500mm long)
• Glass Bowl (sink)
• Through Beam Sensor Kit to stop ice when bowl is full
3. Components Required
• Buy or build a stand for the bowl, this could be nished in mosaics or the top could be marble
or granite. It should be water tight on any sides that are visible.
• Build a support frame for the ice machine above the bowl with straight chute (high up) or
behind a false wall with angled chute (low down)
• Supply waste trap for sink and connect up to drains.
4. Supply Requirements
• 15mm cold water supply
• 32mm drain for basin.
• 15mm Drain for ice machine can boss into 32mm drain.
• 2 x 13amp sockets.
5. Installation
5.1. Ice machine
Please read through the instructions provided with the ice machine before commencing the
installation.
As you may be installing this within a warm spa area it is important that there is good ventilation
and that the temperature is not higher than operating temperature in the manual. If you are
working the machine in air that is too warm it will put strain on the machine and premature
failure.

Sauna & Steam
Oceanic Saunas 01902 450 550 [email protected] 4
Ice Fountain Manual
5.2. Locating the Ice Machine
It is possible to install the machine mounted high up above the fountain or in the room adjacent,
you need to decide which way works best for you either for simplicity or for aesthetics.
Stainless Steel
Chute
Glass Bowl to collect ice
Adjacent room
Ice machine
Option 1
Locate Ice Machine above
Option 2
Locate Ice Machine adjacent

Sauna & Steam
Oceanic Saunas 01902 450 550 [email protected] 5
Ice Fountain Manual
Transmitter
Transmitter
Receiver
Bowl
Chute
Ice machine producing ice Ice machine stopped
Centre line
Bowl
300mm
Rear wall of ice
View from above
5.3. Ice Level Sensor
The machine is controlled via a sensor, once the bowl is full the ice stops the beam from reaching
the receiver on the right of the image below, this stops the ice machine from producing anymore
ice.
The ice level sensor is pre-wired to the ice machine and is supplied with a separate 3 pin plug.
If choosing to hard wire the fountain please note that the plug for the sensor also contains a
transformer.
Install the sensors on the left and right through the centre of the bowl, approximately 300mm from
the back wall.

Sauna & Steam
Oceanic Saunas 01902 450 550 [email protected] 6
Ice Fountain Manual
If for any reason it is not possible to install the ice level sensor there is another solution. The ice
machine has internal sensors to stop the machine if the ice is not freely escaping. Therefore it
would be possible to install the ice collecting bowl at a shallower height from the chute so that
the ice will build up inside the chute and eventually block the internal sensors inside the machine
as shown in the diagram below.
Stainless Steel
Chute
Ice machine stops
producing ice if ice backs
up into the machine
This happens
more eectively
when the chute is
angled
Ice machine
Glass Bowl to collect ice

Sauna & Steam
Oceanic Saunas 01902 450 550 [email protected] 7
Ice Fountain Manual
6. Example
installations
6.1. Vertical alignment
Chute is located directly
below the ice machine
which is installed at high
level above the fountain.
6.2. Horizontal
alignment
The chute is angled above
the bowl and the ice
machine can be installed
at a much lower height
but must be in the room
adjacent or behind a false
wall.
