ODROID Vu5S User manual

2023/12/17 00:03 1/3 Vu5S 5inch MIPI LCD for M1S
ODROID Wiki - https://wiki.odroid.com/
Vu5S 5inch MIPI LCD for M1S
The two-lane MIPI-DSI port can be directly connected to a LCD panel.
A 5 inch 480×854 wide viewing angle LCD and capacitive multi-touch screen is pre-assembled.
The ODROID-Vu5S is dedicated to ODROID-M1S. It can only be used via a MIPI DSI Connector(J7) on
M1S.
The I type Bracket boards are required to dock Vu5S to assembled ODROID-M1S with case.
Software Setting
Software Setting
Specifications
5-inch TFT-LCD
Portrait 480(H) x 854(V) pixels hardware native resolution
Mechanical Dimensions : 136(W) x 83.4(H) mm (Assembled with I Bracket: 106)
Viewable screen size : 109.53 x 61.56 mm (active area)
5 finger capacitive touch input
Power consumption : 1.3W ± 10% (50% duty cycle )
Always set the duty ratio of the PWM signal for LCD backlight control to be less than
50%.
If you set it higher than that, overcurrent will flow to the backlight LED, causing a
heating problem and drastically shortening the lifespan of the LCD module.
There is no problem with Vu8S even if the duty ratio is set to 100%.
This means that in order to use a backlight driver circuit designed for an 8-inch LCD for
a 5-inch LCD, the backlight driving power must be reduced by half.
Physical Dimensions
LCD Bracket Board
Mechanical drawings (DXF format)
vu5s_lcd_bracket.zip

Last update: 2023/11/14 11:02 accessory:display:vu_series:vu5s https://wiki.odroid.com/accessory/display/vu_series/vu5s?rev=1699927352
https://wiki.odroid.com/ Printed on 2023/12/17 00:03
I form Bracket Board
Mechanical drawings (DXF format)
vu5s_i_bracket.zip
Package includes
A. Assembled 5inch TFT LCD + multi touch screen * 1EA
B. M3 x 40(BLACK) Support * 3EA including a spare part
C. M3 x 7(BLACK) Bolt * 7EA including a spare part
D. M3 x 5(SILVER) Bolt* 5EA including a spare part
E. Vu5S LCD Frame Board for M1S * 1EA
F. Vu5S I form Bracket Board for M1S * 2EA
Assembly guide
Please take special care when assemble it.
1. 2.
Mount the two I
Form Bracket boards
with a top-printed
top facing up on the
back of the Vu5S.
Please put the FPCB
Cable on the top of
the I Form Bracket
board.
Two PM3.0x5 Silver
bolts are fastened to
the two I Form
Bracket boards on
the back of the Vu5S
Mount the M1S
built-in assembled
case to the I Form
Bracket board.
Fix it with 4 x
PM3.0x7 black
bolts.
3. 4.

2023/12/17 00:03 3/3 Vu5S 5inch MIPI LCD for M1S
ODROID Wiki - https://wiki.odroid.com/
Plug and fix the
30pin FPCB cable of
Vu5S on the
ODROID-M1S
You will need to
carefully undo the
clamp before
inserting the cable.
Make sure to press
the clamp in to
secure the ribbon in
place.
Mount the M3*40
Support and
PM3.0x7 Black
BOLT to the
bottom of the I
form Bracket
Board
the angle of Vu5S
can be adjusted
up to 85 degrees.
